GETTING TO KNOW YOUR INSTRUMENT PANEL

Service Forward Collision Warning (FCW)

Light — If Equipped

This warning light will illuminate to

indicate a fault in the Forward Collision

Warning System. Contact an authorized

dealer for service

page

232.

Service Stop/Start System Warning Light —

If Equipped

This warning light will illuminate when the

Stop/Start system is not functioning

properly and service is required. Contact

an authorized dealer for service.

Tire Pressure Monitoring System (TPMS)

Warning Light

The warning light switches on and a

message is displayed to indicate that the

tire pressure is lower than the

recommended value and/or that slow

pressure loss is occurring. In these cases, optimal

tire duration and fuel consumption may not be

guaranteed.
Should one or more tires be in the condition

mentioned above, the display will show the

indications corresponding to each tire.

Each tire, including the spare (if provided), should

be checked monthly when cold and inflated to the

inflation pressure recommended by the vehicle

manufacturer on the vehicle placard or tire

inflation pressure label. If your vehicle has tires of

a different size than the size indicated on the

vehicle placard or tire inflation pressure label, you

should determine the proper tire inflation pressure

for those tires.
As an added safety feature, your vehicle has been

equipped with a TPMS that illuminates a low tire

pressure telltale when one or more of your tires is

significantly underinflated. Accordingly, when the

low tire pressure telltale illuminates, you should

stop and check your tires as soon as possible, and

inflate them to the proper pressure. Driving on a

significantly underinflated tire causes the tire to

overheat and can lead to tire failure. Underinflation

also reduces fuel efficiency and tire tread life, and

may affect the vehicle’s handling and stopping

ability.

Please note that the TPMS is not a substitute for

proper tire maintenance, and it is the driver’s

responsibility to maintain correct tire pressure,

even if underinflation has not reached the level to

trigger illumination of the TPMS low tire pressure

telltale.
Your vehicle has also been equipped with a TPMS

malfunction indicator to indicate when the system

is not operating properly. The TPMS malfunction

indicator is combined with the low tire pressure

telltale. When the system detects a malfunction,

the telltale will flash for approximately one minute

and then remain continuously illuminated. This

sequence will continue upon subsequent vehicle

start-ups as long as the malfunction exists. When

the malfunction indicator is illuminated, the

system may not be able to detect or signal low tire

pressure as intended. TPMS malfunctions may

occur for a variety of reasons, including the

installation of replacement or alternate tires or

wheels on the vehicle that prevent the TPMS from

functioning properly. Always check the TPMS

malfunction telltale after replacing one or more

tires or wheels on your vehicle to ensure that the

replacement or alternate tires and wheels allow

the TPMS to continue to function properly.

CAUTION!

Do not continue driving with one or more flat

tires as handling may be compromised. Stop the

vehicle, avoiding sharp braking and steering. If a

tire puncture occurs, repair immediately using

the dedicated tire repair kit and contact an

authorized dealer as soon as possible.

GETTING TO KNOW YOUR INSTRUMENT PANEL

Towing Hook Breakdown Warning Light —

If Equipped

This light illuminates when there is a

failure with the tow hook. Contact an

authorized dealer for service.

Transmission Temperature Warning Light

This light indicates that the transmission

fluid temperature is running hot. This

may occur with severe usage, such as

trailer towing. If this light turns on, safely

pull over and stop the vehicle. Then, shift the

transmission into PARK and run the engine at idle

or slightly higher until the light turns off.

4WD Over Temperature Warning Light

The icon will appear on the instrument

panel display to indicate overheating of

the 4WD system. The mode selected by

the user will be applied as soon as the

system exits the overheating condition.

ELLOW

NDICATOR

IGHTS

4WD Low Indicator Light — If Equipped

This light alerts the driver that the vehicle

is in the 4WD Low mode. The front and

rear driveshafts are mechanically locked

together forcing the front and rear

wheels to rotate at the same speed. Low range

provides a greater gear reduction ratio to provide

increased torque at the wheels

page

90.

4WD Lock Indicator Light

This light alerts the driver that the vehicle

is in the four-wheel drive LOCK mode.

The front and rear driveshafts are

mechanically locked together, forcing the

front and rear wheels to rotate at the same speed

page

90.

Dusk Sensor Malfunction Indicator Light

This symbol lights up (together with a

dedicated message on display) when a

dusk sensor malfunction is detected

page

38.

Electronic Stability Control (ESC) Active

Warning Light — If Equipped

This warning light will indicate when the

ESC system is Active. The ESC Indicator

Light in the instrument cluster will come

on when the ignition is placed in the ON/

RUN or ACC/ON/RUN position, and when ESC is

activated. It should go out with the engine running.

If the ESC Indicator Light comes on continuously

with the engine running, a malfunction has been

detected in the ESC system. If this warning light

remains on after several ignition cycles, and the

vehicle has been driven several miles (kilometers)

CAUTION!

