WARNING!

Pedestrian Emergency Braking (PEB) is not intended
to avoid a collision on its own, nor can PEB detect
every type of potential collision with a pedestrian/
cyclist. The driver has the responsibility to avoid a
collision by controlling the vehicle via braking and
steering. Failure to follow this warning could lead to
serious injury or death.

Turning PEB On Or Off

NOTE:

The default status of PEB is “On.” This allows the sys-
tem to warn you of a possible frontal collision with the
pedestrian/cyclist.

The PEB button is located in the Uconnect display in the
Controls settings

page 133.

To turn the PEB system off, push the Pedestrian Emer-
gency Braking OFF button.

To turn the PEB system back on, push the Warning
Active Braking button.

Changing the PEB status to “Off” deactivates the sys-
tem, so no warning or active braking will be available in
case of a possible frontal collision with the
pedestrian/cyclist.

NOTE:

The PEB system will retain the last setting selected by
the driver after ignition shut down. The system will not
reset to the default setting when the vehicle is
restarted.

TIRE PRESSURE MONITORING
SYSTEM (TPMS)

The TPMS will warn the driver of a low tire pressure
based on the vehicle recommended cold placard
pressure.

The tire pressure will vary with temperature by approxi-
mately 1 psi (7 kPa) for every 12°F (6.5°C). This
means that when the outside temperature decreases,
the tire pressure will decrease. Tire pressure should
always be set based on cold inflation tire pressure. This
is defined as the tire pressure after the vehicle has not
been driven for at least three hours, or driven less than
1 mile (1.6 km) after a three hour period. The cold tire
inflation pressure must not exceed the maximum infla-
tion pressure molded into the tire sidewall. The tire
pressure will also increase as the vehicle is driven. This
is normal and there should be no adjustment for this
increased pressure.

For more information on how to properly inflate the
vehicle’s tires, see

page 236.

The TPMS will warn the driver of a low tire pressure if
the tire pressure falls below the low pressure warning
limit for any reason, including low temperature effects
and natural pressure loss through the tire. The TPMS
will continue to warn the driver of low tire pressure as
long as the condition exists, and will not turn off until
the tire pressure is at or above the recommended cold
placard pressure.

NOTE:

Once the low tire pressure warning (Tire Pressure Moni-
toring System Warning Light) illuminates, you must
increase the tire pressure to the recommended cold
placard pressure in order for the Tire Pressure Monitor-
ing System Warning Light to turn off.

The system will automatically update and the Tire Pres-
sure Monitoring System Warning Light will turn off once
the system receives the updated tire pressures. The
vehicle may need to be driven for up to 20 minutes
above 15 mph (24 km/h) in order for the TPMS to
receive this information.

For example, your vehicle may have a recommended
cold (parked for more than three hours) placard pres-
sure of 33 psi (227 kPa). If the ambient temperature is
68°F (20°C) and the measured tire pressure is 28 psi
(193 kPa), a temperature drop to 20°F (-7°C) will
decrease the tire pressure to approximately 24 psi
(165 kPa). This tire pressure is low enough to turn on
the Tire Pressure Monitoring System Warning Light.
Driving the vehicle may cause the tire pressure to rise
to approximately 28 psi (193 kPa), but the Tire Pres-
sure Monitoring System Warning Light will still be on. In
this situation, the Tire Pressure Monitoring System
Warning Light will turn off only after the tires are
inflated to the vehicle’s recommended cold placard
pressure value

page 259.

NOTE:

CAUTION!

•

The TPMS has been optimized for the original
equipment tires and wheels. TPMS pressures and
warning have been established for the tire size
equipped on your vehicle. Undesirable system
operation or sensor damage may result when
using replacement equipment that is not of the

(Continued)

162

SAFETY

CAUTION!

same size, type, and/or style. The TPMS sensor is
not designed for use on aftermarket wheels and
may contribute to a poor overall system perfor-
mance or sensor damage. Customers are encour-
aged to use Original Equipment Manufacturer
(OEM) wheels to ensure proper TPMS feature
operation.

•

Using aftermarket tire sealants may cause the Tire
Pressure Monitoring System (TPMS) sensor to
become inoperable. After using an aftermarket tire
sealant it is recommended that you take your
vehicle to an authorized dealer to have your sensor
function checked.

•

After inspecting or adjusting the tire pressure
always reinstall the valve stem cap. This will pre-
vent moisture and dirt from entering the valve
stem, which could damage the TPMS sensor.

NOTE:

•

The TPMS is not intended to replace normal tire
care and maintenance, or to provide warning of a
tire failure or condition.

•

The TPMS should not be used as a tire pressure
gauge while adjusting your tire pressure.

•

Driving on a significantly underinflated tire causes
the tire to overheat and can lead to tire failure.
Underinflation also reduces fuel efficiency and tire
tread life, and may affect the vehicle’s handling and
stopping ability.

•

The TPMS is not a substitute for proper tire mainte-
nance, and it is the driver’s responsibility to main-
tain correct tire pressure using an accurate tire

pressure gauge, even if underinflation has not
reached the level to trigger illumination of the Tire
Pressure Monitoring System Warning Light.

•

Seasonal temperature changes will affect tire pres-
sure, and the TPMS will monitor the actual tire pres-
sure in the tire.

Premium System

The Tire Pressure Monitoring System (TPMS) uses wire-
less technology with wheel rim mounted electronic sen-
sors to monitor tire pressure levels. Sensors, mounted
to each wheel as part of the valve stem, transmit tire
pressure readings to the receiver module.

NOTE:

It is particularly important for you to check the tire pres-
sure in all of the tires on your vehicle monthly and to
maintain the proper pressure.

The TPMS consists of the following components:

•

Receiver module

•

Four Tire Pressure Monitoring System sensors

•

Various Tire Pressure Monitoring System messages,
which will display in the instrument cluster display

•

Tire Pressure Monitoring System Warning Light

Tire Pressure Monitoring System Low

Pressure Warnings

The Tire Pressure Monitoring System
Warning Light will illuminate in the instru-
ment cluster and a chime will sound when
tire pressure is low in one or more of the four

active road tires. In addition, the instrument cluster will
display a "Tire Low" message, an “Inflate to XX” mes-
sage, and a graphic showing the pressure values of
each tire with the low tire pressure values highlighted
or in a different color.

Should this occur, you should stop as soon as possible
and inflate the tires with low pressure (those high-
lighted or in a different color in the instrument cluster
display graphic) to the vehicle’s recommended cold
placard pressure value, as shown in the “Inflate to XX”
message. Once the system receives the updated tire
pressures, the system will automatically update, the
pressure values in the graphic display in the instrument
cluster will stop being highlighted or return to their origi-
nal color, and the Tire Pressure Monitoring System
Warning Light will turn off.

NOTE:

When filling warm tires, the tire pressure may need to
be increased up to an additional 4 psi (28 kPa) above
the recommended cold placard pressure in order to
turn the Tire Pressure Monitoring System Warning Light
off.The vehicle may need to be driven for up to 20 min-
utes above 15 mph (24 km/h) in order for the TPMS to
receive this information.

Tire Pressure Monitoring System Low Pressure Warning

SAFETY

163

Service TPMS Warning

When a system fault is detected, the Tire Pressure
Monitoring System Warning Light will flash on and off
for 75 seconds and then remain on solid. The system
fault will also sound a chime. In addition, the instru-
ment cluster will display a "SERVICE TPM SYSTEM" mes-
sage for a minimum of five seconds and then display
dashes (--) in place of the pressure value to indicate
which sensor is not being received.

If the ignition key is cycled, this sequence will repeat,
providing the system fault still exists. If the system fault
no longer exists, the Tire Pressure Monitoring System
Warning Light will no longer flash, and the “SERVICE
TPM SYSTEM” message will no longer display, and a
pressure value will display in place of the dashes. A
system fault can occur due to any of the following:

•

Jamming due to electronic devices or driving next to
facilities emitting the same radio frequencies as the
TPMS sensors

•

Installing some form of aftermarket window tinting
that affects radio wave signals

•

Lots of snow or ice around the wheels or wheel
housings

•

Using tire chains on the vehicle

•

Using wheels/tires not equipped with TPMS sensors

Vehicles With Compact Spare Or Non-Matching Full
Size Spare

1. The compact spare tire or non-matching full size

does not have a Tire Pressure Monitoring System
sensor. Therefore, the TPMS will not monitor the
pressure in the compact or non-matching full size
spare tire.

2. If you install the compact or non-matching full size

spare tire in place of a road tire that has a pressure
below the low-pressure warning limit, upon the next
ignition key cycle, the Tire Pressure Monitoring Sys-
tem Warning Light will remain on and a chime will
sound. In addition, the graphic in the instrument
cluster will still display a different color or high-
lighted pressure value and the “Inflate to XX”
message.

3. After driving the vehicle for up to 20 minutes above

15 mph (24 km/h), the Tire Pressure Monitoring
System Warning Light will flash on and off for
75 seconds and then remain on solid. In addition,
the instrument cluster will display a “SERVICE TPM
SYSTEM” message for five seconds and then display
dashes (--) in place of the pressure value.

4. For each subsequent ignition key cycle, a chime will

sound, the Tire Pressure Monitoring System Warning
Light will flash on and off for 75 seconds and then
remain on solid, and the instrument cluster will dis-
play a “SERVICE TPM SYSTEM” message for five
seconds and then display dashes (--) in place of the
pressure value.

5. Once you repair or replace the original road tire and

reinstall it on the vehicle in place of the compact
spare or non-matching full size, the TPMS will
update automatically. In addition, the Tire Pressure
Monitoring System Warning Light will turn off and
the graphic in the instrument cluster will display a
new pressure value instead of dashes (--), as long as
no tire pressure is below the low-pressure warning
limit in any of the four active road tires. The vehicle
may need to be driven for up to 20 minutes above
15 mph (24 km/h) in order for the TPMS to receive
this information.

TPMS Deactivation — If Equipped

The TPMS can be deactivated if replacing all four wheel
and tire assemblies (road tires) with wheel and tire
assemblies that do not have TPMS sensors, such as
when installing winter wheel and tire assemblies on
your vehicle.

To deactivate the TPMS, first replace all four wheel and
tire assemblies (road tires) with tires not equipped with
Tire Pressure Monitoring System (TPMS) sensors. Then,
drive the vehicle for 20 minutes above 15 mph
(24 km/h). The TPMS will chime, the Tire Pressure
Monitoring System Warning Light will flash on and off
for 75 seconds and then remain on. The instrument
cluster will display the “SERVICE TPM SYSTEM” mes-
sage and then display dashes (--) in place of the pres-
sure values.

Beginning with the next ignition cycle, the TPMS will no
longer chime or display the “SERVICE TPM SYSTEM”
message in the instrument cluster but dashes (--) will
remain in place of the pressure values.

To reactivate the TPMS, replace all four wheel and tire
assemblies (road tires) with tires equipped with TPMS
sensors. Then, drive the vehicle for up to 20 minutes
above 15 mph (24 km/h). The TPMS will chime, the Tire
Pressure Monitoring System Warning Light will flash on
and off for 75 seconds and then turn off. The instru-
ment cluster will display the “SERVICE TPM SYSTEM”
message and then display pressure values in place of
the dashes. On the next ignition cycle the "SERVICE
TPM SYSTEM" message will no longer be displayed as
long as no system fault exists.

