AIR CONDITIONING
17
REPAIR
RECEIVER/DRIER - FROM 99MY
Service repair no - 82.17.03
Remove
1. Remove front bumper valance.
See CHASSIS
AND BODY, Repair.
2. Depressurise A/C system.
See Adjustment.
3. Disconnect multiplug from dual pressure switch.
4. Loosen 2 unions and release pipes from receiver
drier.
5. Remove and discard ’O’ rings from pipes.
CAUTION: Immediately cap all air
conditioning pipes to prevent ingress of
dirt and moisture into the system.
6. Remove 2 nuts securing receiver drier to bracket
and remove receiver drier.
7. Remove dual pressure switch from receiver drier
and discard ’O’ ring.
CAUTION: Plug the connections.
Refit
8. Clean mating faces of pipes, receiver drier and
dual pressure switch.
9. Lubricate new ’O’ rings with compressor oil.
10. Fit ’O’ rings to pipes and dual pressure switch.
11. Fit and tighten dual pressure switch to receiver
drier.
12. Fit receiver drier to bracket and secure with nuts.
13. Fit pipes to receiver drier and tighten unions to
18 Nm (13 lbf.ft).
14. Connect multiplug to dual pressure switch.
15. Evacuate and recharge A/C system.
See
Adjustment.
16. Fit front bumper valance.
See CHASSIS AND
BODY, Repair.