The TPMS has been optimized for the original

equipment tires and wheels. TPMS pressures

and warning have been established for the tire

size equipped on your vehicle. Undesirable sys

tem operation or sensor damage may result

when using replacement equipment that is not

of the same size, type, and/or style. Aftermarket

wheels can cause sensor damage. Using after

market tire sealants may cause the Tire Pres

sure Monitoring System (TPMS) sensor to

become inoperable. After using an aftermarket

tire sealant it is recommended that you take

your vehicle to an authorized dealer to have your

sensor function checked.

WARNING!

If you continue operating the vehicle when the

Transmission Temperature Warning Light is

illuminated you could cause the fluid to boil over,

come in contact with hot engine or exhaust

components and cause a fire.

CAUTION!

Continuous driving with the Transmission

Temperature Warning Light illuminated will

eventually cause severe transmission damage

or transmission failure.

GETTING TO KNOW YOUR INSTRUMENT PANEL

at speeds greater than 30

mph (48

km/h), see an

authorized dealer as soon as possible to have the

problem diagnosed and corrected.



The ESC OFF Indicator Light and the ESC Indi

cator Light come on momentarily each time the

ignition is placed in the ON/RUN or ACC/ON/

RUN position.



The ESC system will make buzzing or clicking

sounds when it is active. This is normal; the

sounds will stop when ESC becomes inactive.



This light will come on when the vehicle is in an

ESC event.

Electronic Stability Control (ESC) OFF

Warning Light — If Equipped

This warning light indicates the ESC is off.
Each time the ignition is turned to ON/

RUN or ACC/ON/RUN, the ESC system

will be on, even if it was turned off previously.

Exterior Bulb Failure Indicator Light —

If Equipped

This light will illuminate when there is a

malfunction in one of the exterior bulbs.

Fuel Cutoff Warning Light — If Equipped

This warning light will illuminate after an

accident has occurred, and the system

has shut the fuel off.

Fuel Cutoff Failure Light — If Equipped

This light will illuminate if there is a fuel

cutoff failure. If this light illuminates, take

it to an authorized dealer and have them

inspect it.

Immobilizer Fail / VPS Electrical Alarm

Indicator Light

This telltale will illuminate when the

vehicle security system has detected an

attempt to break into the vehicle.

NOTE:

After cycling the ignition to the ON/RUN position,

the Vehicle Security Warning Light could illuminate

if a problem with the system is detected. This

condition will result in the engine being shut off

after two seconds.

REEN

NDICATOR

IGHTS

Automatic High Beam Indicator Light —

If Equipped

This indicator shows that the automatic

high beam headlights are on.

Cruise Control Set Indicator Light

This light will turn on when the cruise

control is set to the desired speed

page

95.

Front Fog Indicator Light — If Equipped

This indicator light will illuminate when

the front fog lights are on

page

36.

Hazard Warning Lights

The hazard warning indicators light up

when the vehicles Hazard Warning

flasher switch has been pushed.

Parking/Headlights On Indicator Light

This indicator light will illuminate when

the parking lights or headlights are

turned on

page

36.

Sport Mode Indicator Light — If Equipped

This light will turn on when Sport Mode is

active.

Stop/Start Active Indicator Light —

If Equipped

This indicator light will illuminate when

the Stop/Start function is in “Autostop”

mode.

Turn Signal Indicator Lights

When the left or right turn signal is

activated, the turn signal indicator will

flash independently and the

corresponding exterior turn signal lamps

GETTING TO KNOW YOUR INSTRUMENT PANEL

will flash. Turn signals can be activated when the

multifunction lever is moved down (left) or up

(right).

HITE

NDICATOR

IGHTS

Hill Descent Control (HDC) Indicator Light —

If Equipped

This indicator shows when the HDC

feature is turned on. The lamp will be on

solid when HDC is armed. HDC can only

be armed when the transfer case is in the

4WD Low position and the vehicle speed is less

then 30

mph (48

km/h). If these conditions are not

met while attempting to use the HDC feature, the

HDC indicator light will flash on/off.

Idle Coasting — If Equipped

The Idle Coasting feature saves fuel by

allowing engine speeds to drop to idle.

When Idle Coasting is active, the Idle

Coasting Indicator Light is shown in the

Instrument Cluster Display.

Light Sensor Failure

This light illuminates when there is light

sensor failure. If this light illuminates,

have an authorized dealer inspect it.

Speed Warning Indicator Light —

If Equipped

When Set Speed Warning is turned on,

the speed warning telltale will illuminate

in the instrument cluster with a number

matching the set speed. When the set

speed is exceeded, a single chime will sound along

with pop-up message of “Speed Warning

Exceeded.” Speed Warning can be turned on and

off in the instrument cluster display.
The number “55” is only an example of a speed

that can be set.

LUE

NDICATOR

IGHTS

High Beam Indicator Light

This indicator light will illuminate to

indicate that the high beam headlights

are on. With the low beams activated,

push the multifunction lever forward

(toward the front of the vehicle) to turn on the high

beams. Pull the multifunction lever rearward

(toward the rear of the vehicle) to turn off the high

beams. If the high beams are off, pull the lever

toward you for a temporary high beam on, “flash to

pass” scenario.

