6. Install a suitable clamping device, designed for tow-

ing, to secure the front wheels in the straight
position.

CAUTION!

Towing with the rear wheels on the ground will cause
severe transmission damage. Damage from improper
towing is not covered under the New Vehicle Limited
Warranty.

RECREATIONAL TOWING —
QUADRA-TRAC I (SINGLE-SPEED
TRANSFER CASE) FOUR-WHEEL
DRIVE MODELS

Recreational towing is not allowed.

These models do

not have a N (Neutral) position in the transfer case.

NOTE:

This vehicle may be towed on a flatbed or vehicle trailer
provided all four wheels are

OFF

the ground.

CAUTION!

Towing this vehicle in violation of the previous
requirements can cause severe transmission and/or
transfer case damage. Damage from improper towing
is not covered under the New Vehicle Limited
Warranty.

RECREATIONAL TOWING —
QUADRA–TRAC II/QUADRA–DRIVE
II FOUR-WHEEL DRIVE MODELS

The transfer case must be shifted into N (Neutral) and
the transmission must be in PARK (P) for recreational
towing. The N (Neutral) selection button is located by
the selector switch.

CAUTION!

•

DO NOT dolly tow any four-wheel drive vehicle. Tow-
ing with only one set of wheels on the ground (front
or rear) will cause severe transmission and/or
transfer case damage. Tow with all four wheels
either ON the ground, or OFF the ground (using a
vehicle trailer).

•

Tow only in a forward direction. Towing this vehicle
backwards can cause severe damage to the trans-
fer case.

•

The transmission must be in PARK for recreational
towing.

•

Before recreational towing, perform the procedure
outlined under “Shifting into N (Neutral)” to be
certain that the transfer case is fully in N (Neutral).
Otherwise, internal damage will result.

•

Towing this vehicle in violation of the previous
requirements can cause severe transmission
and/or transfer case damage. Damage from
improper towing is not covered under the New
Vehicle Limited Warranty.

•

Do not use a bumper-mounted clamp-on tow bar
on your vehicle. The bumper face bar will be
damaged.

Shifting Into N (Neutral)

WARNING!

You or others could be injured or killed if you leave
the vehicle unattended with the transfer case in the N
(Neutral) position without first fully engaging the park-
ing brake. The transfer case N (Neutral) position dis-
engages both the front and rear driveshafts from the
powertrain and will allow the vehicle to roll, even if
the transmission is in PARK. The parking brake
should always be applied when the driver is not in the
vehicle.

CAUTION!

It is necessary to follow these steps to be certain that
the transfer case is fully in N (Neutral) before recre-
ational towing to prevent damage to internal parts.

Use the following procedure to prepare your vehicle for
recreational towing:

1. Bring the vehicle to a complete stop on level ground,

with the engine running.

2. Press and hold the brake pedal.

3. Shift the transmission into NEUTRAL.

4. If vehicle is equipped with Quadra-Lift air suspen-

sion, ensure the vehicle is set to Normal Ride
Height.

STARTING AND OPERATING

177

NOTE:

○

Steps 1 through 4 are requirements that must be
met before pushing the N (Neutral) button, and
must continue to be met until the shift has been
completed. If any of these requirements are not
met before pushing the N (Neutral) button or are
no longer met during the shift, then the N (Neu-
tral) indicator light will flash continuously until all
requirements are met or until the N (Neutral)
button is released.

○

The ignition must be in the ON/RUN position for
a shift to take place and for the position indicator
lights to be operable. If the ignition is not in the
ON/RUN position, the shift will not take place
and no position indicator lights will be on or
flashing.

○

A flashing N (Neutral) position indicator light indi-
cates that shift requirements have not been met.

○

If the vehicle is equipped with Quadra-Lift air
suspension, the engine should be started and
left running for a minimum of 60 seconds (with
all the doors closed) at least once every
24 hours. This process allows the air suspension
to adjust the vehicle’s ride height to compensate
for temperature effects.

○

Engaging/disengaging of the Electric Park Brake
requires the ignition to be in the ON/RUN
position.

5. Using a ballpoint pen or similar object, push and

hold the recessed transfer case N (Neutral) button
(located by the selector switch) for five seconds. The
light behind the N symbol will begin to blink red,
indicating shift in progress. The light will stop blink-
ing (stay on solid) when the shift to N (Neutral) is
complete. A “4WD Neutral Warning Vehicle May
Move Even in Park” message will appear in the
instrument cluster.

6. After the shift is completed and the N (Neutral) light

stays on, release the N (Neutral) button.

7. Shift the transmission into REVERSE or DRIVE.

8. Release the brake pedal for five seconds and

ensure that there is no vehicle movement.

9. Press and hold the brake pedal. Shift the transmis-

sion back into NEUTRAL.

10. Apply the Electric Park Brake.

11. With the transmission and transfer case in N (Neu-

tral), push and hold the ENGINE START/STOP but-
ton until the engine turns off. Ensure vehicle is in
RUN position with the engine off.

12. Place the transmission gear selector in PARK.

Release the brake pedal.

13. Attach the vehicle to the tow vehicle using a suit-

able tow bar.

14. Release the Electric Park Brake. Ensure vehicle is

in RUN position with the engine off.

15. Push the ENGINE START/STOP button twice (with-

out pressing the brake pedal), to turn the ignition
to the off position.

Shifting Out Of N (Neutral)

Use the following procedure to prepare your vehicle for
normal usage:

1. Bring the vehicle to a complete stop, leaving it con-

nected to the tow vehicle.

2. Apply the Electric Park Brake.

3. Start the engine.

NOTE:

○

Steps 1 through 5 are requirements that must be
met before pushing the N (Neutral) button, and
must continue to be met until the shift has been
completed. If any of these requirements are not
met before pushing the N (Neutral) button or are
no longer met during the shift, the N (Neutral)
indicator light will flash continuously until all
requirements are met or until the N (Neutral)
button is released.

○

A flashing N (Neutral) position indicator light indi-
cates that shift requirements have not been met.

4. Press and hold the brake pedal.

5. Shift the transmission into NEUTRAL.

N (Neutral) Button

178

STARTING AND OPERATING

6. Using a ballpoint pen or similar object, push and

hold the recessed transfer case N (Neutral) button
(located by the selector switch) for two seconds.

7. When the N (Neutral) indicator light turns off,

release the N (Neutral) button. After the N (Neutral)
button has been released, the transfer case will
shift to the position indicated by the selector switch.

8. Shift the transmission into PARK. Turn the engine

off.

9. Release the brake pedal.

10. Disconnect vehicle from the tow vehicle.

11. Start the engine.

12. Press and hold the brake pedal.

13. Release the Electric Park Brake.

14. Shift the transmission into REVERSE or DRIVE,

release the brake pedal, and check that the
vehicle operates normally.

