Setting Name

Description

Set Date

This setting will allow you to set the day, month and year. Using “+” or “-”, you can scroll through the available days,
months, and years.

Show Time and Date During Screen Off

This setting will allow you to show the time and date while the screen is off. Available options are “On” and “Off”.

Phone/Bluetooth®

When the Phone/Bluetooth® button is pressed on the touchscreen, the system displays the options related to Bluetooth® connectivity from an external audio device or smart-
phone. The list of paired audio devices or smartphones can be accessed from this menu.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Device Manager

This setting will open the Device Manager main screen.

Do Not Disturb All

This setting will open the Do Not Disturb All settings menu. The available options are “On” and “Off”.

Enable Two Active Phones

This setting will enable or disable two active phones with the vehicle. The setting options are “On” and “Off”.

Phone Pop-Ups Displayed In Cluster

This setting will activate phone message pop-ups in the Instrument Cluster Display.

MULTIMEDIA

177

Voice

When the Voice button is pressed on the touchscreen, the system displays the options related to the vehicle’s Voice Recognition feature.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Voice Options

This setting will allow you to change the system’s voice to either “Male” or “Female”.

Wake Up Word

This setting will allow you to set the system’s “Wake Up” word. The available options are “Off”, “Hey, Uconnect”, and “Hey,
Jeep®”.

Voice Barge-In

This setting allows you to respond to a Voice Response before the statement is completed by the system. The available
options are “On” and “Off”.

Show Command List

This setting will allow you to turn the Command List on or off. The “Always” setting will always show the Command List. The
“With Help” setting will show the Command List and provide a brief description of what the command does. The “Never”
setting will turn the Command List off.

Navigation

When the Navigation button is pressed on the touchscreen, the system displays options related to the vehicle’s built-in Navigation system. These settings can change which
icons display on the map, how “time to arrival is calculated”, and route types.
For more information on Navigation and settings, refer to your Uconnect Radio Instruction Manual.

178

MULTIMEDIA

Camera

When the Camera button is pressed on the touchscreen, the system displays the options related to the vehicle’s camera features.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Surround View Camera Delay

This setting will add a timed delay to the Surround View Camera when shifting out of REVERSE.

Surround View Camera Guidelines

This setting will turn the Surround View Camera Guidelines on or off.

ParkView Backup Camera Delay

This setting will add a timed delay to the ParkView Backup Camera when shifting out of REVERSE.

ParkView Backup Camera Active Guidelines

This setting will turn the ParkView Backup Camera Active Guidelines on or off.

Forward Facing Camera Guidelines

This setting will turn the Forward Facing Camera Guidelines on or off.

Mirrors & Wipers

When the Mirrors & Wipers button is pressed on the touchscreen, the system displays the options related to the vehicle’s mirrors and wipers.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Tilt Side Mirrors In Reverse

This setting will tilt the outside side-view mirrors when the ignition is in the ON/RUN position and the transmission gear
selector is in the REVERSE position. The mirrors will move back to their previous position when the transmission is shifted
out of REVERSE. The available settings are “On” and “Off”.

Auto Folding Side Mirrors

This setting will automatically fold and unfold the side-view mirrors when the vehicle is turned off, the doors are locked, or
the key fob button is pushed. The available options are “On” and “Off”.

Rain Sensing Auto Wipers

This setting will turn the Rain Sensing Auto Wipers on or off.

Headlights With Wipers

This setting will turn the headlights on when the wipers are activated.

MULTIMEDIA

179

Lights

When the Lights button is pressed on the touchscreen, the system displays the options related to the vehicle’s exterior and interior lights.

NOTE:

•

When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned on or off. This feature is only allowed by law in the country of the vehicle
purchase.

•

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Ambient Color Personalization

This setting will redirect to a new menu that will allow you to change the ambient lighting color in the cabin.

Headlight Off Delay

This setting will allow you to set the amount of time it takes for the headlights to shut off after the vehicle is turned off.
The available settings are “0 sec”, “30 sec”, “60 sec”, and “90 sec”.

Headlight Illumination On Approach

This setting will allow you to set the amount of time it takes for the headlights to shut off after the vehicle is unlocked.
“Greeting Lights” must be selected and “Headlight Illumination on Approach” must be selected above 0 seconds for the
feature to be enabled. The available settings are “0 sec”, “30 sec”, “60 sec”, and “90 sec”.

Headlights with Wipers

This setting will turn the headlights on when the wipers are activated.

Proximity Wake-Up

This setting will allow you to turn on or off some exterior and interior lighting illumination when approaching the vehicle.

NOTE:

“Headlight Illumination On Approach” must be set to a value other than zero for “Proximity Wake-Up” to be active.

Greeting Lights

When the “Greeting Lights” feature is selected, it enables “Headlight Illumination On Approach”. When “Headlight Illumi-
nation On Approach” is selected, it allows the adjustment of the amount of time the headlights remain on after the doors
are unlocked with the key fob. “Greeting Lights” must be selected and “Headlight Illumination On Approach” must be
selected above zero seconds for the feature to be enabled. The available settings are “On” and “Off”.

Auto Dim High Beams

This setting will allow you to turn the Auto Dim High Beams on or off.

Daytime Running Lights

This setting will allow you to turn the Daytime Running Lights on or off.

Cornering Lights

When this setting is selected, if the steering wheel rotation angle is large or the turn signal indicators are on, a light (incor-
porated in the fog light) will turn on, on the relevant side to improve visibility at night.

Flash Lights With Lock

This setting will allow you to turn the flashing of the lights when the Lock button is pushed on the key fob on or off.

180

MULTIMEDIA

Brakes

When the Brakes button is pressed on the touchscreen, the system will display settings related to the vehicle’s brake system.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Auto Park Brake

This setting will turn the Auto Park Brake on or off.

Brake Service

This setting will allow you to set the brakes for service. When the setting is selected, a pop-up will display with “Yes” and
“No” options.

Doors & Locks

When the Doors & Locks button is pressed on the touchscreen, the system displays the options related to locking and unlocking the vehicle’s doors.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Auto Unlock On Exit

This setting will unlock the doors when any of the doors are opened from the inside.

Flash Lights With Lock

This setting will allow you to turn the flashing of the lights when the Lock button is pushed on the key fob on or off.

Sound Horn With Lock

This setting will sound the horn when the Lock button is pushed on the key fob. The “Off” setting will not sound the horn
when the Lock button is pushed. The “1st Press” setting will sound the horn when the Lock button is pushed once. The
“2nd Press” setting will sound the horn when the Lock button is pushed twice.

Sound Horn With Remote Start

This setting will sound the horn when the remote start is activated from the key fob.

Remote Door Unlock, Door Lock/1st Press Of Key
Fob Unlocks

This setting will change how many pushes of the Unlock button on the key fob are needed to unlock all the doors. The
“Driver Door” setting will only unlock the driver door on the first push on the Unlock button. The “All Doors” setting will
unlock all doors with only one push of the Unlock button.

MULTIMEDIA

181

Setting Name

Description

Passive Entry

This setting will allow you to turn the Passive Entry feature (Keyless Enter ‘n Go™) on or off.

Personal Settings Linked To Key Fob

This setting will recall preset radio stations and driver seat position that have been linked to the key fob.

Power Liftgate Alert

This setting will chime an audible alert when the power liftgate is raising or lowering. Selectable options are “On” and
“Off”.

Hands-Free Power Liftgate

This setting will use hands-free technology to automatically open or close the power liftgate. Selectable options are “On”
and “Off”.

Auto Relock

This setting will lock the doors after 30 seconds of the doors remaining unlocked. The available options are “On” and
“Off”.

Seats & Comfort

When Seats & Comfort button is pressed on the touchscreen, the system displays the options related to the vehicle’s comfort systems when remote start has been activated or
the vehicle has been started.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Easy Exit Seats

This setting will automatically move the driver seat rearward when the engine is shut off. The available settings are “On”
and “Off”.

Auto-On Driver Heated/Ventilated Seat & Heated
Steering Wheel With Vehicle Start

This setting will activate the vehicle’s comfort systems and heated seats or heated steering wheel when the vehicle is
remote started or ignition is started. The “Off” setting will not activate the comfort systems. The “Remote Start” setting
(if equipped) will only activate the comfort systems when using Remote Start. The “All Start” setting will activate the com-
fort systems whenever the vehicle is started.

3rd Row Seat Recline Lockout

This setting will activate the 3rd Row Seat Recline Lockout. Selectable options are “Off”, “Lock On Ignition”, and “Always
Locked”.