RAY

NDICATOR

IGHTS

Cruise Control Ready/Canceled Indicator

Light

This indicator light will illuminate when

the cruise control function is ready (but

not set), or canceled, by the driver

page

95.

ONBOARD DIAGNOSTIC SYSTEM (OBD II)

Your vehicle is equipped with a sophisticated

onboard diagnostic system called OBD II. This

system monitors the performance of the

emissions, engine, and automatic transmission

control systems. When these systems are

operating properly, your vehicle will provide

excellent performance and fuel economy, as well

as engine emissions well within current

government regulations.
If any of these systems require service, the OBD II

system will turn on the Malfunction Indicator Light

(MIL). It will also store diagnostic codes and other

information to assist your service technician in

making repairs. Although your vehicle will usually

be drivable and not need towing, see an authorized

dealer for service as soon as possible.

GETTING TO KNOW YOUR INSTRUMENT PANEL

NBOARD

IAGNOSTIC

YSTEM

(OBD II) C

YBERSECURITY

Your vehicle is required to have an OBD II and a

connection port to allow access to information

related to the performance of your emissions

controls. Authorized service technicians may need

to access this information to assist with the

diagnosis and service of your vehicle and

emissions system

page

133.

EMISSIONS INSPECTION AND

MAINTENANCE PROGRAMS

In some localities, it may be a legal requirement to

pass an inspection of your vehicle's emissions

control system. Failure to pass could prevent

vehicle registration.

For states that require an Inspection and

Maintenance (I/M), this check verifies

the Malfunction Indicator Light (MIL) is

functioning and is not on when the

engine is running, and that the OBD II system is

ready for testing.
Normally, the OBD II system will be ready. The

OBD II system may not be ready if your vehicle was

recently serviced, recently had a depleted battery

or a battery replacement. If the OBD II system

should be determined not ready for the I/M test,

your vehicle may fail the test.

CAUTION!



Prolonged driving with the MIL on could cause

further damage to the emission control

system. It could also affect fuel economy and

driveability. The vehicle must be serviced

before any emissions tests can be performed.



If the MIL is flashing, while the engine is

running, severe catalytic converter damage

and power loss will soon occur. Immediate

service is required.

WARNING!



ONLY an authorized service technician should

connect equipment to the OBD II connection

port in order to read the VIN, diagnose, or

service your vehicle.



If unauthorized equipment is connected to the

OBD II connection port, such as a

driver-behavior tracking device, it may:



Be possible that vehicle systems,

including safety related systems, could be

impaired or a loss of vehicle control could

occur that may result in an accident

involving serious injury or death.



Access, or allow others to access, infor

mation stored in your vehicle systems,

including personal information.

GETTING TO KNOW YOUR INSTRUMENT PANEL

Your vehicle has a simple ignition actuated test,

which you can use prior to going to the test station.

To check if your vehicle's OBD II system is ready,

you must do the following:
1. Cycle the ignition switch to the ON position,

but do not crank or start the engine.

NOTE:

If you crank or start the engine, you will have to

start this test over.
2. As soon as you cycle the ignition switch to the

ON position, you will see the Malfunction

Indicator Light (MIL) symbol come on as part of

a normal bulb check.

3. Approximately 15 seconds later, one of two

things will happen:



The MIL will flash for about 10 seconds and

then return to being fully illuminated until

you turn OFF the ignition or start the engine.

This means that your vehicle's OBD II

system is not ready and you should not

proceed to the I/M station.



The MIL will not flash at all and will remain

fully illuminated until you place the ignition

in the off position or start the engine. This

means that your vehicle's OBD II system is

ready and you can proceed to the I/M

station.

If your OBD II system is not ready, you should see

an authorized dealer or repair facility. If your

vehicle was recently serviced or had a battery

failure or replacement, you may need to do nothing

more than drive your vehicle as you normally would

in order for your OBD II system to update. A

recheck with the above test routine may then

indicate that the system is now ready.
Regardless of whether your vehicle's OBD II system

is ready or not, if the MIL is illuminated during

normal vehicle operation you should have your

vehicle serviced before going to the I/M station.

The I/M station can fail your vehicle because the

MIL is on with the engine running.

(Continued)

STARTING AND OPERATING

STARTING THE ENGINE

Before starting your vehicle, adjust your seat,

adjust the inside and outside mirrors, fasten your

seat belt, and if present, instruct all other

occupants to buckle their seat belts.

Start the engine with the gear selector in the

NEUTRAL or PARK position. Apply the brake before

shifting to any driving range.

Normal Starting
NOTE:

Normal starting of either a cold or warm engine is

obtained without pumping or pressing the accel

erator pedal.
Proceed as follows:
1. Set the Electric Park Brake (EPB) and put the

gear selector in the PARK or NEUTRAL

position.

2. Press on the brake pedal, without pressing the

accelerator.

3. Press the START/STOP ignition button and

release it as soon as the engine is started.

4. If the engine does not start, place the ignition

in the OFF position and wait 10-15 seconds

before attempting to restart the engine.

