STARTING AND OPERATING

RAILER

ITCH

LASSIFICATION

The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow and should be used to assist you in selecting

the correct trailer hitch for your intended towing condition.

Trailer Hitch Classification Definitions

Class

Max. Trailer Hitch Industry Standards

Class I - Light Duty

2,000 lb (907 kg)

Class II - Medium Duty

3,500 lb (1,587 kg)

Class III - Heavy Duty

6,000 lb (2,722kg)

Class IV - Extra Heavy Duty

10,000 lb (4,535 kg)

Refer to the “Trailer Towing Weights (Maximum Trailer Weight Ratings)” chart for the Maximum Gross Trailer Weight (GTW) towable for your given drivetrain.
All trailer hitches should be professionally installed on your vehicle.

STARTING AND OPERATING

189

RAILER

OWING

EIGHTS

AXIMUM

RAILER

EIGHT

ATINGS

)

Grand Cherokee — 2nd Row Seats

Engine

Model

GCWR

Frontal Area

Maximum GTW

Maximum Trailer TW

(See Note)

2.0L

AWD Without Trailer Tow

Prep Group

9,625 lb (4,366 kg)

30 sq ft (2.79 sq m)

3,500 lb (1,588 kg)

350 lb (159 kg)

2.0L

AWD With Trailer Tow

Prep Group

12,125 lb (5,568 kg)

40 sq ft (3.72 sq m)

6,000 lb (2,722 kg)

600 lb (272 kg)

3.6L

AWD Without Trailer Tow

Prep Group

8,600 lb (3,901 kg)

30 sq ft (2.79 sq m)

3,500 lb (1,588 kg)

350 lb (159 kg)

3.6L

AWD With Trailer Tow

Prep Group

11,300 lb (5,126 kg)

40 sq ft (3.72 sq m)

6,200 lb (2,812 kg)

620 lb (281 kg)

3.6L

RWD Without Trailer Tow

Prep Group

8,500 lb (3,856 kg)

30 sq ft (2.79 sq m)

3,500 lb (1,588 kg)

350 lb (159 kg)

3.6L

RWD With Trailer Tow

Prep Group

11,200 lb (5,080 kg)

40 sq ft (3.72 sq m)

6,200 lb (2,812 kg)

620 lb (281 kg)

5.7L

AWD With Trailer Tow

Prep Group

12,700 lb (5,761 kg)

40 sq ft (3.72 sq m)

7,200 lb (3,266 kg)

720 lb (327 kg)

Refer to local laws for maximum trailer towing speeds.

190

STARTING AND OPERATING

Grand Cherokee L — 3rd Row Seats

NOTE:



The trailer tongue weight must be considered as part of the combined weight of occupants and cargo, and should never exceed the weight referenced on the

Tire And Loading Information Placard

page 374. The addition of passengers and cargo may require reducing trailer tongue weight and Gross Trailer Weight

(GTW). Redistributing cargo (to the trailer) may be necessary to avoid exceeding Rear Gross Axle Weight Rating (GAWR).



Vehicles not factory-equipped with the trailer tow package are limited to 3,500 lb (1,588 kg) GTW and 350 lb (158 kg) TW.

Engine

Model

GCWR

Frontal Area

Maximum GTW

Maximum Trailer TW

(See Note)

3.6L

RWD Without Trailer Tow

Prep Group

9,000 lb (4,082 kg)

30 sq ft (2.79 sq m)

3,500 lb (1,588 kg)

350 lb (159 kg)

3.6L

RWD With Trailer Tow

Prep Group

11,700 lb (5,307 kg)

40 sq ft (3.72 sq m)

6,200 lb (2,812 kg)

620 lb (281 kg)

3.6L

AWD Without Trailer Tow

Prep Group

9,000 lb (4,082 kg)

30 sq ft (2.79 sq m)

3,500 lb (1,588 kg)

350 lb (159 kg)

3.6L

AWD With Trailer Tow

Prep Group

11,700 lb (5,307 kg)

40 sq ft (3.72 sq m)

6,200 lb (2,812 kg)

620 lb (281 kg)

5.7L

AWD With Trailer Tow

Prep Group

13,100 lb (5,942 kg)

40 sq ft (3.72 sq m)

7,200 lb (3,266 kg)

720 lb (327 kg)

Refer to local laws for maximum trailer towing speeds.