164

SAFETY

OCCUPANT RESTRAINT SYSTEMS

Some of the most important safety features in your
vehicle are the restraint systems:

OCCUPANT RESTRAINT SYSTEMS
FEATURES
•

Seat Belt Systems

•

Supplemental Restraint Systems (SRS) Air Bags

•

Child Restraints

Some of the safety features described in this section
may be standard equipment on some models, or may
be optional equipment on others. If you are not sure,
ask an authorized dealer.

IMPORTANT SAFETY PRECAUTIONS

Please pay close attention to the information in this
section. It tells you how to use your restraint system
properly, to keep you and your passengers as safe as
possible.

Here are some simple steps you can take to minimize
the risk of harm from a deploying air bag:

1. Children 12 years old and under should always ride

buckled up in the rear seat of a vehicle with a rear
seat.

2. A child who is not big enough to wear the vehicle

seat belt properly must be secured in the appropri-
ate child restraint or belt-positioning booster seat in
a rear seating position

page 181.

3. If a child from 2 to 12 years old (not in a rear-facing

child restraint) must ride in the front passenger
seat, move the seat as far back as possible and use
the proper child restraint

page 181.

4. Never allow children to slide the shoulder belt

behind them or under their arm.

5. You should read the instructions provided with your

child restraint to make sure that you are using it
properly.

6. All occupants should always wear their lap and

shoulder belts properly.

7. The driver and front passenger seats should be

moved back as far as practical to allow the front air
bags room to inflate.

8. Do not lean against the door or window. If your

vehicle has side air bags, and deployment occurs,
the side air bags will inflate forcefully into the space
between occupants and the door and occupants
could be injured.

9. If the air bag system in this vehicle needs to be

modified to accommodate a disabled person, see

page 256 for customer service contact

information.

WARNING!

•

Never place a rear-facing child restraint in front of
an air bag. A deploying passenger front air bag can
cause death or serious injury to a child 12 years or
younger, including a child in a rear-facing child
restraint.

•

Never install a rear-facing child restraint in the
front seat of a vehicle. Only use a rear-facing child
restraint in the rear seat. If the vehicle does not
have a rear seat, do not transport a rear-facing
child restraint in that vehicle.

SEAT BELT SYSTEMS

Buckle up even though you are an excellent driver, even
on short trips. Someone on the road may be a poor
driver and could cause a collision that includes you.
This can happen far away from home or on your own
street.

Research has shown that seat belts save lives, and they
can reduce the seriousness of injuries in a collision.
Some of the worst injuries happen when people are
thrown from the vehicle. Seat belts reduce the possibil-
ity of ejection and the risk of injury caused by striking
the inside of the vehicle. Everyone in a motor vehicle
should be belted at all times.

Enhanced Seat Belt Use Reminder

System (BeltAlert)

Driver And Passenger BeltAlert — If Equipped

BeltAlert is a feature intended to remind the
driver and outboard front seat passenger
(if equipped with outboard front passenger
seat BeltAlert) to buckle their seat belts. The

BeltAlert feature is active whenever the ignition switch
is in the START or ON/RUN position.

Initial Indication

If the driver is unbuckled when the ignition switch is
first in the START or ON/RUN position, a chime will sig-
nal for a few seconds. If the driver or outboard front
seat passenger (if equipped with outboard front pas-
senger seat BeltAlert) is unbuckled when the ignition
switch is first in the START or ON/RUN position the Seat
Belt Reminder Light will turn on and remain on until
both outboard front seat belts are buckled. The out-
board front passenger seat BeltAlert is not active when
an outboard front passenger seat is unoccupied.

SAFETY

165

BeltAlert Warning Sequence

The BeltAlert warning sequence is activated when the
vehicle is moving above a specified vehicle speed range
and the driver or outboard front seat passenger is
unbuckled (if equipped with outboard front passenger
seat BeltAlert) (the outboard front passenger seat
BeltAlert is not active when the outboard front passen-
ger seat is unoccupied). The BeltAlert warning
sequence starts by blinking the Seat Belt Reminder
Light and sounding an intermittent chime. Once the
BeltAlert warning sequence has completed, the Seat
Belt Reminder Light will remain on until the seat belts
are buckled. The BeltAlert warning sequence may
repeat based on vehicle speed until the driver and
occupied outboard front seat passenger seat belts are
buckled. The driver should instruct all occupants to
buckle their seat belts.

Change Of Status

If the driver or outboard front seat passenger
(if equipped with outboard front passenger seat
BeltAlert) unbuckles their seat belt while the vehicle is
traveling, the BeltAlert warning sequence will begin
until the seat belts are buckled again.

The outboard front passenger seat BeltAlert is not
active when the outboard front passenger seat is unoc-
cupied. BeltAlert may be triggered when an animal or
other items are placed on the outboard front passenger
seat or when the seat is folded flat (if equipped). It is
recommended that pets be restrained in the rear seat
(if equipped) in pet harnesses or pet carriers that are
secured by seat belts, and cargo is properly stowed.

BeltAlert can be activated or deactivated by an autho-
rized dealer. FCA US LLC does not recommend deacti-
vating BeltAlert.

NOTE:

If BeltAlert has been deactivated and the driver or out-
board front seat passenger (if equipped with outboard
front passenger seat BeltAlert) is unbuckled the Seat
Belt Reminder Light will turn on and remain on until the
driver and outboard front seat passenger seat belts are
buckled.

Lap/Shoulder Belts

All seating positions in your vehicle are equipped with
lap/shoulder belts.

The seat belt webbing retractor will lock only during
very sudden stops or collisions. This feature allows the
shoulder part of the seat belt to move freely with you
under normal conditions. However, in a collision the
seat belt will lock and reduce your risk of striking the
inside of the vehicle or being thrown out of the vehicle.

WARNING!

•

Relying on the air bags alone could lead to more
severe injuries in a collision. The air bags work with
your seat belt to restrain you properly. In some col-
lisions, the air bags won’t deploy at all. Always
wear your seat belt even though you have air bags.

•

In a collision, you and your passengers can suffer
much greater injuries if you are not properly buck-
led up. You can strike the interior of your vehicle or
other passengers, or you can be thrown out of the
vehicle. Always be sure you and others in your
vehicle are buckled up properly.

•

It is dangerous to ride in a cargo area, inside or
outside of a vehicle. In a collision, people riding in
these areas are more likely to be seriously injured
or killed.

(Continued)

WARNING!

•

Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat
belts.

•

Be sure everyone in your vehicle is in a seat and
using a seat belt properly. Occupants, including the
driver, should always wear their seat belts whether
or not an air bag is also provided at their seating
position to minimize the risk of severe injury or
death in the event of a crash.

•

Wearing your seat belt incorrectly could make your
injuries in a collision much worse. You might suffer
internal injuries, or you could even slide out of the
seat belt. Follow these instructions to wear your
seat belt safely and to keep your passengers safe,
too.

•

Two people should never be belted into a single
seat belt. People belted together can crash into
one another in a collision, hurting one another
badly. Never use a lap/shoulder belt or a lap belt
for more than one person, no matter what their
size.

WARNING!

•

A lap belt worn too high can increase the risk of
injury in a collision. The seat belt forces won’t be at
the strong hip and pelvic bones, but across your
abdomen. Always wear the lap part of your seat
belt as low as possible and keep it snug.

(Continued)

166

SAFETY

WARNING!

•

A twisted seat belt may not protect you properly. In
a collision, it could even cut into you. Be sure the
seat belt is flat against your body, without twists. If
you can’t straighten a seat belt in your vehicle,
take it to an authorized dealer immediately and
have it fixed.

•

A seat belt that is buckled into the wrong buckle
will not protect you properly. The lap portion could
ride too high on your body, possibly causing inter-
nal injuries. Always buckle your seat belt into the
buckle nearest you.

•

A seat belt that is too loose will not protect you
properly. In a sudden stop, you could move too far
forward, increasing the possibility of injury. Wear
your seat belt snugly.

•

A seat belt that is worn under your arm is danger-
ous. Your body could strike the inside surfaces of
the vehicle in a collision, increasing head and neck
injury. A seat belt worn under the arm can cause
internal injuries. Ribs aren’t as strong as shoulder
bones. Wear the seat belt over your shoulder so
that your strongest bones will take the force in a
collision.

•

A shoulder belt placed behind you will not protect
you from injury during a collision. You are more
likely to hit your head in a collision if you do not
wear your shoulder belt. The lap and shoulder belt
are meant to be used together.

•

A frayed or torn seat belt could rip apart in a colli-
sion and leave you with no protection. Inspect the
seat belt system periodically, checking for cuts,
frays, or loose parts. Damaged parts must be
replaced immediately. Do not disassemble or

(Continued)

WARNING!

modify the seat belt system. If your vehicle is
involved in a collision, or if you have questions
regarding seat belt or retractor conditions, take
your vehicle to an authorized FCA dealer or autho-
rized FCA Certified Collision Care Program facility
for inspection.

Lap/Shoulder Belt Operating

Instructions

1. Enter the vehicle and close the door. Sit back and

adjust the seat.

2. The seat belt latch plate is above the back of the

front seat, and next to your arm in the rear seat (for
vehicles equipped with a rear seat). Grab the latch
plate and pull out the seat belt. Slide the latch plate
up the webbing as far as necessary to allow the seat
belt to go around your lap.

3. When the seat belt is long enough to fit, insert the

latch plate into the buckle until you hear a “click”.

4. Position the lap belt so that it is snug and lies low

across your hips, below your abdomen. To remove
slack in the lap belt portion, pull up on the shoulder
belt. To loosen the lap belt if it is too tight, tilt the latch
plate and pull on the lap belt. A snug seat belt reduces
the risk of sliding under the seat belt in a collision.

Pulling Out The Latch Plate

Inserting Latch Plate Into Buckle

Positioning The Lap Belt

SAFETY

167

5. Position the shoulder belt across the shoulder and

chest with minimal, if any slack so that it is comfort-
able and not resting on your neck. The retractor will
withdraw any slack in the shoulder belt.

6. To release the seat belt, push the red button on the

buckle. The seat belt will automatically retract to its
stowed position. If necessary, slide the latch plate
down the webbing to allow the seat belt to retract
fully.

Lap/Shoulder Belt Untwisting Procedure

Use the following procedure to untwist a twisted lap/
shoulder belt.

1. Position the latch plate as close as possible to the

anchor point.

2. At about 6 to 12 inches (15 to 30 cm) above the

latch plate, grab and twist the seat belt webbing
180 degrees to create a fold that begins immedi-
ately above the latch plate.

3. Slide the latch plate upward over the folded web-

bing. The folded webbing must enter the slot at the
top of the latch plate.

4. Continue to slide the latch plate up until it clears the

folded webbing and the seat belt is no longer
twisted.

Adjustable Upper Shoulder Belt

Anchorage

In the driver and outboard front passenger seats, the
top of the shoulder belt can be adjusted upward or
downward to position the seat belt away from your
neck. Push or squeeze the anchorage button to release
the anchorage, and move it up or down to the position
that serves you best.

As a guide, if you are shorter than average, you will pre-
fer the shoulder belt anchorage in a lower position, and
if you are taller than average, you will prefer the shoul-
der belt anchorage in a higher position. After you
release the anchorage button, try to move it up or down
to make sure that it is locked in position.

NOTE:

The adjustable upper shoulder belt anchorage is
equipped with an Easy Up feature. This feature allows
the shoulder belt anchorage to be adjusted in the
upward position without pushing or squeezing the
release button. To verify the shoulder belt anchorage is
latched, pull downward on the shoulder belt anchorage
until it is locked into position.

WARNING!