DRIVING TIPS

ON-ROAD DRIVING TIPS

Utility vehicles have higher ground clearance and a nar-
rower track to make them capable of performing in a
wide variety of off-road applications. Specific design
characteristics give them a higher center of gravity than
conventional passenger cars.

An advantage of the higher ground clearance is a better
view of the road, allowing you to anticipate problems.
They are not designed for cornering at the same speeds
as conventional passenger cars any more than low-
slung sports cars are designed to perform satisfactorily
in off-road conditions. Avoid sharp turns or abrupt
maneuvers. As with other vehicles of this type, failure to
operate this vehicle correctly may result in loss of con-
trol or vehicle rollover.

OFF-ROAD DRIVING TIPS

Quadra-Lift — If Equipped

When off-roading, it is recommended that the lowest
useable vehicle height that will clear the current
obstacle or terrain be selected. The vehicle height
should then be raised as required by the changes in
terrain.

The Selec-Terrain switch will automatically change the
vehicle to the optimized height based on the Selec-
Terrain switch position. The vehicle height can be
changed from the default height for each Selec-Terrain
mode by normal use of the air suspension switches

page 122.

When To Use 4WD LOW — If Equipped

When off-road driving, shift to 4WD LOW for additional
traction. This range should be limited to extreme situa-
tions such as deep snow, mud, or sand where addi-
tional low speed pulling power is needed. Vehicle
speeds in excess of 25 mph (40 km/h) should be
avoided when in 4WD LOW.

WARNING!

Do not drive in 4WD LOW on dry pavement; driveline
damage may result. 4WD LOW locks front and rear
drivelines together and does not allow for differential
action between the front to rear driveshafts. Driving
in 4WD LOW on pavement will cause driveline bind-
ing; use only on wet or slippery surfaces.

Driving Through Water

Although your vehicle is capable of driving through
water, there are a number of precautions that must be
considered before entering the water.

NOTE:

Your vehicle is capable of water fording in up to
20 inches (51 cm) of water, while crossing small rivers
or streams. To maintain optimal performance of your
vehicle's heating and ventilation system it is recom-
mended to switch the system into recirculation mode
during water fording.

N (Neutral) Button

STARTING AND OPERATING

179

CAUTION!

When driving through water, do not exceed 5 mph
(8 km/h). Always check water depth before entering
as a precaution, and check all fluids afterward. Driv-
ing through water may cause damage that may not be
covered by the New Vehicle Limited Warranty.

Driving through water more than a few inches/
centimeters deep will require extra caution to ensure
safety and prevent damage to your vehicle. If you must
drive through water, try to determine the depth and the
bottom condition (and location of any obstacles) prior to
entering. Proceed with caution and maintain a steady
controlled speed less than 5 mph (8 km/h) in deep
water to minimize wave effects.

Flowing Water

If the water is swift flowing and rising (as in storm run-
off), avoid crossing until the water level recedes and/or
the flow rate is reduced. If you must cross flowing water
avoid depths in excess of 9 inches (23 cm). The flowing
water can erode the streambed, causing your vehicle to
sink into deeper water. Determine exit point(s) that are
downstream of your entry point to allow for drifting.

Standing Water

Avoid driving in standing water deeper than 24 inches
(60 cm), and reduce speed appropriately to minimize
wave effects. Maximum speed is 5 mph (8 km/h).

Maintenance

After driving through deep water, inspect your vehicle
fluids and lubricants (engine oil, transmission oil, axle,
transfer case) to ensure the fluids have not been con-
taminated. Contaminated fluid (milky, foamy in appear-
ance) should be flushed/changed as soon as possible
to prevent component damage.

Driving In Snow, Mud And Sand

In heavy snow, when pulling a load, or for additional
control at slower speeds, shift the transmission to a low
gear and shift the transfer case to 4WD LOW if neces-
sary

page 122. Only shift into a lower gear to main-

tain forward motion. Over-revving the engine can spin
the wheels and traction will be lost.

Avoid abrupt downshifts on icy or slippery roads, because
engine braking may cause skidding and loss of control.

Hill Climbing

NOTE:

Before attempting to climb a hill, determine the condi-
tions at the crest and/or on the other side.

Before climbing a steep hill, shift the transmission to a
lower gear and shift the transfer case to 4WD LOW. Use
FIRST gear and 4WD LOW for very steep hills.

If you stall or begin to lose forward motion while climb-
ing a steep hill, allow your vehicle to come to a stop and
immediately apply the brakes. Restart the engine, and
shift into REVERSE (R). Back slowly down the hill, allow-
ing the compression braking of the engine to help regu-
late your speed. If the brakes are required to control
vehicle speed, apply them lightly and avoid locking or
skidding the tires.

WARNING!

If the engine stalls, you lose forward motion, or can-
not make it to the top of a steep hill or grade, never
attempt to turn around. To do so may result in tipping
and rolling the vehicle. Always back carefully straight
down a hill in REVERSE gear. Never back down a hill
in NEUTRAL using only the brake.

Remember, never drive diagonally across a hill. Always
drive straight up or down.

If the wheels start to slip as you approach the crest of a
hill, ease off the accelerator and maintain forward
motion by turning the front wheels slowly. This may pro-
vide a fresh “bite” into the surface and will usually pro-
vide traction to complete the climb.

Traction Downhill

When descending mountains or hills, use Hill Descent
Control or Selec-Speed Control to avoid repeated heavy
braking.

If not equipped with Hill Descent Control or Selec-Speed
Control use the following procedure:

Shift the transmission into a low gear, and the transfer
case into 4WD LOW range. Let the vehicle go slowly
down the hill with all four wheels turning against engine
compression drag. This will permit you to control the
vehicle speed and direction.

When descending mountains or hills, repeated braking
can cause brake fade with loss of braking control. Avoid
repeated heavy braking by downshifting the transmis-
sion whenever possible.

After Driving Off-Road

Off-road operation puts more stress on your vehicle
than does most on-road driving. After going off-road, it
is always a good idea to check for damage. That way
you can get any problems taken care of right away and
have your vehicle ready when you need it.

•

Completely inspect the underbody of your vehicle.
Check tires, body structure, steering, suspension,
and exhaust system for damage.

•

Inspect the radiator for mud and debris and clean
as required.

180

STARTING AND OPERATING

•

Check threaded fasteners for looseness, particularly
on the chassis, drivetrain components, steering, and
suspension. Retighten them, if required, and torque
to the values specified in the Service Manual.

•

Check for accumulations of plants or brush. These
things could be a fire hazard. They might hide dam-
age to fuel lines, brake hoses, axle pinion seals, and
propeller shafts.

•

After extended operation in mud, sand, water, or
similar dirty conditions, have the radiator, fan, brake
rotors, wheels, brake linings, and axle yokes
inspected and cleaned as soon as possible.

WARNING!

Abrasive material in any part of the brakes may cause
excessive wear or unpredictable braking. You might not
have full braking power when you need it to prevent a
collision. If you have been operating your vehicle in dirty
conditions, get your brakes checked and cleaned as
necessary.

