CYLINDER ENGINE

REMOVE AND OVERHAUL ROCKER

SHAFTS AND

VALVE GEAR

1.  Remove  t h e   four  screws  and  lift  off  the  rocker

2.  Remove  the  four  rocker  shaft

bolts  and

covers

lift

off  t h e  assembly complete with baffle plate.

3.

Withdraw  the pushrods  and  retain

in  the sequence

removed.

Dismantle rocker shafts

5 .

Remove  the  split  pin  from one  end  of  the  rocker

4 .   Withdraw  the  following  components  and  retain

7 .

plain washcr.

8.

wave washer.

9.  Rocker arms.

shaft.

them in the correct sequence for reassembly:

Brackets.

11.  Springs.
12.  Examine  each  component  for  wear,  in  particular

the  rockers  and  shafts.  Discard  weak

or

broken

springs.

4.

Remove the hydraulic tappets and place

to

side

with

their  respective  pushrods.  If  a  tappet  cannot

be  removed  leave

i n

position  until  the camshaft  is

removed.

Inspect tappets and pushrods

13.  Hydraulic tappet; inspect  inner  and outer surfaces

of  body  for  blow  holes  and  scoring.  Replace
hydraulic  tappet  if  body  is  roughly  scored

or

grooved, or has a blow  hole extending through  the
wall

i n   a position  to permit  oil  leakage from  lower

chamber.

14.

The prominent  wear  pattern  just  above  lower  end
of  body should  not  be considered a defect  unless

it

is definitely grooved  or scored. I t   is caused by  side
thrust

of

t h e

cam  against

body  while  the tappet

is moving vertically i n  its guide.

15.

Inspect  the

contact  surface  of

t h e

tappets.  Fit

new  tappets  i f   the  surface  is

worn  or

damaged.

16.

hydraulic tappet  body that has been  rotating

will

have  a  round  wear  pattern  and  a  non-rotating

tappet  body  will  have

a  square wear  pattern

with

very slight depression near the centre.

17.  Tappets  MUST  rotate  and  a  circular  wear

condition is

Tappets

can be refitted provided

are no other defects.

18.

I n   t h e   case  of  a  non-rotating  tappet,

fit

new

replacement  and  check  camshaft  lobes  for  wear;
also

ensure  the  new  tappet  rotates

freely

in

the

cylinder block.

inued

95

V8 CYLINDER ENGINE

19.  Fit  a  new  hydraulic  tappet  if  the  area  where  the

pushrod contacts is rough

or otherwise damaged.

20.  Renew  any  pushrod  having  a  rough  or  damaged

ball end

or seat. Also bent rods must be renewed.

Assemble rocker shafts

Fit a split pin  to

one end of  the rocker shaft.

22.  Slide a plain  washer  over the  long end of  the  shaft

23.  Fit a wave washer to abut the plain washer.

to

abut the split pin.

25.  Compress the springs, brackets and rockers, and fit

a  wave  washer,  plain  washer

and  split  pin  to  the

end

of  the rocker shaft.

Locate the oil baffle platc in place over the rockers

furthest  from  the  notched  end

of

rocker  shaft

and fit the bolts through the brackets and place the
assemblies to one side.

REMOVE  AND  OVERHAUL

THE  CYLINDER

HEADS

1.  Evenly  slacken  the  fourteen  cylinder  head  bolts

reversing  the tightening order.

2.  Before  removing  the  heads  mark  them  relative  to

the

L.H.

and

R.H. side of the engine.

3.

Lift off the cvlinder heads and discard the

NOTE:  Two  different  rocker  arms  are  used  and
must  be  fitted

so  that  the  valve  ends  of  the  arms

slope  away  from  the  brackets,  as  indicated  by  the
dotted lines 'A'

on

the

illustration.

Dismantle cylinder heads

--

24.  Assemble the  rocker  arms, brackets and springs

to

4.

Remove the spark plugs.

5 .

