STARTING AND OPERATING

203

until it makes contact with the object. Apply the

throttle lightly while holding a light brake pressure

and ease the vehicle up and over the object.

USING A SPOTTER

There are many times where it is hard to see the

obstacle or determine the correct path.

Determining the correct path can be extremely

difficult when you are confronting many obstacles.

In these cases have someone guide you over,

through, or around the obstacle. Have the person

stand a safe distance in front of you where they

can see the obstacle, watch your tires and

undercarriage, and guide you through.

CROSSING LARGE ROCKS

When approaching large rocks, choose a path

which ensures you drive over the largest of them

with your tires. This will lift your undercarriage over

the obstacle. The tread of the tire is tougher and

thicker than the side wall and is designed to take

the abuse. Always look ahead and make every

effort to cross the large rocks with your tires.

CROSSING A RAVINE, GULLY, DITCH,

WASHOUT OR RUT

When crossing a ravine, gully, ditch, washout or a

large rut, the angled approach is the key to

maintaining your vehicle's mobility. Approach

these obstacles at a 45-degree angle and let each

tire go through the obstacle independently. You

need to use caution when crossing large obstacles

with steep sides. Do not attempt to cross any large

obstacle with steep sides at an angle great enough

to put the vehicle at risk of a rollover. If you get

caught in a rut, dig a small trench to the right or left

at a 45-degree angle ahead of the front tires. Use

the removed dirt to fill the rut ahead of the turnout

you just created. You should now be able to drive

out following the trench you just created at a

45-degree angle.

CROSSING LOGS

To cross a log, approach it at a slight angle

(approximately 10 to 15 degrees). This allows one

front tire to be on top of the log while the other just

starts to climb the log. While climbing the log,

modulate your brake and accelerator to avoid

spinning the log out from under your tires. Then

ease the vehicle off the log using your brakes.

GETTING HIGH-CENTERED

If you get hung up or high-centered on an object,

get out of the vehicle and try to determine what the

vehicle is hung up on, where it is contacting the

underbody and what is the best direction to

recover the vehicle. Depending on what you are in

contact with, jack the vehicle up and place a few

rocks under the tires so the weight is off of the high

point when you let the vehicle down. You can also

try rocking the vehicle or winching the vehicle off

the object.

WARNING!

Crossing obstacles can cause abrupt steering

system loading which could cause you to lose

control of your vehicle.

CAUTION!



Never attempt to straddle a rock that is large

enough to strike your axles or undercarriage.



Never attempt to drive over a rock which is

large enough to contact the door sills.

WARNING!

There is an increased risk of rollover when

crossing an obstacle, at any angle, with steep

sides.

CAUTION!

Do not attempt to cross a log with a greater

diameter than the running ground clearance or

the vehicle will become high-centered.

CAUTION!

Winching or rocking the vehicle off hard objects

increases the risk of underbody damage.

204

STARTING AND OPERATING

Hill Climbing

Hill climbing requires good judgment and a good

understanding of your abilities and your vehicle's

limitations. Hills can cause serious problems.

Some are just too steep to climb and should not be

attempted. You should always feel confident with

the vehicle and your abilities. You should always

climb hills straight up and down. Never attempt to

climb a hill on an angle.

BEFORE CLIMBING A STEEP HILL

As you approach a hill, consider its grade or

steepness. Determine if it is too steep. Look to see

what the traction is on the hill side trail. Is the trail

straight up and down? What is on top and the other

side? Are there ruts, rocks, branches or other

obstacles on the path? Can you safely recover the

vehicle if something goes wrong? If everything

looks good and you feel confident, shift the

transmission into a lower gear with 4L engaged,

and proceed with caution, maintaining your

momentum as you climb the hill.

DRIVING UP HILL

Once you have determined your ability to proceed

and have shifted into the appropriate gear, line

your vehicle up for the straightest possible run.

