30

Quick start

L

Some channels can contain subchannels. If
subchannels are available, an arrow icon is
displayed. To access a subchannel, press and
hold one of the channel search buttons. Press
and release the channel search button
repeatedly to scroll through the available
subchannels.  See CHANNEL OPTIONS
(page 236).

CD OPERATION

Depending on specification, your audio unit
will feature either a single-slot CD player or an
integral 6-disc autochanger.

Single CD player

Insert a disc, label side up, into the player. The
disc will load and start to play.

To end CD playback, briefly press one of the
other mode buttons (FM or AM). Playback will
resume when the CD button is pressed again.

To eject the disc, press the eject button. When
prompted, remove the disc from the CD slot.

CD autochanger

Loading CDs

To insert a single disc, press the CD button
then one of the number buttons (1 to 6). When
prompted by the information display, insert the
disc, label side up. The autochanger will load
the CD in the selected position.

Playing CDs

When in CD mode, press the appropriate CD
number (1 to 6) to start playing the selected
disc. Playback commences and progresses
sequentially through all of the loaded discs.

Playback can be paused by briefly pressing one
of the other mode buttons (FM or AM).
Playback will resume when the CD button is
pressed again.

Ejecting CDs

To eject a single disc, select the required disc
by pressing one of the number buttons 1 to 6
and then press the eject button.

To eject all loaded discs, press and hold the
eject button, the discs will be ejected one at a
time. Remove disc only when the display
shows the message Remove Disc.

Compatible disc types

The use of discs with paper labels or
double-sided dual format discs (CD/DVD)
should be avoided as they could become
jammed.

E88124

14 : 54

1 2 3 4

DAB1 [1]

BBC 5LIVE

100.7

2

FM1

14 : 54

TA

NEWS

HEART   FM

PTY

E83211

31

Quick start

R

Clock setting

Standard audio

Premium audio

1. Switch on the audio system, by pressing

the volume rotary control.

2. Press the MENU button to access the

function menu.

3. Rotate the control to select Clock and

press to confirm selection.

4. On standard audio units, rotate the control

to select Set and press to confirm
selection.

5. Rotate the control to adjust the hour and

minutes. Press the control to confirm
setting after each action. On premium
audio units, the time mode (12 or 24 hr)
can also be set from this menu.

6. Once the time has been set, on standard

audio units, OK will be highlighted. Press
the rotary control to accept the settings.
Press the EXIT button on premium audio
units to cancel and return to the menu.

Telephone - Bluetooth system

Mobile phones with Bluetooth capability can
communicate with the vehicle’s inbuilt
telephone feature. You must pair your
Bluetooth mobile phone with the vehicle’s
system before use.

Pairing a phone to the vehicle's system

1. With the ignition on, press the telephone

mode button on the audio unit.

2. When prompted, press the ENTER control

to confirm that you want to pair a
telephone to the system.

3. The system will ask you to check that your

Bluetooth function on your telephone is
enabled. Press the ENTER control to
confirm. The system will then search for
your telephone.

4. After the search is completed, the detected

telephones will be listed. Rotate the ENTER
control to scroll through the list and press
to select the correct telephone.

5. The audio unit will then display a Bluetooth

access code number. Enter this number
into your telephone. The telephone will
now pair to the system.

6. If the pairing fails, a message will appear

on the audio unit display. Press the ENTER
control to retry or press the EXIT button
and restart the process.

7. To cancel the pairing process, press and

hold the telephone button on the audio
unit.

Clock

OK

06

:15

Set

PM

E84423

CANCEL

SET

Time Set

PM

1

:39

E84424

Mobile phone compatibility

Not all phones are fully compatible with the
Land Rover system. For the latest list of
compatible phones and software versions,
please refer to
www.ownerinfo.landrover.com
Alternatively consult your Land Rover
Dealer/Authorised Repairer.

32

Quick start

L

Making a call

1. With a paired handset, press the telephone

mode button on the audio unit.

2. Enter the required telephone number using

the numeric keypad.

3. Press and release the ENTER control or

operate the answer call switch 1 on the
steering wheel to send.

Receiving a call

To answer an incoming call, press and release
the ENTER control on the audio unit, or operate
the answer call switch 1 on the steering wheel
controls.

To end, or reject an incoming call, press and
release the EXIT button or operate the end call
switch 2 on the steering wheel controls.

Operating note

If more than one paired Bluetooth phone is in
range, the system will automatically select the
last phone used in Bluetooth mode.

1

2

E83216

33

Filling station information

R

Filling station information

FILLING STATION INFORMATION

Fuel filler flap

Fuel filler flap location

A small arrow on the fuel gauge
indicates which side of the vehicle
the fuel filler flap is located.

Fuel filler flap opening

With the vehicle unlocked, pull the flap (as
arrowed in the illustration) to open.

Refuelling

The filler cap is secured to the vehicle by a
strap. For your convenience, a holder is
provided, on the fuel filler flap, to hook the
strap over while refuelling.

After refuelling, tighten the filler cap until it
clicks three times.

Fuel tank capacity

Fuel specification

The correct fuel specification for your vehicle is
shown on the inside of the fuel filler flap. See
TECHNICAL SPECIFICATIONS (page 146).

Incorrect fuelling

Operating note

The fuel filler flap will not open if the vehicle is
locked.

E83705

E83217

E83218

Model

Litres

Gallons

Petrol engine

70

15.4

Diesel engine

68

14.9

CAUTIONS

Land Rover petrol engines are not fitted
with equipment necessary for use of

fuels containing more than 10 percent ethanol.

Do not use E85 fuels (85 percent ethanol
content). If E85 fuels are used, serious

engine and fuel system damage will occur.

CAUTION

If the fuel tank is accidentally filled with
the wrong type of fuel, it is essential that

the engine is not started and you seek qualified
assistance.