182

MULTIMEDIA

Key Off Options

When the Key Off Options button is pressed on the touchscreen, the system displays the options related to vehicle shutoff. These settings will only activate when the ignition is
set to OFF.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Sound Horn With Lower

This setting will sound the horn when the Lower button is pressed on the key fob.

Flash Lights With Lower

This setting will flash the lights when the Lower button is pressed on the key fob.

Easy Exit Seat

This setting adjusts the seats to make exiting the vehicle easier.

Headlight Off Delay

This setting will allow you to set the amount of time the headlights remain on after the vehicle has been turned off. The
available settings are “0 sec”, “30 sec”, “60 sec”, and “90 sec”.

Auto Entry/Exit Suspension

This setting will turn the Auto Entry/Exit Suspension system on or off.

Radio Off Delay

This setting will keep the radio on for the selected amount of time after vehicle shut off. The available options are “0 sec”,
“45 sec”, “5 min”, and “10 min”.

Radio Off With Door

This setting will keep the radio on when a door is opened or until the Radio Off Delay time is reached. The available set-
tings are “On” and “Off”.

Windows With Key Fob

This setting will allow you to control window function while the vehicle is off. The available options are “On” and “Off”.

MULTIMEDIA

183

Suspension

When the Suspension button is pressed on the touchscreen, the system will display settings related to the vehicle’s air suspension.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Auto Entry/Exit Suspension

This setting will turn the Auto Entry/Exit Suspension system on or off.

Display Suspension Messages

This setting will display suspension messages in the Instrument Cluster Display. The “All” setting will display all available
messages. The “Warnings Only” setting will only display warning messages.

Tire Jack Mode

This setting will disable the Air Suspension system to assist in changing a spare tire.

Auxiliary Mode

This setting will allow you to set the Auxiliary Suspension Mode. The available options are “Off”, “Transport Mode”, and
“Wheel Alignment Mode”. In Transport Mode, the vehicle will not auto level when being transported by another vehicle. In
Wheel Alignment Mode, the vehicle will not auto level when a wheel alignment is being performed.

Audio

When the Audio button is pressed on the touchscreen, the system displays options related to the vehicle’s sound system. These settings can change the audio location within
the vehicle, adjust the bass or treble levels, and auto-play settings from an audio device or smartphone.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Balance/Fade

This setting will adjust audio levels from specific speakers in the front/back and left/right of the vehicle. The Speaker icon
can be moved to set audio location.

Equalizer

This setting will adjust the “Bass”, “Mid”, and “Treble” ranges of the audio.

184

MULTIMEDIA

Setting Name

Description

Speed Adjusted Volume

This setting will adjust audio volume as speeds increase. At a higher setting, the volume will increase more as the vehicle
speeds up. The available settings are “Off”, “1”, “2”, and “Max”.

Surround Sound

This setting will turn the Surround Sound system on or off.

AUX Volume Offset

This setting will tune the audio levels from a device connected through the AUX port. The available settings are “+” and “-”.

Auto Play

This setting will automatically begin playing audio from a connected device.

Auto-On Radio

This setting will automatically turn the radio on when the vehicle is started, if selected. The available settings are “Off”,
“On”, and “Recall Last”. With Recall Last, the system resumes the previous task before vehicle shut off.

Radio off With Door

This setting will keep the radio on when a door is opened or until the Radio Off Delay time is reached. The available set-
tings are “On” and “Off”.

Volume Adjustment

This setting will allow you to set the audio volume levels for each option (Media, Phone, Navigation, etc.). You can set the
volume between 0 and 38.

Media Expander

This setting will allow you to turn the Media Expander setting “On” or “Off”.

Loudness

This setting will improve audio quality at lower volumes.

Notifications

When the Notifications button is pressed on the touchscreen, the system displays the options related to Notifications for the system.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Notification Sounds

Turn this setting “On” or “Off” to hear notification sounds throughout your system.

App Drawer Favoriting Pop-Ups

This setting turns the App Favorited pop-up on or off.

App Drawer Unfavoriting Pop-Ups

This setting turns the App Unfavorited pop-up on or off.

New Text Message Pop-Ups

This setting turns receiving/storing a pop-up for new text messages of any connected phone on or off.

Missed Calls Message

This setting turns receiving/storing a pop-up for missed calls of any connected phone on or off.

Navigation Pop-Ups

This setting turns receiving/storing predictive Navigation Pop-Ups on or off.

MULTIMEDIA

185

SiriusXM® Setup

When the SiriusXM® Setup button is pressed on the touchscreen, the system displays the options related to SiriusXM® satellite radio. These settings can be used to skip spe-
cific radio channels and restart favorite songs from the beginning.

NOTE:

•

A subscription to SiriusXM® satellite radio is required for these settings to be functional.

•

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

SiriusXM® Account, Profile, And Settings

This setting will redirect you to the SiriusXM® Settings menu within the SiriusXM® menu.

Block Explicit

This setting will skip over content labeled as explicit. The available settings are “On” and “Off”.

Accessibility — If Equipped

After pressing the Accessibility button on the touchscreen, the following setting will be available:

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Video Button Readback

This setting will turn the Video Button Readback feature on or off.

186

MULTIMEDIA

Software Updates

When the Software Updates button is pressed on the touchscreen, the system will display the setting related to updating the Uconnect software.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Software Downloads over Wi-Fi

This setting will allow software updates to happen over Wi-Fi. Selectable options for the setting are “On” and “Off”.

System Information

After pressing the System Information button on the touchscreen, the following settings will be available:

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Version Information

When this feature is selected, a Version Information screen will appear, displaying information about the version of your
radio.

License Information

When this feature is selected, a License Information screen will appear, displaying the licensing information of your radio.

Passenger License Information

When this feature is selected, Passenger License Information is displayed.

MULTIMEDIA

187

Reset

When the Reset button is pressed on the touchscreen, the system displays the options related to resetting the Uconnect system back to its default settings. These settings can
clear personal data and reset selected settings from other menus.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Restart Radio

This setting will reboot the radio.

Reset Apps Drawer To Default Order

This setting will return the apps drawer to the default order. The available options are “Yes” and “Cancel”. The X button
can also be pressed to cancel the screen.

Restore Settings to Default

This setting will return all the previously changed settings to their factory defaults.

Clear Personal Data

This setting will display a pop-up that gives you the option to clear all personal data from the system, including Bluetooth®
devices and presets.

Reset Wi-Fi Password For Projection

This setting will allow you to reset the vehicle’s Wi-Fi password for smartphone projection. The available options are “Yes”
and “Cancel”. The X button can also be pressed to cancel the screen.

Reset Performance Values

This setting will reset the performance values for your vehicle.

Factory Reset

This setting will restore the radio to its factory default settings.

188

MULTIMEDIA

STEERING WHEEL AUDIO CONTROLS

The remote sound system controls are located on the
rear surface of the steering wheel at the three and nine
o’clock positions.

The right-hand control is a rocker-type switch with a
push button in the center and controls the volume and
mode of the sound system. Pushing the top of the
rocker switch increases the volume, and pushing the
bottom of the rocker switch decreases the volume.

Pushing the right-hand control’s center button makes
the radio switch between the various modes available
(AM/FM/SXM or Media, etc.)

The left-hand control is a rocker-type switch with a push
button in the center. The function of the left-hand con-
trol is different depending on which mode you are in.

The following describes the left-hand control operation
in each mode:

RADIO OPERATION

Pushing the top of the switch will seek up for the next
available station, and pushing the bottom of the switch
will seek down for the next available station.

The button located in the center of the left-hand control
will tune to the next preset station that you have pro-
grammed in the radio preset button.

MEDIA MODE

Pushing the top of the switch once goes to the next
track on the selected media (AUX/USB/Bluetooth®).
Pushing the bottom of the switch once goes to the
beginning of the current track, or to the beginning of
the previous track if it is within eight seconds after the
current track begins to play.

PASSENGER SCREEN — IF EQUIPPED

Your vehicle may be equipped with a Passenger Screen
located above the glove compartment on the passenger
side of the vehicle. From the Passenger Screen, you will
be able to access similar features seen within the
Uconnect radio, such as media functions, Rear Seat
Entertainment with Amazon FireTV Built-in, Navigation,
and device management.

To begin using the Passenger Screen, push the Power
button in the center stack, or press the Power button
under the Controls tab within the Uconnect system. The
Passenger Screen can be turned off by accessing the
Control screen and pressing the Power Off button.