Accelerate with an easy constant throttle and apply

more power as you start up the hill. Do not race

forward into a steep grade; the abrupt change of

grade could cause you to lose control. If the front

end begins to bounce, ease off the throttle slightly

to bring all four tires back on the ground. As you

approach the crest of the hill, ease off the throttle

and slowly proceed over the top. If the wheels start

to slip as you approach the crest of a hill, ease off

the accelerator and maintain headway by turning

the steering wheel no more than a 1/4 turn quickly

back and forth. This will provide a fresh "bite" into

the surface and will usually provide enough

traction to complete the climb. If you do not make

it to the top, place the vehicle in REVERSE and

back straight down the grade using engine

resistance along with the vehicle brakes.

DRIVING DOWNHILL

Before driving down a steep hill, you need to

determine if it is too steep for a safe descent. What

is the surface traction? Is the grade too steep to

maintain a slow, controlled descent? Are there

obstacles? Is it a straight descent? Is there plenty

of distance at the base of the hill to regain control

if the vehicle descends too fast? If you feel

confident in your ability to proceed, then make

sure you are in 4L and proceed with caution. Allow

engine braking to control the descent and apply

your brakes, if necessary, but do not allow the tires

to lock.

DRIVING ACROSS AN INCLINE

If at all possible, avoid driving across an incline. If

it is necessary, know your vehicle's abilities. Driving

across an incline places more weight on the

downhill wheels, which increases the possibilities

of a downhill slide or rollover. Make sure the

surface has good traction with firm and stable

soils. If possible, transverse the incline at an angle

heading slightly up or down.

WARNING!

Never attempt to climb a hill at an angle or turn

around on a steep grade. Driving across an

incline increases the risk of a rollover, which may

result in severe injury.

WARNING!

Do not descend a steep grade in NEUTRAL. Use

vehicle brakes in conjunction with engine

braking. Descending a grade too fast could

cause you to lose control and be seriously

injured or killed.

WARNING!

Driving across an incline increases the risk of a

rollover, which may result in severe injury.

STARTING AND OPERATING

205

IF YOU STALL OR BEGIN TO LOSE HEADWAY

If you stall or begin to lose headway while climbing

a steep hill, allow your vehicle to come to a stop

and immediately apply the brake. Restart the

engine and shift into REVERSE. Back slowly down

the hill allowing engine braking to control the

descent and apply your brakes, if necessary, but

do not allow the tires to lock.

Driving Through Water

Extreme care should be taken crossing any type of

water. Water crossings should be avoided, if

possible, and only be attempted when necessary in

a safe, responsible manner. Only drive through

areas which are designated and approved. Tread

lightly and avoid damage to the environment.

Know your vehicle's abilities and be able to recover

it if something goes wrong. Never stop or shut a

vehicle off when crossing deep water unless you

ingested water into the engine air intake. If the

engine stalls, do not attempt to restart it.

Determine if it has ingested water first. The key to

any crossing is low and slow. Shift into FIRST gear

(manual transmission), or DRIVE (automatic

transmission), with the transfer case in the 4L

position and proceed very slowly with a constant

slow speed of {3 to 5 mph (5 to 8 km/h) maximum}

and light throttle. Keep the vehicle moving; do not

try to accelerate through the crossing. After

crossing any water higher than the bottom of the

axle differentials, inspect all of the vehicle fluids

for signs of water ingestion.

BEFORE YOU CROSS ANY TYPE OF WATER

As you approach any type of water, you need to

determine if you can cross it safely and

responsibly. If necessary, get out and walk through

the water or probe it with a stick. You need to be

sure of its depth, approach angle, current and

bottom condition. Be careful of murky or muddy

waters; check for hidden obstacles. Make sure you

will not be intruding on any wildlife, and you can

recover the vehicle if necessary. The key to a safe

crossing is the water depth, current and bottom

conditions. On soft bottoms, the vehicle will sink in,

effectively increasing the water level on the

vehicle. Be sure to consider this when determining

the depth and the ability to safely cross.

CROSSING PUDDLES, POOLS, FLOODED

AREAS OR OTHER STANDING WATER

Puddles, pools, flooded or other standing water

areas normally contain murky or muddy waters.