•

Wearing your seat belt incorrectly could make your
injuries in a collision much worse. You might suffer
internal injuries, or you could even slide out of the
seat belt. Follow these instructions to wear your seat
belt safely and to keep your passengers safe, too.

(Continued)

WARNING!

•

Position the shoulder belt across the shoulder and
chest with minimal, if any slack so that it is com-
fortable and not resting on your neck. The retractor
will withdraw any slack in the shoulder belt.

•

Misadjustment of the seat belt could reduce the
effectiveness of the safety belt in a crash.

•

Always make all seat belt height adjustments when
the vehicle is stationary.

Second Row Center Seat Belt Operating

Instructions

The second row center seat belt may feature a seat belt
with a mini-latch plate and buckle. The mini-latch plate
and buckle (if equipped) should remain connected at all
times. If the mini-latch plate and buckle become dis-
connected, they must be properly reconnected prior to
the rear center seat belt being used by an occupant.

1. Grab the mini-latch plate and pull the seat belt over

the seat.

Adjustable Anchorage

Pulling Out The Latch Plate

168

SAFETY

2. When the seat belt is long enough to fit, insert the

mini-latch plate into the mini-buckle until you hear a
“click.”

3. Sit back in seat. Slide the regular latch plate up the

webbing as far as necessary to allow the seat belt to
go around your lap.

4. When the seat belt is long enough to fit, insert the

latch plate into the buckle until you hear a “click.”

5. Position the lap belt so that it is snug and lies low

across your hips, below your abdomen. To remove
slack in the lap belt portion, pull up on the shoulder
belt. To loosen the lap belt if it is too tight, pull on
the lap belt. A snug seat belt reduces the risk of
sliding under the seat belt in a collision.

6. Position the shoulder belt on your chest so that it is

comfortable and not resting on your neck. The
retractor will withdraw any slack in the seat belt.

7. To release the seat belt, push the red button on the

buckle.

8. To disengage the mini-latch plate from the mini-

buckle, insert the regular latch plate into the center
red slot on the mini-buckle.

WARNING!

•

If the mini-latch plate and mini-buckle are not
properly connected when the seat belt is used by
an occupant, the seat belt will not be able to pro-
vide proper restraint and will increase the risk of
injury in a collision.

•

When reattaching the mini-latch plate and mini-
buckle, ensure the seat belt webbing is not
twisted. If the webbing is twisted, follow the pre-
ceding procedure to detach the mini-latch plate
and mini-buckle, untwist the webbing, and reat-
tach the mini-latch plate and mini-buckle.

Seat Belt Extender

If a seat belt is not long enough to fit properly, even
when the webbing is fully extended and the adjustable
upper shoulder belt anchorage (if equipped) is in its
lowest position, an authorized dealer can provide you
with a Seat Belt Extender. The Seat Belt Extender

Inserting Mini-Latch Plate Into Mini-Buckle

Inserting Latch Plate Into Buckle

Detaching Mini-Buckle With Seat Belt Tongue

SAFETY

169

should be used only if the existing seat belt is not long
enough. When the Seat Belt Extender is not required for
a different occupant, it must be removed.

WARNING!

•

ONLY use a Seat Belt Extender if it is physically
required in order to properly fit the original seat
belt system. DO NOT USE the Seat Belt Extender if,
when worn, the distance between the front edge of
the Seat Belt Extender buckle and the center of
the occupant’s body is LESS than 6 inches.

•

Using a Seat Belt Extender when not needed can
increase the risk of serious injury or death in a
collision. Only use the Seat Belt Extender when the
lap belt is not long enough and only use in the rec-
ommended seating positions. Remove and store
the Seat Belt Extender when not needed.

Seat Belts And Pregnant Women

Seat belts must be worn by all occupants including
pregnant women: the risk of injury in the event of an
accident is reduced for the mother and the unborn child
if they are wearing a seat belt.

Position the lap belt snug and low below the abdomen
and across the strong bones of the hips. Place the
shoulder belt across the chest and away from the neck.
Never place the shoulder belt behind the back or under
the arm.

Seat Belt Pretensioner

The front outboard seat belt system is equipped with
pretensioning devices that are designed to remove
slack from the seat belt in the event of a collision.
These devices may improve the performance of the
seat belt by removing slack from the seat belt early in a
collision. Pretensioners work for all size occupants,
including those in child restraints.

NOTE:

These devices are not a substitute for proper seat belt
placement by the occupant. The seat belt still must be
worn snugly and positioned properly.

The pretensioners are triggered by the Occupant
Restraint Controller (ORC). Like the air bags, the preten-
sioners are single use items. A deployed pretensioner
or a deployed air bag must be replaced immediately.

Energy Management Feature

The front outboard seat belt system is equipped with an
Energy Management feature that may help further
reduce the risk of injury in the event of a collision. The
seat belt system has a retractor assembly that is
designed to release webbing in a controlled manner.

Switchable Automatic Locking

Retractors (ALR)

The seat belts in the passenger seating positions are
equipped with a Switchable Automatic Locking Retrac-
tor (ALR) which is used to secure a child restraint sys-
tem

page 187.

The figure below illustrates the locking feature for each
seating position.

If the passenger seating position is equipped with an
ALR and is being used for normal usage, only pull the
seat belt webbing out far enough to comfortably wrap
around the occupant’s mid-section so as to not activate
the ALR. If the ALR is activated, you will hear a clicking
sound as the seat belt retracts. Allow the webbing to
retract completely in this case and then carefully pull
out only the amount of webbing necessary to comfort-
ably wrap around the occupant’s mid-section. Slide the
latch plate into the buckle until you hear a "click."

In Automatic Locking Mode, the shoulder belt is auto-
matically pre-locked. The seat belt will still retract to
remove any slack in the shoulder belt. Use the Auto-
matic Locking Mode anytime a child restraint is

Seat Belts And Pregnant Women

Switchable Automatic Locking Retractor (ALR) Locations

170

SAFETY

installed in a seating position that has a seat belt with
this feature. Children 12 years old and under should
always be properly restrained in the rear seat of a
vehicle with a rear seat.

WARNING!

•

How To Engage The Automatic Locking Mode

1. Buckle the combination lap and shoulder belt.

2. Grab the shoulder portion and pull downward until

the entire seat belt is extracted.

3. Allow the seat belt to retract. As the seat belt

retracts, you will hear a clicking sound. This indi-
cates the seat belt is now in the Automatic Locking
Mode.

How To Disengage The Automatic Locking Mode

Unbuckle the combination lap/shoulder belt and allow
it to retract completely to disengage the Automatic
Locking Mode and activate the vehicle sensitive (emer-
gency) locking mode.

WARNING!

•

The seat belt assembly must be replaced if the
switchable Automatic Locking Retractor (ALR) fea-
ture or any other seat belt function is not working
properly when checked according to the proce-
dures in the Service Manual.

•

Failure to replace the seat belt assembly could
increase the risk of injury in collisions.

•

Do not use the Automatic Locking Mode to restrain
occupants who are wearing the seat belt or chil-
dren who are using booster seats. The locked
mode is only used to install rear-facing or forward-
facing child restraints that have a harness for
restraining the child.

SUPPLEMENTAL RESTRAINT
SYSTEMS (SRS)

Some of the safety features described in this section
may be standard equipment on some models, or may
be optional equipment on others. If you are not sure,
ask an authorized dealer.

The air bag system must be ready to protect you in a
collision. The Occupant Restraint Controller (ORC) moni-
tors the internal circuits and interconnecting wiring
associated with the electrical Air Bag System Compo-
nents. Your vehicle may be equipped with the following
Air Bag System Components:

Air Bag System Components

•

Occupant Restraint Controller (ORC)

•

Air Bag Warning Light

•

Steering Wheel and Column

•

Instrument Panel

•

Knee Impact Bolsters

•

Driver and Front Passenger Air Bags

•

Seat Belt Buckle Switch

•

Supplemental Side Air Bags

•

Supplemental Knee Air Bags

•

Front and Side Impact Sensors

•

Seat Belt Pretensioners

•

Seat Track Position Sensors

•

Occupant Classification System

Air Bag Warning Light

The Occupant Restraint Controller (ORC)
monitors the readiness of the electronic
parts of the air bag system whenever the
ignition switch is in the START or ON/RUN

position. If the ignition switch is in the OFF position, the
air bag system is not on and the air bags will not inflate.

The ORC contains a backup power supply system that
may deploy the air bag system even if the battery loses
power or it becomes disconnected prior to deployment.

The ORC turns on the Air Bag Warning Light in the
instrument panel for approximately four to eight sec-
onds for a self-check when the ignition switch is first in
the ON/RUN position. After the self-check, the Air Bag
Warning Light will turn off. If the ORC detects a mal-
function in any part of the system, it turns on the Air
Bag Warning Light, either momentarily or continuously.
A single chime will sound to alert you if the light comes
on again after initial startup.

The ORC also includes diagnostics that will illuminate
the instrument panel Air Bag Warning Light if a malfunc-
tion is detected that could affect the air bag system. The
diagnostics also record the nature of the malfunction.

SAFETY

171

While the air bag system is designed to be maintenance
free, if any of the following occurs, have an authorized
dealer service the air bag system immediately.

•

The Air Bag Warning Light does not come on during
the four to eight seconds when the ignition switch is
first in the ON/RUN position.

•

The Air Bag Warning Light remains on after the four
to eight-second interval.

•

The Air Bag Warning Light comes on intermittently or
remains on while driving.

NOTE:

If the speedometer, tachometer, or any engine related
gauges are not working, the Occupant Restraint Control-
ler (ORC) may also be disabled. In this condition the air
bags may not be ready to inflate for your protection.
Have an authorized dealer service the air bag system
immediately.

WARNING!

Ignoring the Air Bag Warning Light in your instrument
panel could mean you won’t have the air bag system
to protect you in a collision. If the light does not come
on as a bulb check when the ignition is first turned
on, stays on after you start the vehicle, or if it comes
on as you drive, have an authorized dealer service
the air bag system immediately.

Redundant Air Bag Warning Light

If a fault with the Air Bag Warning Light is
detected, which could affect the Supplemen-
tal Restraint System (SRS), the Redundant
Air Bag Warning Light will illuminate on the

instrument panel. The Redundant Air Bag Warning Light

will stay on until the fault is cleared. In addition, a
single chime will sound to alert you that the Redundant
Air Bag Warning Light has come on and a fault has
been detected. If the Redundant Air Bag Warning Light
comes on intermittently or remains on while driving
have an authorized dealer service the vehicle immedi-
ately

page 74.

Front Air Bags

This vehicle has front air bags and lap/shoulder belts
for both the driver and front passenger. The front air
bags are a supplement to the seat belt restraint sys-
tems. The driver front air bag is mounted in the center
of the steering wheel. The passenger front air bag is
mounted in the instrument panel, above the glove com-
partment. The words “SRS AIRBAG” or “AIRBAG” are
embossed on the air bag covers.

WARNING!

•

Being too close to the steering wheel or instrument
panel during front air bag deployment could cause
serious injury, including death. Air bags need room
to inflate. Sit back, comfortably extending your
arms to reach the steering wheel or instrument
panel.

•

Driver And Passenger Front Air Bag

Features

The Advanced Front Air Bag system has multistage
driver and front passenger air bags. This system pro-
vides output appropriate to the severity and type of col-
lision as determined by the Occupant Restraint Control-
ler (ORC), which may receive information from the front
impact sensors (if equipped) or other system
components.

The first stage inflator is triggered immediately during
an impact that requires air bag deployment. A low
energy output is used in less severe collisions. A higher
energy output is used for more severe collisions.