TART

EATURE

Do not press the accelerator. Press briefly the

START/STOP ignition button and release it. The

starter motor will continue to run but will

automatically disengage when the engine is

running.

NGINE

AILS

TART

If the engine fails to start after you have followed

the “Normal Starting” procedure, and has not

experienced an extended park condition as

identified in “Extended Park Starting” procedure

below, it may be flooded. Push the accelerator

pedal all the way to the floor and hold it there.

Crank the engine for no more than 10 seconds.

This should clear any excess fuel in case the

engine is flooded. Leave the ignition in the RUN

position, release the accelerator pedal and repeat

the “Normal Starting” procedure.

WARNING!



Never leave children alone in a vehicle, or with

access to an unlocked vehicle.



Allowing children to be in a vehicle unattended

is dangerous for a number of reasons. A child

or others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the gear

selector.



Do not leave the key fob in or near the vehicle

(or in a location accessible to children), and do

not leave the ignition in the ON or RUN posi

tion. A child could operate power windows,

other controls, or move the vehicle.

WARNING!

Never pour fuel or other flammable liquid into

the throttle body air inlet opening in an attempt

to start the vehicle. This could result in flash fire

causing serious personal injury.

WARNING!



Never pour fuel or other flammable liquid into

the throttle body air inlet opening in an

attempt to start the vehicle. This could result

in flash fire causing serious personal injury.

STARTING AND OPERATING

OLD

EATHER

PERATION

To ensure reliable starting under extreme cold

conditions an externally powered electric block

heater (if equipped) is required for the 1.3L Turbo

engine below -20°F (-29°C).

To prevent possible engine damage while starting

at low temperatures, this vehicle will inhibit engine

cranking when the ambient temperature is less

than -20°F (-29°C) for the 1.3L Turbo engine, and

the oil temperature sensor reading indicates an

engine block heater has not been used. The

message “plug in engine heater” will be displayed

in the instrument cluster when the ambient

temperature is below -4°F (-20°C) at the time the

engine is shut off as a reminder to avoid possible

crank delays at the next cold start.

XTENDED

ARK

TARTING

NOTE:

Extended Park condition occurs when the vehicle

has not been started or driven for at least 30 days.
1. Install a battery charger or jumper cables to

the battery to ensure a full battery charge

during the crank cycle.

2. Press the START/STOP ignition button and

release it when the engine starts.

3. If the engine fails to start within 10 seconds,

place the ignition in the OFF position, wait

10 to 15 seconds to allow the starter to cool,

then repeat the Extended Park Starting

procedure.

4. If the engine fails to start after eight attempts,

allow the starter to cool for at least

minutes, then repeat the procedure.

FTER

TARTING

— W

ARMING

NGINE

Proceed as follows:



Travel slowly, letting the engine run at a reduced

RPM, without accelerating suddenly.



It is recommended to wait until the engine

coolant temperature gauge starts to rise for

maximum performance.

TOPPING

NGINE

To shut off the engine with a vehicle speed greater

than 5

mph (8

km/h), you must push and hold the

ignition or push the START/STOP button three

times consecutively within a few seconds. The

engine will shut down, and the ignition will be

placed in the RUN position.
Vehicles Equipped With Electronic Key

(Keyless Enter ‘n Go™)
Turning off the car (cycle the ignition from the RUN

position to the OFF position), the power supply to

the accessories are maintained for a period of

three minutes.



Do not attempt to push or tow your vehicle to

get it started. Vehicles equipped with an auto

matic transmission cannot be started this

way. Unburned fuel could enter the catalytic

converter and once the engine has started,

ignite and damage the converter and vehicle.



If the vehicle has a discharged battery,

booster cables may be used to obtain a start

from a booster battery or the battery in

another vehicle. This type of start can be

dangerous if done improperly

page

278.

CAUTION!

To prevent damage to the starter, do not

continuously crank the engine for more than

10 seconds at a time. Wait 10 to 15 seconds

before trying again.

WARNING!

CAUTION!

To prevent damage to the starter, do not crank

continuously for more than 10 seconds at a

time. Wait 10 to 15 seconds before trying again.

STARTING AND OPERATING

NOTE:

If the vehicle fails to shut off using the ignition

page

64.

Opening the driver side door with the ignition in

RUN will sound a short chime that reminds the

driver to place the ignition to OFF.
When the ignition is in the OFF position, the

window switches remain active for three minutes.

Opening a front door will cancel this function.
After severe driving, idle the engine to allow the

temperature inside the engine compartment to

cool before shutting off the engine.

URBOCHARGER

“C

OOL

OWN

” —

QUIPPED

This vehicle is equipped with an after-run pump to

cool the turbocharger after the engine is shut off.

Depending on the type of driving and the amount

of cargo, the pump will run for up to 10

minutes

after the engine has been shut off to circulate

coolant through the turbocharger. Although the

pump is rubber-mounted for quiet operation, it is

normal to hear it running during this time.

