Frelander 2. Manual - part 698

Steering wheel

ADJUSTING THE STEERING WHEEL

To adjust the steering wheel :-

1. Release the locking mechanism by pulling

the lever down.

2. Adjust the steering wheel to the desired

position.

3. Push the locking lever back up, and ensure

that it's fully home.

AUDIO CONTROL

1. Press to switch between radio, CD, or AUX.

2. Press to increase volume.

3. Press to decrease volume.

4. Press and release to scroll through preset

radio stations or CD tracks. Press to
search up or down for the next or previous
radio station/CD track.

WARNINGS

Never adjust the steering wheel
position whilst the vehicle is in motion.
Doing so will reduce control of the

vehicle, and may cause unpredictable steering
movements.

After adjusting the steering wheel
position, ensure that the locking lever
is returned to the fully up position.

Failure to do so will reduce control of the
vehicle, and may cause unpredictable steering
movements.

E82965

2
3

E83208

Steering wheel

Audio control using the telephone
buttons

When the telephone system is inoperative the
telephone controls on the steering wheel can
be used to operate the audio system.

1. Operates as a menu control. Press to enter

or confirm menus selections.

2. Operates as an exit control. press to return

to the previous screen or menu.

3. Operates as forward motion of the rotary

control. Press to scroll forward through
menu items.

4. Operates as backward motion of the rotary

control. Press to scroll back through menu
items.

E83782

Lighting

LIGHTING CONTROL

Main switch panel

1. Headlamps/side lamps off.

2. Side lamps on.

3. Headlamp dipped beam on.

4. Autolamps on.

5. Headlamp levelling control.

6. Rear fog lamps on/off.

7. Front fog lamps on/off.

8. Facia illumination dimmer control.

Main beam

1. When the headlamp dipped beams are

switched on, push the indicator stalk to
change to full beam.

2. To flash the headlamps at anytime, briefly

pull the indicator stalk and release it.

When the headlamp main beam is
on, the main beam warning
indicator will illuminate.

Note: Do not use main beam where it may
dazzle other road users.

Headlamp courtesy delay

This feature enables the driver to keep the area
in front of the vehicle illuminated for a short
period after the vehicle has been locked.

1. Switch off the ignition.

2. Pull the indicator stalk (main beam flash)

towards the steering wheel, and exit the
vehicle as normal.

The headlamps will remain on for
thirty seconds. The length of time
that the headlamps remain on, can

be adjusted by your Land Rover
Dealer/Authorised Repairer.

FRONT FOG LAMPS

Front fog lamps will only operate when
headlamp dipped beam, or Auto lamps are
selected. Press the front fog lamp button to
switch on, press again to switch off.

E80804

E80805

E80808

Lighting

REAR FOG LAMPS

Rear fog lamps will only operate when
headlamp dipped beam, or Auto lamps are
selected. Press the rear fog lamp button to
switch on, press again to switch off.

ADJUSTING THE HEADLAMPS

Note: The headlamps must be removed in
order to change the beam pattern. See
CHANGING A BULB (page 77).

The tourist lever allows you to adjust the
headlamps to the correct beam pattern for
driving in countries where vehicles drive on the
left, or the right.

When new, the lever will be set to the correct
position for the country in which the vehicle is
sold. To change the pattern for driving on the
other side of the road, move the lever to the
opposite position.

Note: When changing the beam pattern using
the lever, ensure that you change the lever
position on both headlamps.

HEADLAMP LEVELLING

Halogen headlamps

Use the headlamp levelling control to account
for vehicle loading changes.

Xenon headlamps

Headlamp levelling is adjusted automatically if
Xenon headlamps are fitted.

E80806

E83553

Vehicle load

Switch position

Driver only

Driver and front seat

passenger

Driver and passengers

in all seats

Maximum gross

vehicle weight

Maximum rear axle

load

2.5