You must link Bluetooth® headphones to the Passen-
ger Screen to begin listening to the system’s audio

page 192.

NOTE:

The Passenger Screen will need to be turned On each
time the vehicle is started, and the system will display
the Home screen upon boot up.

PASSENGER SCREEN
PERMISSIONS

Through the Uconnect system, features within the Pas-
senger Screen can be activated and deactivated
through Passenger Screen Permissions. To access Per-
missions, press the Vehicle button in the Menu Bar and
select the Settings tab. Then, press the Passenger
Screen Settings menu. Press the On button for the Pas-
senger Screen Permissions setting to activate
Permissions.

By default, the Passenger Screen Permissions setting is
set to “Off”, and the driver will need to give permission
for the different features.

Steering Wheel Audio Controls

Passenger Screen Permissions Settings Menu

MULTIMEDIA

189

When Permissions is turned “On”, you can individually
select the permissions for the followings:

•

Navigation

•

Device Manager

•

Rear Seat Entertainment — If Equipped

Passenger Screen Permissions can also be activated
through the Controls screen, under the Vehicle button
in the Menu Bar. If “Deny Passenger Screen Permis-
sions” is turned “On”, the setting will switch itself to
“Off”.

HOME SCREEN

When the Passenger Screen is started up and no other
media was running during the last ignition cycle, the
Home screen will display. Here, you can select from the
features of the Passenger Screen. On the left side of
the screen, you can access “Notifications and System
Controls”.

The Notifications button (the bell) will take you to the
Notifications screen, identical to what is seen in the
main radio.

You can cycle between the features by swiping left or
right on the touchscreen. When accessing a feature,
press the Home button on the left side to access the
feature view and select a different feature.

The available features are:

•

Audio

•

Video & Images

•

HDMI

•

Rear Seat Entertainment — If Equipped

•

Navigation

•

Devices

•

Cameras

Controls Screen

From the Controls Screen, you can adjust the daytime/
nighttime brightness of the screen, change headphone
volume, and power off the Passenger Screen.

To change the brightness, adjust the slider up or down,
or press the Up or Down Arrow button located next to
the slider. “Up” will increase brightness; “Down” will
decrease brightness. Daytime and nighttime brightness
levels will vary, and the adjustment maximum/
minimum will differ depending on the time of day.

To change the headphone volume, adjust the slider up
or down, or press the Up or Down Arrow button located
next to the slider. “Up” will increase the volume; “Down”
will decrease the volume.

NOTE:

Headphone volume can also be manually adjusted from
the headphones. Changing the headphone volume
manually will not reflect in the headphone volume
slider on the Passenger Screen.

If the Screen Off button is pressed, the Passenger
Screen will continue to operate, but the screen will go
dark. Tap the screen again to return to the display.
While the screen is off, audio will continue to play from
the Passenger Screen.

The Power Off button will fully shut down the Passenger
Screen. No audio or video will play from it.

Passenger Screen Home Screen

1 — Home Screen Button
2 — Notifications Button
3 — Controls Button
4 — Feature Cards

Passenger Screen Controls Screen

1 — Screen Off
2 — Display Brightness
3 — Manage Headphones
4 — Headphone Volume
5 — Power Off
6 — Mute Headphones

190

MULTIMEDIA

AUDIO AND VIDEO

Audio allows you to listen to your favorite radio station,
a connected USB device, or connected media device.
You can directly change the source on the Home screen
by pressing the Source button in the feature. You can
also expand it by pressing the Full Screen View button.

To change the media source, press the Source button
and then press on the desired source. The available
sources are:

•

Live Radio (FM, AM, SXM)

•

Bluetooth®

•

USB 1

•

USB 2

•

AUX

•

AV 1 — If Equipped

•

AV 2 — If Equipped

•

Rear Screen 1 Listen In — If Equipped

•

Rear Screen 2 Listen In — If Equipped

NOTE:

•

Audio devices connected via Bluetooth® must be
done through the Device Manager in the radio. For
more information on pairing a device, refer to your
Uconnect Radio Instruction Manual.

•

If the driver is listening to “Live Radio”, the option
will not be available in the Passenger Screen. Select
“Now Playing On Radio” to listen to the currently
playing station. If the driver selects a radio station
while the Passenger Screen is playing live radio con-
tent, the feed will end on the Passenger Screen and
control will be given to the Uconnect system.

On the Preset menu, you will be able to listen to saved
radio presets. Press the desired preset to begin
listening.

The Browse tab will let you browse through different
radio stations or audio saved onto a USB or audio
device. Press “Browse” and select from the different
folders. You can scroll up and down to view the options
within those folders. Press on the desired radio station
or audio track to begin playing it.

When the USB source is selected, you can chose a
video file to play if saved to a USB device. Press
“Browse” and locate the folder with the video file. Press
the video file name, and it will begin to play on the Pas-
senger Screen.

NOTE:

Not all video files will be supported from a USB. Certain
video files may require digital rights to view or play.
These may be unavailable for playback on the Passen-
ger Screen.

Audio Feature

1 — All Sources Tab
2 — Now Playing Tab
3 — Browse Tab

Playing A Video

1 — Source Bar
2 — Now Playing Tab
3 — Browse Button
4 — Preset Bar
5 — Related Button
6 — Seek Down Button
7 — Tune Button
8 — Seek Up Button
9 — Replay Button

MULTIMEDIA

191

REAR SEAT ENTERTAINMENT WITH
AMAZON FIRE TV BUILT-IN —
IF EQUIPPED

Rear Seat Entertainment with Fire TV built-in will let you
control and listen in to the content being played on the
rear entertainment screens. You can view the contents
of the rear screens, lock the rear screens, change the
source of the rear screens, or turn the rear screens on
or off

page 194.

HDMI PROJECTING

HDMI lets you connect a device to the provided HDMI
port, using an HDMI cable, and project the device
directly to the Passenger Screen. To begin, plug a
device into the HDMI port. Then, press the HDMI button
on the touchscreen.

HDMI will continue to show the menu bar and Head-
phone Paring button.

NOTE:

•

The HDMI Card will not automatically launch when a
new device is connected. The HDMI Card will show a
device connected, and the Card will need to be
pressed.

•

If the user disconnects a device from the HDMI port
while the HDMI Card is in full screen, the system will
close HDMI and reload the Home screen.

DEVICE MANAGER

Device Manager provides an easy place to view all the
devices connected to the Uconnect system and lets you
pair the Driver’s smartphone to the Uconnect system.
You will also pair Bluetooth® headphones to the Pas-
senger Screen from this screen.

For more information on pairing your smartphone, refer
to your Uconnect Radio Instruction Manual.

To pair a set of Bluetooth® Headphones:

1. If viewing Device Manager in full screen, press the

Add Device button. If viewing Device Manager on the
Home screen, press “Pair Bluetooth® headphones”.

2. From the pop-up, press “Search For Headphones”.

The system will begin searching for the Bluetooth®
signal of your headphones.

3. Select the name of your headphones from the list of

possible devices. The system will connect to the
headphones.

NOTE:

The Passenger Screen will connect to previously paired
Bluetooth® headphones after Passenger Screen
activation.

Removing Bluetooth® Headphones

1. From the Controls screen, press the Manage Head-

phones button.

2. Press the Settings button (gear icon) next to the set

of headphones you wish to remove.

3. Press “Delete Device”; the Bluetooth® headphones

will be removed from the system.

NAVIGATION

Navigation allows you to assist the driver in searching
for destinations using Uconnect’s built-in Navigation
system. For information on the full functionality of Navi-
gation, refer to your Uconnect Radio Instruction
Manual.

When a new route is selected from the Passenger
Screen, a confirmation will be sent to the driver. The
driver will be able to confirm or deny the route.

Device Manager

1 — Device Settings Button
2 — Phone Connectivity Button
3 — Media Connectivity Button
4 — Android Auto™/Apple CarPlay® Button
5 — Add Device Button
6 — Manage Headphone Button
7 — Do Not Disturb Button
8 — Two Active Phones Button

192

MULTIMEDIA

NOTE:

Using Navigation on the Passenger Screen will not
affect the Navigation screen in the Uconnect system.
The Driver can continue to use Navigation while the
Passenger Screen can “suggest” new routes or stops.

CAMERA

Camera will display the equipped vehicle camera feed.
When selected, press the desired Camera button. The
feed from that camera will display in the center of the
touchscreen. Press the X button or Back Arrow button
to return to the Home screen.