ENGINE BREAK-IN RECOMMENDATIONS

A long break-in period is not required for the engine

and drivetrain (transmission and axle) in your

vehicle.
Drive moderately during the first 300

miles

(500

km). After the initial 60

miles (100

km),

speeds up to 50 or 55

mph (80 or 90

km/h) are

desirable.
While cruising, brief full-throttle acceleration within

the limits of local traffic laws contributes to a good

break-in. Wide-open throttle acceleration in low

gear can be detrimental and should be avoided.
The engine oil installed in the engine at the factory

is a high-quality energy conserving type lubricant.

Oil changes should be consistent with anticipated

climate conditions under which vehicle operations

will occur. For the recommended viscosity and

quality grades

page

345.

NOTE:

A new engine may consume some oil during its first

few thousand miles (kilometers) of operation. This

should be considered a normal part of the break-in

and not interpreted as a problem.

ELECTRIC PARK BRAKE (EPB)

Your vehicle is equipped with an EPB that offers

simple operation, and some additional features

that make the parking brake more convenient and

useful.
The parking brake is primarily intended to prevent

the vehicle from rolling while parked. Before

leaving the vehicle, make sure that the parking

brake is applied. Also, be certain to leave the

transmission in PARK.
The EPB switch is located in the center console.
You can engage the EPB in two ways:



Manually, by applying the parking brake switch.



Automatically, by enabling the Auto Park Brake

feature in the customer programmable features

section of the Uconnect settings or in “Safe

Hold” conditions.

CAUTION!

Never use Non-Detergent Oil or Straight Mineral

Oil in the engine or damage may result.

STARTING AND OPERATING

Electric Park Brake Switch

To apply the EPB manually, pull up on the switch

momentarily. You may hear a sound from the back

of the vehicle while the EPB engages. Once the

parking brake is fully engaged, the Brake Warning

Light in the instrument cluster and an indicator on

the switch will illuminate. If your foot is on the

brake pedal while you apply the EPB, you may

notice a small amount of brake pedal movement.

The EPB can be applied even when the ignition is

in the OFF position however, it can only be released

when the ignition is in the RUN position.
NOTE:

The EPB fault lamp will illuminate if the EPB switch

is held for longer than 60 seconds in either the

released or applied position. The light will extin

guish upon releasing the switch.
If the Auto Park Brake feature is enabled, the EPB

will automatically engage whenever the

transmission is moved into PARK when the ignition

switch is in the STOP/OFF position. If your foot is on

the brake pedal, you may notice a small amount of

brake pedal movement while the EPB is engaging.
The EPB will be automatically released if the

driver's seat belt is buckled (only in case of

automatic transmission) and driver's intention to

start (in forward or reverse direction) is recognized

by the system.
To release the EPB manually, the ignition must be

in the RUN position. Put your foot on the brake

pedal, then push the EPB switch down

momentarily. You may hear a sound from the back

of the car while the parking brake disengages. You

may also notice a small amount of movement in

the brake pedal. Once the EPB is fully disengaged,

the Brake Warning Light in the instrument cluster

and the LED indicator on the switch will extinguish.
NOTE:

When parking on a hill, it is important to turn the

front wheels toward the curb on a downhill grade

and away from the curb on an uphill grade. Apply

the EPB before placing the gear selector in PARK,

otherwise the load on the transmission locking

mechanism may make it difficult to move the gear

selector out of PARK. The EPB should always be

applied whenever the driver is not in the vehicle.

WARNING!



When exiting the vehicle, always remove the

key fob from the vehicle and lock your vehicle.



Never leave children alone in a vehicle, or with

access to an unlocked vehicle. Allowing chil

dren to be in a vehicle unattended is

dangerous for a number of reasons. A child or

others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the transmis

sion gear selector.



Do not leave the key fob in or near the vehicle

(or in a location accessible to children), and do

not leave the ignition in the ON or RUN posi

tion. A child could operate power windows,

other controls, or move the vehicle.



Be sure the parking brake is fully disengaged

before driving; failure to do so can lead to

brake failure and a collision.



Always fully apply the parking brake when

leaving your vehicle, or it may roll and cause

damage or injury. Also be certain to leave the

transmission in PARK. Failure to do so may

allow the vehicle to roll and cause damage or

injury.

STARTING AND OPERATING

If exceptional circumstances should make it

necessary to engage the EPB while the vehicle is in

motion, maintain upward pressure on the EPB

switch for as long as engagement is desired. The

Brake Warning Light could illuminate in case the

hydraulic system is not available. The rear stop

lamps will also be illuminated automatically while

the vehicle remains in motion.
To disengage the EPB while the vehicle is in

motion, release the switch. If the vehicle is brought

to a complete stop using the EPB, when the vehicle

reaches approximately 1.9

mph (3

km/h) the EPB

will remain engaged.

In the unlikely event of a malfunction of the EPB

system, a yellow EPB fault lamp will illuminate. This

may be accompanied by the Brake Warning Light

flashing. In this status, some EPB functionalities

may be deactivated. In this event, urgent service of

the EPB system is required. Do not rely on the EPB

to hold the vehicle stationary.