Front Air Bag/Knee Bolster Locations

1 — Driver And Passenger Front Air Bags
2 — Driver Knee Impact Bolster/Supplemental Driver
Knee Air Bag
3 — Passenger Knee Impact Bolster

172

SAFETY

This vehicle may be equipped with a driver and/or front
passenger seat belt buckle switch that detects whether
the driver or front passenger seat belt is buckled. The
seat belt buckle switch may adjust the inflation rate of
the Advanced Front Air Bags.

This vehicle may be equipped with driver and/or front
passenger seat track position sensors that may adjust
the inflation rate of the Advanced Front Air Bags based
upon seat position.

This vehicle is equipped with a right front passenger
Occupant Classification System (OCS) that is designed
to provide Passenger Advanced Front Air Bag output
appropriate to the occupant’s seated weight input, as
determined by the OCS.

WARNING!

•

No objects should be placed over or near the air
bag on the instrument panel or steering wheel
because any such objects could cause harm if the
vehicle is in a collision severe enough to cause the
air bag to inflate.

•

Do not put anything on or around the air bag cov-
ers or attempt to open them manually. You may
damage the air bags and you could be injured
because the air bags may no longer be functional.
The protective covers for the air bag cushions are
designed to open only when the air bags are
inflating.

•

Relying on the air bags alone could lead to more
severe injuries in a collision. The air bags work with
your seat belt to restrain you properly. In some col-
lisions, air bags won’t deploy at all. Always wear
your seat belts even though you have air bags.

Front Air Bag Operation

Front Air Bags are designed to provide additional pro-
tection by supplementing the seat belts. Front air bags
are not expected to reduce the risk of injury in rear,
side, or rollover collisions. The front air bags will not
deploy in all frontal collisions, including some that may
produce substantial vehicle damage — for example,
some pole collisions, truck underrides, and angle offset
collisions.

On the other hand, depending on the type and location
of impact, front air bags may deploy in crashes with
little vehicle front-end damage but that produce a
severe initial deceleration.

Because air bag sensors measure vehicle deceleration
over time, vehicle speed and damage by themselves
are not good indicators of whether or not an air bag
should have deployed.

Seat belts are necessary for your protection in all colli-
sions, and also are needed to help keep you in position,
away from an inflating air bag.

When the Occupant Restraint Controller (ORC) detects a
collision requiring the front air bags, it signals the infla-
tor units. A large quantity of non-toxic gas is generated
to inflate the front air bags.

The steering wheel hub trim cover and the upper pas-
senger side of the instrument panel separate and fold
out of the way as the air bags inflate to their full size.
The front air bags fully inflate in less time than it takes
to blink your eyes. The front air bags then quickly
deflate while helping to restrain the driver and front
passenger.

Occupant Classification System (OCS) —

Front Passenger Seat

The Occupant Classification System (OCS) is part of a
Federally regulated safety system for this vehicle. It is
designed to provide Passenger Advanced Front Air Bag
output appropriate to the occupant’s seated weight, as
determined by the OCS.

The Occupant Classification System (OCS) consists of
the following:

•

Occupant Restraint Controller (ORC)

•

Occupant Classification Module (OCM) and Sensor
located in the front passenger seat

•

Air Bag Warning Light

Occupant Classification Module (OCM) And Sensor

The Occupant Classification Module (OCM) is located
underneath the front passenger seat. The Sensor is
located beneath the passenger seat cushion foam. Any
weight on the seat will be sensed by the Sensor. The
OCM uses input from the Sensor to determine the front
passenger’s most probable classification. The OCM
communicates this information to the ORC. The ORC
may reduce the inflation rate of the Passenger
Advanced Front Air Bag deployment based on occupant
classification. In order for the OCS to operate as
designed, it is important for the front passenger to be
seated properly and properly wearing the seat belt.

The OCS will NOT prevent deployment of the Passenger
Advanced Front Air Bag. The OCS may reduce the infla-
tion rate of the Passenger Advanced Front Air Bag if the
OCS estimates that:

•

The front passenger seat is unoccupied or has very
light objects on it; or

•

The front passenger seat is occupied by a small pas-
senger, including a child; or

SAFETY

173

•

The front passenger seat is occupied by a rear-
facing child restraint; or

•

The front passenger is not properly seated or his or
her weight is taken off of the seat for a period of
time.

Front Passenger Seat

Occupant Status

Front Passenger Air

Bag Output

Rear-facing child restraint Reduced-power

deployment

Child, including a child in
a forward-facing child
restraint or booster seat*

Reduced-power deploy-
ment OR Full-power
deployment

Properly seated adult

Full-power deployment
OR reduced-power
deployment

Unoccupied seat

Reduced-power
deployment

* It is possible for a child to be classified as an adult,
allowing a full-power Passenger Advanced Front Air Bag
deployment. Never allow children to ride in the front
passenger seat and never install a child restraint sys-
tem, including a rear-facing child restraint, in the front
passenger seat.

WARNING!

•

(Continued)

WARNING!

•

Children 12 years or younger should always ride
buckled up in the rear seat of a vehicle with a rear
seat.

The OCS determines the front passenger’s most prob-
able classification. The OCS estimates the seated
weight on the front passenger seat and where that
weight is located. The OCS communicates the classifi-
cation status to the ORC. The ORC uses the classifica-
tion to determine whether the Passenger Advanced
Front Air Bag inflation rate should be adjusted.

In order for the OCS to operate as designed, it is impor-
tant for the front passenger to be seated properly and
properly wearing the seat belt. Properly seated passen-
gers are:

•

Sitting upright

•

Facing forward

•

Sitting in the center of the seat with their feet com-
fortably on or near the floor

•

Sitting with their back against the seatback and the
seatback in an upright position

Lighter Weight Passengers (Including Small Adults)

When a lighter weight passenger, including a small
adult, occupies the front passenger seat, the OCS may
reduce the inflation rate of the Passenger Advanced
Front Air Bag. This does not mean that the OCS is work-
ing improperly.

Do not decrease OR increase the front passenger’s
seated weight on the front passenger seat

The front passenger’s seated weight must be properly
positioned on the front passenger seat. Failure to do so
may result in serious injury or death. The OCS deter-
mines the most probable classification of the occupant
that it detects. The OCS will detect the front passen-
ger’s decreased or increased seated weight, which may
result in an adjusted inflation rate of the Passenger
Advanced Front Air Bag in a collision. This does not
mean that the OCS is working improperly. Decreasing
the front passenger’s seated weight on the front pas-
senger seat may result in a reduced-power deployment
of the Passenger Advanced Front Air Bag. Increasing

Seated Properly

174

SAFETY

the front passenger’s seated weight on the front pas-
senger seat may result in a full-power deployment of
the Passenger Advanced Front Air Bag.

Examples of improper front passenger seating include:

•

The front passenger’s weight is transferred to
another part of the vehicle (like the door, arm rest or
instrument panel).

•

The front passenger leans forward, sideways, or
turns to face the rear of the vehicle.

•

The front passenger’s seatback is not in the full
upright position.

•

The front passenger carries or holds an object while
seated (e.g., backpack, box, etc.).

•

Objects are lodged under the front passenger seat.

•

Objects are lodged between the front passenger
seat and center console.

•

Accessories that may change the seated weight on
the front passenger seat are attached to the front
passenger seat.

•

Anything that may decrease or increase the front
passenger’s seated weight.

The OCS determines the front passenger’s most prob-
able classification. If an occupant in the front passen-
ger seat is seated improperly, the occupant may provide
an output signal to the OCS that is different from the
occupant’s properly seated weight input, for example:

Not Seated Properly

SAFETY

175

WARNING!

•

If a child restraint system, child, small teenager or
adult in the front passenger seat is seated improp-
erly, the occupant may provide an output signal to
the OCS that is different from the occupant’s prop-
erly seated weight input. This may result in serious
injury or death in a collision.

•

Always wear your seat belt and sit properly, with
the seatback in an upright position, your back
against the seatback, sitting upright, facing for-
ward, in the center of the seat, with your feet com-
fortably on or near the floor.

•

Do not carry or hold any objects (e.g., backpacks,
boxes, etc.) while seated in the front passenger
seat. Holding an object may provide an output sig-
nal to the OCS that is different than the occupant’s
properly seated weight input, which may result in
serious injury or death in a collision.

•

Placing an object on the floor under the front pas-
senger seat may prevent the OCS from working
properly, which may result in serious injury or
death in a collision. Do not place any objects on
the floor under the front passenger seat.

The Air Bag Warning Light in the instrument panel

will turn on whenever the OCS is unable to classify the
front passenger seat status. A malfunction in the OCS
may affect the operation of the air bag system.

If the Air Bag Warning Light does not come on, or

stays on after you start the vehicle, or it comes on as
you drive, take the vehicle to an authorized dealer for
service immediately.

The passenger seat assembly contains critical OCS
components that may affect the Passenger Advanced
Front Air Bag inflation. In order for the OCS to properly

classify the seated weight of a front seat passenger, the
OCS components must function as designed. Do not
make any modifications to the front passenger seat
components, assembly, or to the seat cover. If the seat,
trim cover, or cushion needs service for any reason,
take the vehicle to an authorized dealer. Only FCA US
LLC approved seat accessories may be used.

The following requirements must be strictly followed:

•

Do not modify the front passenger seat assembly or
components in any way.

•

Do not use prior or future model year seat covers or
cushions not designated by FCA US LLC for the spe-
cific model being repaired. Always use the correct
seat cover and cushion specified for the vehicle.

•

Do not replace the seat cover or cushion with an
aftermarket seat cover or cushion.

•

Do not add a secondary seat cover or mat.

•

At no time should any Supplemental Restraint Sys-
tem (SRS) component or SRS related component or
fastener be modified or replaced with any part
except those which are approved by FCA US LLC.

WARNING!

•

Unapproved modifications or service procedures to
the passenger seat assembly, its related compo-
nents, seat cover or cushion may inadvertently
change the air bag deployment in case of a frontal
collision. This could result in death or serious
injury to the front passenger if the vehicle is
involved in a collision. A modified vehicle may not
comply with required Federal Motor Vehicle Safety
Standards (FMVSS) and/or Canadian Motor
Vehicle Safety Standards (CMVSS).

(Continued)

WARNING!

•

If it is necessary to modify the air bag system for
persons with disabilities, contact an authorized
dealer.

Knee Impact Bolsters

The Knee Impact Bolsters help protect the knees of the
driver and front passenger, and position the front occu-
pants for improved interaction with the front air bags.

WARNING!

•

Do not drill, cut, or tamper with the knee impact
bolsters in any way.

•

Do not mount any accessories to the knee impact
bolsters such as alarm lights, stereos, citizen band
radios, etc.

Supplemental Driver Knee Air Bag

This vehicle is equipped with a Supplemental Driver
Knee Air Bag mounted in the instrument panel below
the steering column. The Supplemental Driver Knee Air
Bag provides enhanced protection during a frontal
impact by working together with the seat belts, preten-
sioners, and front air bags.

Supplemental Side Air Bags

Supplemental Seat-Mounted Side Air Bags (SABs)

This vehicle is equipped with Supplemental Seat-
Mounted Side Air Bags (SABs).

176

SAFETY

Supplemental Seat-Mounted Side Air Bags (SABs) are
located in the outboard side of the front seats. The
SABs are marked with “SRS AIRBAG” or “AIRBAG” on a
label or on the seat trim on the outboard side of the
seats.
The SABs may help to reduce the risk of occupant injury
during certain side impacts, in addition to the injury
reduction potential provided by the seat belts and body
structure.