NOTE:

The Passenger Screen will lose access to a camera if
the driver chooses to view it on the Uconnect system or
if a condition would activate the camera on the
Uconnect system (the rearview camera being activated
when the vehicle is shifted into REVERSE).

3RD PARTY APPS

If equipped, your vehicle may contain some 3rd party
apps, which will further enhance your Uconnect system.

McIntosh

McIntosh is a 3rd party app that can enhance your
Uconnect system’s media player. For the app to be
effective, there must be audio playback in the Uconnect
media player. McIntosh can control the playback of
audio as well as display the output level decibel meters.

To launch the app, begin playing audio and follow these
steps:

1. Press the Apps button.

2. Press the McIntosh app.

The McIntosh app will allow you to perform the following when listening to music:

NOTE:

The Seek feature will not work while using Bluetooth®.

Skip Backward

Press to skip backward. Press and hold to fast rewind.

Play/Pause

Press to play/pause the track.

Skip Forward

Press to skip forward. Press and hold to fast forward.

Repeat

Press to repeat track. Press again to repeat playlist. Press again to turn off (works only with a USB device).

Change Channel Down

Press to change channel down. Press and hold to seek channel down. While using AM/FM, pressing the channel down will change
the frequency by 0.1. Pressing and holding in AM/FM will seek channels.

Change Channel Up

Press to change channel up. Press and hold to seek channel up. While using AM/FM, pressing the channel up will change the fre-
quency by 0.1. Pressing and holding in AM/FM will seek channels.

Press to access McIntosh settings.

About

Press to learn more about McIntosh.

Audio

Press to open the audio settings page of the Uconnect media player.

McIntosh

MULTIMEDIA

193

NOTE:

To change the source within the app, press the source
name. Pressing this will open a menu with all available
sources. To change the audio source outside of the
app, press the Media button, and then press the
Sources button.

To exit the app, press any of the buttons on the Bottom
Menu Bar.

Day/Night Mode

Press the Menu button in the upper left-hand corner to
access McIntosh settings. Tap on a Mode to set it as
the default, or tap “Auto Mode” to enable your screen to
automatically switch between Day and Night Modes.

Theater Mode

Press the Menu button in the upper left-hand corner to
access McIntosh settings. Under the Theater Mode sec-
tion, select “On” to bring forward the McIntosh meters.
This will enlarge the meters for a more prominent view.

NOTE:

Theater Mode will engage after 10 seconds without
input from the user.

For more information on McIntosh, the McIntosh app
and its functionality, please visit
https://www.mcintoshlabs.com.

REAR SEAT ENTERTAINMENT (RSE) WITH
AMAZON FIRE TV BUILT-IN —
IF EQUIPPED

OVERVIEW

Rear Seat Entertainment with Fire TV built-in is
designed to give your family years of enjoyment.

Fire TV lets passengers enjoy a wide variety of content
from popular apps (subscriptions may be required).
Stream videos, play games, listen to music, get informa-
tion, and watch downloaded programs all while on the
road. Two Voice Remotes with Alexa are included with
the system. Press the Microphone button on the Voice
Remote with Alexa to easily find, launch, and control
content. Check sports scores, play music, control smart
home devices, or see your live camera feeds (compat-
ible smart home device required and sold separately).
In addition to streaming and downloaded content,
changing the input in Fire TV also enables you to:

•

Mirror what’s on your phone or tablet to Fire TV via
Miracast capable devices

•

Stream your favorite shows with Fire TV

•

Plug and play a variety of standard video games or
devices into the HDMI port

•

Listen to audio over wired or wireless headphones
(not included, customer will have to provide their
own or play audio through in-cabin speakers with
Listen In feature in front seat)

•

Plug and play a variety of devices into the front seat
Video USB port. USB ports located under the rear
screens are charge only

•

Watch content individually on each rear display or
mirror across both displays to watch together

NOTE:

Vehicle must be in an active and usable cellular range
and properly equipped with a Uconnect 5 NAV system
and Rear Seat Entertainment with Fire TV package.
Streaming requires a Wi-Fi connection and registered
Amazon account to run Fire TV in the vehicle. Stream-
ing service subscriptions are not included. Services and
features are subject to change or withdrawal at any
time, may not be available in all areas and languages,
and may require separate subscriptions.

Please review this Owner's Manual to become familiar
with RSE features and operation.

GETTING STARTED

1 — Rear Seat Entertainment (Rear Touchscreen)
2 — Headphone Jack
3 — USB C Charging Port
4 — HDMI Port
5 — Uconnect System (Front Touchscreen)

Rear Screen Entertainment For Uconnect 5/5 NAV

194

MULTIMEDIA

There are four different ways to operate the features of
Rear Seat Entertainment with Fire TV built-in:

•

Voice Remote with Alexa

•

Front radio screen

•

Passenger screen (if equipped)

•

Individual rear touchscreens for Rear Seat Enter-
tainment with Fire TV built-in touch on each rear
screen

For information on the front media hub USB/AUX ports,

page 67.

ACCESSING REAR SEAT
ENTERTAINMENT WITH FIRE TV
BUILT-IN FROM THE FRONT RADIO
SCREEN

You can access your Rear Seat Entertainment with Fire
TV built-in system by following these steps:

Option 1

1. Press the Media button.

2. Press the Rear Seat button icon.

Option 2

1. Press the Apps button on the bottom of the

touchscreen.

2. Press the Uconnect Theater button on the touch-

screen. You may need to navigate to different pages
in the Apps drawer to find the Uconnect Theater
button.

ACCESSING REAR SEAT
ENTERTAINMENT WITH FIRE TV
BUILT-IN FROM THE REAR
SCREENS

You can also access your Rear Seat Entertainment with
Fire TV built-in by choosing one of the following options:

Option 1

•

The system will automatically turn on when the
vehicle is started. Pushing the power button on the
Voice Remote with Alexa will turn the system back
on if it was manually shut off. If the screen is inac-
tive and goes to a screen saver, the system can be
woken up by either tapping the screen or pushing
any button on the Voice Remote with Alexa.

Option 2

•

Swiping on either of the rear touchscreens.

NOTE:

When using the rear screens, the system will launch
with Fire TV.

ACCESSING REAR SEAT
ENTERTAINMENT WITH FIRE TV
BUILT-IN FROM THE PASSENGER
SCREEN — IF EQUIPPED

You can also access Rear Seat Entertainment with Fire
TV built-in content from the Passenger Screen.

Follow these steps:

1. Access the Home screen for the Passenger Screen.

2. Swipe right on the Home screen and select Fire TV

Rear Seat Entertainment Controls.

FIRST TIME STARTING UP (USING
THE REAR SCREENS)

Boot-up Screen

When turning on the system for the first time from the
rear screens, a boot-up screen will appear on the sys-
tem displaying the Fire TV logo.

During this boot-up sequence, language options will be
available for the system.

Voice Remote with Alexa Pairing

After the boot-up sequence is complete, the system will
then give the option to pair a Voice Remote with Alexa
(two are included with the system).

Follow the on-screen instructions for how to pair a Voice
Remote with Alexa to the system. Two Voice Remotes with
Alexa are included to be paired with each rear screen.

A Voice Remote with Alexa can be paired to each rear
screen. It will function with the rear screen it was paired
with. The pairing steps will need to be done for each
rear screen.

NOTE:

If the Voice Remote with Alexa pairing fails, on-screen
instructions will appear for trying to pair again.

Connecting to a Network

During the start-up process, the system will need to be
connected to a network to function. Multiple network
sources can be options for the system.

Some options for a network connection are:

•

Wi-Fi Hotspot using a capable smartphone (if acti-
vated, it will show as a possible network for the sys-
tem on the screen).

•

Outside connection like a home Wi-Fi network.

•

In-vehicle Wi-Fi.

MULTIMEDIA

195

NOTE:

When a network is connected to the system for the first
time, an over-the-air-software update will take place
using the Wi-Fi connection. It is recommended that an
unlimited Wi-Fi connection, if available, be used during
this update. After this first-time update, updates will
only occur when one is available.

Account Sign-in

The next step will be the option to sign in to your Ama-
zon account.

There are two options to sign into the system:

•

I already have an Amazon account:

already existing Amazon account

•

I am new to Amazon:

Create a new Amazon Account

If “I am new to Amazon” is selected, follow the
on-screen steps to set up an Amazon account with the
system.

