PP06T–01

–

PREPARATION

SFI

PP–9

54

1997 LEXUS ES300   (RM511U)

SEQUENTIAL MULTIPORT FUEL INJECTION

SST (Special Service Tools)

09268–41047

Injection Measuring Tool Set

09268–41250

T Joint

09268–45012

EFI Fuel Pressure Gauge

(09268–41100)

Clamp

Except California

(09268–41300)

Clamp

For California

09631–22020

Power Steering Hose Nut

14 x 17 mm Wrench Set

Fuel line flare nut

09817–16011

Back–up Light Switch Tool

Knock sensor

09842–30070

Wiring ”F” EFI Inspection

09843–18020

Diagnosis Check Wire

PP06U–01

PP–10

–

PREPARATION

SFI

55

1997 LEXUS ES300   (RM511U)

RECOMMENDED TOOLS

09040–00010

Hexagon Wrench Set .

09082–00040

TOYOTA Electrical Tester.

09200–00010

Engine Adjust Kit .

09258–00030

Hose Plug Set .

Plug for the vacuum hose, fuel

hose etc.

PP06V–01

–

PREPARATION

SFI

PP–11

56

1997 LEXUS ES300   (RM511U)

EQUIPMENT

Carburetor cleaner

Throttle body

Graduated cylinder

Injector

OBD II scan tool

Soft brush

Throttle body

Sound scope

Injector

Torque wrench

Vacuum gauge

PP2XL–01

PP–12

–

PREPARATION

SFI

57

1997 LEXUS ES300   (RM511U)

SSM (Special Service Materials)

08826–00080

Seal Packing Black or equivalent

(FIPG)

Intake air control valve
