CHASSIS AND BODY DIMENSIONS

BODY DIMENSIONS

77-1-5

BODY DIMENSIONS

Body Dimensions

The following dimensional information is shown to assist the technician in the diagnosis and repair of body panels.
The information is shown in two different forms. In the first part of the information X,Y and Z dimensions are shown
and in the second part actual point to point dimensions are shown.

The X,Y,Z dimensions are the planes used by Land Rover for the measurement of body panels. The whole bodyshell
lies within a parallel grid system. See following illustrations.

The 'X' plane is an imaginery vertical plane which measures distances along the length of the vehicle. The start point
for this plane is through the centre of the rear wheels.

The 'Y' plane is an imaginery plane through the centre of the vehicle and measures distances across the vehicle. As
a rule, body dimensions are symmetrical about the centre line.

The 'Z' plane is an imaginery horizontal plane which measures distances in height of the vehicle. The start point for
this plane is through the centre of the rear wheels.

M77 1757

-2400

(-94.488)

X

-1800

(-70.866)

-1200

-600

0

600

(-47.244)

(-23.622)

(23.622)

X

X

X

X

X

1200

(47.244)

Z

600

(23.622)

Z

0

Z

M77 1756

0

Y

600

(23.622)

Y

600

(23.622)

Y

CHASSIS AND BODY DIMENSIONS

77-1-6

BODY DIMENSIONS

The point to point dimensional information shown are actual distances between two points. These points used are
either intersection points or holes. Where holes are taken, the point of measurement is always from the hole centre.

X,Y,Z dimensional information
Figures shown outside brackets are metric measurements (millimetres) and those inside brackets are imperial
measurements (inches).

Body to chassis mounting holes

I.D

Description

X

Y

Z

A

Front mounting hole

-3071.6

419.1

271.5

(-120.929)

(16.500)

(10.688)

B

Second mounting hole

-2130.5

414.3

233.4

(-83.877)

(16.311)

(9.188)

C

Third mounting hole

-1763.7

660.4

78.0

(-69.437)

(26.000)

(3.070)

D

Fourth mounting hole

-1055.6

414.3

169.8

(-41.559)

(16.311)

(6.685)

E

Fifth mounting hole

-552.3

660.4

78.0

(-21.744)

(26.000)

(3.070)

F

Sixth mounting hole

-44.000

275.0

296.4

(-1.732)

(10.826)

(11.669)

G

Rear mounting hole

925.6

495.3

184.6

(36.440)

(19.500)

(7.267)

M77 1759

A

B

C

D

E

F

G

CHASSIS AND BODY DIMENSIONS

BODY DIMENSIONS

77-1-7

Front end information

I.D

Description

X

Y

Z

A

Grille mounting slot

-3190.5

413.9

303

(-125.610)

(16.295)

(11.929)

B

Headlamp mounting panel,

-3124

686.6

335

slot

(-122.992)

(27.031)

(13.188)

C

Bonnet locking platform, jig

-3065.8

611

584.7

location hole

(-120.700)

(24.055)

(23.019)

D

Valance upper, jig location

-2789.4

770.5

507.1

hole

(-109.818)

(30.334)

(19.964)

E

First wing fixing hole

-3064.8

768

650.4

(-120.661)

(30.236)

(25.606)

F

Second wing fixing hole

-2787.9

778.7

686.1

(-109.759)

(30.657)

(27.011)

G

Third wing fixing hole

-2523.9

785.4

704.5

(-99.366)

(30.921)

(27.736)

H

Fourth wing fixing hole

-2259

789.6

718.4

(-88.937)

(31.086)

(28.283)

J

Fifth wing fixing hole

-1993.9

793

728.9

(-78.5)

(31.220)

(28.696)

M77 1753

B

C

D

E

F

G

H

J

A

CHASSIS AND BODY DIMENSIONS

77-1-8

BODY DIMENSIONS

Front end/side information

I.D

Description

X

Y

Z

A

Bonnet hinge fixing, top hole

-1906.3

706

742.9

(-75.051)

(27.795)

(29.248)

B

Windscreen finisher, top slot

-1508.9

715

1229

(-59.405)

(28.147)

(48.385)

C

'A' post top, top hinge fixing

-1859

809.6

584.7

hole

(-120.700)

(24.055)

(23.019)

D

'A' post bottom, top hinge

-1859

809.6

289.1

fixing hole

(-120.700)

(24.055)

(11.381)

E

'B/C' post top, top hinge

-860.5

809.8

680.5

fixing

(-33.877)

(31.881)

(26.791)

F

'B/C' post top, jig location

-841.5

809.8

644.5

hole

(-33.129)

(31.881)

(25.374)

G

'B/C' post bottom, top hinge

-860.5

809.8

290.3

fixing hole

(-33.877)

(31.881)

(11.429)

H

'B/C' post bottom, jig location

-841.5

809.8

254.2

hole

(-33.129)

(31.881)

(10.007)

J

'D' post, door striker fixing,

-75.4

782.3

619.1

top hole

(-2.968)

(30.799)

(24.374)

M77 1755A

B

C

H

F

D

J

A

 G