UTO

ARK

RAKE

The EPB can be programmed to be applied

automatically whenever the vehicle speed is below

1.9

mph (3

km/h) and the automatic transmission

is placed in PARK whenever the ignition is in the

OFF position. Auto Park Brake is enabled and

disabled by customer selection through the

Customer Programmable Features section of the

Uconnect Settings.
Any single Auto Park Brake application can be

bypassed by pushing the EPB switch to the release

position while the transmission is placed in PARK

and the ignition is in the RUN position. In some

cases, if the ignition is cycled from ON/RUN to OFF

and the gear selector is not firmly locked in the

PARK position, EPB applies automatically even if

Auto Park Brake has been previously disabled.

AFE

OLD

SafeHold is a safety feature of the EPB system that

will engage the parking brake automatically if the

vehicle is left unsecured while the ignition is in the

RUN position.

The EPB will automatically engage if all of the

following conditions are met:



Vehicle speed is below 1.9

mph (3

km/h).



There is no attempt to press the brake pedal or

accelerator pedal.



The seat belt is unbuckled.



The driver door is open.



The vehicle is not in the PARK position.

SafeHold can be temporarily bypassed by pushing

the EPB Switch while the driver door is open and

the brake pedal is pressed. Once manually

bypassed, SafeHold will be enabled again once the

vehicle reaches 12

mph (20

km/h) or the ignition

is placed to the OFF position and back to RUN

again.

RAKE

ERVICE

ODE

We recommend having your brakes serviced by an

authorized dealer. You should only make repairs

for which you have the knowledge and the right

equipment. You should only enter Brake Service

Mode during brake service.
When servicing your rear brakes, it may be

necessary for you or your technician to push the

rear piston into the rear caliper bore. With the EPB

system, this can only be done after retracting the

EPB actuator. The actuator retraction can be done

easily by entering the Brake Service Mode. This

CAUTION!

If the Brake System Warning Light remains on

with the parking brake released, a brake system

malfunction is indicated. Have the brake system

serviced by an authorized dealer immediately.

WARNING!

Driving the vehicle with the parking brake

engaged, or repeated use of the parking brake

to slow the vehicle may cause serious damage to

the brake system. Be sure the parking brake is

fully disengaged before driving; failure to do so

can lead to brake failure and a collision.

STARTING AND OPERATING

(Continued)

menu based system will guide you through the

steps necessary to retract the EPB actuator in

order to perform rear brake service.
Service Mode has requirements that must be met

in order to be activated:



The vehicle must be at a standstill.



The parking brake must be disabled.



The transmission must be in park or neutral.



The EPB switch not activated.



The vehicle in ignition RUN position.



The brake pedal not pressed.

While in service mode, the EPB fault lamp will flash

continuously while the ignition is in the RUN

position.
NOTE:

A dedicated message will appear in the instrument

cluster if Brake Service Mode cannot be activated.
When brake service work is complete, the following

steps must be followed to reset the parking brake

system to normal operation:



Ensure the vehicle is at a standstill.



Press the brake pedal with moderate force.



Apply the EPB Switch.

NOTE:

A dedicated message will appear in the instrument

cluster if Brake Service Mode cannot be deacti

vated.

9-SPEED AUTOMATIC TRANSMISSION

NOTE:

You must press and hold the brake pedal while

shifting out of PARK.
The transmission gear range (PRND) is displayed

beside the gear selector and in the instrument

cluster display. To select a gear range, push the

lock button on the gear selector and move the

selector rearward or forward. You must also press

the brake pedal to shift the transmission out of

PARK, or to shift from NEUTRAL into DRIVE or

REVERSE when the vehicle is stopped or moving at

low speeds

page

90. Select the DRIVE range for

normal driving.
The electronically-controlled transmission adapts

its shift schedule based on driver inputs, along

with environmental and road conditions. The

transmission electronics are self-calibrating;

therefore, the first few shifts on a new vehicle may

be somewhat abrupt. This is a normal condition,

and precision shifts will develop within a few

hundred miles (kilometers).

WARNING!

You can be badly injured working on or around a

motor vehicle. Do only that service work for

which you have the knowledge and the right

equipment. If you have any doubt about your

ability to perform a service job, take your vehicle

to a competent mechanic.

WARNING!



It is dangerous to shift out of PARK or

NEUTRAL if the engine speed is higher than

idle speed. If your foot is not firmly pressing

the brake pedal, the vehicle could accelerate

quickly forward or in reverse. You could lose

control of the vehicle and hit someone or

something. Only shift into gear when the

engine is idling normally and your foot is firmly

pressing the brake pedal.



Unintended movement of a vehicle could

injure those in or near the vehicle. As with all

vehicles, you should never exit a vehicle while

the engine is running. Before exiting a vehicle,

always come to a complete stop, then apply

the parking brake, shift the transmission into

PARK, and turn the ignition OFF. When the

ignition is in the OFF position, the transmis

sion is locked in PARK, securing the vehicle

against unwanted movement.