When the SAB deploys, it opens the seam on the out-
board side of the seatback’s trim cover. The inflating
SAB deploys through the seat seam into the space
between the occupant and the door. The SAB moves at
a very high speed and with such a high force that it
could injure occupants if they are not seated properly,
or if items are positioned in the area where the SAB
inflates. Children are at an even greater risk of injury
from a deploying air bag.

WARNING!

Do not use accessory seat covers or place objects
between you and the Side Air Bags; the performance
could be adversely affected and/or objects could be
pushed into you, causing serious injury.

Supplemental Side Air Bag Inflatable Curtains
(SABICs)

This vehicle is equipped with Supplemental Side Air Bag
Inflatable Curtains (SABICs).

Supplemental Side Air Bag Inflatable Curtains (SABICs)
are located above the side windows. The trim covering
the SABICs is labeled “SRS AIRBAG” or “AIRBAG.”

SABICs may help reduce the risk of head and other inju-
ries to front and rear seat outboard occupants in cer-
tain side impacts, in addition to the injury reduction
potential provided by the seat belts and body structure.

The SABIC deploys downward, covering the side win-
dows. An inflating SABIC pushes the outside edge of the
headliner out of the way and covers the window. The

SABICs inflate with enough force to injure occupants if
they are not belted and seated properly, or if items are
positioned in the area where the SABICs inflate. Chil-
dren are at an even greater risk of injury from a deploy-
ing air bag.

The SABICs may help reduce the risk of partial or com-
plete ejection of vehicle occupants through side win-
dows in certain side impact events.

WARNING!

•

Do not mount equipment, or stack luggage or
other cargo up high enough to block the deploy-
ment of the SABICs. The trim covering above the
side windows where the SABIC and its deployment
path are located should remain free from any
obstructions.

•

In order for the SABICs to work as intended, do not
install any accessory items in your vehicle which
could alter the roof. Do not add an aftermarket
sunroof to your vehicle. Do not add roof racks that
require permanent attachments (bolts or screws)
for installation on the vehicle roof. Do not drill into
the roof of the vehicle for any reason.

Side Impacts

The Side Air Bags are designed to activate in certain
side impacts. The Occupant Restraint Controller (ORC)
determines whether the deployment of the Side Air
Bags in a particular impact event is appropriate, based
on the severity and type of collision. The side impact
sensors aid the ORC in determining the appropriate
response to impact events. The system is calibrated to
deploy the Side Air Bags on the impact side of the
vehicle during impacts that require Side Air Bag occu-
pant protection. In side impacts, the Side Air Bags

Front Supplemental Seat-Mounted Side Air Bag

Supplemental Side Air Bag Inflatable Curtain (SABIC)

Label Location

SAFETY

177

deploy independently; a left side impact deploys the left
Side Air Bags only and a right-side impact deploys the
right Side Air Bags only. Vehicle damage by itself is not
a good indicator of whether or not Side Air Bags should
have deployed.

The Side Air Bags will not deploy in all side collisions,
including some collisions at certain angles, or some
side collisions that do not impact the area of the pas-
senger compartment. The Side Air Bags may deploy
during angled or offset frontal collisions where the front
air bags deploy.

Side Air Bags are a supplement to the seat belt
restraint system. Side Air Bags deploy in less time than
it takes to blink your eyes.

WARNING!

•

Occupants, including children, who are up against
or very close to Side Air Bags can be seriously
injured or killed. Occupants, including children,
should never lean on or sleep against the door,
side windows, or area where the side air bags
inflate, even if they are in an infant or child
restraint.

•

Seat belts (and child restraints where appropriate)
are necessary for your protection in all collisions.
They also help keep you in position, away from an
inflating Side Air Bag. To get the best protection
from the Side Air Bags, occupants must wear their
seat belts properly and sit upright with their backs
against the seats. Children must be properly
restrained in a child restraint or booster seat that
is appropriate for the size of the child.

WARNING!

•

Side Air Bags need room to inflate. Do not lean
against the door or window. Sit upright in the cen-
ter of the seat.

•

Being too close to the Side Air Bags during deploy-
ment could cause you to be severely injured or
killed.

•

Relying on the Side Air Bags alone could lead to
more severe injuries in a collision. The Side Air
Bags work with your seat belt to restrain you prop-
erly. In some collisions, Side Air Bags won’t deploy
at all. Always wear your seat belt even though you
have Side Air Bags.

NOTE:

Air bag covers may not be obvious in the interior trim,
but they will open during air bag deployment.

Rollover Events

Side Air Bags and seat belt pretensioners are designed
to activate in certain rollover events. The Occupant
Restraint Controller (ORC) determines whether deploy-
ment in a particular rollover event is appropriate, based
on the severity and type of collision. Vehicle damage by
itself is not a good indicator of whether or not Side Air
Bags and seat belt pretensioners should have
deployed.

The Side Air Bags and seat belt pretensioners will not
deploy in all rollover events. The rollover sensing system
determines if a rollover event may be in progress and
whether deployment is appropriate. In the event the
vehicle experiences a rollover or near rollover event,
and deployment is appropriate, the rollover sensing
system will deploy the side air bags and seat belt pre-
tensioners on both sides of the vehicle.

The SABICs may help reduce the risk of partial or com-
plete ejection of vehicle occupants through side win-
dows in certain rollover or side impact events.

Air Bag System Components

NOTE:

The Occupant Restraint Controller (ORC) monitors the
internal circuits and interconnecting wiring associated
with electrical Air Bag System Components listed below:

•

Occupant Restraint Controller (ORC)

•

Air Bag Warning Light

•

Steering Wheel and Column

•

Instrument Panel

•

Knee Impact Bolsters

•

Driver and Front Passenger Air Bags

•

Seat Belt Buckle Switch

•

Supplemental Side Air Bags

•

Supplemental Knee Air Bags

•

Front and Side Impact Sensors

•

Seat Belt Pretensioners

•

Seat Track Position Sensors

•

Occupant Classification System

If A Deployment Occurs

The front air bags are designed to deflate immediately
after deployment.

NOTE:

Front and/or side air bags will not deploy in all colli-
sions. This does not mean something is wrong with the
air bag system.

178

SAFETY

If you do have a collision which deploys the air bags,
any or all of the following may occur:

•

The air bag material may sometimes cause abra-
sions and/or skin reddening to the occupants as the
air bags deploy and unfold. The abrasions are simi-
lar to friction rope burns or those you might get slid-
ing along a carpet or gymnasium floor. They are not
caused by contact with chemicals. They are not per-
manent and normally heal quickly. However, if you
haven’t healed significantly within a few days, or if
you have any blistering, see your doctor
immediately.

•

As the air bags deflate, you may see some smoke-
like particles. The particles are a normal by-product
of the process that generates the non-toxic gas used
for air bag inflation. These airborne particles may
irritate the skin, eyes, nose, or throat. If you have
skin or eye irritation, rinse the area with cool water.
For nose or throat irritation, move to fresh air. If the
irritation continues, see your doctor. If these par-
ticles settle on your clothing, follow the garment
manufacturer’s instructions for cleaning.

Do not drive your vehicle after the air bags have
deployed. If you are involved in another collision, the air
bags will not be in place to protect you.

WARNING!

Deployed air bags and seat belt pretensioners cannot
protect you in another collision. Have the air bags,
seat belt pretensioners, and the seat belt retractor
assemblies replaced by an authorized dealer immedi-
ately. Also, have the Occupant Restraint Controller
System serviced as well.

NOTE:

•

Air bag covers may not be obvious in the interior
trim, but they will open during air bag deployment.

•

After any collision, the vehicle should be taken to an
authorized dealer immediately.

Enhanced Accident Response System

In the event of an impact, if the communication net-
work remains intact, and the power remains intact,
depending on the nature of the event, the Occupant
Restraint Controller (ORC) will determine whether to
have the Enhanced Accident Response System perform
the following functions:

•

Cut off fuel to the engine (if equipped)

•

Cut off battery power to the electric motor
(if equipped)

•

Flash hazard lights as long as the battery has power

•

Turn on the interior lights, which remain on as long
as the battery has power or for 15 minutes from the
intervention of the Enhanced Accident Response
System

•

Unlock the power door locks

Your vehicle may also be designed to perform any of
these other functions in response to the Enhanced Acci-
dent Response System:

•

Turn off the Fuel Filter Heater, Turn off the HVAC
Blower Motor, Close the HVAC Circulation Door

•

Cut off battery power to the:

○

Engine

○

Electric Motor (if equipped)

○

Electric power steering

○

Brake booster

○

Electric park brake

○

Automatic transmission gear selector

○

Horn

○

Front wiper

NOTE:

After an accident, place the ignition in the STOP (OFF/
LOCK) position and remove the key from the ignition
switch to avoid draining the battery. Carefully check the
vehicle for fuel leaks in the engine compartment and
on the ground near the engine compartment and fuel
tank before resetting the system and starting the
engine. If there are no fuel leaks or damage to the
vehicle electrical devices (e.g. headlights) after an acci-
dent, reset the system by following the procedure
described below. If you have any doubt, contact an
authorized dealer.

Enhanced Accident Response System

Reset Procedure

After the event occurs, when the system is active, a
message regarding fuel cutoff is displayed. Turn the
ignition switch from ignition AVV/START or MAR/ON/
RUN to ignition STOP/OFF/LOCK. Carefully check the
vehicle for fuel leaks in the engine compartment and
on the ground near the engine compartment and fuel
tank before resetting the system and starting the
engine.

Depending on the nature of the event the left and right
turn signal lights, located in the instrument panel, may
both be blinking and will continue to blink. In order to
move your vehicle to the side of the road, you must fol-
low the system reset procedure.

SAFETY

179

Customer Action

NOTE:

Each step MUST BE held for at least two seconds

Customer Will See

1. Turn ignition STOP/OFF/LOCK. (Turn Signal Switch Must be placed in Neutral State).

2. Turn ignition MAR/ON/RUN.

Right turn light BLINKS.
Left turn light is OFF.

3. Turn right turn signal switch ON.

Right turn light is ON SOLID.
Left turn light BLINKS.

4. Place turn signal in neutral state.

Right turn light is OFF.
Left turn light BLINKS.

5. Turn left turn signal switch ON.

Right turn light BLINKS.
Left turn light is ON SOLID.

6. Place turn signal in neutral state.

Right turn light BLINKS.
Left turn light is OFF.

7. Turn right turn signal switch ON.

Right turn light is ON SOLID.
Left turn light BLINKS.

8. Place turn signal in neutral state.

Right turn light is OFF.
Left turn light BLINKS.

9. Turn left turn signal switch ON.

Right turn light is ON SOLID.
Left turn light is ON SOLID.

10. Turn left turn signal switch OFF. (Turn Signal Switch Must be placed in Neutral
State).

Right turn light is OFF.
Left turn light is OFF.

11. Turn ignition STOP/OFF/LOCK.

12. Turn ignition MAR/ON/RUN. (Entire sequence needs to be completed within one
minute or sequence will need to be repeated).

System is now reset and the engine may be started.

Turn hazard flashers OFF (Manually).

If a reset procedure step is not completed within 60 seconds, then the turn signal lights will blink and the reset procedure must be performed again in order to be successful.

180

SAFETY

Maintaining Your Air Bag System

WARNING!

