LT 95 FOUR

SPEED GEARBOX

REMOVE

AND

OVERHAUL

MAINSHAFT

TRANSFER GEAR

Special tool:

mainshaft output gear puller

Remove

mainshaft rear bearing housing.

2.  Lift out the roller bearing.
3.  Remove the snap-ring.
4.  Withdraw the shim washer.

5 .

transfer  gcar  is  retained  on  the  splines  with

Loctite 275. Use

a puller 1861388 to withdraw it.

NOTE: The roller bearing outer race is located by a

roll

pin  which

be  punched-out  before  the  race  can  be

removed.

Assembling

Fit the transfer gear to the mainshaft.
Fit the shim washer and snap-ring.
Check  the  end-float  between

the

washer  and

snap-ring.  End-float  to  be

0,050

(0.002 in)

maximum.  Shim  washer  range

to

(0.071 to

0.079 in) in

(0.002 in) stages.

Fit

the roller bearing and rear bearing housing.

REMOVE

AND

OVERHAUL

INTERMEDIATE

GEARS ASSEMBLY

Special tool:

slave intermediate shaft

Remove t h e  speedometer drive housing.

2.  Remove the gearbox bottom cover.
3.  Screw  a suitable extractor into  the 8

hole provided

in the intermediate gear shaft.

4.

Hold  the  intermediate gear cluster

in

position  and

withdraw the shaft.

5.

the slave shaft

to

retain together the

gears assembly.

6.  Withdraw the intermediate gears assembly.
7.  Slide  the  thrust  washers,  bearings  and  gears  from

8.  The  input  gear  and  outer  member  is  a  riveted

the slave shaft.

assembly and no dismantling is permitted.

9.  Remove  the

ring  seal  from  the  intermediate

gear shaft.

Wash  and  degreasc  all  parts  and

for  wear

and  renew

if  necessary.  When  new,  the  thrust

bearing washers have a

coating, i f  this only

has worn away there is no need

to renew them.

Assemble intermediate gears

11.

Place the slave shaft on t h e  bench, extractor thread
end uppermost.

12.

Fit  a  pear-shaped  thrust  washer,  inner  ring  and  a

thrust  bearing  washer  to  the  shaft  (ring  grooved
face downwards).

13.

Fit  a  needle-roller  bearing  and  the  ‘high’  gear
(plain face first) to t h e  shaft.

41

LT 95 FOUR SPEED GEARBOX

ST12

1 OM

14.

Position a thrust  bearing washer on the ‘high’ gear.

15.  Fit  a  spacer,

bearing  and

a  further

spacer to the input gear inner

16.  Position

assembled input  gear on  the  shaft and

engage  the  lower  spacer

in  the  previously

positioned  thrust  bearing

17.  Locatc  a  thrust  bearing  washer  over

upper

spacer.

18.  Fit  a needle roller  bearing and  the ‘low’ gear (plain

side last)

to

the shaft.

19.

Fit  the remaining thrust  needle  bearing,  inner  ring

and thrust washer (ring grooved face upwards).

42

20.  When  the  foregoing  bearing  clearance  check  has

been  completcd.

the

and  slave

shaft

assembly into

transfer gearbox  and

selector forks.

21.

Withdraw the slave shaft and lubricate the bearings

through the shaft aperture.

22.

Fit  the intermediate shaft and

ring

with

the

flat on the shaft toward

t h e

differential u n i t .

Measure  the  clearance  between  the  rear  thrust

washer  and  the  gear  casing.  This  must  be

to

(0.006 to

0.009 in).

24.  Adjustment  is  carried  out  by  substituting  one  or

both  of

thrust  washcrs.  The  washers  are

available

in

(0.139 in),

(0.143 in) and

(0.147  in) thicknesses.

Refit the gearbox bottom cover.

26.  Refit  the speedometer drive

housing.

..

...

..:

LT

95 FOUR SPEED GEARBOX

REMOVE AND OVERHAUL DIFFERENTIAL UNIT

Special tool:

- bearing extractor

Select the differential lock.