These water types normally contain hidden

obstacles and make it difficult to determine an

accurate water depth, approach angle, and bottom

condition. Murky or muddy water holes are where

you want to hook up tow straps prior to entering.

This makes for a faster, cleaner and easier vehicle

recovery. If you are able to determine you can

safely cross, than proceed using the low and slow

method.

WARNING!

If the engine stalls or you lose headway or

cannot make it to the top of a steep hill or grade,

never attempt to turn around. To do so may

result in tipping and rolling the vehicle, which

may result in severe injury. Always back carefully

straight down a hill in REVERSE. Never back

down a hill in NEUTRAL using only the vehicle

brakes. Never drive diagonally across a hill,

always drive straight up or down.

CAUTION!



Water ingestion into the axles, transmission,

transfer case, engine or vehicle interior can

occur if you drive too fast or through too deep

of water. Water can cause permanent damage

to engine, driveline or other vehicle compo

nents, and your brakes will be less effective

once wet and/or muddy.



When driving through water, do not exceed

5 mph (8 km/h). Always check water depth

before entering as a precaution, and check all

fluids afterward. Driving through water may

cause damage that may not be covered by the

New Vehicle Limited Warranty.

206

STARTING AND OPERATING

CROSSING DITCHES, STREAMS, SHALLOW

RIVERS OR OTHER FLOWING WATER

Flowing water can be extremely dangerous. Never

attempt to cross a fast running stream or river

even in shallow water. Fast moving water can

easily push your vehicle downstream, sweeping it

out of control. Even in very shallow water, a high

current can still wash the dirt out from around your

tires putting you and your vehicle in jeopardy.

There is still a high risk of personal injury and

vehicle damage with slower water currents in

depths greater than the vehicle's running ground

clearance. You should never attempt to cross

flowing water which is deeper than the vehicle's

running ground clearance. Even the slowest

current can push the heaviest vehicle downstream

and out of control if the water is deep enough to

push on the large surface area of the vehicle's

body. Before you proceed, determine the speed of

the current, the water's depth, approach angle,

bottom condition and if there are any obstacles.

Then cross at an angle heading slightly upstream

using the low and slow technique.

After Driving Off-Road

Off-road operation puts more stress on your

vehicle than does most on-road driving. After going

off-road, it is always a good idea to check for

damage. That way you can get any problems taken

care of right away and have your vehicle ready

when you need it.



Completely inspect the underbody of your

vehicle. Check tires, body structure, steering,

suspension, and exhaust system for damage.



Inspect the radiator for mud and debris and

clean as required.



Check threaded fasteners for looseness, partic

ularly on the chassis, drivetrain components,

steering, and suspension. Retighten them, if

required, and torque to the values specified in

the Service Manual.



Check for accumulations of plants or brush.

These things could be a fire hazard. They might

hide damage to fuel lines, brake hoses, axle

pinion seals, and propeller shafts.



After extended operation in mud, sand, water, or

similar dirty conditions, have the radiator, fan,

brake rotors, wheels, brake linings, and axle

yokes inspected and cleaned as soon as

possible.

NOTE:

Inspect the clutch vent holes in the manual trans

mission bell housing for mud and debris and clean

as required.



If you experience unusual vibration after driving

in mud, slush or similar conditions, check the

wheels for impacted material. Impacted mate

rial can cause a wheel imbalance and freeing

the wheels of it will correct the situation.

CAUTION!

Muddy waters can reduce the cooling system

effectiveness by depositing debris onto the

radiator.

WARNING!

Never drive through fast moving deep water. It

can push your vehicle downstream, sweeping it

out of control. This could put you and your

passengers at risk of injury or drowning.

WARNING!

Abrasive material in any part of the brakes may

cause excessive wear or unpredictable braking.

You might not have full braking power when you

need it to prevent a collision. If you have been

operating your vehicle in dirty conditions, get

your brakes checked and cleaned as necessary.