•

Modifications to any part of the air bag system
could cause it to fail when you need it. You could
be injured if the air bag system is not there to pro-
tect you. Do not modify the components or wiring,
including adding any kind of badges or stickers to
the steering wheel hub trim cover or the upper pas-
senger side of the instrument panel. Do not modify
the front fascia/bumper, vehicle body structure, or
add aftermarket side steps or running boards.

•

It is dangerous to try to repair any part of the air
bag system yourself. Be sure to tell anyone who
works on your vehicle that it has an air bag system.

•

Do not attempt to modify any part of your air bag
system. The air bag may inflate accidentally or may
not function properly if modifications are made.
Take your vehicle to an authorized dealer for any
air bag system service. If your seat, including your
trim cover and cushion, needs to be serviced in
any way (including removal or loosening/tightening
of seat attachment bolts), take the vehicle to an
authorized dealer. Only manufacturer approved
seat accessories may be used. If it is necessary to
modify the air bag system for persons with disabili-
ties, contact an authorized dealer.

Event Data Recorder (EDR)

This vehicle is equipped with an event data recorder
(EDR). The main purpose of an EDR is to record, in cer-
tain crash or near crash-like situations, such as an air
bag deployment or hitting a road obstacle, data that will
assist in understanding how a vehicle’s systems
performed.

The EDR is designed to record data related to vehicle
dynamics and safety systems for a short period of time,
typically 30 seconds or less. The EDR in this vehicle is
designed to record such data as:

•

How various systems in your vehicle were operating;

•

Whether or not the driver and passenger safety
belts were buckled/fastened;

•

How far (if at all) the driver was depressing the
accelerator and/or brake pedal; and,

•

How fast the vehicle was traveling.

These data can help provide a better understanding of
the circumstances in which crashes and injuries occur.

NOTE:

EDR data are recorded by your vehicle only if a non-
trivial crash situation occurs; no data are recorded by
the EDR under normal driving conditions and no per-
sonal data (e.g., name, gender, age, and crash location)
are recorded. However, other parties, such as law
enforcement, could combine the EDR data with the type
of personally identifying data routinely acquired during
a crash investigation.

To read data recorded by an EDR, special equipment is
required, and access to the vehicle or the EDR is
needed. In addition to the vehicle manufacturer, other
parties, such as law enforcement, that have the special
equipment, can read the information if they have
access to the vehicle or the EDR.

CHILD RESTRAINTS

Everyone in your vehicle needs to be buckled up at all
times, including babies and children. Every state in the
United States, and every Canadian province, requires
that small children ride in proper restraint systems. This
is the law, and you can be prosecuted for ignoring it.

Children 12 years or younger should ride properly buck-
led up in a rear seat, if available. According to crash
statistics, children are safer when properly restrained in
the rear seats rather than in the front.

WARNING!

In a collision, an unrestrained child can become a
projectile inside the vehicle. The force required to
hold even an infant on your lap could become so
great that you could not hold the child, no matter how
strong you are. The child and others could be badly
injured or killed. Any child riding in your vehicle
should be in a proper restraint for the child’s size.

There are different sizes and types of restraints for chil-
dren from newborn size to the child almost large
enough for an adult safety belt. Always check the child
seat Owner’s Manual to make sure you have the correct
seat for your child. Carefully read and follow all the
instructions and warnings in the child restraint Owner’s
Manual and on all the labels attached to the child
restraint.

Before buying any restraint system, make sure that it
has a label certifying that it meets all applicable Safety
Standards. You should also make sure that you can
install it in the vehicle where you will use it.

NOTE:

•

For additional information, refer to http://
www.nhtsa.gov/parents-and-caregivers or call:
1–888–327–4236

•

Canadian residents should refer to Transport
Canada’s website for additional information:
https://tc.canada.ca/en/road-transportation/
child-car-seat-safety

SAFETY

181

Summary Of Recommendations For Restraining Children In Vehicles

Child Size, Height, Weight Or Age

Recommended Type Of Child Restraint

Infants and Toddlers

Children who are two years old or younger and who have
not reached the height or weight limits of their child
restraint

Either an Infant Carrier or a Convertible Child Restraint,
facing rearward in a rear seat of the vehicle

Small Children

Children who are at least two years old or who have out-
grown the height or weight limit of their rear-facing child
restraint

Forward-Facing Child Restraint with a five-point Harness,
facing forward in a rear seat of the vehicle

Larger Children

Children who have outgrown their forward-facing child
restraint, but are too small to properly fit the vehicle’s
seat belt

Belt Positioning Booster Seat and the vehicle seat belt,
seated in a rear seat of the vehicle

Children Too Large for Child Restraints

Children 12 years old or younger, who have outgrown the
height or weight limit of their booster seat

Vehicle Seat Belt, seated in a rear seat of the vehicle

Infant And Child Restraints

Safety experts recommend that children ride rear-facing
in the vehicle until they are two years old or until they
reach either the height or weight limit of their rear-
facing child restraint. Two types of child restraints can
be used rear-facing: infant carriers and convertible child
seats.

The infant carrier is only used rear-facing in the vehicle.
It is recommended for children from birth until they
reach the weight or height limit of the infant carrier.
Convertible child seats can be used either rear-facing or
forward-facing in the vehicle. Convertible child seats
often have a higher weight limit in the rear-facing direc-
tion than infant carriers do, so they can be used rear-
facing by children who have outgrown their infant car-
rier but are still less than at least two years old.
Children should remain rear-facing until they reach the
highest weight or height allowed by their convertible
child seat.

WARNING!

•

Older Children And Child Restraints

Children who are two years old or who have outgrown
their rear-facing convertible child seat can ride forward-
facing in the vehicle. Forward-facing child seats and
convertible child seats used in the forward-facing direc-
tion are for children who are over two years old or who
have outgrown the rear-facing weight or height limit of
their rear-facing convertible child seat. Children should
remain in a forward-facing child seat with a harness for
as long as possible, up to the highest weight or height
allowed by the child seat.

All children whose weight or height is above the
forward-facing limit for the child seat should use a belt-
positioning booster seat until the vehicle’s seat belts fit
properly. If the child cannot sit with knees bent over the
vehicle’s seat cushion while the child’s back is against
the seatback, they should use a belt-positioning
booster seat. The child and belt-positioning booster
seat are held in the vehicle by the seat belt.

182

SAFETY

WARNING!

•

Improper installation can lead to failure of an
infant or child restraint. It could come loose in a
collision. The child could be badly injured or killed.
Follow the child restraint manufacturer’s directions
exactly when installing an infant or child restraint.

•

After a child restraint is installed in the vehicle, do
not move the vehicle seat forward or rearward
because it can loosen the child restraint attach-
ments. Remove the child restraint before adjusting
the vehicle seat position. When the vehicle seat
has been adjusted, reinstall the child restraint.

•

When your child restraint is not in use, secure it in
the vehicle with the seat belt or LATCH anchor-
ages, or remove it from the vehicle. Do not leave it
loose in the vehicle. In a sudden stop or accident,
it could strike the occupants or seatbacks and
cause serious personal injury.

Children Too Large For Booster Seats

Children who are large enough to wear the shoulder
belt comfortably, and whose legs are long enough to
bend over the front of the seat when their back is
against the seatback, should use the seat belt in a rear
seat. Use this simple 5-step test to decide whether the
child can use the vehicle’s seat belt alone:

1. Can the child sit all the way back against the back of

the vehicle seat?

2. Do the child’s knees bend comfortably over the front

of the vehicle seat while the child is still sitting all
the way back?

3. Does the shoulder belt cross the child’s shoulder

between the neck and arm?

4. Is the lap part of the belt as low as possible, touch-

ing the child’s thighs and not the stomach?

5. Can the child stay seated like this for the whole trip?

If the answer to any of these questions was “no,” then
the child still needs to use a booster seat in this
vehicle. If the child is using the lap/shoulder belt, check
seat belt fit periodically and make sure the seat belt
buckle is latched. A child’s squirming or slouching can
move the belt out of position. If the shoulder belt con-
tacts the face or neck, move the child closer to the cen-
ter of the vehicle, or use a booster seat to position the
seat belt on the child correctly.

WARNING!

Never allow a child to put the shoulder belt under an
arm or behind their back. In a crash, the shoulder
belt will not protect a child properly, which may result
in serious injury or death. A child must always wear
both the lap and shoulder portions of the seat belt
correctly.

Recommendations For Attaching Child Restraints

Restraint Type

Combined Weight of the

Child + Child Restraint

Use Any Attachment Method Shown With An “X” Below

LATCH – Lower Anchors

Only

Seat Belt Only

LATCH – Lower Anchors

+ Top Tether Anchor

Seat Belt + Top Tether

Anchor

Rear-Facing Child Restraint

Up to 65 lb (29.5 kg)

Rear-Facing Child Restraint

More than 65 lb (29.5 kg)

Forward-Facing Child

Restraint

Up to 65 lb (29.5 kg)

Forward-Facing Child

Restraint

More than 65 lb (29.5 kg)

SAFETY

183

Lower Anchors And Tethers For CHildren

(LATCH) Restraint System

Your vehicle is equipped with the child restraint anchor-
age system called LATCH, which stands for Lower
Anchors and Tethers for CHildren. The LATCH system
has three vehicle anchor points for installing LATCH-
equipped child seats. There are two lower anchorages
located at the back of the seat cushion where it meets
the seatback and one top tether anchorage located
behind the seating position. These anchorages are
used to install LATCH-equipped child seats without
using the vehicle’s seat belts. Some seating positions
may have a top tether anchorage but no lower anchor-
ages. In these seating positions, the seat belt must be
used with the top tether anchorage to install the child
restraint. Please see the following table for more
information.

LATCH Positions For Installing Child

Restraints In This Vehicle

Frequently Asked Questions About Installing Child Restraints With LATCH

What is the weight limit (child’s weight + weight of the
child restraint) for using the LATCH anchorage system to
attach the child restraint?

65 lb (29.5 kg)

Use the LATCH anchorage system until the combined
weight of the child and the child restraint is 65 lb (29.5
kg). Use the seat belt and tether anchor instead of the
LATCH system once the combined weight is more than
65 lb (29.5 kg).

Can the LATCH anchorages and the seat belt be used
together to attach a rear-facing or forward-facing child
restraint?

Do not use the seat belt when you use the LATCH anchor-
age system to attach a rear-facing or forward-facing child
restraint.
Booster seats may be attached to the LATCH anchorages
if allowed by the booster seat manufacturer. See your
booster seat owner’s manual for more information.

LATCH Label

LATCH Positions

Lower Anchorage Symbol (2 Anchorages Per Seat-

ing Position)

Top Tether Anchorage Symbol

184

SAFETY

Frequently Asked Questions About Installing Child Restraints With LATCH

Can a child seat be installed in the center position using
the inner LATCH lower anchorages from the outboard
seating positions?

Yes

You can install child restraints with flexible lower anchors
in the center position. The inner anchorages are
16 inches (400 mm) apart. Do not install child restraints
with rigid lower anchors in the center position.

Can two child restraints be attached using a common
lower LATCH anchorage?

Never “share” a LATCH anchorage with two or more child
restraints. If the center position does not have dedicated
LATCH lower anchorages, use the seat belt to install a
child seat in the center position next to a child seat using
the LATCH anchorages in an outboard position.

Can the rear-facing child restraint touch the back of the
front passenger seat?

Yes

The child seat may touch the back of the front passenger
seat if the child restraint manufacturer also allows con-
tact. See your child restraint owner’s manual for more
information.

Can the rear head restraints be removed?

