Defender 90 / 110 / 130. Manual - part 48





CYLINDER ENGINE

20.  Place a piece of  Plastigauge across

the centre of the

crankshaft main bearing journals.

21.  Locate  the  bearing  lower  shell  into  the  main

bearing cap.

22.

Fit  numbers  one

to

four  main  bearing  caps  and

shells. Torque:

to 7,6 kgf

(50 to

55

Ibf

ft).

23.  Fit  the  rear  main  bearing  cap  and  shell.  Torque:

to

9,6 kgf m (65 to 70 Ibf  ft).

Do

not  allow  the

crankshaft  to  be  rotated while the Plastigauge  is in
use.

24.  Remove the main bearing caps and shells.
25.  Using the  scale printed  on  the Plastigauge packet,

measure  the  flattened  Plastigauge  at  its  widest
point.

26.  The  graduation  that  most  closely  corresponds  to

the

width  of  the  Plastigauge  indicates  the  bearing

clearance.

The  correct  bearing  clearance  with  new

or

overhauled  components  is  0,023  to  0,065
(0.0009

to

0.0025 in).

28.  If  the correct clearance is not obtained  initially, use

selective bearing assembly.

29.  Wipe off  the Plastigauge with an

rag.

Do

NOT

scrape

it

off.

30.  Maintain  the  bearing  shells and caps

in  sets and

in

the correct sequence.

Renew spigot bearing

31.  Carefully remove the old bearing.
32.  Fit  the spigot  bearing flush  with, or to  a maximum

of  1,6

(0.063 in)  below  the  end  face

of  the

crankshaft.

33.  Ream  the  spigot  bearing  to  19,177

0,025

(0.7504

0.001 in)  inside  diameter.  Ensure  all

swarf is removed.

ASSEMBLING ENGINE

FIT CRANKSHAFT AND MAIN BEARINGS

1.

Locate  the  upper  main  bearing  shells  into
cylinder block;  these  must  be the shells with  the oil
drilling and oil grooves.

2.  Locate the  flanged upper  main  bearing shell

in

the

centre position.

3.  Lubricate the crankshaft main bearing journals and

bearing  shells  with  clean  engine  oil  and  lower  the

crankshaft into position.

CYLINDER

ENGINE

4.  Lubricate  the  lower  main  bearing  shells  and  fit

numbers one

to

four  main  bearing caps and  shells

only,  leaving  the  fixing  bolts  finger  tight  at  this
stage.

5 .

Fit the cruciform side seals to the grooves each side

of  the  rear  main  bearing cap.

Do

not  cut  the  side

seals  to  length,  they  must  protrude
(0.062 in)  approximately  above  the  bearing  cap

parting face.

6.

Apply  Hylomar

jointing compound  to

rearmost  half

of

the  rear main  bearing  cap parting

face or, if  preferred, to the equivalent

on the

cylinder block as illustrated.

7.  Lubricate  the  bearing  half  and  bearing  cap  side

seals with clean engine oil.

8.

Fit  the bearing  cap assembly  to the  engine.

Do not

tighten  the fixings at this stage but  ensure that  the

cap  is  fully  home  and  squarely  seated

on

the

cylinder block.

9.  -Tension  the  cap bolts  equally  by  one-quarter  turn

approximately, t h e n  back  off one complete turn

on

each fixing bolt.

NOTE:  The  lubricant  coating  must  cover  the  seal
guide outer surface completely to ensure that the

oil

seal lip

is not turned back during assembly.

Position the oil seal, lipped side towards the engine,

onto the seal guide.  The seal outside diameter must
be clean and dry.

12.  Push  home  the  oil seal  fully  and squarely  by  hand

into the recess  formed

in the cap and block  until

it

abuts against the machined step in the recess.

Withdraw the seal guide.

13.  Tighten  the  main  bearing  cap  bolts  to  the  corrcct

torque  noting  that  the  bolts  for  numbers

one

to

four  bearings  have

a  different  torque  to  number

five bearing cap bolts.