•

If you experience unusual vibration after driving in
mud, slush or similar conditions, check the wheels
for impacted material. Impacted material can cause
a wheel imbalance and freeing the wheels of it will
correct the situation.

STARTING AND OPERATING

181

MULTIMEDIA

UCONNECT SYSTEMS

For detailed information about your Uconnect 5/5 NAV
With 10.1-inch Display or Uconnect 5 NAV With 12-inch
Display system, refer to your Uconnect Radio Instruction
Manual.

NOTE:

Uconnect screen images are for illustration purposes
only and may not reflect exact software for your vehicle.

CYBERSECURITY

Depending on applicability, your vehicle may be able to
send or receive information from a wired or wireless
network. This information allows systems and features
in your vehicle to function properly.

Your vehicle may be equipped with certain security fea-
tures to reduce the risk of unauthorized and unlawful
access to vehicle systems and wireless communica-
tions. Vehicle software technology continues to evolve
over time and FCA US LLC, working with its suppliers,
evaluates and takes appropriate steps as needed. As
always, if you experience unusual behavior, contact an
authorized dealer immediately,

page 348, or refer

to your Uconnect Radio Instruction Manual for addi-
tional contact information.

The risk of unauthorized and unlawful access to your
vehicle systems may still exist, even if the most recent
version of vehicle software (such as Uconnect software)
is installed.

WARNING!

•

ONLY insert trusted media devices/components
into your vehicle. Media of unknown origin could
possibly contain malicious software, and if
installed in your vehicle, it may increase the possi-
bility for vehicle systems to be breached.

•

As always, if you experience unusual vehicle behav-
ior, contact an authorized dealer immediately.

NOTE:

To help further improve user experience, features, sta-
bility, etc., and minimize the potential risk of a security
breach, vehicle owners should routinely check
www.driveuconnect.com (US Residents) or
www.driveuconnect.ca (Canadian Residents) to learn
about available Uconnect software updates.

UCONNECT SETTINGS

The Uconnect system uses a combination of buttons on
the touchscreen and buttons on the faceplate located
on the center of the instrument panel. These buttons
allow you to access and change the customer program-
mable features. Many features can vary by vehicle.

Buttons on the faceplate are located below and/or
beside the Uconnect system in the center of the instru-
ment panel. In addition, there is a SCROLL/ENTER con-
trol knob located on the right side. Turn the control
knob to scroll through menus and change settings.
Push the center of the control knob one or more times
to select or change a setting.

Your Uconnect system may also have SCREEN OFF and
MUTE buttons on the faceplate.

Push the SCREEN OFF button on the faceplate to turn
off the Uconnect screen. Push the button again or tap
the screen to turn the screen on.

Press the Back Arrow button to exit out of a Menu or
certain option on the Uconnect system.

Push and hold the Power button on the radio’s face-
plate for a minimum of 15 seconds to reset the radio.

CUSTOMER PROGRAMMABLE
FEATURES

Uconnect 5 NAV With 12-inch Display

1 — Uconnect Buttons On The Touchscreen
2 — Uconnect Buttons On The Faceplate

182

Press the Vehicle button, then press the Settings tab at
the top of the touchscreen. In this menu, the Uconnect
system allows you to access all of the available pro-
grammable features.

NOTE:

•

Only one touchscreen area may be selected at a
time.

•

Depending on the vehicle’s options, feature settings
may vary.

•

Push the Open/Close button on the Front Comfort
And Convenience Display to access the fold-out
screen.

When making a selection, press the button on the
touchscreen to enter the desired menu. Once in the
desired menu, press and release the preferred setting

option until a check mark appears next to the setting,
showing that setting has been selected. Once the set-
ting is complete, press the Vehicle button to exit to the
screen. Pressing the Up or Down Arrow button on the
right side of the screen will allow you to toggle up or
down through the available settings.

Display

When the Display button is pressed on the touchscreen, the system will display the options related to the theme (if equipped), brightness, and color of the touchscreen. The
available settings are:

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Language

This setting will change the language of the Uconnect system and Instrument Cluster
Display. The available languages are English, Italiano, Français, and Español.

Display Mode

This setting will allow you to set the brightness manually or have the system set it auto-
matically. The “Auto” setting has the system automatically adjust the display bright-
ness. The “Manual” setting will allow the user to adjust the brightness of the display.

Display Brightness With Headlights ON

This setting will allow you to set the brightness when the headlights are on. To access
this setting, Display Mode must be set to “Manual”. The “+” setting will increase the
brightness; the “-” will decrease the brightness.

Display Brightness With Headlights OFF

This setting will allow you to set the brightness when the headlights are off. To access
this setting, Display Mode must be set to “Manual”. The “+” setting will increase the
brightness; the “-” will decrease the brightness.

Set Theme

This setting will allow you to change the display theme.

Theme Mode

This setting will allow you to adjust the brightness of your theme. Setting options are
“Light”, “Dark” and “Auto”. Select to show themes in Light or Dark mode. “Auto”
changes the theme with the headlights.

MULTIMEDIA

183

Setting Name

Description

Units

This setting will allow you to change the units. The available options are “Speed” (mph
or km/h), “Distance” (mi or km), “Current Consumption” (mpg [US], mpg [UK],
L/100 km, or km/L), “Pressure” (psi, kPa, or bar), and “Temperature” (°C or °F) units
of measurement independently.

Touchscreen Beep

This setting will allow you to turn the touchscreen beep on or off.

Show Main Category Bar Labels

This setting will allow you to turn the bottom main category bar labels on or off.

Control Screen Timeout

This setting allows you to set the Control Screen to turn off automatically after five sec-
onds or stay open until manually closed.

Navigation Next Turn Pop-ups Displayed In Cluster

This setting will display Navigation prompts in the Instrument Cluster Display.

Phone Pop-ups Displayed In Cluster

This setting will display smartphone notifications and messages in the Instrument
Cluster Display.

Message Pop-Ups Displayed with Button Press

This setting will turn message notifications on or off.

Ready To Drive Pop-ups

This setting will enable the Ready To Drive pop-ups in the Instrument Cluster Display.

Entertainment Screens

When the Entertainment Screens button is pressed on the touchscreen, the system displays the different options related to the vehicle’s Entertainment system.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Passenger Screen Permissions

This setting will enable or disable Passenger Screen Permissions. The options within
this setting are “Navigation”, “Device Manager”, and “Uconnect Theater” all with “On”
and “Off” options.

Rear Seat Screen Permissions

This setting will enable or disable your Rear Seat Screen Permissions. “On” and “Off”
options are found within “Navigation”.

184

MULTIMEDIA

My Profile

When the My Profile button is pressed on the touchscreen, the system displays options related to the vehicle’s profiles.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Language

This setting will change the language of the Uconnect system and Instrument Cluster
Display. The available languages are English, Italiano, Français, and Español.