Parental Controls

Another feature that will appear during this first time
set up is parental controls.

When the parental controls page appears, it will give
the options “Enable Parental Controls” and “No Paren-
tal Controls”. If “Enable Parental Controls” is selected,
follow the on-screen steps to set up parental controls
for the system.

ALEXA VOICE CONTROL

A feature with Rear Seat Entertainment with Fire TV
built-in that enhances your experience is Alexa. It is
simple to get started using this feature. Push the Micro-
phone button at the top of the Voice Remote with Alexa
to activate Alexa and get started.

LISTEN VIA VEHICLE SPEAKERS

A feature within Rear Seat Entertainment with Fire TV
built-in is the front radio Listen feature. On the front
radio Home screen for Fire TV, select the Listen button
in the top right corner on either card for Screen 1 or 2.
This will allow you to have either rear screen play audio
through all the speakers in the vehicle.

QUICK MENU

Accessing the quick menu will give you more options for
Fire TV.

To access the quick menu, tap the screen and it will
appear. The quick menu is also accessible by pushing
the Gear/Settings button on the Voice Remote with
Alexa.

Some options of the quick menu are:

•

Power

— This will power the screen off.

•

On-Screen Remote

— This will bring up the

on-screen remote to use with the system.

•

Back

— This will let you go back a page.

•

Home

— This will take you to the Home screen.

•

Gear/Settings

— This will let you access certain set-

tings in the system. For more setting options, select
“Settings” within the on-screen Gear/Settings
menu.

•

Vehicle

— This will bring up the Vehicle menu. From

here you can adjust rear climate controls and the
Are We There Yet? app.

PARENTAL CONTROLS (USING THE
REAR SCREENS)

If parental controls were not set during the first time
start up of the system, they can be set by following
these steps:

1. Push the Gear/Settings button on the Voice Remote

with Alexa or tap the screen to access Settings in
the “quick menu”.

2. Select the Gear/Settings icon on the screen.

3. Select “Settings” on the screen.

4. While in Settings, select “Preferences”.

5. Select “Parental Controls”; from here you can turn

Parental Controls on or off and set up a PIN for the
controls using the Voice Remote with Alexa.

VOICE REMOTE WITH ALEXA
PAIRING (USING THE REAR
SCREENS)

If the Voice Remote with Alexa needs to be paired again
or a new remote is being paired, follow these
procedures:

1. Install batteries into the remote.

2. Tap the screen and Select the Gear/Settings icon on

the screen.

3. Select “Settings” on the screen.

4. In Settings, select “Controllers & Bluetooth®

Devices”.

5. From this menu, select “Add New Remote”.

6. Follow the on-screen steps for Voice Remote with

Alexa pairing.

196

MULTIMEDIA

A long press on the Home button can also re-pair a
Voice Remote with Alexa that has become
disconnected.

NOTE:

Your vehicle is included with two Voice Remotes with
Alexa. A Voice Remote with Alexa can be paired to each
rear screen. It will function with the rear screen it was
paired with. The pairing steps will need to be done for
each rear screen.

MEDIA SOURCES INPUT (USING
THE FRONT RADIO AND REAR
SCREENS)

Front Radio Screen

Users can select inputs for each rear screen from the
front radio touchscreen by selecting the Rear Seat tab
and choosing the desired content by selecting “Launch
Source” on the Screen 1 or Screen 2 tab.

Inputs available within Launch Source under “Inputs”
are “Fire TV”, “HDMI”, and “USB”.

Rear Screens

To select inputs on the rear screen, scroll down on the
Fire TV Home screen and select your desired input
under “Input”.

Inputs can also be selected from the Brand tab in the
top menu. While in this tab, scroll down to “Inputs” for
selection options.

NOTE:

The Brand tab naming in the top menu will depend on
the naming of the vehicle’s brand.

VOICE REMOTE WITH ALEXA

Power Button

— Turns the screen for the selected

channel on or off.

5-way Navigation Control

— This control has options

by pressing the Circle button Up, Down, Left, or
Right to navigate on-screen for selections and push-
ing the center button to confirm selections.

Back

— Push to exit out of menus or return to the

previous screen.

Home

— Push to return to the Fire TV Home screen.

Seek Backward/Rewind Button

— Push and hold to

fast rewind through the current audio track or video
chapter. Push once to revert back to the previous
track.

Volume

— Push the - button to decrease the volume

and + button to increase the volume.

Channel Guide

— Push to access the channel guide

for the system.

Mute

— Mutes headphone audio.

Prime Video

— Push to launch Prime Video app.

10.

App 1

— Push to navigate to App 1.

11.

Microphone Button

— Push to activate Alexa.

12.

— Push to access the Fire TV menu.

13.

Seek Forward Button

— Push and hold to fast for-

ward through the current audio track or video
chapter. Push once to skip to the next track.

14.

Play/Pause Button ||

— Begin/resume or pause

disc play.

15.

Channel +/-

— Push the up or down arrow button

on the Channel button to browse channels avail-
able in Fire TV.

16.

Recent

— Push to access recently viewed content

on Fire TV.

17.

Gear/Settings

— Push to bring up setting options

for Fire TV.

18.

App 2

— Push to launch App 2.

19.

Vehicle Button

— Push to activate the Vehicle

menu.

Voice Remote With Alexa

MULTIMEDIA

197

REPLACING THE VOICE REMOTE
WITH ALEXA BATTERIES

Each Voice Remote with Alexa requires two AAA batter-
ies for operation.

To replace the batteries:

1. Locate the battery compartment on the back of the

Voice Remote with Alexa, then slide the battery
cover downward.

2. Remove the old batteries and follow battery recy-

cling procedures for your area.

3. Install new batteries, making sure to orient them

according to the polarity diagram shown inside the
battery compartment.

4. Slide the battery compartment cover back on.

REAR SEAT ENTERTAINMENT WITH
FIRE TV BUILT-IN STREAMING
(USING THE FRONT RADIO AND
REAR SCREENS)

Access Using Launch Source

To access Rear Seat Entertainment with Fire TV built-in
from the front radio, press the Media tab located on the
bottom menu bar. Then select the Rear Seat option
located on the top menu bar. Select “Launch Source”,
and then under “Inputs” select “Fire TV Home”.

Access Using Browse Media

Selecting “Browse Media” on the front radio screen will
give access to different media within Rear Seat Enter-
tainment with Fire TV built-in.

These options will be in the top menu of “Browse
Media” and include:

•

Fire TV

— Selecting “Fire TV” will show streaming

options for categories and to select apps. This
option will be selectable on the left slider menu in
“Browse Media”. While in “Browse Media” under
Fire TV, it will display recent activity under “Recent”.
This will display recent videos viewed from Fire TV
and recent downloads as well.

•

USB Video

— Under “USB Videos”, videos will appear

that are options with a USB device connected to
Rear Seat Entertainment with Fire TV built-in.

•

USB Music

— Under “USB Music”, music will appear

that are options with a USB device connected to
Rear Seat Entertainment with Fire TV built-in.

Access Using the Voice Remote with Alexa and Rear
Screens

Rear passengers will be able to access some options
for streaming by pressing the “Prime Video”, “App 1”, or
“App 2” button on the Voice Remote with Alexa. Select-
ing one of those buttons on the Voice Remote with
Alexa will take you to the home page for that respective
streaming service. Turning on either of the rear screens
will launch Fire TV. By default, the rear screens will
always launch in Fire TV. More streaming options can
be selected on the Fire TV home page.

Fire TV

Fire TV is your source for online streaming with Rear
Seat Entertainment with Fire TV built-in.

NOTE:

A data source needs to be connected to the system for
streaming to be accessible. This can be set up when Fire
TV is turned on for the first time from the rear screens.
Some of these options can be an in-vehicle 4G Wi-Fi hot
spot, capable Wi-Fi hot spot from a mobile device, or
Wi-Fi from an outside source like a home or a garage.

To access Fire TV on the front screen, select “Launch
Source” on the front radio rear seat screen and then
“Fire TV Home” under the Inputs.

Viewing from the front radio screen or passenger
screen mirrors or controls the Fire TV experience from
one of the rear Fire TV displays.

The menu bar for Fire TV will have the options for
“Home”, “Find”, “Library”, “Brand”, and “Live”.

Below the menu bar will be streaming options linked to
your Prime account like “Prime Video”.

The front radio screen offers some options:

•

Power

— This will turn Fire TV on or off.