STARTING AND OPERATING

191

RAILER

ITCH

ECEIVER

OVER

EMOVAL

— I

QUIPPED

Your vehicle may be equipped with a trailer hitch

receiver cover, this must be removed to access the

trailer hitch receiver. This cover is located at the

bottom center of the rear fascia/bumper.
1. Turn the two locking retainers located at the

bottom of the hitch receiver cover a quarter

turn counterclockwise and pull bottom of the

hitch receiver cover outward (towards you).

2. Pull the bottom of the cover outward (towards

you) then downwards to disengage the tabs

located at the top of the hitch receiver cover to

remove.

Hitch Receiver Cover

To reinstall the cover after towing repeat the

procedure in reverse order.
NOTE:

Be sure to engage all tabs of the hitch receiver

cover in the fascia/bumper prior to installation.

RAILER

ONGUE

EIGHT

Never exceed the maximum tongue weight

stamped on your fascia/bumper or trailer hitch.

Weight Distribution

Consider the following items when computing the

weight on the rear axle of the vehicle:



The tongue weight of the trailer.



The weight of any other type of cargo or equip

ment put in or on your vehicle.



The weight of the driver and all passengers.

NOTE:

Remember that everything put into or on the trailer

adds to the load on your vehicle. Also, additional

factory-installed options or dealer-installed options

must be considered as part of the total load on

your vehicle. Refer to the Tire And Loading Infor

mation Placard for the maximum combined weight

of occupants and cargo for your vehicle.

1 — Hitch Receiver Cover
2 — Locking Retainers

WARNING!

Always load a trailer with 60% of the weight in

the front of the trailer. This places 10% of the

GTW on the tow hitch of your vehicle. Loads

balanced over the wheels or heavier in the rear

can cause the trailer to sway severely side to

side which will cause loss of control of the

vehicle and trailer. Failure to load trailers heavier

in front is the cause of many trailer collisions.

192

STARTING AND OPERATING

(Continued)

OWING

EQUIREMENTS

To promote proper break-in of the new vehicle

drivetrain components, the following guidelines

are recommended.

Perform the maintenance listed in the Scheduled

Servicing

page 330. When towing a trailer,

never exceed the GAWR or GCWR ratings.

Towing Requirements — Tires



Do not attempt to tow a trailer while using a

compact spare tire.



Do not drive more than 50 mph (80 km/h) when

towing while using a full size spare tire.



Proper tire inflation pressures are essential to

the safe and satisfactory operation of your

vehicle.



Check the trailer tires for proper tire inflation

pressures before trailer usage.



Check for signs of tire wear or visible tire

damage before towing a trailer.



Replacing tires with a higher load carrying

capacity will not increase the vehicle's GVWR

and GAWR limits.



For further information

page 374.

CAUTION!



Do not tow a trailer at all during the first

500 miles (805 km) the new vehicle is driven.

The engine, axle or other parts could be

damaged.



Then, during the first 500 miles (805 km) that

a trailer is towed, do not drive over 50 mph

(80 km/h) and do not make starts at full

throttle. This helps the engine and other parts

of the vehicle wear in at the heavier loads.

WARNING!



Make certain that the load is secured in the

trailer and will not shift during travel. When

trailering cargo that is not fully secured,

dynamic load shifts can occur that may be

difficult for the driver to control. You could lose

control of your vehicle and have a collision.



When hauling cargo or towing a trailer, do not

overload your vehicle or trailer. Overloading can

cause a loss of control, poor performance or

damage to brakes, axle, engine, transmission,

steering, suspension, chassis structure or tires.