Locating The LATCH Anchorages

The lower anchorages are round bars that
are found at the rear of the seat cushion
where it meets the seatback, below the
anchorage symbols on the seatback. They

are just visible when you lean into the rear seat to
install the child restraint. You will easily feel them if you
run your finger along the gap between the seatback
and seat cushion.

Lower Anchorage Location

SAFETY

185

Locating The Upper Tether Anchorages

There are tether strap anchorages behind
each rear seating position located on the
back of the seat.

LATCH-compatible child restraint systems will be
equipped with a rigid bar or a flexible strap on each
side. Each will have a hook or connector to attach to
the lower anchorage and a way to tighten the connec-
tion to the anchorage. Forward-facing child restraints
and some rear-facing child restraints will also be
equipped with a tether strap. The tether strap will have
a hook at the end to attach to the top tether anchorage
and a way to tighten the strap after it is attached to the
anchorage.

Center Seat LATCH

Do not install child restraints with rigid lower attachments
in the center seating position. Only install this type of child
restraint in the outboard seating positions. Child restraints
with flexible, webbing mounted lower attachments can be
installed in any rear seating position.

WARNING!

Never use the same lower anchorage to attach more
than one child restraint. If you are installing LATCH-
compatible child restraints next to each other, you
must use the seat belt for the center position. You
can then use either the LATCH anchors or the vehi-
cle’s seat belt for installing child seats in the out-
board positions.

Please see

page 186 for typical installation

instructions.

Always follow the directions of the child restraint
manufacturer when installing your child restraint. Not
all child restraint systems will be installed as described
here.

To Install A LATCH-Compatible Child

Restraint

If the selected seating position has a Switchable Auto-
matic Locking Retractor (ALR) seat belt, stow the seat
belt, following the instructions below. See

page 187

to check what type of seat belt each seating position
has.

1. Loosen the adjusters on the lower straps and on the

tether strap of the child seat so that you can more
easily attach the hooks or connectors to the vehicle
anchorages.

2. Place the child seat between the lower anchorages

for that seating position. If the second row seat can
be reclined, you may recline the seat and/or raise
the head restraint (if adjustable) to get a better fit. If
the rear seat can be moved forward and rearward in

the vehicle, you may wish to move it to its rear-most
position to make room for the child seat. You may
also move the front seat forward to allow more room
for the child seat.

3. Attach the lower hooks or connectors of the child

restraint to the lower anchorages in the selected
seating position.

4. If the child restraint has a tether strap, connect it to

the top tether anchorage. See

page 188 for

directions to attach a tether anchor.

5. Tighten all of the straps as you push the child

restraint rearward and downward into the seat.
Remove slack in the straps according to the child
restraint manufacturer’s instructions.

6. Test that the child restraint is installed tightly by

pulling back and forth on the child seat at the belt
path. It should not move more than 1 inch
(25.4 mm) in any direction.

How To Stow An Unused Switchable-

ALR (ALR) Seat Belt:

When using the LATCH attaching system to install a
child restraint, stow all ALR seat belts that are not being
used by other occupants or being used to secure child
restraints. An unused belt could injure a child if they
play with it and accidentally lock the seat belt retractor.
Before installing a child restraint using the LATCH sys-
tem, buckle the seat belt behind the child restraint and
out of the child’s reach. If the buckled seat belt inter-
feres with the child restraint installation, instead of
buckling it behind the child restraint, route the seat belt
through the child restraint belt path and then buckle it.
Do not lock the seat belt. Remind all children in the
vehicle that the seat belts are not toys and that they
should not play with them.

Tether Anchorage Locations

186

SAFETY

WARNING!

•

Improper installation of a child restraint to the
LATCH anchorages can lead to failure of the
restraint. The child could be badly injured or killed.
Follow the child restraint manufacturer’s directions
exactly when installing an infant or child restraint.

•

Child restraint anchorages are designed to with-
stand only those loads imposed by correctly-fitted
child restraints. Under no circumstances are they
to be used for adult seat belts, harnesses, or for
attaching other items or equipment to the vehicle.

Installing Child Restraints Using The

Vehicle Seat Belt

Child restraint systems are designed to be secured in
vehicle seats by lap belts or the lap belt portion of a
lap/shoulder belt.

WARNING!

•

Improper installation or failure to properly secure a
child restraint can lead to failure of the restraint.
The child could be badly injured or killed.

•

Follow the child restraint manufacturer’s directions
exactly when installing an infant or child restraint.

The seat belts in the passenger seating positions are
equipped with a Switchable Automatic Locking Retrac-
tor (ALR) that is designed to keep the lap portion of the
seat belt tight around the child restraint so that it is not
necessary to use a locking clip. The ALR retractor can
be “switched” into a locked mode by pulling all of the
webbing out of the retractor and then letting the web-
bing retract back into the retractor. If it is locked, the
ALR will make a clicking noise while the webbing is
pulled back into the retractor.

See the “Automatic Locking Mode” description

page 170 for additional information on ALR.

Lap/Shoulder Belt Systems For

Installing Child Restraints In This Vehicle

Frequently Asked Questions About Installing Child Restraints With Seat Belts

What is the weight limit (child’s weight + weight of the child
restraint) for using the Tether Anchor with the seat belt to
attach a forward-facing child restraint?

Weight limit of the Child Restraint

Always use the tether anchor when using the seat belt to
install a forward-facing child restraint, up to the recom-
mended weight limit of the child restraint.

Can the rear-facing child restraint touch the back of the
front passenger seat?

Yes

Contact between the front passenger seat and the child
restraint is allowed, if the child restraint manufacturer also
allows contact.

Can the rear head restraints be removed?

Can the buckle stalk be twisted to tighten the seat belt
against the belt path of the child restraint?

Do not twist the buckle stalk in a seating position with an
ALR retractor.

Automatic Locking Retractor (ALR) Locations

ALR — Switchable Automatic Locking Retractor

Top Tether Anchorage Symbol

SAFETY

187

Installing A Child Restraint With A

Switchable Automatic Locking Retractor

(ALR):

Child restraint systems are designed to be secured in
vehicle seats by lap belts or the lap belt portion of a
lap/shoulder belt.

WARNING!

•

Improper installation or failure to properly secure a
child restraint can lead to failure of the restraint.
The child could be badly injured or killed.

•

Follow the child restraint manufacturer’s directions
exactly when installing an infant or child restraint.

1. Place the child seat in the center of the seating posi-

tion. If the second row seat can be reclined, you may
recline the seat and/or raise the head restraint (if
adjustable) to get a better fit. If the rear seat can be
moved forward and rearward in the vehicle, you may
wish to move it to its rear-most position to make
room for the child seat. You may also move the front
seat forward to allow more room for the child seat.

2. Pull enough of the seat belt webbing from the

retractor to pass it through the belt path of the child
restraint. Do not twist the belt webbing in the belt
path.

3. Slide the latch plate into the buckle until you hear a

“click.”

4. Pull on the webbing to make the lap portion tight

against the child seat.

5. To lock the seat belt, pull down on the shoulder part

of the belt until you have pulled all the seat belt
webbing out of the retractor. Then, allow the web-
bing to retract back into the retractor. As the web-
bing retracts, you will hear a clicking sound. This
means the seat belt is now in the Automatic
Locking mode.

6. Try to pull the webbing out of the retractor. If it is

locked, you should not be able to pull out any web-
bing. If the retractor is not locked, repeat step 5.

7. Finally, pull up on any excess webbing to tighten the

lap portion around the child restraint while you push
the child restraint rearward and downward into the
vehicle seat.

8. If the child restraint has a top tether strap and the

seating position has a top tether anchorage, con-
nect the tether strap to the anchorage and tighten
the tether strap. See

page 188 for directions to

attach a tether anchor.

9. Test that the child restraint is installed tightly by

pulling back and forth on the child seat at the belt
path. It should not move more than 1 inch
(25.4 mm) in any direction.

Any seat belt system will loosen with time, so check the
belt occasionally, and pull it tight if necessary.

Installing Child Restraints Using The Top

Tether Anchorage:

WARNING!

Do not attach a tether strap for a rear-facing car seat
to any location in front of the car seat, including the
seat frame or a tether anchorage. Only attach the
tether strap of a rear-facing car seat to the tether
anchorage that is approved for that seating position,
located behind the top of the vehicle seat. See

page 184 for the location of approved tether

anchorages in your vehicle.

1. Look behind the seating position where you plan to

install the child restraint to find the tether anchor-
age. You may need to move the seat forward to pro-
vide better access to the tether anchorage. If there
is no top tether anchorage for that seating position,
move the child restraint to another position in the
vehicle if one is available.

188

SAFETY

2. Route the tether strap to provide the most direct

path for the strap between the anchor and the child
seat. If your vehicle is equipped with adjustable rear
head restraints, raise the head restraint, and where
possible, route the tether strap under the head
restraint and between the two posts. If not possible,
lower the head restraint and pass the tether strap
around the outboard side of the head restraint.

3. Attach the tether strap hook of the child restraint to

the top tether anchorage as shown in the diagram.

4. Remove slack in the tether strap according to the

child restraint manufacturer’s instructions.

WARNING!

•

An incorrectly anchored tether strap could lead to
increased head motion and possible injury to the
child. Use only the anchorage position directly
behind the child seat to secure a child restraint top
tether strap.

(Continued)

WARNING!

•

If your vehicle is equipped with a split rear seat,
make sure the tether strap does not slip into the
opening between the seatbacks as you remove
slack in the strap.

SAFETY TIPS

TRANSPORTING PASSENGERS

NEVER TRANSPORT PASSENGERS IN THE CARGO AREA.

WARNING!

•

Do not leave children or animals inside parked
vehicles in hot weather. Interior heat buildup may
cause serious injury or death.

•

It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seriously
injured or killed.

•

Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat
belts.

•

Be sure everyone in your vehicle is in a seat and
using a seat belt properly.

TRANSPORTING PETS

Air Bags deploying in the front seat could harm your
pet. An unrestrained pet will be thrown about and possi-
bly injured, or injure a passenger during panic braking
or in a collision.

Pets should be restrained in the rear seat (if equipped)
in pet harnesses or pet carriers that are secured by
seat belts.

SAFETY CHECKS YOU SHOULD
MAKE INSIDE THE VEHICLE

Seat Belts

Inspect the seat belt system periodically, checking for
cuts, frays, and loose parts. Damaged parts must be
replaced immediately. Do not disassemble or modify
the system.

If your vehicle is involved in a collision, or if you have
questions regarding the seat belt or retractor condi-
tions, take your vehicle to an authorized FCA dealer or
authorized FCA Certified Collision Care Program facility
for inspection.

Air Bag Warning Light

The Air Bag Warning Light will turn on for
four to eight seconds as a bulb check when
the ignition switch is first placed in the
ON/RUN position. If the light is either not on

during starting, stays on, or turns on while driving, have
the system inspected at an authorized dealer as soon
as possible. After the bulb check, this light will illumi-
nate with a single chime when a fault with the Air Bag
System has been detected. It will stay on until the fault
is removed. If the light comes on intermittently or
remains on while driving, have an authorized dealer
service the vehicle immediately

page 165.

Rear Seat Tether Anchors

SAFETY

189

Defroster

Check operation by selecting the defrost mode and
place the blower control on high speed. You should be
able to feel the air directed against the windshield. See
an authorized dealer for service if your defroster is inop-
erable.

Floor Mat Safety Information

Always use floor mats designed to fit your vehicle. Only
use a floor mat that does not interfere with the opera-
tion of the accelerator, brake or clutch pedals. Only use
a floor mat that is securely attached using the floor mat
fasteners so it cannot slip out of position and interfere
with the accelerator, brake or clutch pedals or impair
safe operation of your vehicle in other ways.