207

MULTIMEDIA

UCONNECT SYSTEMS

For detailed information about your Uconnect

4/4C/4C NAV With 8.4-inch Display system, refer

to your Uconnect Owner’s Manual Supplement.

NOTE:

Uconnect screen images are for illustration

purposes only and may not reflect exact software

for your vehicle.

CYBERSECURITY

Your vehicle may be a connected vehicle and may

be equipped with both wired and wireless

networks. These networks allow your vehicle to

send and receive information. This information

allows systems and features in your vehicle to

function properly.

Your vehicle may be equipped with certain security

features to reduce the risk of unauthorized and

unlawful access to vehicle systems and wireless

communications. Vehicle software technology

continues to evolve over time and FCA US LLC,

working with its suppliers, evaluates and takes

appropriate steps as needed.
The risk of unauthorized and unlawful access to

your vehicle systems may still exist, even if the

most recent version of vehicle software (such as

Uconnect software) is installed.

NOTE:



To help further improve vehicle security and

minimize the potential risk of a security breach,

vehicle owners should:



Routinely check www.driveuconnect.com

(US Residents) or www.driveuconnect.ca

(Canadian Residents) to learn about avail

able Uconnect software updates.



Only connect and use trusted media

devices (e.g. personal mobile phones,

USBs, CDs).

UCONNECT SETTINGS

The Uconnect system uses a combination of

buttons on the touchscreen and buttons on the

faceplate located on the center of the instrument

panel. These buttons allow you to access and

change the Customer Programmable Features.

Many features can vary by vehicle.

WARNING!



ONLY insert trusted devices/components into

your vehicle. Media of unknown origin could

possibly contain malicious software, and if

installed in your vehicle, it may increase the

possibility for vehicle systems to be breached.



As always, if you experience unusual vehicle

behavior, take your vehicle to an authorized

dealer immediately.

208

MULTIMEDIA

Buttons on the faceplate are located below and/or

beside the Uconnect system in the center of the

instrument panel. In addition, there is a SCROLL/

ENTER control knob located on the right side. Turn

the control knob to scroll through menus and

change settings. Push the center of the control

knob one or more times to select or change a

setting.
Your Uconnect system may also have SCREEN OFF

and MUTE buttons on the faceplate.
Push the SCREEN OFF button on the faceplate to

turn off the Uconnect screen. Push the button

again or tap the screen to turn the screen on.
Press the Back Arrow button to exit out of a Menu

or certain option on the Uconnect system.

USTOMER

ROGRAMMABLE

EATURES

Uconnect 4C/4C NAV Touchscreen And Faceplate Buttons

For the Uconnect 4 With 7-inch Display and the

Uconnect 4/4C/4C NAV With 8.4-inch Display
Press the Apps button, then press the Settings

button on the touchscreen to display the menu

setting screen. In this mode the Uconnect system

allows you to access programmable features.

NOTE:



Depending on the vehicle’s options, feature

settings may vary.



All settings should be changed with the ignition

in the ON/RUN position.

When making a selection, only press one button at

a time to enter the desired menu. Once in the

desired menu, press and release the preferred

setting option until a check mark appears next to

the setting, showing that setting has been

selected. Once the setting is complete, press the X

button on the touchscreen to close out of the

settings screen. Pressing the Up or Down Arrow

button on the right side of the screen will allow you

to toggle up or down through the available settings.

1 — Uconnect Buttons On The Touchscreen
2 — Uconnect Buttons On The Faceplate

MULTIMEDIA

209

Language

Display

When the Language button is pressed on the touchscreen, the system displays the different language options. Once an option is selected, the system will

display in the chosen language. The available setting is:

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Language

This setting will change the language of the Uconnect system and Instrument

Cluster Display. The available languages are English, Français, and Español.

When the Display button is pressed on the touchscreen, the system will display the options related to the theme (if equipped), brightness, and color of the

touchscreen. The available settings are:

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Display Mode

This setting will allow you to set the brightness manually or have the system

set it automatically. The “Auto” setting has the system automatically adjust

the display brightness. The “Manual” setting will allow the user to adjust the

brightness of the display.