Safety chains must always be used between

your vehicle and trailer. Always connect the

chains to the hook retainers of the vehicle

hitch. Cross the chains under the trailer

tongue and allow enough slack for turning

corners.



Vehicles with trailers should not be parked on

a grade. When parking, apply the parking

brake on the tow vehicle. Put the tow vehicle

transmission in PARK (P). For four-wheel drive

vehicles, make sure the transfer case is not in

NEUTRAL (N). Always, block or "chock" the

trailer wheels.



GCWR must not be exceeded.



Total weight must be distributed between the

tow vehicle and the trailer such that the

following four ratings are not exceeded:



GVWR



GTW

WARNING!



GAWR



Tongue weight rating for the trailer hitch

utilized

WARNING!

STARTING AND OPERATING

193

Towing Requirements — Trailer Brakes



Do not interconnect the hydraulic brake system

or vacuum system of your vehicle with that of

the trailer. This could cause inadequate braking

and possible personal injury.



An electronically actuated trailer brake

controller is required when towing a trailer with

electronically actuated brakes. When towing a

trailer equipped with a hydraulic surge actuated

brake system, an electronic brake controller is

not required.



Trailer brakes are recommended for trailers

over 1,000 lb (453 kg) and required for trailers

in excess of 2,000 lb (907 kg).

Towing Requirements — Trailer Lights And

Wiring

Whenever pulling a trailer, regardless of the trailer

size, stop lights and turn signals on the trailer are

required for motoring safety.
The Trailer Tow Package may include a four- and

seven-pin wiring harness. Use a factory approved

trailer harness and connector.
NOTE:

Do not cut or splice wiring into the vehicle’s wiring

harness.
The electrical connections are all complete to the

vehicle but you must mate the harness to a trailer

connector. Refer to the following illustrations.

NOTE:



Disconnect the trailer wiring connector from the

vehicle (or any other device plugged into

vehicle’s electrical connectors) before

launching a boat into water.



Be sure to reconnect once clear from water

area.

Four-Pin Connector

WARNING!



Do not connect trailer brakes to your vehicle's

hydraulic brake lines. It can overload your

brake system and cause it to fail. You might

not have brakes when you need them and

could have an accident.



Towing any trailer will increase your stopping

distance. When towing, you should allow for

additional space between your vehicle and the

vehicle in front of you. Failure to do so could

result in an accident.

CAUTION!

If the trailer weighs more than 1,000 lb (453 kg)

loaded, it should have its own brakes and they

should be of adequate capacity. Failure to do this

could lead to accelerated brake lining wear, higher

brake pedal effort, and longer stopping distances.

1 — Ground
2 — Park
3 — Left Stop/Turn
4 — Right Stop/Turn

194

STARTING AND OPERATING

Seven-Pin Connector

OWING

IPS

Before towing, practice turning, stopping, and

backing up the trailer in an area located away from

heavy traffic.

Automatic Transmission

Select the DRIVE (D) range when towing. The

transmission controls include a drive strategy to

avoid frequent shifting when towing. However, if

frequent shifting does occur while in DRIVE, you

can use the AutoStick shift control to manually

select a lower gear.
NOTE:

Using a lower gear while operating the vehicle

under heavy loading conditions, will improve

performance and extend transmission life by

reducing excessive shifting and heat buildup. This

action will also provide better engine braking.

Cruise Control — If Equipped



Do not use on hilly terrain or with heavy loads.



When using the Cruise Control, if you experience

speed drops greater than 10 mph (16 km/h),

disengage until you can get back to cruising

speed.



Use Cruise Control in flat terrain and with light

loads to maximize fuel efficiency.

1 — Backup Lamps
2 — Running Lamps
3 — Left Stop/Turn
4 — Ground
5 — Battery
6 — Right Stop/Turn
7 — Electric Brakes

STARTING AND OPERATING

195

RECREATIONAL TOWING (BEHIND MOTORHOME)

OWING

HIS

EHICLE

EHIND

NOTHER

EHICLE

NOTE:



When towing your vehicle, always follow applicable state and provincial laws. Contact state and provincial Highway Safety offices for additional details.