WARNING!

An improperly attached, damaged, folded, or stacked
floor mat, or damaged floor mat fasteners may cause
your floor mat to interfere with the accelerator, brake,
or clutch pedals and cause a loss of vehicle control.
To prevent SERIOUS INJURY or DEATH:

•

ALWAYS securely attach your floor mat
using the floor mat fasteners. DO NOT
install your floor mat upside down or turn
your floor mat over. Lightly pull to confirm
mat is secured using the floor mat fasteners on a
regular basis.

•

ALWAYS REMOVE THE EXISTING FLOOR
MAT FROM THE VEHICLE before installing
any other floor mat. NEVER install or
stack an additional floor mat on top of
an existing floor mat.

(Continued)

WARNING!

•

ONLY install floor mats designed to fit your vehicle.
NEVER install a floor mat that cannot be properly
attached and secured to your vehicle. If a floor mat
needs to be replaced, only use a FCA approved
floor mat for the specific make, model, and year of
your vehicle.

•

ONLY use the driver’s side floor mat on the driver’s
side floor area. To check for interference, with the
vehicle properly parked with the engine off, fully
depress the accelerator, the brake, and the clutch
pedal (if present) to check for interference. If your
floor mat interferes with the operation of any
pedal, or is not secure to the floor, remove the
floor mat from the vehicle and place the floor mat
in your trunk.

•

ONLY use the passenger’s side floor mat on the
passenger’s side floor area.

•

ALWAYS make sure objects cannot fall or slide into
the driver’s side floor area when the vehicle is
moving. Objects can become trapped under accel-
erator, brake, or clutch pedals and could cause a
loss of vehicle control.

•

NEVER place any objects under the floor mat (e.g.,
towels, keys, etc.). These objects could change the
position of the floor mat and may cause interfer-
ence with the accelerator, brake, or clutch pedals.

•

If the vehicle carpet has been removed and
re-installed, always properly attach carpet to the
floor and check the floor mat fasteners are secure
to the vehicle carpet. Fully depress each pedal to
check for interference with the accelerator, brake,
or clutch pedals then re-install the floor mats.

(Continued)

WARNING!

•

It is recommended to only use mild soap and water
to clean your floor mats. After cleaning, always
check your floor mat has been properly installed
and is secured to your vehicle using the floor mat
fasteners by lightly pulling mat.

PERIODIC SAFETY CHECKS YOU
SHOULD MAKE OUTSIDE THE
VEHICLE

Tires

Examine tires for excessive tread wear and uneven
wear patterns. Check for stones, nails, glass, or other
objects lodged in the tread or sidewall. Inspect the
tread for cuts and cracks. Inspect sidewalls for cuts,
cracks, and bulges. Check the lug nut/bolt torque for
tightness. Check the tires (including spare) for proper
cold inflation pressure.

Lights

Have someone observe the operation of brake lights
and exterior lights while you work the controls. Check
turn signal and high beam indicator lights on the instru-
ment panel.

Door Latches

Check for proper closing, latching, and locking.

190

SAFETY

Fluid Leaks

Check area under the vehicle after overnight parking for
fuel, coolant, oil, or other fluid leaks. Also, if gasoline
fumes are detected or if fuel or brake fluid leaks are
suspected, the cause should be located and corrected
immediately.

EXHAUST GAS

WARNING!

Exhaust gases can injure or kill. They contain carbon
monoxide (CO), which is colorless and odorless.
Breathing it can make you unconscious and can
eventually poison you. To avoid breathing (CO), follow
these safety tips:

•

Do not run the engine in a closed garage or in con-
fined areas any longer than needed to move your
vehicle in or out of the area.

•

If you are required to drive with the trunk/liftgate/
rear doors open, make sure that all windows are
closed and the climate control BLOWER switch is
set at high speed. DO NOT use the recirculation
mode.

•

If it is necessary to sit in a parked vehicle with the
engine running, adjust your heating or cooling con-
trols to force outside air into the vehicle. Set the
blower at high speed.

The best protection against carbon monoxide entry into
the vehicle body is a properly maintained engine
exhaust system.

Whenever a change is noticed in the sound of the
exhaust system, when exhaust fumes can be detected
inside the vehicle, or when the underside or rear of the
vehicle is damaged, have an authorized dealer inspect

the complete exhaust system and adjacent body areas
for broken, damaged, deteriorated, or mispositioned
parts. Open seams or loose connections could permit
exhaust fumes to seep into the passenger compart-
ment. In addition, inspect the exhaust system each
time the vehicle is raised for lubrication or oil change.
Replace as required.

CARBON MONOXIDE WARNINGS

WARNING!

Carbon monoxide (CO) in exhaust gases is deadly.
Follow the precautions provided to prevent carbon
monoxide poisoning:

•

Do not inhale exhaust gases. They contain carbon
monoxide, a colorless and odorless gas, which can
kill. Never run the engine in a closed area, such as
a garage, and never sit in a parked vehicle with the
engine running for an extended period. If the
vehicle is stopped in an open area with the engine
running for more than a short period, adjust the
ventilation system to force fresh, outside air into
the vehicle.

•

Guard against carbon monoxide with proper main-
tenance. Have the exhaust system inspected every
time the vehicle is raised. Have any abnormal con-
ditions repaired promptly. Until repaired, drive with
all side windows fully open.

SAFETY

191

IN CASE OF EMERGENCY

HAZARD WARNING FLASHERS

The Hazard Warning Flashers button is located in the
lower center area of the instrument panel.

NOTE:

Your vehicle may be equipped with an Emergency Stop
Signal (ESS)

page 155.

Push the button to turn on the Hazard Warning Flash-
ers. When the button is activated, all directional turn
signals will flash on and off to warn oncoming traffic of
an emergency. Push the button a second time to turn
off the Hazard Warning Flashers.

This is an emergency warning system and it should not
be used when the vehicle is in motion. Use it only when
your vehicle is disabled or signaling a safety hazard
warning for other motorists.

When you must leave the vehicle to seek assistance,
the Hazard Warning Flashers will continue to operate
even though the ignition is placed in the OFF position.

NOTE:

With extended use, the Hazard Warning Flashers may
wear down your battery.

SOS MIRROR — IF EQUIPPED

If equipped, the Rearview mirror contains an SOS
button.

WARNING!

ALWAYS obey traffic laws and pay attention to the
road. ALWAYS drive safely with your hands on the
steering wheel. You have full responsibility and
assume all risks related to the use of the features
and applications in this vehicle. Only use the features
and applications when it is safe to do so. Failure to do
so may result in an accident involving serious injury
or death.

NOTE:

•

Your vehicle may be transmitting data as authorized
by the subscriber

page 259.

•

The SOS button will only function if you are con-
nected to an operable LTE (voice/data) or 4G (data)
network, which comes as a built in function. Other
Uconnect services will only be operable if your
SiriusXM Guardian™ service is active and you are
connected to an operable LTE (voice/data) or 4G
(data) network.

SOS Call

1. Press or hold the SOS Call button on the Rearview

Mirror.

NOTE:

In case the SOS Call button is pushed in error, there
will be a 10 second delay before the SOS Call sys-
tem initiates a call to an SOS operator. To cancel the
SOS Call connection, push the SOS call button on
the Rearview Mirror or press the cancellation button
on the Device Screen. Termination of the SOS Call
will turn off the green LED light on the Rearview
Mirror.

2. The LED light located next to the SOS button on the

Rearview Mirror will turn green once a connection to
an SOS operator has been made.

Hazard Warning Flashers Button

SOS Mirror

192

3. Once a connection between the vehicle and an SOS

operator is made, the SOS Call system may transmit
the following important vehicle information to an
SOS operator:

○

Indication that the occupant placed an SOS Call

○

The vehicle brand

○

The last known GPS coordinates of the vehicle

4. You should be able to speak with the SOS operator

through the vehicle audio system to determine if
additional assistance is needed.

WARNING!

ALWAYS obey traffic laws and pay attention to the road.
ALWAYS drive safely with your hands on the steering
wheel. You have full responsibility and assume all risks
related to the use of the features and applications in
this vehicle. Only use the features and applications
when it is safe to do so. Failure to do so may result in
an accident involving serious injury or death.

NOTE:

○

Your vehicle may be transmitting data as autho-
rized by the subscriber.

○

Once a connection is made between the vehi-
cle’s SOS Call system and the SOS operator, the
SOS operator may be able to open a voice con-
nection with the vehicle to determine if addi-
tional assistance is needed. Once the SOS opera-
tor opens a voice connection with the vehicle’s
SOS Call system, the operator should be able to
speak with you or other vehicle occupants and
hear sounds occurring in the vehicle. The vehi-
cle’s SOS Call system will attempt to remain con-
nected with the SOS operator until the SOS
operator terminates the connection.

5. The SOS operator may attempt to contact appropri-

ate emergency responders and provide them with
important vehicle information and GPS coordinates.

WARNING!

•

If anyone in the vehicle could be in danger (e.g.,
fire or smoke is visible, dangerous road conditions
or location), do not wait for voice contact from an
Emergency Services Agent. All occupants should
exit the vehicle immediately and move to a safe
location.

•

Never place anything on or near the vehicle’s oper-
able network and GPS antennas. You could pre-
vent operable network and GPS signal reception,
which can prevent your vehicle from placing an
emergency call. An operable network and GPS sig-
nal reception is required for the SOS Call system to
function properly.

•

The SOS Call system is embedded into the vehi-
cle’s electrical system. Do not add aftermarket
electrical equipment to the vehicle’s electrical sys-
tem. This may prevent your vehicle from sending a
signal to initiate an emergency call. To avoid inter-
ference that can cause the SOS Call system to fail,
never add aftermarket equipment (e.g., two-way
mobile radio, CB radio, data recorder, etc.) to your
vehicle’s electrical system or modify the antennas
on your vehicle. IF YOUR VEHICLE LOSES BATTERY
POWER FOR ANY REASON (INCLUDING DURING OR
AFTER AN ACCIDENT), THE UCONNECT FEATURES,
APPS AND SERVICES, AMONG OTHERS, WILL NOT
OPERATE.

•

Modifications to any part of the SOS Call system
could cause the air bag system to fail when you
need it. You could be injured if the air bag system
is not there to help protect you.

SOS Call System Limitations

Vehicles sold in Mexico

DO NOT

have SOS Call system

capabilities.

SOS or other emergency line operators in Mexico may
not answer or respond to SOS system calls.

If the SOS Call system detects a malfunction, any of the
following may occur at the time the malfunction is
detected, and at the beginning of each ignition cycle:

•

The Rearview Mirror light located next to the SOS
button will continuously illuminate red.

•

The Device Screen will display the following mes-
sage “Vehicle device requires service. Please con-
tact an authorized dealer.”

•

An In-Vehicle Audio message will state “Vehicle
device requires service. Please contact an autho-
rized dealer.”

WARNING!

•

Ignoring the Rearview Mirror light could mean you
will not have SOS Call services. If the Rearview
Mirror light is illuminated, have an authorized
dealer service the SOS Call system immediately.

•

The Occupant Restraint Control module turns on
the Air Bag Warning Light on the instrument panel
if a malfunction in any part of the system is
detected. If the Air Bag Warning Light is illumi-
nated, have an authorized dealer service the Occu-
pant Restraint Control system immediately.

IN CASE OF EMERGENCY

193

Jeep Compass (2024 year). Manual in english - page 6