14.  Using  a  feeler  gauge  or a  dial  indicator  check  the

crankshaft  end-float,

to

(0.004  to

0.008 in).

CAUTION:

Do  not  handle  the  seal

lip,

visually  check

that  it  is  not  damaged  and  ensure  that  the  outside
diameter remains clean and dry.

10.  Position  the  seal guide

RO 1014 on  the crankshaft

flange.

11.  Ensure  that  the  oil  seal  guide  and  the  crankshaft

journal  are  scrupulously  clean,  then  coat  the  seal
guide and

oil seal journal with clean engine oil.

CAUTION:  D

not  exceed

1,000 engine

when

first  starting  the  engine,  otherwise  the  crankshaft rear

oil

seal will be damaged.

112

V8

CYLINDER

ENGINE

--

...

FIT CONNECTING-RODS AND PISTONS

7.

Using

a  piston  ring  compressor,  locate  the  piston

into the cylinder bore, until

the piston  crown  is just

below

the cylinder block  top face.

1.  Locate the applicable crankshaft journal at

B.D.C.

2.  Place  the  bearing  upper  shell

in  the  connecting-

rod.

3.  Retain  the  upper  shell  by  screwing the guide bolts

onto

the connecting-rods.

4.

insert  the connecting-rod  and  piston  assembly into

its  respective  bore,  noting  that  the  domed  shape
boss  on  the  connecting-rod  must  face  towards  t h e
front

of  the  engine  on  the  right-hand  bank  of

cylinders  and  towards

the  rear  on  the  left-hand

bank.  When  both  connecting-rods  are  fitted,  the
bosses will face inwards towards each other.

5.

Position  the oil control piston  rings

so that  the ring

gaps are  all  at one side, between  t h e  gudgeon  pin
and  piston  thrust  face.

gaps  in  the  ring

rails  approximately

25

(1

in)  each  side

of

expander ring joint.

6 .   Position  the  compression  rings  so  that  their  gaps

are  on  opposite  sides  of  the  piston  between  the

gudgeon pin and piston thrust face.

8.

Pull  the connecting  rods

on  to

crankpins using

the guide rods.

9.  Place the bearing lower shell

in

connecting-rod

cap.

10.  Locate  the cap and shell

onto

t h e

connecting-rod,

noting that  the  rib on  the  edge

of  the cap must  be

towards  the  front  of  the  engine

on

the

right-hand

bank  of  cylinders  and  towards  the  rear  on  the
left-hand bank.

11.

Check  that  the  connecting-rods  move  freely

sideways  on

the

crankshaft.  Tightness  indicates

insufficient  bearing  clearance

or

misaligned

connecting-rod.

. .

’..

continued

V8 CYLINDER ENGINE

3.  Temporarily fit  the camshaft chain  wheel  with

marking ‘FRONT’

or ‘F’ outwards.

4.  Turn the camshaft until  the mark

on  the  camshaft

chain  wheel

is

at  the  six  o’clock  position,  then

remove  the  chain  wheel  without  disturbing
camshaft.

5.

Encircle  the  chain  wheels  with  the  chain  keeping
the timing marks aligned.

12.  Check  the  end-float  between  the  connecting-rods

on each crankshaft journal.  Clearance limits:
to

(0.006 to 0.014 in).

13.  Tighten

connecting-rod  nuts  to  the  correct

torque. Fit the

oil

and

joint washer.

FIT CAMSHAFT TIMING

GEARS AND CHAIN

R R

Lubricate  the  camshaft  journals  and  carefully

insert the camshaft into the cylinder block.

2.  Turn the crankshaft  t o  bring number one piston  to

T.D.C.

6.

Engage the chain wheel  asscmbly on the camshaft

and  crankshaft  key  locations  and  check  that  the
camshaft key  is parallel  t o  the shaft axis

to

ensure

adequate lubrication

of  the distributor drive gear.

114
