PREPARATION

ENGINE MECHANICAL

PP–5

50

1997 LEXUS ES300   (RM511U)

RECOMMENDED TOOLS

09040–00010

Hexagon Wrench Set .

09090–04020

Engine Sling Device

For suspending engine

09200–00010

Engine Adjust Kit .

09258–00030

Hose Plug Set .

Plug for the vacuum hose, fuel

hose etc

09904–00010

Expander Set .

PP06Q–01

PP–6

–

PREPARATION

ENGINE MECHANICAL

51

1997 LEXUS ES300   (RM511U)

EQUIPMENT

Abrasive compound

Caliper gauge

CO/HC meter

Connecting rod aligner

Cylinder gauge

Dial indicator

Dye penetrant

Engine tune–up tester

Groove cleaning tool

Heater

Magnetic finger

Micrometer

OBDII scan tool

Pin hole grinder

Piston pin hole

Piston ring compressor

Piston ring expander

Plastigage

Precision straight edge

Ridge reamer

Soft brush

Spring tester

Valve spring

Steel square

Valve spring

Thermometer

Torque wrench

Valve seat cutter

Vernier calipers

Wire brush

Valve

PP2XF–01

–

PREPARATION

ENGINE MECHANICAL

PP–7

52

1997 LEXUS ES300   (RM511U)

SSM (Special Service Materials)

08826–00080

Seal Packing Black or equivalent

(FIPG)

Camshaft bearing cap

Semi–circular plug

Cylinder head cover

Rear oil seal retainer

08826–00100

Seal Packing 1282B,

THREE BOND 1282B or equivalent

(FIPG)

Engine coolant drain union

Water seal plate

Water inlet housing

08833–00070

Adhesive 1324,

THREE BOND 1324 or equivalent

Spark plug tube

Drive plate bolt

08833–00080

Adhesive 1344

THREE BOND 1344

LOCTITE 242 or equivalent

No.1 idler pulley pivot bolt

PP06S–01

PP–8

–

PREPARATION

EMISSION CONTROL

53

1997 LEXUS ES300   (RM511U)

EMISSION CONTROL

EQUIPMENT

Torque wrench

MITYVAC (Hand–held vacuum pump)