Vehicles equipped with Quadra-Lift must be placed in Transport Mode before tying them down (from the body) on a trailer or flatbed truck

page 136. If the

vehicle cannot be placed in Transport Mode (for example, engine will not run), tie-downs should be fastened over the tires using specific straps (not to the

body). Failure to follow these instructions may cause fault codes to be set and/or cause loss of proper tie-down tension.

Towing Condition

Wheels OFF The Ground

Two-Wheel Drive Models

Four-Wheel Drive Models

Without 4WD LOW

Four-Wheel Drive Models

With 4WD LOW

Flat Tow

NONE

NOT ALLOWED

See Instructions



Transmission in PARK



Ensure vehicle is set to

Normal Ride Height — if

equipped



Transfer case in N

(NEUTRAL)



Tow in forward direction

Dolly Tow

Front

NOT ALLOWED

Rear

NOT ALLOWED

On Trailer

ALL

196

STARTING AND OPERATING

ECREATIONAL

OWING

— T

-W

HEEL

RIVE

ODELS

DO NOT flat tow this vehicle. Damage to the

drivetrain will result.
Recreational towing (for two-wheel drive models) is

allowed ONLY if the rear wheels are OFF the

ground. This may be accomplished using a tow

dolly or vehicle trailer. If using a tow dolly, follow

this procedure:
1. Properly secure the dolly to the tow vehicle,

following the dolly manufacturer's

instructions.

2. Drive the rear wheels onto the tow dolly.
3. Apply the Electric Park Brake. Shift the

transmission into PARK.

4. Turn the ignition OFF.
5. Properly secure the rear wheels to the dolly,

following the dolly manufacturer’s

instructions.

6. Install a suitable clamping device, designed for

towing, to secure the front wheels in the

straight position.

ECREATIONAL

OWING

—

UADRA

-T

RAC

I (S

INGLE

-S

PEED

RANSFER

ASE

WITHOUT

4WD LOW

ANGE

) F

OUR

-W

HEEL

RIVE

ODELS

Recreational towing is not allowed. These models

do not have a N (NEUTRAL) position in the transfer

case.
NOTE:

This vehicle may be towed on a flatbed or vehicle

trailer provided all four wheels are OFF the ground.

ECREATIONAL

OWING

—

UADRA

–T

RAC

WITH

4WD LOW

ANGE

The transfer case must be shifted into N

(NEUTRAL) and the transmission must be in PARK

(P) for recreational towing. The N (NEUTRAL)

selection button is adjacent to the air suspension

switch. Shifts into and out of transfer case N

(NEUTRAL) can take place with the selector switch

in any mode position.
NOTE:



Ensure vehicle is set to Normal Ride Height - if

equipped

page 136.



If the vehicle is equipped with Quadra-Lift air

suspension, the engine should be started and

left running for a minimum of 60 seconds (with

all the doors closed) at least once every 24

hours. This process allows the air suspension to

adjust the vehicle’s ride height to compensate

for temperature effects.

CAUTION!

Towing with the rear wheels on the ground will

cause severe transmission damage. Damage

from improper towing is not covered under the

New Vehicle Limited Warranty.

CAUTION!

Towing this vehicle in violation of the above

requirements can cause severe transmission

and/or transfer case damage. Damage from

improper towing is not covered under the New

Vehicle Limited Warranty.

STARTING AND OPERATING

197

Shifting Into Transfer Case N (NEUTRAL)

Use the following procedure to prepare your

vehicle for recreational towing:
1. Bring the vehicle to a complete stop on level

ground, with the engine running.