Display Brightness With Headlights ON/Brightness

This setting will allow you to set the brightness when the headlights are on. To

access this setting, Display Mode must be set to Manual. The “+” setting will

increase the brightness; the “-” will decrease the brightness.

Display Brightness With Headlights OFF/Brightness

This setting will allow you to set the brightness when the headlights are off. To

access this setting, Display Mode must be set to Manual. The “+” setting will

increase the brightness; the “-” will decrease the brightness.

210

MULTIMEDIA

Units

Set Theme

This setting will allow you to change the display theme.

Touchscreen Beep

This setting will allow you to turn the touchscreen beep on or off.

Control Screen Timeout

This setting allows you to set the Control Screen to turn off automatically after

five seconds or stay open until manually closed.

Navigation Turn-by-Turn Displayed in Cluster

This setting will display navigation prompts in the Instrument Cluster Display.

Phone Pop-ups Displayed in Cluster

This setting will display smartphone notifications and messages in the

Instrument Cluster Display.

SiriusXM® Travel Link Weather Alerts

This setting will turn the weather alerts on or off.

Setting Name

Description

When the Units button is pressed on the touchscreen, the system displays the different measurement options. The selected unit of measurement will display in

the instrument cluster display and Navigation system (if equipped). The available settings are:

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

This setting will change the unit of measurement on the display to US.

Metric

This setting will change the unit of measurement on the display to Metric.

Custom

This setting changes the “Speed” (MPH or km/h), “Distance” (mi or km), “Fuel

Consumption” (MPG [US], MPG [UK], L/100 km, or km/L), “Pressure” (psi,

kPa, or bar), “Temperature” (°C or °F), and “Torque” (Nm or lb-ft) units of

measurement independently.

MULTIMEDIA

211

Voice

Clock

When the Voice button is pressed on the touchscreen, the system displays the options related to the vehicle’s Voice Recognition feature.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Voice Response Length

This setting will change the response length for the Voice Recognition system.

The “Brief” setting provides a shortened audio description from the system.

The “Detailed” setting provides the full audio description from the system.

Show Command List

This setting will allow you to turn the Command List on or off. The “Always”

setting will always show the Command List. The “With Help” setting will show

the Command List and provide a brief description of what the command does.

The “Never” setting will turn the Command List off.

When the Clock button is pressed on the touchscreen, the system displays the different options related to the vehicle’s internal clock.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Sync Time With GPS

This setting will sync the time to the GPS receiver in the system. The system

will control the time via the GPS location.

Set Time Hours

This setting will allow you to set the hours. Sync Time With GPS must be off

for this setting to be available. The “+” setting will increase the hours.

The “-” setting will decrease the hours.

212

MULTIMEDIA

Camera

Set Time Minutes

This setting will allow you to set the minutes. Sync Time With GPS must be off

for this setting to be available. The “+” setting will increase the minutes. The

“-” setting will decrease the minutes.

Set Time And Format/Time Format

This setting will allow you to set the time format (AM/PM). Sync Time With GPS

must be off for this setting to be available. The “12 hrs” setting will set the

time to a 12-hour format. The “24 hrs” setting will set the time to a 24-hour

format.

Show Time in Status Bar/Show Time Status

This setting will place the time in the radio’s status bar.

Setting Name

Description

When the Camera button is pressed on the touchscreen, the system displays the options related to the vehicle’s camera features.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

ParkView Backup Camera Delay

This setting will add a timed delay to the ParkView Backup Camera when

shifting out of REVERSE.

Active ParkView Backup Camera Guidelines

This setting will turn the Active ParkView Backup Camera Guidelines on or off.

Fixed ParkView Backup Camera Guidelines

This setting will turn the Fixed ParkView Backup Camera Guidelines on or off.

Forward Facing Camera Guidelines

This setting will turn the Forward Facing Camera Guidelines on or off.