Display Mode

This setting will adjust the display for the radio to “Auto” or “Manual”. “Manual” allows
for more customization with the radio display.

Display Brightness Headlights On

Display Brightness Headlights Off

Set Theme

This setting will allow you to change the display theme.

Theme Mode

Units

Touchscreen Beep

This setting will allow you to turn the touchscreen beep on or off.

Show Main Category Bar Labels

This setting will allow the main category bar labels to be shown on or off.

Navigation Next Turn Pop-ups Displayed In Cluster

This setting will display Navigation prompts in the Instrument Cluster Display.

Phone Pop-ups Displayed In Cluster

This setting will display smartphone notifications and messages in the Instrument
Cluster Display.

Message Pop-ups Displayed with Button Press

This setting will turn message notifications on or off.

MULTIMEDIA

185

Setting Name

Description

System Text Size

This setting will allow you to change the text on the radio to “Standard”, “Large”, or
“Taller”.

Time Format

This setting will allow you to set the time format (AM/PM). Sync Time With GPS must
be Off for this setting to be available. The “12 hrs” setting will set the time to a
12-hour format. The “24 hrs” setting will set the time to a 24-hour format.

Voice Options

This setting will allow you to change the voice options for the radio to “Male” or
“Female”.

Wake Up Word

This setting will allow you to set the system’s “Wake Up” word. An available option is
“Hey Uconnect”.

Voice Barge-in

This setting will allow Voice Barge-in to be turned on or off. For more information about
Voice Barge-in, refer to your Uconnect Radio Instruction Manual.

Show Command List

This setting will allow the Command List to be shown on or off.

Ambient Color Personalization

This setting will redirect to a new menu that will allow you to change the ambient light-
ing color in the cabin.

Radio Off Delay

This setting will keep the radio on for the selected amount of time after vehicle shut
off. The available options are “0 sec”, “45 sec”, “5 min”, and “10 min”.

Radio Off with Door

This setting will keep the radio on when a door is opened or until the Radio Off Delay
time is reached. The available settings are “On” and “Off”.

Key Off Power Delay

This setting will keep certain electrical features running after the engine is turned off.
When any door is opened, the electronics will deactivate. The available settings are
“0 sec”, “45 sec”, “5 min”, and “10 min”.

App Drawer Favoriting Pop-ups

This setting will allow you to favorite app drawer pop-ups with “On” and “Off” options.

App Drawer Unfavoritings Pop-ups

This setting will allow you to unfavorite app drawer pop-ups with “On” and Off” options.

New Text Message Pop-ups

This setting will allow you to have pop-up notifications for new text messages. Setting
options are “On” and “Off”.

Missed Calls Message

This setting will allow you to have pop-up notifications for missed calls. Setting options
are “On” and “Off”.

Navigation Pop-ups

This setting will allow you to have pop-up notifications for Navigation. Setting options
are “On” and “Off”.

186

MULTIMEDIA

Setting Name

Description

Navigation Settings

This setting will redirect to the list of Navigation settings. Refer to your Uconnect Radio
Instruction Manual for further information.

Auto-On Driver Heated/Ventilated Seat & Heated Steering Wheel With Vehicle Start

This setting will activate the vehicle’s comfort system and heated seats or heated
steering wheel when the vehicle is remote started or ignition is started. The “Off” set-
ting will not activate the comfort systems. The “Remote Start” setting will only activate
the comfort systems when using Remote Start. The “All Start” setting will activate the
comfort systems whenever the vehicle is started.

Audio Settings

This setting will open the submenu containing the audio settings

page 201.

TomTom Traffic And Travel Services

This setting will turn TomTom Traffic And Travel Services (if equipped) on or off. An
active subscription is required for this feature to work.

Reset App Drawer to Default Order

This setting will reset the app drawer to its factory default layout.

Restore Settings to Default

This setting will return all the previously changed settings to their factory defaults.

More Profile Options

This setting will give access to more profile options.

Safety & Driving Assistance

When the Safety & Driving Assistance button is pressed on the touchscreen, the system displays the options related to the vehicle’s safety settings. These options will differ
depending on the features equipped on the vehicle. The settings may display in list form or within subfolders on the screen. To access a subfolder, select the desired folder; the
available options related to that feature will then display on the screen.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Forward Collision Warning — Located In Automatic Emergency Braking Submenu

This setting will turn the Forward Collision Warning (FCW) system on or off. The “Off”
setting will deactivate the FCW system. The “Warning Only” setting will provide only an
audible chime when a collision is detected. The “Warning + Active Braking” setting will
provide an audible chime and apply some brake pressure when a collision is detected.

MULTIMEDIA

187

Setting Name

Description

Forward Collision Warning Sensitivity — Located In Automatic Emergency Braking
Submenu

This setting will change the distance at which the Forward Collision Warning alert
sounds. The “Medium” setting will have the FCW system signal when an object is in
view, and the possibility of a collision is detected. The “Near” setting will have the FCW
system signal when the object is closer to the vehicle. The “Far” setting will have the
FCW system signal when an object is at a far distance from the vehicle.

Pedestrian Emergency Braking — Located In Automatic Emergency Braking Submenu

This setting will turn the Pedestrian Emergency Braking system on or off. This setting is
located in “Automatic Emergency Braking”.

Active Driving Assist Steering Wheel Vibration

This setting will turn the Active Driving Assist Steering Wheel Vibration on or off.

Active Lane Management

This setting will alert the driver by vibrating the steering wheel and/or moving the
steering wheel, when a lane departure is detected. The available options within Active
Lane Management are Lane Management “Vibration Only”, “Steering Assist Only”, and
“Vibration + Steering Assist”; Lane Warning “Early”, “Medium”, and “Late”; Vibration
Strength “Low”, “Medium” and “High”; and Steering Assist Strength “Low”, “Medium”
and “High”.

Traffic Sign Assist

This setting will turn Traffic Sign Assist on or off.

Traffic Sign Assist Warning

This setting will allow you to set the warning type related to the traffic sign. The avail-
able options are “Off”, “Visual”, and “Visual + Chime”.

Night Vision Video Warning

This setting will turn the Night Vision Video Warning and green/gray cluster indicator
light on or off.

ParkSense

This setting will change the type of ParkSense alert when a close object is detected
and can provide both an audible chime and a visual display.

Front ParkSense Volume

This setting adjusts the volume of the Front ParkSense system. The available settings
are “Low”, “Medium”, and “High”.

Rear ParkSense Volume

This setting adjusts the volume of the Rear ParkSense system. The available settings
are “Low”, “Medium”, and “High”.

Active ParkSense Mode

This setting will adjust the level of vehicle control when the Active ParkSense Mode is
active. The available settings are “Full Auto” and “Steering Only”

Active ParkSense Proximity Chime

This setting will turn the Active ParkSense Proximity Chime on or off.