•

Screen 1 and Screen 2 Toggle

— This toggles

between the Rear Screens (for use with front radio
screen only).

•

Collapse

— While viewing on the front radio screen,

this will collapse the screen to dashboard view.

•

Source Drawer

— This will open the “Source Drawer”

and the source logo will be displayed on the icon.

•

Browse Media

— This will open the “Browse Media”

pop-up.

•

Back

— This will let you go back the previous page.

•

Fire TV Home

— This will take you back to the Fire

TV home page.

•

— This will open the Fire TV menu.

•

Remote icon

— This will display the on-screen

remote.

198

MULTIMEDIA

NOTE:

Front radio screen mirroring and watching can only be
done when the vehicle is in PARK. The vehicle must be
in an active and usable cellular range and properly
equipped with a Uconnect 5 NAV system and Rear Seat
Entertainment with Fire TV package. For streaming, a
Wi-Fi connection and registered Amazon account are
required to run Fire TV in the vehicle. Streaming service
subscriptions are not included. Services and features
are subject to change or withdrawal at any time, may
not be available in all areas and languages, and may
require separate subscriptions.

FIRE TV APPS/GAMES (USING THE
REAR SCREENS)

Apps and games can be accessed using Rear Seat
Entertainment with Fire TV built-in.

To access Apps on the rear screen, turn on the system
and select “Find” in the top menu. On the Find page,
select “App Store®”. Within the App Store® you can
purchase apps and games. From here you can also
select from all the apps and games that have been
purchased.

ARE WE THERE YET?

When a navigation route has been set from the
Uconnect system, the second-row passengers can use
“Are We There Yet?” for an animated screen showing
distance and time remaining on navigation routes, as
well as the estimated time of arrival with pop-up
notifications.

Some screen information includes:

•

Decrease Timing Between Notifications Button

•

Notifications ON/OFF Button

•

Increase Timing Between Notifications Button

•

Arrival Time

•

Time Remaining Until Destination Is Reached

•

Distance Remaining

To access “Are We There Yet?” from the rear screens,
follow these steps:

1. Tap one of the rear screens and select the Vehicle

icon or push the Vehicle button on the Voice Remote
with Alexa.

2. Select “Are We There Yet?” near the bottom of the

menu on the first page of options.

USING THE VIDEO USB PORT

Plug in a USB drive or mass storage device and play
your favorite music or movies.

NOTE:

To view USB media on the rear screens, insert a USB
drive into the port. The USB drive port is located under
the radio controls in the instrument panel.

On the rear screen you can browse the content of the
USB device by going to the USB source in the inputs.
Use the search feature to find your media faster.

PLAY VIDEO GAMES

Connect the video game console to either of the HDMI
ports located behind either of the first row seats.

NOTE:

Certain high-end video games may exceed the power
limit of the vehicle's Power Inverter

page 70.

Headphone Jack/HDMI/USB

1 — Headphone Jack (Headphone Output Only)
2 — USB Port (Charge Only)
3 — HDMI Port

MULTIMEDIA

199

HEADPHONES OPERATION

Rear Seat Entertainment with Fire TV built-in does not
come equipped with headphones. Customers will need
to provide their own wireless headphones that can be
paired with the system using Bluetooth®. Customers
can also use their own wired headphones and plug
them into a Headphone Jack located under one of the
rear screens.

Wireless Headphones Pairing

To pair wireless headphones with Rear Seat Entertain-
ment with Fire TV built-in using the rear screens, follow
these steps:

1. Push the Gear/Settings button on the Voice Remote

with Alexa or tap the screen.

2. Select the Gear/Settings icon on the screen.

3. Select “Settings” on the screen.

4. While in Settings, select “Controllers & Bluetooth®

Devices”.

5. Select “Other Bluetooth® Devices” and follow the

on-screen steps for pairing.

While multiple headphones can be paired, only one will
output audio at a time.

REAR CLIMATE CONTROLS

The Rear Climate Controls can also be controlled using
Rear Seat Entertainment with Fire TV built-in

page 57.

Rear Climate Controls can be accessed by using the
Vehicle menu. Tap on either rear screen and select the
Vehicle icon or press the Vehicle button on the Voice
Remote with Alexa. Then select the Rear Climate Con-
trols option.

Options within Rear Climate Controls are:

Icon

Description

Climate Control ON Button

Press and release this button to turn the Rear Climate Controls on.

OFF

Climate Control OFF Button

Press and release this button to turn the Rear Climate Controls off.

SYNC

SYNC Button

Pressing this button will sync both sides of the Rear Climate Controls.

AUTO Button

Automatically controls the rear interior cabin temperature by adjusting airflow distribution and amount. Toggling this function will cause the system to switch
between Manual mode and Automatic mode.

200

MULTIMEDIA

Icon

Description

Rear Passenger Temperature Up and Down Buttons

Provides the rear passengers with independent temperature control. Press the button on the touchscreen to increase or decrease the temperature. The tem-
perature will get warmer as you move up toward the red arrow and colder as you move down toward the blue arrow.

Headliner

Mode

Headliner Mode

Air comes from the outlets in the headliner. Each of these outlets can be individually adjusted to direct the flow of air. Moving the air vanes of the outlets to
one side will shut off the airflow.

Bi-Level Mode

Air comes from both the headliner outlets and the floor outlets.

NOTE:

In many temperature positions, the Bi-Level mode is designed to provide cooler air out of the headliner outlets and warmer air from the floor outlets.

Floor Mode

Air comes from the floor outlets.

MULTIMEDIA

201

Icon

Description

1,2,3, etc.

Blower Control

Blower Control is used to regulate the amount of air forced through the Climate system. There are seven blower speeds available. Adjusting the blower will
cause Automatic mode to switch to Manual operation.

LEGAL & COMPLIANCE

To access Legal and Compliance information about
Rear Seat Entertainment with Fire TV built-in from the
rear screens, follow these steps:

1. Push the Gear/Settings button on the Voice Remote

with Alexa or tap the screen.

2. Select the Gear/Settings icon on the screen.

3. Select “Settings” on the screen.

4. While in the Settings menu, select “My Fire TV” and

then “Legal & Compliance”.

OFF-ROAD PAGES — IF EQUIPPED

Your vehicle may be equipped with Off-Road Pages,
which provides the vehicle status information while
operating on off-road conditions. It supplies information
relating to the vehicle ride height, the status of the
transfer case, the pitch and roll of the vehicle, and the
active Selec-Terrain Mode.

To access Off-Road Pages, press the Off Road button
on the touchscreen from the Vehicle menu, and then
press “Launch Off-Road”.

Off-Road Pages has the following selectable pages:

•

Vehicle Dynamics

•

Accessory Gauges

•

Pitch & Roll

•

Selec-Terrain — If Equipped

•

Suspension — If Equipped

•

Forward Facing Camera — If Equipped

NOTE:

With a Connected Services subscription (if equipped),
you can record your Off-Road data and send it directly
to the mobile app. Press the Record button to begin.

OFF-ROAD PAGES STATUS BAR

The Off-Road Pages Status Bar is located along the bot-
tom of Off-Road Pages and is present on each of the
selectable page options. It provides continually updat-
ing information for the following items:

•

Current Transfer Case Status

•

Current Selec-Terrain Mode

•

Current Latitude/Longitude

•

Current Altitude of the vehicle

•

Status of Hill Descent Control or Selec-Speed Con-
trol Selected Speed in mph (km/h).

•

Current Terrain Mode

Status Bar

1 — Transfer Case Status
2 — Current Latitude/Longitude
3 — Current Altitude
4 — Hill Descent Control Or Selec-Speed Control
5 — Current Terrain Mode

202

MULTIMEDIA

VEHICLE DYNAMICS

The Vehicle Dynamics page displays information con-
cerning the vehicle’s drivetrain.

The following information is displayed:

•

Steering angle in degrees

•

Status of Transfer Case

•

Status of the Rear Axle Locker — If Equipped

•

Status of Sway Bar — If Equipped

ACCESSORY GAUGES

The Accessory Gauges page displays the current status
of the vehicle’s Coolant Temperature, Oil Temperature,
Oil Pressure, Transmission Temperature, and Battery
Voltage.

PITCH & ROLL

The Pitch & Roll page displays the vehicle’s current
pitch (angle up and down) and roll (angle side to side)
in degrees. The Pitch & Roll gauges provide a visualiza-
tion of the current vehicle angle.

