Defender Electric Diagrams. Manual - part 34

   CONNECTOR DETAILS

DEFENDER 90 NAS

C83

C83
MAIN HARNESS TO
INSTRUMENT
HARNESS
10 Way
Female
LIGHT GREY
Behind instrument pack

Cav

Color Cct

Cav

Color Cct

1

WG

ALL

6

WS

ALL

2

B

ALL

7

GB

ALL

3

YK

ALL

8

GU

ALL

4

RW

ALL

9

WB

ALL

5

SR

ALL

10

BR

ALL

CONNECTOR DETAILS

DEFENDER 90 NAS

C86

C86
CIGAR LIGHTER
1 Way
Female
NATURAL
Behind dash trim panel

Cav

Color Cct

1

GO

ALL

   CONNECTOR DETAILS

DEFENDER 90 NAS

C89

C89
CIGAR LIGHTER
1 Way
Female
NATURAL
Behind dash trim panel

Cav

Color Cct

1

B

ALL

CONNECTOR DETAILS

DEFENDER 90 NAS

C90

C90
IGNITION SWITCH
1 Way
Female
NATURAL
Behind instrument pack

Cav

Color Cct

1

WR

ALL