Side Distance Warning

This setting will adjust the warning for side distance. The available options are “Off”,
“Sound Only”, and “Sound & Display”.

188

MULTIMEDIA

Setting Name

Description

Drowsy Driver Alert

This setting will monitor the driver’s driving habits and warn you of any changes, indi-
cating that the driver may be drowsy. The available options are “On” and “Off”.

Blind Spot Alert

This setting will change the type of alert provided when an object is detected in the
vehicle’s blind spot. The “Off” setting will turn off Blind Spot Alert. The “Lights” setting
will activate the Blind Spot Alert lights on the outside mirrors. The “Lights & Chime”
setting will activate the lights on the outside mirrors and an audible chime.

Electric Power Steering Default

This setting will change the Electric Power Steering mode. The available options are
“Comfort” for a lower effort steering experience, “Normal” for the standard effort steer-
ing experience, and “Sport” for a higher effort steering experience.

Power Side Step

This setting will activate the Power Side Step. The “Auto” setting will lower the step
when the door is opened and retract it once the door is closed. The “Off” setting will
deactivate the feature.

Hill Start Assist

This setting will turn the Hill Start Assist system on or off.

Tire Fill Assist

This setting will turn Tire Fill Assist on or off.

New Speed Zone Indication

This setting will allow you to set if the system will warn you that the speed limit has
changed in an area. The available options are “Off”, “Visual”, and “Visual + Chime”.

Rear ParkSense Braking Assist

This setting will turn the Rear ParkSense Braking Assist on or off.

Rear Seat Alert

When this setting is turned on and the rear doors are opened while the engine is run-
ning, or if the engine is turned on within 10 minutes of the door opening, a message
will appear to check the rear seat when the vehicle is powered OFF.

MULTIMEDIA

189

Clock

When the Clock button is pressed on the touchscreen, the system displays the different options related to the vehicle’s internal clock.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Sync Time With GPS

This setting will sync the time to the GPS receiver in the system. The system will con-
trol the time via the GPS location.

Set Time

This setting will allow you to set the hours and minutes. Sync Time With GPS must be
off for this setting to be available. The “+” setting will increase the hours or minutes.
The “-” setting will decrease the hours or minutes.

Time Format

This setting will allow you to set the time format (AM/PM). Sync Time With GPS must
be off for this setting to be available. The “12 hrs” setting will set the time to a 12-hour
format. The “24 hrs” setting will set the time to a 24-hour format.

Set Date

This setting will allow you to set the day, month and year. Using “+” or “-”, you can
scroll through the available days, months, and years.

Show Time and Date During Screen Off

This setting will allow you to show the time and date while the screen is off. Available
options are “On” and “Off”.

Set Time Hours

This setting will allow you to set the hours. Sync Time With GPS must be off for this
setting to be available. The “+” setting will increase the hours. The “-” setting will
decrease the hours.

Set Time Minutes

This setting will allow you to set the minutes. Sync Time With GPS must be off for this
setting to be available. The “+” setting will increase the minutes. The “-” setting will
decrease the minutes.

Show Time in Status Bar

This setting will place the time in the radio’s status bar.

190

MULTIMEDIA

Phone/Bluetooth®

When the Phone/Bluetooth® button is pressed on the touchscreen, the system displays the options related to Bluetooth® connectivity from an external audio device or smart-
phone. The list of paired audio devices or smartphones can be accessed from this menu.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Device Manager

This setting will open the Device Manager main screen.

Do Not Disturb All

This setting will open the Do Not Disturb All Settings menu. The available options are
“On” and “Off”.

Enable Two Active Phones

This setting will enable or disable two active phones within the vehicle. The setting
options are “On” and “Off”.

Phone Pop-Ups Displayed In Cluster

This setting will activate phone message pop-ups in the Instrument Cluster Display.

Do Not Disturb

This setting will open the Do Not Disturb settings menu. The settings are “Auto Reply”
(both, text, call), “Auto Reply Message” (custom, default), and “Custom Auto Reply
Message” (create message).

Phone Repetition

This setting will turn the Phone Repetition function on or off.

Voice

When the Voice button is pressed on the touchscreen, the system displays the options related to the vehicle’s Voice Recognition feature.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Primary Voice Assistant

This setting allows you to choose your voice assistant between “Alexa” and
“Uconnect”.

Voice Options

This setting will allow you to change the system’s voice to either “Male” or “Female”.

MULTIMEDIA

191

Setting Name

Description

Wake Up Word

This setting will allow you to set the system’s “Wake Up” word. An available option is
“Hey Uconnect”.

Voice Barge-In

This setting allows you to respond to a Voice Response before the statement is com-
pleted by the system. The available options are “On” and “Off”.

Show Command List

This setting will allow you to turn the Command List on or off. The “Always” setting will
always show the Command List. The “With Help” setting will show the Command List
and provide a brief description of what the command does. The “Never” setting will
turn the Command List off.

Navigation

When the Navigation button is pressed on the touchscreen, the system displays options related to the vehicle’s built-in Navigation system. These settings can change which
icons display on the map, how “time to arrival is calculated”, and route types.
For more information on Navigation and settings, refer to your Uconnect Radio Instruction Manual.

Trailer

When the Trailer button is pressed on the touchscreen, the system will display settings related to trailer towing.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Current Trailer

Select from “Trailer 1”, “Trailer 2”, “Trailer 3”, and “Trailer 4”. These trailer designa-
tions can be used to save different trailer settings.

Trailer Name

This setting will personalize the trailer name depending on the type of trailer you are
hauling. Select the trailer name from the following list: trailer, boat, car, cargo, dump,
equipment, flatbed, horse, gooseneck, livestock, motorcycle, snowmobile, travel, utility,
and 5th wheel.

192

MULTIMEDIA

Setting Name

Description

Braking

This setting will set the system to a specific trailer type. The available options are
“Light Electric”, “Heavy Electric”, “Light Electric Over Hydraulic”, and “Heavy Electric
Over Hydraulic”.

Camera

When the Camera button is pressed on the touchscreen, the system displays the options related to the vehicle’s camera features.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Surround View Camera Delay

This setting will add a timed delay to the Surround View Camera when shifting out of
REVERSE.

Surround View Camera Guidelines

This setting will turn the Surround View Camera Guidelines on or off.

ParkView Backup Camera Delay

This setting will add a timed delay to the ParkView Backup Camera when shifting out
of REVERSE.

ParkView Backup Camera Active Guidelines

This setting will turn the ParkView Backup Camera Active Guidelines on or off.

Forward Facing Camera Guidelines

This setting will turn the Forward Facing Camera Guidelines on or off.

MULTIMEDIA

193

Mirrors & Wipers

When the Mirrors & Wipers button is pressed on the touchscreen, the system displays the options related to the vehicle’s mirrors and wipers.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Tilt Side Mirrors In Reverse

This setting will tilt the outside side-view mirrors when the ignition is in the ON/RUN
position and the transmission gear selector is in the REVERSE position. The mirrors
will move back to their previous position when the transmission is shifted out of
REVERSE. The available settings are “On” and “Off”.

