Defender Electric Diagrams. Manual - part 49

   CONNECTOR DETAILS

DEFENDER 90 NAS

C287

C287
HEADER 3
20 Way
Female
GREY
Behind dash trim panel

Cav

Color Cct

Cav

Color Cct

1

WG

ALL

10

BY

ALL

2

WG

ALL

11

BY

ALL

3

WG

ALL

13

G

ALL

4

WG

ALL

14

G

ALL

5

WG

ALL

16

G

ALL

6

WG

ALL

17

G

ALL

7

WG

ALL

18

G

ALL

8

WG

ALL

19

G

ALL

9

BY

ALL

20

G

ALL

CONNECTOR DETAILS

DEFENDER 90 NAS

C288

C288
HEADER 4
20 Way
Female
ORANGE
Behind instrument pack

Cav

Color Cct

Cav

Color Cct

1

LGB

ALL

11

PU

ALL

2

LGB

ALL

12

PU

ALL

3

LGB

ALL

13

PU

ALL

5

RS

ALL

14

WN

ALL

6

RS

ALL

15

WN

ALL

7

RS

ALL

16

WN

ALL

8

BLG

ALL

17

YK

ALL

9

BLG

ALL

18

YK

ALL

10

BLG

ALL

20

YK

ALL

   CONNECTOR DETAILS

DEFENDER 90 NAS

C289

C289
HEADER 5
20 Way
Female
GREEN
Behind front of center
console

Cav

Color Cct

Cav

Color Cct

1

UW

ALL

11

P

ALL

2

UW

ALL

13

G

ALL

3

UW

ALL

14

G

ALL

4

UW

ALL

15

G

ALL

6

BR

ALL

16

G

ALL

7

BR

ALL

17

G

ALL

8

BR

ALL

18

G

ALL

9

P

ALL

19

G

ALL

10

P

ALL

20

G

ALL

CONNECTOR DETAILS

DEFENDER 90 NAS

C306

C306
DIFFERENTIAL LOCK
1 Way
Female
BLACK
Above gearbox

Cav

Color Cct

1

BU

ALL
