Lighting

74

L

HAZARD WARNING FLASHERS

Press the switch to turn the hazard warning
lamps on. When the hazard warning lamps are
operating, the indicator warning lamps will
flash in time with the hazard warning lamps.

Note: Hazard warning lamps can be used when
the ignition is on or off.

ADAPTIVE FRONT LIGHTING SYSTEM
(AFS)

1. Vehicle without AFS.

2. Vehicle with AFS.

When cornering using dipped beam, AFS will
adjust the headlamp beams to provide
improved illumination in the direction of travel.

AFS is deactivated when :-
• reverse gear is selected.
• the vehicle is stationary.
• daylight running lamps are on.

E80807

1

2

E80823

75

Lighting

R

If a system fault is detected the
headlamps will attempt to move to
the central position, and remain

stationary. The AFS warning indicator will
illuminate to indicate that a fault is present.

 If the warning indicator illuminates, contact
your Land Rover Dealer/Authorised Repairer as
soon as possible.

DIRECTION INDICATORS

The direction indicators are operated using the
indicator stalk. Move the stalk up or down, to
indicate turning right or left.

The indicators will operate three times if the
stalk is briefly pushed up or down.

E80822

Lighting

76

L

INTERIOR LAMPS

1. Sun visor lamps. Switch on or off as

required using the switch.

2. Map reading/interior lamps. The switch

allows them to be turned on, off, or set to
operate when the doors are opened.

3. Luggage compartment lamp.

Automatically illuminates when the doors
are opened.

4. Puddle lamps. Automatically illuminate

when the doors are opened.

5. Glove box lamp. Automatically illuminates

when the glove box is opened.

6. Footwell lamps. Automatically illuminate

when the doors are opened.

APPROACH LAMPS

The approach lamp feature turns on the
parking lamps, indicator lamps, door mirror
lamps, number plate lamps, interior lamps, and
puddle lamps remotely. This feature is
activated with the remote control.  See USING
THE REMOTE CONTROL (page 41).

The length of time which the lights
remain on can be adjusted by your
Land Rover Dealer/Authorised

Repairer.

3

2

4

1

2

6

4

1

5

6

1

2

E83602

77

Lighting

R

CHANGING A BULB

General information

Note: In certain territories it is a legal
requirement to carry spare bulbs. A
replacement bulb kit is available as an
approved accessory from your Land Rover
Dealer/Authorised Repairer.

Halogen bulbs

Halogen bulbs are used for main beam, dipped
beam, and front fog lamps. Take care not to
touch the glass part of the bulb with your
fingers; always use a cloth to handle the bulb.
If necessary use methylated spirits to remove
finger prints.

Xenon lamps

Seek advice about the correct
disposal of Bi-Xenon lamp units
from a Land Rover

Dealer/Authorised Repairer, or your local
authority.

CAUTION

Alway replace bulbs with the correct
type and specification. If you are in any
doubt contact your Land Rover

Dealer/Authorised Repairer for advice.

WARNINGS

Replacement or maintenance of
Xenon lamps should only be carried
out by suitably qualified personnel.

High voltage is required to ignite the
gas and metal vapour which are used
to power Xenon lamps. Contact with

this voltage can cause serious injuries.

Bi-Xenon lamp units operate at a very
high temperature. Ensure that the
lamp units have cooled before

attempting to touch them.

Xenon lamp units contain Mercury
which is highly toxic, and can be
extremely harmful.