2. Press and hold the brake pedal.
3. Shift the transmission into NEUTRAL.

4. If vehicle is equipped with Quadra-Lift air

suspension, ensure the vehicle is set to

Normal Ride Height with the Auto Entry/Exit

setting deselected.
NOTE:



Steps 1 through 4 are requirements that

must be met before pushing the N

(NEUTRAL) button, and must continue to be

met until the shift has been completed. If

any of these requirements are not met

before pushing the N (NEUTRAL) button or

are no longer met during the shift, then the

N (NEUTRAL) indicator light will flash contin

uously until all requirements are met or until

the N (NEUTRAL) button is released.



The ignition must be in the ON/RUN position

for a shift to take place and for the position

indicator lights to be operable. If the ignition

is not in the ON/RUN position, the shift will

not take place and no position indicator

lights will be on or flashing.



A flashing N (NEUTRAL) position indicator

light indicates that shift requirements have

not been met.

CAUTION!



DO NOT dolly tow any 4WD vehicle. Towing

with only one set of wheels on the ground

(front or rear) will cause severe transmission

and/or transfer case damage. Tow with all

four wheels either ON the ground, or OFF the

ground (using a vehicle trailer).



Tow only in a forward direction. Towing this

vehicle backwards can cause severe damage

to the transfer case.



The transmission must be in PARK for recre

ational towing.



Before recreational towing, perform the proce

dure outlined under “Shifting into N

(NEUTRAL)” to be certain that the transfer

case is fully in N (NEUTRAL). Otherwise,

internal damage will result.



Towing this vehicle in violation of the above

requirements can cause severe transmission

and/or transfer case damage. Damage from

improper towing is not covered under the New

Vehicle Limited Warranty.



Do not use a bumper-mounted clamp-on tow

bar on your vehicle. The bumper face bar will

be damaged.

WARNING!

You or others could be injured or killed if you

leave the vehicle unattended with the transfer

case in the N (NEUTRAL) position without first

fully engaging the Electric Park Brake. The

transfer case N (NEUTRAL) position disengages

both the front and rear driveshafts from the

powertrain and will allow the vehicle to roll, even

if the transmission is in PARK. The Electric Park

Brake should always be applied when the driver

is not in the vehicle.

CAUTION!

It is necessary to follow these steps to be certain

that the transfer case is fully in N (NEUTRAL)

before recreational towing to prevent damage to

internal parts.

198

STARTING AND OPERATING



If the vehicle is equipped with Quadra-Lift

air suspension, the engine should be

started and left running for a minimum of

60 seconds (with all the doors closed) at

least once every 24 hours. This process

allows the air suspension to adjust the

vehicle’s ride height to compensate for

temperature effects.



Engaging/disengaging of the Electric Park

Brake requires the ignition to be in the ON/

RUN position.



If shift conditions/interlocks are not met, a

“4WD Shift Canceled” or a “4WD Shift

Aborted/ Retry Shift” message will be

displayed on the instrument cluster. To reat

tempt shift, put the transmission in

NEUTRAL (N) and push and hold the 4WD

LOW button.



If shift conditions/interlocks are not met, a

“To Complete 4WD Shift Put Transmission

In Neutral” or a “To Complete 4WD Shift

Speed Must Be Below 3 MPH” or a “To

Complete 4WD Shift Allow Engine To Return

To Idle” message will flash from the instru

ment cluster display

page 98.

5. Using a ballpoint pen or similar object, push

and hold the recessed transfer case N

(NEUTRAL) button (located by the selector

switch) for more than four seconds. The light

behind the N symbol will blink, indicating shift

in progress. The light will stop blinking (stay on

solid) when the shift to N (NEUTRAL) is

complete. A “Four Wheel Drive System In

Neutral” message will appear in the

instrument cluster.

N (NEUTRAL) Button

6. After the shift is complete and the N

(NEUTRAL) light stays on, release the N

(NEUTRAL) button.

7. Shift the transmission into REVERSE or DRIVE.
8. Release the brake pedal for five seconds and

ensure that there is no vehicle movement.

9. Press and hold the brake pedal. Shift the

transmission back into NEUTRAL.