Rain Sensing Auto Wipers

This setting will turn the Rain Sensing Auto Wipers on or off.

Headlights With Wipers

This setting will turn the headlights on when the wipers are activated. Setting options
are “On” and “Off”.

Setting Name

Description

Auto Folding Side Mirrors

This setting will automatically fold and unfold the side-view mirrors when the vehicle is
turned off, the doors are locked, or the key fob button is pushed. The available options
are “On” and “Off”.

194

MULTIMEDIA

Lights

When the Lights button is pressed on the touchscreen, the system displays the options related to the vehicle’s exterior and interior lights.

NOTE:

•

When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned on or off. This feature is only allowed by law in the country of the vehicle
purchase.

•

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Ambient Color Personalization

This setting will redirect to a new menu that will allow you to change the ambient light-
ing color in the cabin.

Interior Ambient Lighting

This setting will allow you to adjust the brightness of the interior ambient lights. The
available options are “Level 1” through “Level 6”.

Headlight Off Delay

This setting will allow you to set the amount of time it takes for the headlights to shut
off after the vehicle is turned off. The available settings are “0 sec”, “30 sec”,
“60 sec”, and “90 sec”.

Headlight Illumination On Approach

This setting will allow you to set the amount of time it takes for the headlights to shut
off after the vehicle is unlocked. “Greeting Lights” must be selected and “Headlight
Illumination On Approach” must be selected above 0 seconds for the feature to be
enabled. The available settings are “0 sec”, “30 sec”, “60 sec”, and “90 sec”.

Headlights with Wipers

This setting will turn the headlights on when the wipers are activated.

Proximity Wake-Up

Proximity detection is a system which activates specific interior and exterior lights as
the vehicle is approached with a valid key fob. This feature provides an increased
sense of welcome and security as the user enters the vehicle in the dark. This setting
will turn the Proximity Wake-Up on or off.

NOTE:

For the exterior lighting to be activated, “Headlight Illumination On Approach” must be
set to a value other than zero.

MULTIMEDIA

195

Setting Name

Description

Greeting Lights

When the “Greeting Lights” feature is selected, it enables “Headlight Illumination On
Approach”. When “Headlight Illumination On Approach” is selected, it allows the
adjustment of the amount of time the headlights remain on after the doors are
unlocked with the key fob. “Greeting Lights” must be selected and “Headlight Illumina-
tion On Approach” must be selected above zero seconds for the feature to be enabled.
The available settings are “On” and “Off”.

Auto Dim High Beams

This setting will allow you to turn the Auto Dim High Beams on or off.

Daytime Running Lights

This setting will allow you to turn the Daytime Running Lights on or off.

Cornering Lights

When this setting is selected, if the steering wheel rotation angle is large or the turn
signal indicators are on, a light (incorporated in the fog light) will turn on, on the rel-
evant side to improve visibility at night.

Flash Lights With Lock

This setting will allow you to turn the flashing of the lights when the Lock button is
pushed on the key fob on or off. Available settings are “On” and “Off”.

Flash Lights With Suspension Lower

This setting will allow you to turn the flashing of the lights when the Suspension Lower-
ing button is pushed on the key fob on or off.

Brakes

When the Brakes button is pressed on the touchscreen, the system will display the settings related to the vehicle’s Brake system.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Auto Park Brake

This setting will turn the Auto Park Brake on or off.

Brake Service

This setting will allow you to set the brakes for service. When the setting is selected, a
pop-up will display “Yes” and “No” options.

196

MULTIMEDIA

Doors & Locks

When the Doors & Locks button is pressed on the touchscreen, the system displays the options related to locking and unlocking the vehicle’s doors.

NOTE:

•

The Auto Door Locks feature default condition is enabled. When enabled, the door locks will lock automatically when the vehicle’s speed exceeds 15 mph (24 km/h). The
Auto Door Locks feature can be enabled or disabled by an authorized dealer per written request of the customer. Please see an authorized dealer for service.

•

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Auto Door Locks

This setting will allow you to change if the doors lock automatically when the vehicle
reaches 15 mph (24 km/h).

Auto Unlock On Exit

This setting will unlock the doors when any of the doors are opened from the inside.

Flash Lights With Lock

This setting will allow you to turn the flashing of the lights when the Lock button is
pushed on the key fob on or off. Available settings are “On” and “Off”.

Sound Horn With Lock

This setting will sound the horn when the Lock button is pushed on the key fob. The
“Off” setting will not sound the horn when the Lock button is pushed. The “1st Press”
setting will sound the horn when the Lock button is pushed once. The “2nd Press” set-
ting will sound the horn when the Lock button is pushed twice.

Sound Horn With Remote Start

This setting will sound the horn when the remote start is activated from the key fob.

Remote Door Unlock, Door Lock/1st Press Of Key Fob Unlocks

This setting will change how many pushes of the Unlock button on the key fob are
needed to unlock all the doors. The “Driver Door” setting will only unlock the driver
door on the first push on the Unlock button. The “All Doors” setting will unlock all
doors with only one push of the Unlock button.

Passive Entry

This setting will allow you to turn the Passive Entry feature (Keyless Enter ‘n Go™) on
or off.

Personal Settings Linked To Key Fob

This setting will recall preset radio stations and driver seat position that have been
linked to the key fob.

Power Liftgate Alert

This setting will chime an audible alert when the power liftgate is raising or lowering.
Selectable options are “On” and “Off”.

Hands-Free Power Liftgate

This setting will use hands-free technology to automatically open or close the power
liftgate. Selectable options are “On” and “Off”.

MULTIMEDIA

197

Setting Name

Description

Auto Relock

This setting will lock the doors after 30 seconds of the doors remaining unlocked. The
available options are “On” and “Off”.

Seats & Comfort

When Seats & Comfort button is pressed on the touchscreen, the system displays the options related to the vehicle’s comfort systems when remote start has been activated or
the vehicle has been started.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Easy Exit Seats

This setting will automatically move the driver seat rearward when the engine is shut
off. The available settings are “On” and “Off”.

Auto-On Driver Heated/Ventilated Seat & Heated Steering Wheel With Vehicle Start

This setting will activate the vehicle’s comfort systems and heated seats or heated
steering wheel when the vehicle is remote started or ignition is started. The “Off” set-
ting will not activate the comfort systems. The “Remote Start” setting will only activate
the comfort systems when using Remote Start. The “All Start” setting will activate the
comfort systems whenever the vehicle is started.

3rd Row Seat Recline Lockout

This setting will activate the 3rd Row Seat Recline Lockout. Selectable options are
“Off”, “Lock On Ignition” and “Always Locked”.