When leaving the vehicle, always make sure

the ignition is in the OFF position, remove the

key fob from the vehicle, and lock the vehicle.

STARTING AND OPERATING

EAR

ELECTOR

The transmission gear selector has PARK,

REVERSE, NEUTRAL, DRIVE, and AutoStick (+/-)

shift positions. Manual shifts can be made using

the AutoStick shift control. Toggling the gear

selector forward (-) or rearward (+) while in the

AutoStick position (beside the DRIVE position) will

manually select the transmission gear, and will

display the current gear in the instrument cluster

as 1, 2, 3, etc.
NOTE:

If the gear selector cannot be moved to the PARK,

REVERSE, or NEUTRAL position (when pushed

forward) it is probably in the AutoStick (+/-)

position (beside the DRIVE position). In AutoStick

mode, the transmission gear (1, 2, 3, etc.) is

displayed in the instrument cluster. Move the gear

selector to the right (into the DRIVE [D] position) for

access to PARK, REVERSE, and NEUTRAL.

Gear Selector Lock Button

This transmission has been developed to meet the

needs of the manufacturer’s current and future

lineup of FWD/AWD vehicles. Software and

calibration is refined to optimize the customer’s

driving experience and fuel economy. By design,

some vehicle and drive-line combinations utilize

NINTH gear only in very specific driving situations

and conditions.
Only shift from DRIVE to PARK or REVERSE when

the accelerator pedal is released and the vehicle is

stopped. Be sure to keep your foot on the brake

pedal when shifting between these gears.
DO NOT press the accelerator pedal when shifting

from PARK or NEUTRAL into another gear range.



Never leave children alone in a vehicle, or with

access to an unlocked vehicle. Allowing chil

dren to be in a vehicle unattended is

dangerous for a number of reasons. A child or

others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the transmis

sion gear selector.



Do not leave the key fob in or near the vehicle

(or in a location accessible to children), and do

not leave the ignition in the ON or RUN posi

tion. A child could operate power windows,

other controls, or move the vehicle.

CAUTION!



Shift into or out of PARK or REVERSE only after

the vehicle has come to a complete stop.



Do not shift between PARK, REVERSE,

NEUTRAL, or DRIVE when the engine is above

idle speed.



Before shifting into any gear, make sure your

foot is firmly pressing the brake pedal.

WARNING!

STARTING AND OPERATING

(Continued)

EAR

ANGES

PARK (P)
This range supplements the Electric Park Brake

(EPB) by locking the transmission. The engine can

be started in this range. Never attempt to use

PARK while the vehicle is in motion.
When parking on a hill, apply the EPB before

shifting the transmission to PARK, otherwise the

load on the transmission locking mechanism may

make it difficult to move the gear selector out of

PARK. As an added precaution, turn the front

wheels toward the curb on a downhill grade and

away from the curb on an uphill grade.
When exiting the vehicle, always:



Apply the parking brake.



Shift the transmission into PARK.



Turn the ignition OFF.



Remove the key fob from the vehicle.

CAUTION!

After selecting any gear range, wait a moment to

allow the selected gear to engage before

accelerating. This is especially important when

the engine is cold.

WARNING!



Never use the PARK position as a substitute

for the parking brake. Always apply the

parking brake fully when exiting the vehicle to

guard against vehicle movement and possible

injury or damage.



Your vehicle could move and injure you and

others if it is not in PARK. Check by trying to

move the transmission gear selector out of

PARK with the brake pedal released. Make

sure the transmission is in PARK before

exiting the vehicle.



The transmission may not engage PARK if the

vehicle is moving. Always bring the vehicle to a

complete stop before shifting to PARK, and

verify that the transmission gear position indi

cator solidly indicates PARK (P) without

blinking. Ensure that the vehicle is completely

stopped, and the PARK position is properly

indicated, before exiting the vehicle.



It is dangerous to shift out of PARK or

NEUTRAL if the engine speed is higher than

idle speed. If your foot is not firmly pressing

the brake pedal, the vehicle could accelerate

quickly forward or in reverse. You could lose

control of the vehicle and hit someone or

something. Only shift into gear when the

engine is idling normally (or stopped) and your

foot is firmly pressing the brake pedal.



Unintended movement of a vehicle could

injure those in or near the vehicle. As with all

vehicles, you should never exit a vehicle while

the engine is running or the propulsion system

is active. Before exiting a vehicle, always come

to a complete stop, then apply the parking

brake, shift the transmission into PARK, and

turn the ignition OFF. When the ignition is in

the OFF position, the transmission is locked in

PARK, securing the vehicle against unwanted

movement.



When leaving the vehicle, always make sure

the ignition is in the OFF position, remove the

key fob from the vehicle, and lock the vehicle.

WARNING!

STARTING AND OPERATING

The following indicators should be used to ensure

that you have properly engaged the transmission

into the PARK position:



When shifting into PARK, press the lock button

on the gear selector, and firmly move the gear

selector all the way forward until it stops and is

fully seated.



Look at the transmission gear position display

and verify that it indicates the PARK position (P),

and is not blinking.