10. Apply the Electric Park Brake.

11. With the transmission and transfer case in N

(NEUTRAL), push and hold the ENGINE START/

STOP button until the engine turns off. Ensure

vehicle is in RUN position with the engine off.

12. Place the transmission gear selector in PARK.

Release the brake pedal.

13. Attach the vehicle to the tow vehicle using a

suitable tow bar.

14. Release the Electric Park Brake. Ensure

vehicle is in RUN position with the engine off.

15. Push the ENGINE START/STOP button twice

(without pressing the brake pedal), to turn the

ignition to the OFF position.

Shifting Out Of Transfer Case N (NEUTRAL)

Use the following procedure to prepare your

vehicle for normal use:
1. Bring the vehicle to a complete stop, leaving

it connected to the tow vehicle.

2. Apply the Electric Park Brake.
3. Start the engine or for 4xe vehicles ensure the

vehicle is in Ready to Drive mode, the READY

indicator will appear in the instrument cluster

display.

STARTING AND OPERATING

199

NOTE:



Steps 1 through 5 are requirements that

must be met before pushing the N

(NEUTRAL) button, and must continue to be

met until the shift has been completed. If

any of these requirements are not met

before pushing the N (NEUTRAL) button or

are no longer met during the shift, the N

(NEUTRAL) indicator light will flash continu

ously until all requirements are met or until

the N (NEUTRAL) button is released.



The ignition must be in the ON/RUN position

for a shift to take place and for the position

indicator lights to be operable. If the ignition

is not in the ON/RUN position, the shift will

not take place and no position indicator

lights will be on or flashing.



A flashing N (NEUTRAL) position indicator

light indicates that shift requirements have

not been met.

4. Press and hold the brake pedal.
5. Shift the transmission into NEUTRAL.
6. Using a ballpoint pen or similar object, push

and hold the recessed transfer case N

(NEUTRAL) button (located by the selector

switch) for five seconds.

N (NEUTRAL) Button

NOTE:

If the engine is in high idle after a cold start, the

instrument cluster will display “To Complete 4WD

Shift Allow Engine To Return To Idle” and the

transfer case will not be able to shift out of N

(NEUTRAL).
7. When the N (NEUTRAL) indicator light turns off,

release the N (NEUTRAL) button. After the N

(NEUTRAL) button has been released, the

transfer case will always shift to 4WD HI.

8. Shift the transmission into PARK. Turn the

engine off.

9. Release the brake pedal.
10. Disconnect vehicle from the tow vehicle.
11. Start the engine.

12. Press and hold the brake pedal.
13. Release the Electric Park Brake.
14. Shift the transmission into REVERSE or DRIVE,

release the brake pedal, and check that the

vehicle operates normally.

DRIVING TIPS

-R

OAD

RIVING

IPS

Utility vehicles have higher ground clearance and a

narrower track to make them capable of

performing in a wide variety of off-road

applications. Specific design characteristics give

them a higher center of gravity than conventional

passenger cars.
An advantage of the higher ground clearance is a

better view of the road, allowing you to anticipate

problems. They are not designed for cornering at

the same speeds as conventional passenger cars

any more than low-slung sports cars are designed

to perform satisfactorily in off-road conditions.

Avoid sharp turns or abrupt maneuvers. As with

other vehicles of this type, failure to operate this

vehicle correctly may result in loss of control or

vehicle rollover.

200

STARTING AND OPERATING

-R

OAD

RIVING

IPS

Quadra-Lift — If Equipped

When off-roading, it is recommended that the

lowest useable vehicle height that will clear the

current obstacle or terrain be selected. The vehicle

height should then be raised as required by the

changes in terrain.
The Selec-Terrain switch will automatically change

the vehicle to the optimized height based on the

Selec-Terrain switch position. The vehicle height

can be changed from the default height for each

Selec-Terrain mode by normal use of the air

suspension switches

page 131.

