Anti-Lock Control - Front Wheel Speed Sensor

Removal and Installation

Removal

Raise and support the vehicle.

1.

Remove the front wheel and tire.

Refer to:

Wheel and Tire

 (204-04 W heels and Tires, Removal and

Installation).

2.

Release the fender splash shield.

Refer to:

Fender Splash Shield

 (501-02 Front End Body Panels,

Removal and Installation).

3.

4.

Torque: 5 Nm

5.

Installation

To install, reverse the removal procedure.

1.

If a new component is to be installed, configure using IDS.

2.

Anti-Lock Control - Rear Wheel Speed Sensor

Removal and Installation

Removal

• NOTE: Removal steps in this procedure may contain installation details.

1.

WARNING: Make sure to support the vehicle with axle

stands.

Raise and support the vehicle.

1.

Remove the rear wheel and tire.

Refer to:

Wheel and Tire

 (204-04 W heels and Tires, Removal and

Installation).

2.

3.

4.

Torque: 5 Nm

5.

Installation

To install, reverse the removal procedure.

1.

If a new component is to be installed, configure using Land Rover
approved diagnostic equipment.

2.

Anti-Lock Control - Traction Control - Anti-Lock Control - Traction Control

Description and Operation

OVERVIEW

The anti-lock control - traction control section is incorporated within the anti-lock control - stability assist section of the
workshop manual.
For additional information, refer to:

Anti-Lock Control - Stability Assist

 (206-09C Anti-Lock Control - Stability Assist,

Description and Operation).
