Frelander 2. Manual - part 687





26

Quick start

L

 Sand

Suitable for soft, predominantly dry,
yielding sandy ground, e.g. sand
dunes and deserts. If the sand is

damp or wet the Mud-Ruts program may be
more beneficial.

Parking aid

With the ignition on, the front and rear parking
sensors are activated whenever reverse gear is
selected. A short confirmation tone will sound
after one second.

If an obstruction is detected by the sensors, an
intermittent tone will sound (higher pitch for
objects detected by the front sensors). As the
vehicle moves closer to the obstruction the
intermittent tone increases in frequency.

When the distance between the sensor and the
obstruction is less than approximately 30 cm
(1 foot) the tone becomes continuous.

The parking aid is automatically switched off
when the vehicle's forward speed exceeds 16
km/h (10 mph).

Front parking aid - manual operation

When driving into a limited space, the front
parking aid can be manually activated by
pressing the switch on the facia. The switch
will illuminate and a short confirmation tone
will sound.

Wading

When wading through water, select the
program suitable for the surface beneath the
water.

The maximum depth of water should not
exceed 500 mm (19.7 inches).

E83206

27

Quick start

R

Audio system

Standard audio

1. Press to switch audio unit on or off and

rotate to adjust the volume.

2. Press appropriate number to select

required preset radio station or disc from
autochanger.

3. Display screen.

4. Press to access the audio unit menu.

5. Rotate to scroll through menu options or

adjust settings. Press to select a menu
item or confirm a change.

6. Press to automatically search for a radio

station or select a track on a CD.

7. Press to manually search for a radio

station or to search in a CD track

8. Press to eject the currently selected CD.

9. Press button repeatedly to scroll through

the sound settings options. With the
desired sound setting selected, rotate
control 1 to adjust. Confirm new setting by
pressing button 9.

10. Press the appropriate mode button to

select FM, AM, CD or AUX.

BBC R4

2

FM1

14 : 54

TA

NEWS

PTY

E84421

7

3

2

1

9

4

5

6

7

6

8

10

28

Quick start

L

Premium audio

1. Press to switch audio unit on or off and

rotate to adjust the volume.

2. Display screen.

3. Press to automatically search for a radio

station or select a track on a CD.

4. Press to manually search for a radio

station or to search in a CD track

5. Press to eject the currently selected CD.

6. Press the appropriate mode button to

select FM, AM or CD.
• Press and release the FM button to

change between FM1, FM2, DAB1 and
DAB2.

• Press and hold the CD button to change

between CD and AUX input.

7. Telephone button.

8. Press to access the audio unit menu.

9. Rotate to scroll through menu options or

radio presets. Press to select a menu item
or confirm a change.

10. Press appropriate number to select

required preset radio station or disc from
autochanger.

11. Press and hold to automatically store radio

stations. Press and release to access the
autostored stations.

12. Press button repeatedly to scroll through

the sound settings options. With the
desired sound setting selected, rotate
control 1 to adjust. Confirm new setting by
pressing button 12.

TA

NEWS

PTY

100.7

FM1

14 : 54

HEART   FM

1 2 3 4

6

2

E84422

3

4

5

4

3

6

7

8

2

1

9

10

11

12

6

29

Quick start

R

Steering wheel controls

1. Press to switch between Radio, CD, or

AUX.

2. Press to increase volume.

3. Press to decrease volume.

4. Press and release to scroll through preset

radio stations or CD tracks. Press and hold
for two seconds to search up or down for
the next radio station/CD track.

Radio operation

Press either the FM or AM button to select the
required waveband. Repeated presses of either
button will scroll through the FM and AM
waveband memory options.

Storing radio stations

To automatically store radio stations, press
and hold either the FM or AM button on
standard audio units or the AUTO button on
premium audio units. The stations will be
stored under the preset numbers in the
selected waveband.

To recall a preset station, press and release one
of the numbered preset buttons.

A selection of radio presets can be stored
manually.  See STATION PRESET BUTTONS
(page 226).

DAB radio

On the premium audio unit, press and release
the FM button repeatedly until either DAB1 or
DAB2 is displayed. To automatically tune all the
available digital radio channels, press and hold
the AUTO button.

Use the channel search buttons to scroll
through the list of available channels. When
you find a channel you want to store, press and
hold a numbered preset button.

1

2
3

4

E83208

FM1

14 : 54

Classic

1 2 3 4

6

100.3

E83210

Auto-tuning
50%

E88130

E85661