When To Use 4WD LOW Range —

If Equipped

When off-road driving, shift to 4WD LOW for

additional traction. This range should be limited to

extreme situations such as deep snow, mud, or

sand where additional low speed pulling power is

needed. Vehicle speeds in excess of 25 mph

(40 km/h) should be avoided when in 4WD LOW

range.

Driving Through Water

Although your vehicle is capable of driving through

water, there are a number of precautions that

must be considered before entering the water.
NOTE:

Your vehicle is capable of water fording in up to

24 inches (61 cm) with air suspension or

21 inches (53 cm) without air suspension, of water

while crossing small rivers or streams. To maintain

optimal performance of your vehicle's heating and

ventilation system it is recommended to switch the

system into recirculation mode during water

fording. Be sure to avoid lowering the vehicle in

water, ensure that the easy exit entry setting is

turned off in Uconnect settings.

Driving through water more than a few inches/

centimeters deep will require extra caution to

ensure safety and prevent damage to your vehicle.

If you must drive through water, try to determine

the depth and the bottom condition (and location

of any obstacles) prior to entering. Proceed with

caution and maintain a steady controlled speed

less than 5 mph (8 km/h) in deep water to

minimize wave effects.
Flowing Water
If the water is swift flowing and rising (as in storm

run-off), avoid crossing until the water level

recedes and/or the flow rate is reduced. If you

must cross flowing water avoid depths in excess of

9 inches (23 cm). The flowing water can erode the

streambed, causing your vehicle to sink into

deeper water. Determine exit point(s) that are

downstream of your entry point to allow for drifting.

WARNING!

Do not drive in 4WD LOW range on dry

pavement; driveline damage may result. 4WD

LOW range locks front and rear drivelines

together and does not allow for differential

action between the front to rear driveshafts.

Driving in 4WD LOW on pavement will cause

driveline binding; use only on wet or slippery

surfaces.

CAUTION!

When driving through water, do not exceed

5 mph (8 km/h). Always check water depth

before entering as a precaution, and check all

fluids afterward. Driving through water may

cause damage that may not be covered by the

New Vehicle Limited Warranty.

STARTING AND OPERATING

201

Standing Water
Avoid driving in standing water deeper than

24 inches (61 cm) with air suspension or

21 inches (53 cm) without air suspension, and

reduce speed appropriately to minimize wave

effects. Maximum speed is 5 mph (8 km/h).
Maintenance
After driving through deep water, inspect your

vehicle fluids and lubricants (engine oil,

transmission oil, axle, transfer case) to ensure the

fluids have not been contaminated. Contaminated

fluid (milky, foamy in appearance) should be

flushed/changed as soon as possible to prevent

component damage.

Driving In Snow, Mud And Sand

In heavy snow, when pulling a load, or for

additional control at slower speeds, shift the

transmission to a low gear and shift the transfer

case to 4WD LOW if necessary

page 131. Only

shift into a lower gear to maintain forward motion.

Over-revving the engine can spin the wheels and

traction will be lost.
Avoid abrupt downshifts on icy or slippery roads,

because engine braking may cause skidding and

loss of control.

Hill Climbing

NOTE:

Before attempting to climb a hill, determine the

conditions at the crest and/or on the other side.
Before climbing a steep hill, shift the transmission

to a lower gear and shift the transfer case to 4WD

LOW. Use FIRST gear and 4WD LOW for very steep

hills.
If you stall or begin to lose forward motion while

climbing a steep hill, allow your vehicle to come to

a stop and immediately apply the brakes. Restart

the engine, and shift into REVERSE (R). Back slowly

down the hill, allowing the compression braking of

the engine to help regulate your speed. If the

brakes are required to control vehicle speed, apply

them lightly and avoid locking or skidding the tires.

Remember, never drive diagonally across a hill.

Always drive straight up or down.
If the wheels start to slip as you approach the crest

of a hill, ease off the accelerator and maintain

forward motion by turning the front wheels slowly.

This may provide a fresh “bite” into the surface and

will usually provide traction to complete the climb.

