C1053

CONNECTOR

DEFENDER 1999 MY

Gauge - Coolant
temperature

Female
BLACK

Behind instrument pack

P5818

C1199

C1060

C1055 C1053

C0232

Cav

Col

CCT

1

RO

ALL

2

B

ALL

CONNECTOR

C1054

DEFENDER 1999 MY

Gauge - Fuel

Female
BLACK

Behind instrument pack

P5761

C1294

C1061 C1054

C1052

C1200

Cav

Col

CCT

1

B

ALL

2

LGB

ALL

3

WG

ALL

C1055

CONNECTOR

DEFENDER 1999 MY

Gauge - Fuel

Female
BLACK

Behind instrument pack

P5818

C1199

C1060

C1055 C1053

C0232

Cav

Col

CCT

1

RO

ALL

2

B

ALL

CONNECTOR

C1060

DEFENDER 1999 MY

Speedometer

Female
RED

Behind instrument pack

P5818

C1199

C1060

C1055 C1053

C0232

Cav

Col

CCT

1

YK

ALL

2

BR

ALL

3

K

ALL

4

RO

ALL

6

NU

ALL

7

B

ALL

9

PN

ALL

10

WG

ALL
