PREPARATION

STEERING

PP–45

90

1997 LEXUS ES300   (RM511U)

(09951–00180)

Replacer 18

PS gear

(09951–00240)

Replacer 24

PS gear

(09951–00250)

Replacer 25

PS gear

(09951–00260)

Replacer 26

PS gear

(09951–00290)

Replacer 29

PS gear

(09951–00310)

Replacer 31

PS gear

(09951–00320)

Replacer 32

PS gear

(09951–00330)

Replacer 33

PS vane pump

(09951–00340)

Replacer 34

PS gear

(09951–00400)

Replacer 40

PS gear

(09951–00430)

Replacer 43

PS gear

(09952–06010)

Adapter

PS gear

09950–70010

Handle Set

PP–46

–

PREPARATION

STEERING

91

1997 LEXUS ES300   (RM511U)

(09951–07100)

Handle 100

PS vane pump

(09951–07200)

Handle 200

PS gear

(09951–00360)

Replacer 36

PS gear

09960–10010

Variable Pin Wrench Set

(09962–01000)

Variable Pin Wrench Arm Assy

PS vane pump

(09963–01000)

Pin 10

PS vane pump

PP0AT–03

–

PREPARATION

STEERING

PP–47

92

1997 LEXUS ES300   (RM511U)

RECOMMENDED TOOLS

09025–00010

Torque Wrench (30 <kgfcm>) .

PS vane pump

PS gear

09042–00010

Torx Socket T30 .

Tilt steering column

09904–00010

Expander Set .

09905–00012

Snap Ring No.1 Expander .

09905–00013

Snap Ring Pliers .

PP0AU–01

PP–48

–

PREPARATION

STEERING

93

1997 LEXUS ES300   (RM511U)

EQUIPMENT

Belt tension gauge

On–vehicle inspection

Caliper gauge

PS vane pump

Calipers

PS vane pump

Dial indicator

PS gear

Feeler gauge

PS vane pump

Micrometer

PS vane pump

Torque wrench