MULTIMEDIA

213

Safety & Driving Assistance

When the Safety & Driving Assistance button is selected on the touchscreen, the system displays the options related to the vehicle’s safety settings. These

options will differ depending on the features equipped on the vehicle. The settings may display in list form or within subfolders on the screen. To access a

subfolder, select the desired folder; the available options related to that feature will then display on the screen.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Forward Collision Warning Sensitivity — Located In Automatic Emergency

Braking Submenu

This setting will change the distance at which the Forward Collision Warning

(FCW) alert sounds. The “Medium” setting will have the FCW system signal

when an object is in view, and the possibility of a collision is detected. The

“Near” setting will have the FCW system signal when the object is closer to the

vehicle. The “Far” setting will have the FCW system signal when an object is at

a far distance from the vehicle.

Forward Collision Warning — Located In Automatic Emergency Braking

Submenu

This setting will turn the Forward Collision Warning (FCW) system on or off.

The “Off” setting will deactivate the FCW system. The “Warning Only” setting

will provide only an audible chime when a collision is detected. The “Warning

+ Active Braking” setting will provide an audible chime and apply some brake

pressure when a collision is detected.

ParkSense

This setting will change the type of ParkSense alert when a close object is

detected and provide both an audible chime and a visual display.

Front ParkSense Volume

This setting adjusts the volume of the Front ParkSense system. The available

settings are “Low”, “Medium”, and “High”.

Rear ParkSense Volume

This setting adjusts the volume of the Rear ParkSense system. The available

settings are “Low”, “Medium”, and “High”.

214

MULTIMEDIA

Mirrors & Wipers

Blind Spot Alert

This setting will change the type of alert provided when an object is detected

in a vehicle’s blind spot. The “Off” setting will turn off Blind Spot Alert. The

“Lights” setting will activate the Blind Spot Alert lights on the outside mirrors.

The “Lights & Chime” setting will activate both the lights on the outside

mirrors and an audible chime.

Hill Start Assist

This setting will turn the Hill Start Assist system on or off.

ParkView Backup Camera Delay

This setting will add a timed delay to the ParkView Backup Camera when

shifting out of REVERSE.

Active ParkView Backup Camera Guide Lines

This setting will turn the Active ParkView Backup Camera Guide Lines on or

off.

Fixed ParkView Backup Camera Guide Lines

This setting will turn the Fixed ParkView Backup Camera Guide Lines on or off.

Forward Facing Camera Guidelines

This setting will turn the Forward Facing Camera Guidelines on or off.

Tire Fill Assist

This setting will turn the Tire Fill Assist on or off.

Setting Name

Description

When the Mirrors & Wipers button is pressed on the touchscreen, the system displays the option related to the vehicle’s mirrors and wipers.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Headlights With Wipers

This setting will turn the headlights on when the wipers are activated.

MULTIMEDIA

215

Lights

When the Lights button is pressed on the touchscreen, the system displays the options related to the vehicle’s exterior and interior lights.

NOTE:



When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned on or off. This feature is only allowed by law in the country

of the vehicle purchased.



Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Headlight Off Delay

This setting will allow you to set the amount of time it takes for the headlights

to shut off after the vehicle is turned off. The available settings are “0 sec”,

“30 sec”, “60 sec”, and “90 sec”.

Headlight Illumination On Approach/Illuminated Approach

This setting will allow you to set the amount of time it takes for the headlights

to shut off after the vehicle is unlocked. The available settings are “0 sec”,

“30 sec”, “60 sec”, and “90 sec”.

Headlights With Wipers

This setting will turn the headlights on when the wipers are activated.

Auto Dim High Beams/Automatic High Beam Headlamps

This setting will allow you to turn the Auto Dim High Beams on or off.

Daytime Running Lights

This setting will allow you to turn the Daytime Running Lights on or off.

Flash Lights With Lock

This setting will allow you to turn the flashing of the lights when the Lock

button is pushed on the key fob on or off.

Interior Ambient Lights

This setting will allow you to turn the Interior Ambient Lights on or off.

