Defender Electric Diagrams. Manual - part 165





C1061

CONNECTOR

DEFENDER 1999 MY

Speedometer

Female
RED

Behind instrument pack

P5761

C1294

C1061 C1054

C1052

C1200

Cav

Col

CCT

1

WO

ALL

3

GB

ALL

5

GU

22

7

LGB

ALL

9

LGU

22

CONNECTOR

C1095

DEFENDER 1999 MY

Diode

BLACK

Below RH rear wheelarch

P5582

C0929

C1260

C1305

C1306

C1095

C0942

C0350

Cav

Col

CCT

1

RY

ALL

2

RY

ALL

C1102

CONNECTOR

DEFENDER 1999 MY

Tail door harness to chassis
harness

Male
NATURAL

Behind RH rear trim panel

P5601

C0512

C0455

C0704

C1102

Cav

Col

CCT

1

G

ALL

2

RLG

ALL

3

NLG

ALL

CONNECTOR

C1103

DEFENDER 1999 MY

Chassis harness to tail door
harness

Male
BLACK

RH side of taildoor, behind
trim panel

P5817

C1104

C1103

Cav

Col

CCT

1

WB

ALL