198

MULTIMEDIA

Key Off Options

When the Key Off Options button is pressed on the touchscreen, the system displays the options related to vehicle shutoff. These settings will only activate when the ignition is
set to OFF.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Easy Exit Seat

This setting adjusts the seats to make exiting the vehicle easier.

Key Off Power Delay

Headlight Off Delay

This setting will allow you to set the amount of time the headlights remain on after the
vehicle has been turned off. The available settings are “0 sec”, “30 sec”, “60 sec”,
and “90 sec”.

Auto Entry/Exit Suspension

This setting will turn the Auto Entry/Exit Suspension system on or off.

Radio Off Delay

This setting will keep the radio on for the selected amount of time after vehicle shut
off. The available options are “0 sec”, “45 sec”, “5 min”, and “10 min”.

Radio Off With Door

This setting will keep the radio on when a door is opened or until the Radio Off Delay
time is reached. The available settings are “On” and “Off”.

Windows With Key Fob

This setting will allow you to control window function while the vehicle is off. The avail-
able options are “On” and “Off”.

MULTIMEDIA

199

Suspension

When the Suspension button is pressed on the touchscreen, the system will display settings related to the vehicle’s air suspension.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Sound Horn With Lower

This setting will allow you to sound the horn when the Suspension Lowering button is
pushed on the key fob.

Flash Lights With Lower

This setting will allow you to turn the flashing of the lights when the Suspension Lower-
ing button is pushed on the key fob on or off.

Auto Entry/Exit Suspension

This setting will turn the Auto Entry/Exit Suspension system on or off.

Display Suspension Messages

This setting will display suspension messages in the Instrument Cluster Display. The
“All” setting will display all available messages. The “Warnings Only” setting will only
display warning messages.

Tire Jack Mode

This setting will disable the Air Suspension system to assist in changing a spare tire.

Auxiliary Modes

This setting will allow you to set the Auxiliary Suspension Mode. The available options
are “Off”, “Transport Mode”, and “Wheel Alignment Mode”. In Transport Mode, the
vehicle will not auto level when being transported by another vehicle. In Wheel Align-
ment Mode, the vehicle will not auto level when a wheel alignment is being performed.

200

MULTIMEDIA

Audio

When the Audio button is pressed on the touchscreen, the system displays options related to the vehicle’s sound system. These settings can change the audio location within
the vehicle, adjust the bass or treble levels, and auto-play settings from an audio device or smartphone.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Balance/Fade

This setting will adjust audio levels from specific speakers in the front/back and left/
right of the vehicle. The Speaker icon can be moved to set audio location.

Equalizer

This setting will adjust the “Bass”, “Mid”, and “Treble” ranges of the audio.

Speed Adjusted Volume

This setting will adjust audio volume as speeds increase. At a higher setting, the vol-
ume will increase more as the vehicle speeds up. The available settings are “Off”, “1”,
“2”, and “3”.

Surround Sound

This setting will turn the Surround Sound system on or off.

AUX Volume Offset

This setting will tune the audio levels from a device connected through the AUX port.
The available settings are “+” and “-”.

Auto Play

This setting will automatically begin playing audio from a connected device.

Auto-On Radio

This setting will automatically turn the radio on when the vehicle is started, if selected.
The available settings are “Off”, “On”, and “Recall Last”. With Recall Last, the system
resumes the previous task before vehicle shut off.

Radio off With Door

This setting will keep the radio on when a door is opened or until the “Radio Off Delay”
time is reached. The available settings are “On” and “Off”.

Volume Adjustment

This setting will allow you to set the audio volume levels for each option (Media,
Phone, Navigation, etc.). You can set the volume between 0 and 38.

Media Expander

This setting will allow you to turn the Media Expander setting “On” or “Off”.

MULTIMEDIA

201

Notifications

When the Notifications button is pressed on the touchscreen, the system displays the options related to Notifications for the system.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Notifications Sounds

Turn this setting on or off to hear notification sounds throughout your system.

App Drawer Favoriting Pop-ups

This setting turns the App Favorited pop-up on or off.

App Drawer Unfavoriting Pop-ups

This setting turns the App Unfavorited pop-up on or off.

New Text Message Pop-ups

This setting turns receiving/storing a pop-up for new text messages from any con-
nected phone on or off.

Missed Calls Message

This setting turns receiving/storing a pop-up for missed calls from any connected
phone on or off.

Navigation Pop-ups

This setting turns receiving/storing predictive Navigation pop-ups on or off.

Wireless Charger Status Popups

This setting turns the Wireless Charger Status pop-up on or off.

Drive Mode Transition Popups

This setting turns the Drive Mode Transition pop-up on or off.

202

MULTIMEDIA

SiriusXM® Setup

When the SiriusXM® Setup button is pressed on the touchscreen, the system displays the options related to SiriusXM® satellite radio. These settings can be used to skip spe-
cific radio channels and restart favorite songs from the beginning.

NOTE:

•

A subscription to SiriusXM® satellite radio is required for these settings to be functional.

•

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

SiriusXM® Account, Profile, And Settings

This setting will redirect you to the SiriusXM® Settings menu within the SiriusXM®
menu.

Block Explicit

This setting will skip over content labeled as explicit. The available settings are “On”
and “Off”.

Accessibility — If Equipped

After pressing the Accessibility button on the touchscreen, the following setting will be available:

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Video Button Readback

This setting will turn the Video Button Readback feature on or off.

MULTIMEDIA

203

Software Updates

When the Software Updates button is pressed on the touchscreen, the system will display the setting related to updating the Uconnect software.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Software Downloads over Wi-Fi

This setting will allow software updates to happen over Wi-Fi. Selectable options are
“On” and “Off”.

System Information

After pressing the System Information button on the touchscreen, the following settings will be available:

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Version Information

When this feature is selected, a Version Information screen will appear, displaying
information about the version of your radio.

License Information

When this feature is selected, a License Information screen will appear, displaying the
licensing information of your radio.

Passenger License Information

When this feature is selected, Passenger License Information is displayed.

204

MULTIMEDIA

Reset

When the Reset button is pressed on the touchscreen, the system displays the options related to resetting the Uconnect system back to its default settings. These settings can
clear personal data and reset selected settings from other menus.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Restart Radio

This setting will reboot the radio.

Reset Apps Drawer To Default Order

This setting will return the apps drawer to the default order. The available options are
“Yes” and “Cancel”. The X button can also be pressed to cancel the screen.

Restore Settings to Default

This setting will return all the previously changed settings to their factory defaults.

Clear Personal Data

This setting will display a pop-up that gives you the option to clear all personal data
from the system, including Bluetooth® devices and presets.

Reset Wi-Fi Password For Projection

This setting will allow you to reset the vehicle’s Wi-Fi password for smartphone projec-
tion. The available options are “Yes” and “Cancel”. The X button can also be pressed
to cancel the screen.

Reset Performance Values

This setting will reset the performance values from your vehicle.

Factory Reset

This setting will restore the radio to its factory default settings.