Traction Downhill

When descending mountains or hills, use Hill

Descent Control or Selec-Speed Control to avoid

repeated heavy braking.
If not equipped with Hill Descent Control or

Selec-Speed Control use the following procedure:
Shift the transmission into a low gear, and the

transfer case into 4WD LOW range. Let the vehicle

go slowly down the hill with all four wheels turning

against engine compression drag. This will permit

you to control the vehicle speed and direction.
When descending mountains or hills, repeated

braking can cause brake fade with loss of braking

control. Avoid repeated heavy braking by

downshifting the transmission whenever possible.

WARNING!

If the engine stalls, you lose forward motion, or

cannot make it to the top of a steep hill or grade,

never attempt to turn around. To do so may

result in tipping and rolling the vehicle. Always

back carefully straight down a hill in REVERSE

gear. Never back down a hill in NEUTRAL using

only the brake.

202

STARTING AND OPERATING

After Driving Off-Road

Off-road operation puts more stress on your

vehicle than does most on-road driving. After going

off-road, it is always a good idea to check for

damage. That way you can get any problems taken

care of right away and have your vehicle ready

when you need it.



Completely inspect the underbody of your

vehicle. Check tires, body structure, steering,

suspension, and exhaust system for damage.



Inspect the radiator for mud and debris and

clean as required.



Check threaded fasteners for looseness, partic

ularly on the chassis, drivetrain components,

steering, and suspension. Retighten them, if

required, and torque to the values specified in

the Service Manual.



Check for accumulations of plants or brush.

These things could be a fire hazard. They might

hide damage to fuel lines, brake hoses, axle

pinion seals, and propeller shafts.



After extended operation in mud, sand, water, or

similar dirty conditions, have the radiator, fan,

brake rotors, wheels, brake linings, and axle

yokes inspected and cleaned as soon as

possible.



If you experience unusual vibration after driving

in mud, slush or similar conditions, check the

wheels for impacted material. Impacted mate

rial can cause a wheel imbalance and freeing

the wheels of it will correct the situation.

WARNING!

Abrasive material in any part of the brakes may

cause excessive wear or unpredictable braking.

You might not have full braking power when you

need it to prevent a collision. If you have been

operating your vehicle in dirty conditions, get

your brakes checked and cleaned as necessary.

203

MULTIMEDIA

UCONNECT SYSTEMS

For detailed information about your Uconnect 5/

5 NAV With 8.4-inch Display or Uconnect 5/5 NAV

With 10.1-inch Display system, refer to your

Uconnect Radio Instruction Manual.
NOTE:

Uconnect screen images are for illustration

purposes only and may not reflect exact software

for your vehicle.

CYBERSECURITY

Depending on applicability, your vehicle may be

able to send or receive information from a wired or

wireless network. This information allows systems

and features in your vehicle to function properly.

Your vehicle may be equipped with certain security

features to reduce the risk of unauthorized and

unlawful access to vehicle systems and wireless

communications. Vehicle software technology

continues to evolve over time and FCA US LLC,

working with its suppliers, evaluates and takes

appropriate steps as needed. As always, if you

experience unusual behavior, contact an

authorized dealer immediately,

page 403, or

refer to your Uconnect Radio Instruction Manual

for additional contact information.
The risk of unauthorized and unlawful access to

your vehicle systems may still exist, even if the

most recent version of vehicle software (such as

Uconnect software) is installed.

NOTE:

To help further improve user experience, features,

stability, etc., and minimize the potential risk of a

security breach, vehicle owners should routinely

check

www.driveuconnect.com (US Residents) or

www.driveuconnect.ca (Canadian Residents) to

learn about available Uconnect software updates.

WARNING!



ONLY insert trusted devices/components into

your vehicle. Media of unknown origin could

possibly contain malicious software, and if

installed in your vehicle, it may increase the

possibility for vehicle systems to be breached.



As always, if you experience unusual vehicle

behavior, take your vehicle to an authorized

dealer immediately.

Jeep Grand Cherokee (2023 year). Manual in english - page 12