2.  Rcmove

differential lock actuator assembly

3.  Remove the front output shaft and housing.
4.  Remove the speedometer drive housing.

Remove the intermediate cluster assembly.

6.

Remove the differential assembly.

NOTE:  During  dismantling  it  is  essential  that

all

components  are  marked  in  their  original  position  and
relative  to  other  components,

so  that  if  original

components  are  refitted,  their  initial  setting

is

maintained.

7.

Press off the roller bearings using tool

8.  Withdraw the  high-speed gear, which  is secured by

Loct tc.

9.  Remove the fixings, low-speed gear to casing.

10.

Withdraw the gear.

11.  Remove the casing securing bolts.
12.  Lift  off

t h e

rear

case  assembly  (and  oil  retaining

ring

later gearboxes).

13.  Withdraw  the side gear (and thrust washer

later

boxes).

14.  Slidc

out  the  cross-shafts  and

the  bevel

pinions  and  thrust  washers  from  the  front  case
assembly.

15.  Withdraw  the side gear (and thrust washer

boxes)

to

the front case assembly.

NOTE:  From  gearbox  numbers  1300

and  1700

the  following  modifications  have  been  made  to

the differential.
A.  Introduction of side gear bushes.

Improved thrust washers.

C.  Addition of thrust washer on side gears.

Modified cross pins.

E.  Addition of oil retaining ring.

The  new  differential  part  number  FRC  7740

is

only

interchangeable with  superceded  unit  part  number
340.

43

LT 95

FOUR SPEED GEARBOX

NOTE:  If  replacements  are  required,  replace  the

following items

16

and 17 as sets.

16.  Bevel pinions and side gears (set of six).
17.  Cross-shafts (set of
18.  Check the gear teeth for damage.
19.  Check  all  parts  for  satisfactory  general  condition

including  the sidc gear bushcs.

NOTE:  The differential  case  halves  are a  matched
pair, and halves must not  be changed individually.

Assemble differential to gearbox

27.  Refit the differential unit.
28.  Refit

speedometer drive housing.

29.  Refit

output shaft and housing.

30.  Rcfit the diffcrential lock actuator assembly

NOTE:  If  a  replacement  differential  unit  is  being
fitted,  carry out  the  ‘Differential  hearing  pre-load

check’, described  in  ‘Speedometer  drive housing

Overhaul’.

Assemble differential

CAUTION:  It  is  essential  that  during  the  following

assembly all components are well lubricated with new oil
of the correct grade.

20.

Fit  a sidc gear into the

casing.

21.

side gear into the front casing.

Fit  the  bevel  pinions,  thrust  washers  and

shafts into the front casing.

23.

Fit

casing  to

front casing. Tighten  the

bolts evenly

in  sequence to

correct torquc.  Use

Loctite 275 on threads.

24.  Offer the low gear to the differential casing.
25.  Align  the  fixing  holes  and  fit

the

bolts

in

sequence to the correct torque.

Loctite

26.

Fit the roller bearings and refit  the diffcrential

REMOVE  AND  OVERHAUL  TRANSFER  GEAR
LEVER AND CROSS-SHAFT

1.

Remove the

top

2.  Slacken the selector finger pinch bolt.
3 .   Drive  out  the  retaining  pin,  gear  lever  to  cross-

4.

Withdraw the gear lever.
Withdraw the cross-shaft  and spacer.

6.

Lift out the selector finger.

7.

Remove the retaining plates.

8.  Withdraw the scaling rings.

shaft.

Assemble gear lever and cross-shaft

9.  Position the selector finger in

t h e

gearbox.

Fit  the  cross-shaft  and  spacing  collar  and

the selector finger.

side of the gearbox.

11.

Fit  the sealing ring and  retaining plate  at  the

R . H .

12.  Fit

the gear lever and retaining

pin.

NOTE:

If  the differential case or bearings have been

replaced,  carry  out  the  ‘Differential  bearing
load check’.

44