With the brake pedal released, verify that the

gear selector will not move out of PARK.

REVERSE (R)
This range is for moving the vehicle backward.

Shift into REVERSE only after the vehicle has come

to a complete stop.
NEUTRAL (N)
Use this range when the vehicle is standing for

prolonged periods with the engine running. The

engine may be started in this range. Apply the

Electric Park Brake and shift the transmission into

PARK if you must exit the vehicle.

DRIVE (D)
This range should be used for most city and

highway driving. It provides the smoothest upshifts

and downshifts, and the best fuel economy. The

transmission automatically upshifts through all

forward gears.
When frequent transmission shifting occurs (such

as when operating the vehicle under heavy loading

conditions, in hilly terrain, traveling into strong

head winds or while towing a heavy trailer), use the

AutoStick shift control to select a lower gear. Under



Never leave children alone in a vehicle, or with

access to an unlocked vehicle. Allowing chil

dren to be in a vehicle unattended is

dangerous for a number of reasons. A child or

others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the transmis

sion gear selector.



Do not leave the key fob in or near the vehicle

(or in a location accessible to children), and do

not leave the ignition in the ON/RUN position.

A child could operate power windows, other

controls, or move the vehicle.

CAUTION!



Before moving the transmission gear selector

out of PARK, you must turn the ignition to the

ON/RUN position, and also press the brake

pedal. Otherwise, damage to the gear selector

could result.



DO NOT race the engine when shifting from

PARK or NEUTRAL into another gear range, as

this can damage the drivetrain.

WARNING!

Do not coast in NEUTRAL and never turn off the

ignition to coast down a hill. These are unsafe

practices that limit your response to changing

traffic or road conditions. You might lose control

of the vehicle and have a collision.

CAUTION!

Towing the vehicle, coasting, or driving for any

other reason with the transmission in NEUTRAL

can cause severe transmission damage.
For Recreational Towing

page

129.

For Towing A Disabled Vehicle

page

283.

STARTING AND OPERATING

these conditions, using a lower gear will improve

performance and extend transmission life by

reducing excessive shifting and heat buildup.
If the transmission temperature exceeds normal

operating limits, the transmission controller may

modify the transmission shift schedule, reduce

engine torque, and/or expand the range of torque

converter clutch engagement. This is done to

prevent transmission damage due to overheating.
If the transmission becomes extremely hot, the

Transmission Temperature Warning Light may

illuminate and the transmission may operate

differently until the transmission cools down.
During cold temperatures, transmission operation

may be modified depending on engine and

transmission temperature as well as vehicle

speed. This feature improves warm up time of the

engine and transmission to achieve maximum

efficiency. Engagement of the torque converter

clutch, and shifts into EIGHTH or NINTH gear, are

inhibited until the transmission fluid is warm.

Normal operation will resume once the

transmission temperature has risen to a suitable

level.
AutoStick
AutoStick is a driver-interactive transmission

feature providing manual shift control, giving you

more control of the vehicle. AutoStick allows you to

maximize engine braking, eliminate undesirable

upshifts and downshifts, and improve overall

vehicle performance. This system can also provide

you with more control during passing, city driving,

cold slippery conditions, mountain driving, trailer

towing and many other situations.
Operation
When the gear selector is in the AutoStick position

(beside the DRIVE position), it can be moved

forward and rearward. This allows the driver to

manually select the transmission gear being used.

Moving the gear selector forward (-) triggers a

downshift, and rearward (+) an upshift. The current

gear is displayed in the instrument cluster.
NOTE:

In AutoStick mode, the transmission will only shift

up or down when the driver moves the gear

selector rearward (+) or forward (-), except as

described below:



The transmission will automatically upshift

when necessary to prevent engine overspeed.



The transmission will automatically downshift

as the vehicle slows (to prevent engine lugging)

and will display the current gear.



The transmission will automatically downshift to

FIRST or SECOND gear (depending on model)

when coming to a stop. After a stop, the driver

should manually upshift (+) the transmission as

the vehicle is accelerated.



You can start out (from a stop) in FIRST or

SECOND gear. Starting out in SECOND gear can

be helpful in snow or icy conditions. Tap the gear

selector forward or rearward to select the

desired gear after the vehicle is brought to a

stop.



If a requested downshift would cause the

engine to overspeed, that shift will not occur.



The system will ignore attempts to upshift at too

low of a vehicle speed.



Avoid using Cruise Control when AutoStick is

engaged because the transmission will not shift

automatically.



Transmission shifting will be more noticeable

when AutoStick is enabled.



The system may revert to automatic shift mode

if a fault or overheat condition is detected.

To disengage AutoStick mode, return the gear

selector to the DRIVE position. You can shift in or

out of the AutoStick position at any time without

taking your foot off the accelerator pedal.

WARNING!

Do not downshift for additional engine braking

on a slippery surface. The drive wheels could

lose their grip and the vehicle could skid,

causing a collision or personal injury.

Jeep Renegade (2022 year). Manual in english - page 5
