C0504

CONNECTOR

DEFENDER 1999 MY

ECU - ABS

Female
BLACK

Beneath RH seat

P5599

C0504

C0505

C0506

Cav

Col

CCT

1

NW

12

2

GO

12

5

K

12

8

NR

ALL

9

BW

12

10

SP

12

11

YK

12

12

B

12

17

YS

ALL

18

RS

ALL

CONNECTOR

C0505

DEFENDER 1999 MY

ECU - ABS

Female
BLACK

Beneath RH seat

P5599

C0504

C0505

C0506

Cav

Col

CCT

1

W

12

2

W

12

3

G

12

4

G

12

5

G

12

6

G

12

7

W

12

8

W

12

C0506

CONNECTOR

DEFENDER 1999 MY

ECU - ABS

Female
BLACK

Beneath RH seat

P5599

C0504

C0505

C0506

Cav

Col

CCT

1

SW

ALL

2

SR

ALL

3

B

ALL

4

SG

ALL

5

SU

ALL

6

RB

ALL

7

SY

ALL

8

SN

ALL

10

SP

ALL

11

SK

ALL

15

WO

12

CONNECTOR

C0507

DEFENDER 1999 MY

Pump - Return - ABS

Female
NATURAL

Adjacent pedal box

P5565

C0007

C0507

Cav

Col

CCT

1

NR

ALL

2

B

ALL