Using  the  valve  spring  compressor  276102,

or  a

suitable  alternative, remove  the valves and springs

the rocker shaft.

and retain in sequence

for refitting.

96

V8

CYLINDER ENGINE

6.

Clean  the  combustion  chambers  with  a  soft  wire
brush.

7.

Clean the valves.

8.

Clean the valve guide bores.

Fit new valve guides

9.  Regrind or fit new valves as necessary.

10.  If

a valve  must  be ground

to a

knife-edge to obtain

11.

The correct angle

for the valve face is 45 degrees.

12.

The correct  angle  for

the

seat is

46

degrees,

and  t h e   seat  witness  should  be  towards  the  outer
edge.

true seat, fit a new valve.

793M

13.  Check  the  valve  guides  and

fit

replacements  as

necessary.  Using  the valve  guide  remover

274401,

drive out the old  guides from  the  rocker shaft side
of  the cylinder head.

14.

Lubricate  the  new  valve  guide  and  place  in

position.  Using  guide  drift  600959 drive  the  guide
into  the  cylinder  head

until  it

protrudes

19

in) above the valve spring recess

in

the head.

NOTE: Service valve guides are

(0.001 in)

larger  on  the  outside  diameter  than  the  original
equipment to ensure interference fit.

Examine and

fit

new valve seats

15.  Check  the  valve  seats  for  wear,  pits  and  burning

and renew the inserts if  necessary.

continued

97

16.  Remove the old seat inserts by  grinding them  away

until they are thin enough to be cracked and prised
out.

17.  Heat the cylinder  head  evenly  to approximately  65

(1

50 degrees

F).

Press

new  insert  into

recess  in

cylinder

head.

CYLINDER ENGINE

NOTE:  Service  valve  seat  inserts  are  available  in
two over-sizes:

and

(0.010

and

0.020

in)  larger  on  the  outside  diameter  to  ensure
interference fit.

If  necessary, cut

t h e

valve seats to 46

degrees.

The nominal seat width  is

(0.031 in).

If

t h e

seat  exceeds

(0.078 in)

it

should  be

reduced to the specified width  by  the use of 20 and
70

21.  The

valve  seat  diameter,  A  is

ins)  and

exhaust valvc  seat  is

(1.240  ins)

22.  Ensure that  the cutter blades are correctly fitted  to

the  cutter  head  with

t h e

angled  end  of  t h e   blade

downwards facing

t h e

work, as illustrated.

Check  that  the  cutter  blades  are  adjusted

so  that

the  middle  of  the  blade  contacts  the  area

of

material

to

be  cut.  Use  the  key  provided

i n

the

hand  set

MS  76.  Use  light  pressure,  and  remove

only

minimum  material necessary.

23.  Smear a small quantity

of  engineers' blue round the

valve  seat  and  revolve  a  properly  ground  valve
against  the  seat.  A  continuous  fine  line  should
appear  round  the  valve.  If  there

a  gap

of  not

more than  12

it

can

be

by  lapping.

24.  Alternatively, insert

strip of  cellophane  between

t h e

valve and seat, hold  the valve down  by

stem

and  slowly  pull  out  the  cellophane.  I f

is

drag the seal is satisfactory in that spot. Repeat  this
in  at  least  eight  places.  Lapping-in

will

correct  a

small open spot.

Assemble valves to cylinder head

25.  Before  fitting the  valves  and springs the  height  of

each  valve  above the head  must  be checked. Insert
each  valve

in

turn  in  its  guide  and  whilst  holding

the head firmly against the seat, measure the height
of

stem  above  the  valve  spring  seat  surface.

This  dimension  must  n o t   exceed

(1.875  ins).

If  necessary  renew

valve  or  grind

the end of the valvc

26.  Lubricate the valve

and

the valves,

springs  and  caps  and  secure  with  the  collets  using
valve spring compressor 276102.
NOTE:  Seals are  fitted  to  the  inlet  valves

on

later

engines, but these can also

be

fitted to early engines

if

required.

98
