Restrain  the  sector  shaft  adjuster  with  a

8.

Remove  the  six  bolts  securing  the  sector  shaft

hexagonal  key and remove the locknut.

cover.

9.  Hold  the  sector  shaft cover  and  turn  the  adjuster

and  screw  clockwise  until  the  cover  can  be
removed.

10.  Lift-out the sector shaft.

..

ST

11.

Remove the  rack  and piston  assembly  and  collect

the rack adjuster thrust pad.

ST

12.  Drive-out the worm adjusting screw locking pin.

13.  Using  special  tool

remove  the input shaft

worm adjusting screw anti-clockwise.

Tap the  spiined

end  of  the  input  shaft  to  free  the

outer bearing.  Remove  the  bearing  track  and  ball
cage assembly.

33

15.  Withdraw  the  input  shaft,  worm  and  valve

assembly.

STEERING

15

Release  the  circlip  and  remove  the  steel  washer

17.  Remove the wire circlip, anti-extrusion  washer and

and

oil seal from the sector shaft housing.

seal from t h e  input shaft housing.

Sector shaft assembly

5.

Check that no side play or wear exists in the roller.

6.  Check the condition of the adjuster and its retainer

7.

The  axial  clearance

of  the  adjuster  should  not

8.  Examine the bearing journals on the shaft for wear

9.  Check  the  gear  teeth  for  excessive  and  uneven

and that the crimping

is sound.

exceed

in).

and damage.

wear, scores and pitting.

continued

INSPECTION

AND

OVERHAUL OF COMPONENTS

Steering box

housing

1.  Examine  the  sector  shaft  upper  and  lower  needle

roller bearings and

if necessary drive them from the

housing with a suitable drift.

2.  Inspect the  input shaft needle bearing  and if

drive  it  from  the  housing  and  press-in  a
replacement.

3.  Examine the piston bore for wear and scores.
4.  Check the input shaft bores

for wear and scores.

34

STEERING

Valve and worm assembly

NOTE:

If  the  inner  ball  race  is  faulty  and  unfit

for

further  service  it  cannot  be  renewed  and  a  new  valve
and worm assembly must be obtained and fitted. Should
this  be  the  case,  the  following  checks of  the  valve  and

worm can be ignored.

10.  Examine  the  valve  rings  which  must  be  free  from

cuts,  scratches and  scores.

Also,

the  rings  should

be a loose fit

in t h e  grooves.

11.  If  any  ring  is  unsatisfactory,  all  the  rings  must  be

renewed. When removing

the rings take care not to

damage the valve grooves.

12.  T o   fit  new  rings  use  special  tool

which

consists

of  the following three parts:-

a)  Ring expander.
b)  Split

c)  Ring compressor.

Before  using  the  tool

each  part  with  the

recommended power steering fluid.

13.  Warm  the  five  rings  in

water  leaving  them  in

the water until ready for fitting.  When pliable, feed
the  ring  for  the

groove  (nearest  the  roller

bearing)  over

expander  and  position  the

expander  over  t h e   input  shaft,  slide

ring  into

the  groove  and  mould

it

into  position  with  the

fingers.

13

14.  Encircle  the  ring  with  the  split  coller  and  squeeze

the  coller  together,  by  hand,  and  hold  for
approximately thirty seconds.

Remove  the  split  coller  and  with  care,  ease  the

compressor  tool  over t h e   ring  and  leave  for  a
minutes

to

cool before carefully

the tool.

16.  Using  the  expander  tool,  as  before,  fit  the

remaining  four  rings,  one  at  a  time,  into  the
grooves and mould with  the fingers.  It is  important
that

only  one  ring  at  a  time  is  placed  on  the

expander  since  in  the  meantime  the  remaining
rings could cool in an expanded condition making

it

difficult to locate and contract

rings

in

valve

grooves. Encircle the four rings with the split coller
and  squeeze  together

for  approximately  thirty

seconds.  Then,  with  care,  ease  the  compression
tool over the four rings and allow to cool for about
five  minutes  before  carefully  withdrawing  the
compressor.

continued

S

TEERING

17.  Examine the bearing surfaces

of the valve assembly

for wear and scores.

18.

Examine the worm track for wear and pitting.

19.

Check  that  the  end-float  between  the  locator  and

valve sleeve does not exceed

(0.005 in).

20.  Rotary movement  between  the components at the

trim pin is permissible.

21.  Check that no free movement exists on the torsion

bar  assembly  pin  between

the  input  shaft  and

worm.

29.

Remove  the  plastic  seal  and  the

ring  seal

30.  Ensure that the outer  diameters of  the  piston  are

31.  Fit a new

ring seal to the piston groove.

beneath it, from the piston groove.

free from burrs and damage.

17

20

22.  The valve and worm assembly should be renewed

if

there is wear at the following points:
a)  Inner and outer bearing tracks.
b)  Worm.
c)  Valve locator.
d)  Input shaft needle bearing Journal.

23.  Examine the outer ball race and track for wear and

general  condition.  The  race  should  be  renewed  if
there is wear and pitting o r  if a new valve and worm
assembly

is being fitted.

Thrust pad

and adjuster

24.  Examine the thrust pad for scores.
25.  Check that the thrust pad seat in  the adjuster is not

26.  Check that the thrust pad spring is not broken.

worn or scored.

Rack and piston

27.  Examine the rack teeth for wear and pitting.
28.  Check  that  the  surface  on  which  the  thrust  pad

bears is not

and scored.

32.  To

fit a new plastic seal to the piston, warm the seal

in hot water and fit to the piston groove.  Insert the
piston  in  the inverted position

piston  first  into

the cylinder and leave to cool.

Sector shaft cover

33.  Examine the sector shaft cover needle bearing  and

if  necessary  extract the  bearing  taking care  not  to
damage the housing.

continued