Vehicle Dynamics Menu

1 — Vehicle Dynamics
2 — Steering Angle
3 — Transfer Case Status
4 — Rear Axle Status

Accessory Gauges Menu

1 — Coolant Temperature
2 — Oil Temperature
3 — Oil Pressure
4 — Transmission Temperature
5 — Battery Voltage

Pitch & Roll Menu

1 — Current Pitch
2 — Current Roll

MULTIMEDIA

203

SELEC-TERRAIN — IF EQUIPPED

The Selec-Terrain page displays the current Selec-
Terrain Mode through a high resolution image. Adjust-
ing the Selec-Terrain Mode will alter the image on the
screen. The vehicle must be in the ON/RUN position to
display Selec-Terrain information.

The selectable modes are as follows:

•

Rock — Vehicle Must Be In 4WD Low

•

Sand/Mud

•

Snow

•

Auto — Default

•

Sport

NOTE:

The Off-Road Pages Status Bar will also display the cur-
rent Selec-Terrain Mode.

SUSPENSION — IF EQUIPPED

The Suspension page displays information concerning
the vehicle’s suspension.

The following information is displayed:

•

Wheel Articulation

•

Current Ride Height Status

○

Off-Road 2

○

Off-Road 1

○

Normal

○

Aero

○

Entry/Exit

NOTE:

The wheel articulation will be represented by a yellow
color in the Wheel Articulation. If Ride Height is
adjusted, the Ride Height indicator on the screen will
switch to the appropriate height and the Wheel Articula-
tion will show the movement and change in height.

RADIO OPERATION AND MOBILE PHONES

Under certain conditions, the mobile phone being on in
your vehicle can cause erratic or noisy performance
from your radio. This condition may be lessened or
eliminated by repositioning the mobile phone within the
vehicle. This condition is not harmful to the radio. If
your radio performance does not satisfactorily improve
from repositioning the mobile phone, it is recom-
mended that the volume be turned down or off during
mobile phone operation when not using the Uconnect
system.

REGULATORY AND SAFETY
INFORMATION

US/CANADA

Exposure to Radio Frequency Radiation

The radiated output power of the internal wireless radio
is far below the FCC and IC radio frequency exposure
limits. Nevertheless, the wireless radio will be used in
such a manner that the radio is 8 inches (20 cm) or
further from the human body.

The internal wireless radio operates within guidelines
found in radio frequency safety standards and recom-
mendations, which reflect the consensus of the scien-
tific community.

The radio manufacturer believes the internal wireless
radio is safe for use by consumers. The level of energy
emitted is far less than the electromagnetic energy
emitted by wireless devices such as mobile phones.
However, the use of wireless radios may be restricted in
some situations or environments, such as aboard air-
planes. If you are unsure of restrictions, you are encour-
aged to ask for authorization before turning on the wire-
less radio

page 331.

Suspension Menu

1 — Wheel Articulation
2 — Current Ride Height

204

MULTIMEDIA

SAFETY

SAFETY FEATURES

ANTI-LOCK BRAKE SYSTEM (ABS)

The ABS provides increased vehicle stability and brake
performance under most braking conditions. The sys-
tem automatically prevents wheel lock and enhances
vehicle control during braking.

The ABS performs a self-check cycle to ensure that the
ABS is working properly each time the vehicle is started
and driven. During this self-check, you may hear a slight
clicking sound as well as some related motor noises.

The ABS is activated during braking when the system
detects one or more wheels are beginning to lock. Road
conditions such as ice, snow, gravel, bumps, railroad
tracks, loose debris, or panic stops may increase the
likelihood of ABS activation(s).

You also may experience the following normal charac-
teristics when the ABS activates:

•

ABS motor noise or clicking sounds (you may con-
tinue to hear for a short time after the stop)

•

Brake pedal pulsations

•

A slight drop of the brake pedal at the end of the
stop

The ABS is designed to function with the Original Equip-
ment Manufacturer (OEM) tires. Modification may result
in degraded ABS performance.

WARNING!

•

The ABS contains sophisticated electronic equip-
ment that may be susceptible to interference
caused by improperly installed or high output radio
transmitting equipment. This interference can
cause possible loss of anti-lock braking capability.
Installation of such equipment should be per-
formed by qualified professionals.

•

Pumping of the Anti-Lock Brakes will diminish their
effectiveness and may lead to a collision. Pumping
makes the stopping distance longer. Just press
firmly on your brake pedal when you need to slow
down or stop.

•

The ABS cannot prevent the natural laws of physics
from acting on the vehicle, nor can it increase
braking or steering efficiency beyond that afforded
by the condition of the vehicle brakes and tires or
the traction afforded.

•

The ABS cannot prevent collisions, including those
resulting from excessive speed in turns, following
another vehicle too closely, or hydroplaning.

•

The capabilities of an ABS equipped vehicle must
never be exploited in a reckless or dangerous man-
ner that could jeopardize the user’s safety or the
safety of others.

Anti-Lock Brake System (ABS) Warning

Light

The yellow ABS Warning Light will turn on when the igni-
tion is placed in the ON/RUN mode and may stay on for
as long as four seconds.

If the ABS Warning Light remains on or comes on while
driving, it indicates that the anti-lock portion of the
brake system is not functioning and that service is
required. However, the conventional brake system will
continue to operate normally if the ABS Warning Light is
on.

If the ABS Warning Light is on, the brake system should
be serviced as soon as possible to restore the benefits
of Anti-Lock Brakes. If the ABS Warning Light does not
come on when the ignition is placed in the ON/RUN
mode, have the light repaired as soon as possible.

DROWSY DRIVER DETECTION
(DDD) — IF EQUIPPED

DDD detects when the driver is feeling fatigued and
warns the driver to pull over and take a break.

To Activate/Deactivate

DDD can be activated and deactivated through the
Uconnect system by selecting the following in order:

1. “Safety & Driving Assistance”

2. “Drowsy Driver Detection”

205

WARNING!

The DDD system is an aid for driving and does not
relieve the driver of the responsibility of driving the
vehicle. Always drive alert and get plenty of rest
before driving. If you experience fatigue while driving,
do not wait for the DDD to intervene with a warning.
Choose a safe and secure location where you can pull
over safely for a break. Only return to the road when
you are in the right physical and mental condition to
prevent endangering yourself and others.

System Operation

Using feedback obtained from the driver’s steering pat-
terns, any buttons/switches that are pressed, and from
the front camera, the system implements two operating
logics:

•

The first operating logic takes the driving style into
account, observing the road and detecting to what
extent the driver can continue driving with few lane
crossing events.

•

The second operating logic measures the time
spent behind the wheel with the vehicle speed
above 40 mph (60 km/h) and below 100 mph
(160 km/h).

If the driving style indicates that the driver is unable to
follow the road trajectory and respect the horizontal
lane markings while within the operating speed range
of the system, a pop up will display on the instrument
cluster display to suggest that the driver should stop for
a break. An audible signal will also sound.

If the driver

accepts

the suggestion provided by the sys-

tem by pushing the “OK” button on the left side of the
steering wheel, the message will disappear from the
display.

If the driver

does not acknowledge

the warning, it will

be displayed for 60 seconds and then disappear.

NOTE:

In the event of a DDD system failure, a dedicated mes-
sage will appear in the instrument cluster display.

REAR SEAT REMINDER ALERT
(RSRA)

RSRA alerts of the possible presence of an object, pas-
senger, or pet in the rear seats through a visual and
auditory notification. When the system is activated, it
displays the message "Check Rear Seat" on the instru-
ment cluster display and sounds an auditory alert upon
the driver placing the ignition in the OFF position to exit
the vehicle. The system will activate automatically if a
rear door is opened within 10 minutes of the ignition
being placed in the ON/RUN position. RSRA should be
used as a reminder to check the rear seats, it does not
directly detect objects, passengers, or pets and is only
activated when the previous conditions are met.

To enable or disable RSRA, see

page 169.

WARNING!

•

Before exiting a vehicle, always come to a com-
plete stop, then shift the automatic transmission
into PARK and apply the parking brake.

•

Always make sure the keyless ignition node is in
the OFF position, key fob is removed from the
vehicle and vehicle is locked.

•

Never leave children alone in a vehicle, or with
access to an unlocked vehicle. Leaving children in
a vehicle unattended is dangerous for a number of
reasons. A child or others could be seriously or
fatally injured. Children should be warned not to
touch the parking brake, brake pedal or the gear
selector.

•

Do not leave children or animals inside parked
vehicles in hot weather. Interior heat buildup may
cause serious injury or death.

