   CONNECTOR DETAILS

DEFENDER 90 NAS

C278

C278
WASHER/WIPER
SWITCH
6 Way
Female
NATURAL
Behind steering column
cowl - RH side

Cav

Color Cct

1

ULG

ALL

2

LGB

ALL

3

LGG

ALL

4

YLG

ALL

5

RLG

ALL

6

G

ALL

CONNECTOR DETAILS

DEFENDER 90 NAS

C282

C282
HEADLAMP RELAY
5 Way
Female
YELLOW
Behind front of center
console

t:\compuset\erl\faceview\YPP10009.tif

Cav

Color Cct

30

U

ALL

85

WG

ALL

86

B

ALL

87

UY

ALL

   CONNECTOR DETAILS

DEFENDER 90 NAS

C285

C285
HEADER 1
20 Way
Female
BLUE
Behind instrument pack

Cav

Color Cct

Cav

Color Cct

Cav

Color Cct

1

B

ALL

8

RB

ALL

15

RW

ALL

2

B

ALL

9

RB

ALL

16

RW

ALL

3

B

ALL

10

RB

ALL

17

RW

ALL

4

B

ALL

11

WY

ALL

18

RW

ALL

5

B

ALL

12

WY

ALL

19

RW

ALL

6

B

ALL

13

WY

ALL

20

RW

ALL

7

RB

ALL

14

WY

ALL

CONNECTOR DETAILS

DEFENDER 90 NAS

C286

C286
HEADER 2
20 Way
Female
BLUE
Behind dash trim panel

Cav

Color Cct

Cav

Color Cct

1

B

ALL

11

GW

ALL

2

B

ALL

12

GW

ALL

4

B

ALL

13

GW

ALL

5

B

ALL

14

GW

ALL

6

B

ALL

15

BY

ALL

7

GR

ALL

16

BY

ALL

8

GR

ALL

17

BY

ALL

9

GR

ALL

18

BY

ALL

10

GR

ALL