MULTIMEDIA

205

STEERING WHEEL AUDIO CONTROLS

The remote sound system controls are located on the
rear surface of the steering wheel at the three and nine
o’clock positions.

The right-hand control is a rocker-type switch with a
push button in the center and controls the volume and
mode of the sound system. Pushing the top of the
rocker switch will increase the volume, and pushing the
bottom of the rocker switch will decrease the volume.

Pushing the right-hand control’s center button will make
the radio switch between the various modes available
(AM/FM/SXM or Media, etc.).

The left-hand control is a rocker-type switch with a push
button in the center. The function of the left-hand con-
trol is different depending on which mode you are in.

The following describes the left-hand control operation
in each mode:

RADIO OPERATION

Pushing the top of the switch will seek up for the next
available station and pushing the bottom of the switch
will seek down for the next available station.

The button located in the center of the left-hand control
will tune to the next preset station that you have pro-
grammed in the radio Preset button.

MEDIA MODE

Pushing the top of the switch once goes to the next
track on the selected media (AUX/USB/Bluetooth®).
Pushing the bottom of the switch once goes to the
beginning of the current track, or to the beginning of
the previous track if it is within eight seconds after the
current track begins to play.

PASSENGER SCREEN — IF EQUIPPED

Your vehicle may be equipped with a Passenger Screen
located above the glove compartment on the passenger
side of the vehicle. From the Passenger Screen, you will
be able to access similar features seen within the
Uconnect radio, such as media functions, Rear Seat
Entertainment with Amazon FireTV Built-in, Navigation,
and device management.

To begin using the Passenger Screen, push the Power
button in the center stack, or press the Power button
under the Controls tab within the Uconnect system. The
Passenger Screen can be turned off by accessing the
Control screen and pressing the Power Off button.

You must link Bluetooth® headphones to the Passen-
ger Screen to begin listening to the system’s audio

page 209.

NOTE:

•

The Passenger Screen will need to be turned On
each time the vehicle is started, and the system will
display the Home screen upon boot up.

•

Passenger Screen images are for illustration pur-
poses only and may not reflect exact software for
your vehicle.

Steering Wheel Audio Controls

Passenger Screen Location

206

MULTIMEDIA

PASSENGER SCREEN
PERMISSIONS

Through the Uconnect system, features within the Pas-
senger Screen can be activated and deactivated
through Passenger Screen Permissions. To access Per-
missions, press the Vehicle button in the Menu Bar and
select the Settings tab. Then, press the Passenger
Screen settings menu. Press the On button for the Pas-
senger Screen Permission setting to activate
permissions.

By default, the Passenger Screen Permissions setting is
set to Off, and the driver will need to give permission for
the different features.

When Permissions is turned On, you can individually
select the permissions for the following:

•

Navigation

•

Device Manager

•

Driver Media

•

Rear Seat Entertainment — If Equipped

Passenger Screen Permissions can also be activated
through the Controls screen, under the Vehicle button
in the Menu Bar. If “Deny Passenger Screen Permis-
sions” is turned On, the setting will switch itself to Off.

HOME SCREEN

When the Passenger Screen is started up and no other
media was running during the last ignition cycle, the
Home screen will display. Here, you can select from the
features of the Passenger Screen. On the left side of
the screen, you can access “Notifications and system
Controls”.

The Notifications button (the bell) will take you to the
Notification screen, identical to what is seen in the
main radio.

You can cycle between the features by swiping left or
right on the touchscreen. When accessing a feature,
press the Home/Apps button on the left side to access
the feature view and select a different feature.

The available features are:

•

Audio

•

Video & Images

•

HDMI

•

Rear Seat Entertainment — If Equipped

•

Navigation

•

Devices

•

Cameras

Controls Screen

From the Controls Screen, you can adjust the daytime/
nighttime brightness of the screen, change headphone
volume, and power off the Passenger Screen.

To change the brightness, adjust the slider up or down,
or press the Up or Down Arrow button located next to
the slider. “Up” will increase brightness; “Down” will
decrease brightness. Daytime and nighttime brightness
levels will vary, and the adjustment maximum/
minimum will differ depending on the time of day.

To change the headphone volume, adjust the slider up
or down, or press the Up or Down Arrow button located
next to the slider. “Up” will increase the volume; “Down”
will decrease the volume.

Passenger Screen Permissions

Passenger Screen Home Screen

1 — Home Screen Button
2 — Notification Button
3 — Controls Button
4 — Feature Cards

MULTIMEDIA

207

NOTE:

Headphone volume can also be manually adjusted from
the headphones. Changing the headphone volume
manually will not reflect in the headphone volume
slider on the Passenger Screen.

If the Screen Off button is pressed, the Passenger
Screen will continue to operate, but the screen will go
dark. Tap the screen again to return to the display.
While the screen is off, audio will continue to play from
the Passenger Screen.

The Power Off button will fully shut down the Passenger
Screen. No audio or video will play from it.

AUDIO AND VIDEO

Audio allows you to listen to your favorite radio station,
a connected USB device, or connected media device.
You can directly change the source on the Home screen
by pressing the Source button in the feature. You can
also expand it by pressing the Full Screen View button.

To change the media source, press the Source button
and then press on the desired source. The available
sources are:

•

Live Radio (FM, AM, SXM)

•

Bluetooth®

•

USB 1

•

USB 2

•

AUX

•

AV 1 — If Equipped

•

AV 2 — If Equipped

•

Rear Screen 1 Listen In — If Equipped

•

Rear Screen 2 Listen In — If Equipped

NOTE:

•

Audio devices connected via Bluetooth® must be
done through the Device Manager in the radio. For
more information on pairing a device, refer to your
Uconnect Radio Instruction Manual.

•

If the driver is listening to “Live Radio”, the option
will not be available in the Passenger Screen. Select
“Now Playing On Radio” to listen to the currently
playing station. If the driver selects a radio station
while the Passenger Screen is playing live radio con-
tent, the feed will end on the Passenger Screen and
control will be given to the Uconnect system.

On the Preset menu, you will be able to listen to saved
radio presets. Press the desired preset to begin
listening.

The Browse tab will let you browse through different
radio stations or audio saved onto a USB or audio
device. Press “Browse” and select from the different
folders. You can scroll up and down to view the options
within those folders. Press on the desired radio station
or audio track to begin playing it.

When the USB source is selected, you can choose a
video file to play if saved to a USB device. Press
“Browse” and locate the folder with the video file. Press
the video file name, and it will begin to play on the Pas-
senger Screen.

Passenger Screen Controls Screen

1 — Screen Off
2 — Brightness
3 — Pair/Unpair Headphones
4 — Headphone Volume
5 — Power Off
6 — Mute

Passenger Screen Audio Feature

1 — All Sources Tab
2 — Now Playing Tab
3 — Browse Tab

208

MULTIMEDIA

Jeep Wagoneer (2024 year). Manual in english - page 6
