C0184

CONNECTOR

DEFENDER 1999 MY

Sensor - Temperature - Fuel
rail - Td5

Female
BLACK

Top of engine - RH side

C184

P5388

Cav

Col

CCT

1

KB

ALL

2

YW

ALL

CONNECTOR

C0185

DEFENDER 1999 MY

Warning lamp - Ignition / no
charge - V8

Eyelet
BRASS

Front of engine - centre

Cav

Col

CCT

1

YN

ALL

C0187

CONNECTOR

DEFENDER 1999 MY

Switch - Oil pressure - Td5

Female
NATURAL

Lower rear of engine - RH
side

C187

P5411

Cav

Col

CCT

1

WN

ALL

2

B

ALL

CONNECTOR

C0187

DEFENDER 1999 MY

Switch - Oil pressure - V8

Female
NATURAL

RH side of engine

Cav

Col

CCT

1

WN

ALL