ELECTRONIC BRAKE CONTROL
(EBC) SYSTEM

If applicable, refer to the “Hybrid Supplement” for addi-
tional information.

Your vehicle is equipped with an advanced EBC system.
This system includes the Anti-Lock Brake System (ABS),
Brake Assist System (BAS), Electronic Brake Force Dis-
tribution (EBD), Electronic Roll Mitigation (ERM), Elec-
tronic Stability Control (ESC), Hill Start Assist (HSA), and
Traction Control System (TCS). These systems work
together to enhance both vehicle stability and control in
various driving conditions.

Your vehicle may also be equipped with Dynamic Steer-
ing Torque (DST), Rain Brake Support (RBS), Ready
Alert Braking (RAB), and Trailer Sway Control (TSC).

DDD Warning Message

206

SAFETY

Brake Assist System (BAS)

The BAS is designed to optimize the vehicle’s braking
capability during emergency braking maneuvers. The
system detects an emergency braking situation by
sensing the rate and amount of brake application and
then applies optimum pressure to the brakes. This can
help reduce braking distances. The BAS complements
the Anti-Lock Brake System (ABS). Applying the brakes
very quickly results in the best BAS assistance. To
receive the benefit of the system, you must apply con-
tinuous braking pressure during the stopping sequence
(do not “pump” the brakes). Do not reduce brake pedal
pressure unless braking is no longer desired. Once the
brake pedal is released, the BAS is deactivated.

WARNING!

The Brake Assist System (BAS) cannot prevent the
natural laws of physics from acting on the vehicle, nor
can it increase the traction afforded by prevailing
road conditions. BAS cannot prevent collisions,
including those resulting from excessive speed in
turns, driving on very slippery surfaces, or hydroplan-
ing. The capabilities of a BAS-equipped vehicle must
never be exploited in a reckless or dangerous man-
ner, which could jeopardize the user's safety or the
safety of others.

Brake System Warning Light

The red Brake System Warning Light will turn on when
the ignition is placed in the ON/RUN mode and may
stay on for as long as four seconds.

If the Brake System Warning Light remains on or comes
on while driving, it indicates that the brake system is
not functioning properly and that immediate service is
required. If the Brake System Warning Light does not
come on when the ignition is placed in the ON/RUN
mode, have the light repaired as soon as possible.

Electronic Brake Force Distribution

(EBD)

EBD manages the distribution of the braking torque
between the front and rear axles by limiting braking
pressure to the rear axle. This is done to prevent over-
slip of the rear wheels to avoid vehicle instability, and to
prevent the rear axle from entering ABS before the front
axle.

Electronic Roll Mitigation (ERM)

ERM anticipates the potential for wheel lift by monitor-
ing the driver’s steering wheel input and the speed of
the vehicle. When ERM determines that the rate of
change of the steering wheel angle and vehicle’s speed
are sufficient to potentially cause wheel lift, it then
applies the appropriate brake and may also reduce
engine power to lessen the chance that wheel lift will
occur. ERM can only reduce the chance of wheel lift
occurring during severe or evasive driving maneuvers; it
cannot prevent wheel lift due to other factors, such as
road conditions, leaving the roadway, or striking objects
or other vehicles.

NOTE:

ERM is disabled any time the ESC is in “Full Off” mode
(if equipped). See

page 207 for a complete expla-

nation of the available ESC modes.

WARNING!

Many factors, such as vehicle loading, road condi-
tions and driving conditions, influence the chance
that wheel lift or rollover may occur. ERM cannot pre-
vent all wheel lift or rollovers, especially those that
involve leaving the roadway or striking objects or
other vehicles. The capabilities of an ERM-equipped
vehicle must never be exploited in a reckless or dan-
gerous manner which could jeopardize the user's
safety or the safety of others.

Electronic Stability Control (ESC)

ESC enhances directional control and stability of the
vehicle under various driving conditions. ESC corrects
for oversteering or understeering of the vehicle by
applying the brake of the appropriate wheel(s) to assist
in counteracting the following conditions. Engine power
may also be reduced to help the vehicle maintain the
desired path.

•

Oversteer — when the vehicle is turning more than
appropriate for the steering wheel position.

•

Understeer — when the vehicle is turning less than
appropriate for the steering wheel position.

ESC uses sensors in the vehicle to determine the
vehicle path intended by the driver and compares it to
the actual path of the vehicle. When the actual path
does not match the intended path, ESC applies the
brake of the appropriate wheel to assist in counteract-
ing the oversteer or understeer condition.

SAFETY

207

The ESC Activation/Malfunction Indicator Light located
in the instrument cluster will start to flash as soon as
the ESC system becomes active. The ESC Activation/
Malfunction Indicator Light also flashes when the Trac-
tion Control System (TCS) is active. If the ESC
Activation/Malfunction Indicator Light begins to flash
during acceleration, ease up on the accelerator and
apply as little throttle as possible. Be sure to adapt your
speed and driving to the prevailing road conditions.

WARNING!

•

Electronic Stability Control (ESC) cannot prevent the
natural laws of physics from acting on the vehicle,
nor can it increase the traction afforded by prevailing
road conditions. ESC cannot prevent accidents,
including those resulting from excessive speed in
turns, driving on very slippery surfaces, or hydroplan-
ing. ESC also cannot prevent accidents resulting from
loss of vehicle control due to inappropriate driver
input for the conditions. Only a safe, attentive, and
skillful driver can prevent accidents. The capabilities
of an ESC equipped vehicle must never be exploited
in a reckless or dangerous manner which could jeop-
ardize the user’s safety or the safety of others.

•

Vehicle modifications, or failure to properly main-
tain your vehicle, may change the handling charac-
teristics of your vehicle, and may negatively affect
the performance of the ESC system. Changes to
the steering system, suspension, braking system,
tire type and size or wheel size may adversely
affect ESC performance. Improperly inflated and
unevenly worn tires may also degrade ESC perfor-
mance. Any vehicle modification or poor vehicle
maintenance that reduces the effectiveness of the
ESC system can increase the risk of loss of vehicle
control, vehicle rollover, personal injury and death.

ESC Operating Modes

Depending upon model and mode of operation, the ESC
system may have multiple operating modes.

ESC On

This is the normal operating mode for the ESC. When-
ever the vehicle is started, the ESC system will be in
this mode. This mode should be used for most driving
conditions. Alternate ESC modes should only be used
for specific reasons as noted in the following
paragraphs.

Partial Off

This mode may be useful if the vehicle becomes stuck.
This mode may modify TCS and ESC thresholds for acti-
vation, which allows for more wheel spin than normally
allowed.

To enter the “Partial Off” mode, momentarily push the
ESC OFF button and the ESC OFF Indicator Light will
illuminate. To turn the ESC on again, momentarily push
the ESC OFF button and the ESC OFF Indicator Light will
turn off.

NOTE:

For vehicles with multiple partial ESC modes, the push
and release of the button will toggle the ESC modes.
Multiple attempts may be required to return to "ESC On"
mode.

WARNING!

•

When in “Partial Off” mode, the TCS functionality
of ESC (except for the limited slip feature
described in the TCS section) has been disabled
and the ESC OFF Indicator Light will be illuminated.
When in “Partial Off” mode, the engine power
reduction feature of TCS is disabled, and the
enhanced vehicle stability offered by the ESC sys-
tem is reduced.

•

Trailer Sway Control (TSC) is disabled when the
ESC system is in the “Partial Off” mode.

ESC Activation/Malfunction Indicator

Light And ESC OFF Indicator Light

The ESC Activation/Malfunction Indicator
Light in the instrument cluster will come on
when the ignition is placed in the ON/RUN
mode. It should go out with the engine run-

ning. If the ESC Activation/Malfunction Indicator Light
comes on continuously with the engine running, a mal-
function has been detected in the ESC system. If this
light remains on after several ignition cycles, and the
vehicle has been driven several miles (kilometers) at
speeds greater than 30 mph (48 km/h), see an autho-
rized dealer as soon as possible to have the problem
diagnosed and corrected.

The ESC Activation/Malfunction Indicator Light starts to
flash as soon as the tires lose traction and the ESC sys-
tem becomes active. The ESC Activation/Malfunction
Indicator Light also flashes when TCS is active. If the
ESC Activation/Malfunction Indicator Light begins to
flash during acceleration, ease up on the accelerator

208

SAFETY

Jeep Grand Cherokee L (2024 year). Manual in english - page 6