216

MULTIMEDIA

Doors & Locks

When the Doors & Locks button is pressed on the touchscreen, the system displays the options related to locking and unlocking the vehicle’s doors.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Auto Door Locks

This setting will allow you to change if the doors lock automatically when the

vehicle reaches 12 mph (19 km/h).

Auto Unlock On Exit

This setting will unlock the doors when any of the doors are opened from the

inside.

Flash Lights With Lock

This setting will allow you to turn the flashing of the lights when the Lock

button is pushed on the key fob on or off.

Sound Horn With Lock/Horn With Lock

This setting will sound the horn when the Lock button is pushed on the key

fob. The “Off” setting will not sound the horn when the Lock button is pushed.

The “1st Press” setting will sound the horn when the Lock button is pushed

once. The “2nd Press” setting will sound the horn when the Lock button is

pushed twice.

Sound Horn With Remote Start/Horn With Remote Start

This setting will sound the horn when the remote start is activated from the

key fob.

Remote Door Unlock, Door Lock/1st Press Of Key Fob Unlocks

This setting will change how many pushes of the Unlock button on the key fob

are needed to unlock all the doors. The “Driver Door” setting will only unlock

the driver door on the first push on the Unlock button. The “All Doors” setting

will unlock all doors with only one push of the Unlock button.

Passive Entry

This setting will allow you to turn the Passive Entry feature (Keyless Enter ‘n

Go™) on or off.

MULTIMEDIA

217

Seats & Comfort/Auto-On Comfort Systems

AUX Switches

When Seats & Comfort/Auto-On Comfort Systems button is pressed on the touchscreen, the system displays the option related to the vehicle’s comfort systems

when remote start has been activated or the vehicle has been started.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Auto-On Heated Seat & Steering Wheel

This setting will activate the vehicle’s comfort system and heated seats or

heated steering wheel when the vehicle is remote started or ignition is

started. The “Off” setting will not activate the comfort systems. The “Remote

Start” setting will only activate the comfort systems when using Remote Start.

The “All Start” setting will activate the comfort systems whenever the vehicle

is started.

When the AUX Switches button is pressed on the touchscreen, the system displays the options related to the four vehicle AUX switches.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

AUX 1-4

This setting will adjust the type and power source for the four vehicle AUX

switches. There are two types: “Latching” and “Momentary”. The power

source for the AUX switches can either be set to run off the “Battery” or from

the “Ignition”. In addition to setting the type and power source, you can set if

the vehicle will recall the previous state at which the AUX switches were set.

The Recalled Last State setting can be set to “On” or “Off”. Last state

conditions are met only if the type is set to Latching and the power source is

set to Ignition.

218

MULTIMEDIA

Key Off Options/Engine Off Options

Audio

After pressing the Key Off Options/Engine Off Options button on the touchscreen, the following settings will be available:

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Doors On Key Off Power Delay/Doors On Power Delay

This setting will keep certain electrical features running after the engine is

turned on. When any door is opened, the electronics will deactivate. The

available settings are “0 sec”, “45 sec”, “5 min”, and “10 min”.

Doors Off Key Off Power Delay/Doors Off Power Delay

This setting will keep certain electrical features running after the engine is

turned off. When any door is opened, the electronics will deactivate. The

available settings are “0 sec”, “45 sec”, “5 min”, and “10 min”.

Headlight Off Delay

This setting will allow you to set the amount of time the headlights remain on

after the vehicle has been turned off. The “+” will increase the amount of

time. The “-” will decrease the amount of time.

When the Audio button is pressed on the touchscreen, the system displays options related to the vehicle’s sound system. These settings can change the audio

location within the vehicle, adjust the bass or treble levels, and auto-play settings from an audio device or smartphone.

NOTE:

Depending on the vehicle’s options, feature settings may vary.

Setting Name

Description

Balance/Fade

This setting will adjust audio levels from specific speakers in the front/back

and left/right of the vehicle. The Speaker icon can be moved to set audio

location.

Equalizer

This setting will adjust the “Bass”, “Mid”, and “Treble” ranges of the audio.

Content .. 11 12 13 14 ..
