GETTING TO KNOW YOUR VEHICLE

INDSHIELD

IPER

PERATION

Rotate the windshield wiper knob to one of the two

detent positions for intermittent settings, the third

detent for low wiper operation and the fourth for

high wiper operation.
Windshield Washer Operation
To use the washer, pull the lever toward you and

hold while spray is desired. If the lever is pulled

while in the intermittent setting, the wipers will turn

on and operate for several wipe cycles after the

lever is released, and then resume the intermittent

interval previously selected.
If the lever is pulled while the wipers are in the off

position, the wipers will operate for several wipe

cycles, then turn off.

Mist
Use this feature when weather conditions make

occasional usage of the wipers necessary. Push

the lever upward to the MIST position and release

for a single wiping cycle.
NOTE:

The Mist feature does not activate the washer

pump; therefore, no washer fluid will be sprayed on

the windshield. The wash function must be used in

order to spray the windshield with washer fluid.
For information on wiper care and replacement,

see

page

297.

AIN

ENSING

IPERS

— I

QUIPPED

This feature senses rain or snow fall on the

windshield and automatically activates the wipers.

Rotate the end of the multifunction lever to one of

two detent positions to activate this feature.
The sensitivity of the system can be adjusted with

the multifunction lever. Wiper delay position one is

the least sensitive, and wiper delay position two is

the most sensitive. Place the wiper switch in the O

(off) position when not using the system.
NOTE:

If the end of the multifunction lever rotates from off

to the first intermittent setting or from the first

intermittent setting to the second intermittent

setting, the wipers will perform a round up to clean

the windshield.

Rain Sensor

NOTE:



The Rain Sensing feature will not operate when

the wiper switch is in the low or high-speed posi

tion.



The Rain Sensing feature may not function prop

erly when ice or dried salt water is present on

the windshield.



Use of Rain-X or products containing wax or sili

cone may reduce Rain Sensing performance.



The Rain Sensing feature can be turned on or off

through Uconnect Settings

page

133.

The Rain Sensing system has protection features

for the wiper blades and arms, and will not operate

under the following conditions:



Change In Ignition Position — If the vehicle is in

Rain Sensing mode and the ignition is cycled

from OFF to ON, the auto wiper will be

WARNING!

Sudden loss of visibility through the windshield

could lead to a collision. You might not see other

vehicles or other obstacles. To avoid sudden

icing of the windshield during freezing weather,

warm the windshield with the defroster before

and during windshield washer use.

GETTING TO KNOW YOUR VEHICLE

suppressed until vehicle speed is greater than

mph (5

km/h), or the wiper switch is moved

out of and back into the Intermittent wipe posi

tion.



Transmission In NEUTRAL Position — The Rain

Sensing system will not operate if the NEUTRAL

gear is selected at speeds of 3

mph (5

km/h) or

less unless the wiper switch is moved or the

gear selector is moved out of NEUTRAL.



Remote Start Mode Inhibit — On vehicles

equipped with the Remote Start system, Rain

Sensing wipers are not operational when the

vehicle is in the Remote Start mode. Once the

operator is in the vehicle and has placed the

ignition switch in the ON/RUN position, Rain

Sensing wiper operation can resume, if it has

been selected, and no other inhibit conditions

(mentioned previously) exist.

EAR

INDOW

IPER

ASHER

The rear wiper/washer controls are located on the

windshield wiper/washer lever on the right side of

the steering column. The rear wiper/washer is

operated by rotating a switch, located at the

middle of the lever.
NOTE:

If the front wiper is moving and the vehicle is

shifted in REVERSE, the rear wiper will perform one

round up to clean the rear window.

Rotate the center portion of the lever

upward to the first detent for intermittent

operation and to the second detent for

continuous rear wiper operation. If the

front wiper is set to Automatic mode (on the wiper

lever as well as enabled through Uconnect

Settings), placing the rear wiper in an intermittent

position will cause the front and rear wipers to sync

up. Turning the front wipers off will cause the rear

wipers to also stop.

To use the washer, push the lever

forward and hold while spray is desired. If

the lever is pushed while the wiper is in

the off position, the wiper will operate for

several wipe cycles, then turn off.
If the lever is pushed while in the intermittent

setting, the wiper will turn on and operate for

several wipe cycles after the end of the lever is

released, and then resume the intermittent

interval previously selected.
NOTE:

As a protective measure, the pump will stop if the

switch is held for more than 30 seconds. Once the

lever is released, the pump will resume normal

operation.

INDSHIELD

IPER

-I

CER

—

QUIPPED

Your vehicle may be equipped with a Windshield

Wiper De-Icer feature that may be activated under

the following conditions:



Activation By Front Defrost — The Windshield

Wiper De-Icer will be activated automatically in

the case of a cold weather manual start with full

front defrost, and the ambient temperature is

below 40°F (4.4°C).

CAUTION!

Failure to follow these cautions can cause

damage to the heating elements:



Use care when washing the inside of the rear

window. Do not use abrasive window cleaners

on the interior surface of the window. Use a

soft cloth and a mild washing solution, wiping

parallel to the heating elements. Labels can

be peeled off after soaking with warm water.



Do not use scrapers, sharp instruments, or

abrasive window cleaners on the interior

surface of the window.



Keep all objects a safe distance from the

window.

GETTING TO KNOW YOUR VEHICLE



Activation By Rear Defrost — The Windshield

Wiper De-Icer will be activated automatically

when the rear defrost is turned on and the

ambient temperature is below 40°F (4.4°C).



Activation By Remote Start Operation — When

Remote Start is active and the outside ambient

temperature is less than 40°F (4.4°C), the

Windshield Wiper De-Icer will activate. Exiting

Remote Start will resume its previous operation.

If the Windshield Wiper De-Icer was active, the

timer and operation will continue

page

133.

Auto-On Rear Window Defroster/Windshield Wiper

De-Icer — If Equipped
When placing the vehicle’s ignition in the ON/RUN

position, the Rear Window Defroster and

Windshield Wiper De-Icer will automatically turn on

when the outside ambient temperature is less than

40°F (4.4°C).
The Rear Window Defroster and Windshield Wiper

De-Icer automatically turn off after approximately

minutes. To manually shut the defroster/

windshield off, push the Rear Defrost button.
Auto On can be enabled or disabled through the

Uconnect Settings

page

133.

CLIMATE CONTROLS

The Climate Control system allows you to regulate

the temperature, air flow, and direction of air

circulating throughout the vehicle. The controls are

located on the touchscreen (if equipped) and on

the instrument panel below the radio.

UTOMATIC

LIMATE

ONTROL

ESCRIPTIONS

UNCTIONS

Uconnect 4C NAV with 8.4-inch Display Automatic Climate

Controls

MAX A/C Button

Press and release the MAX A/C button on

the touchscreen to change the current

setting to the coldest output of air. The

MAX A/C indicator illuminates when MAX

A/C is on. Pressing the button again will cause the

MAX A/C operation to exit.
NOTE:

The MAX A/C button is only available on the touch

screen.

A/C Button

Press and release the A/C button on the

touchscreen, or push the button on the

faceplate to change the current setting.

The A/C indicator illuminates when A/C is

ON.

The Air Conditioning (A/C) button allows the

operator to manually activate or deactivate the air

conditioning system. When the air conditioning

system is turned on, dehumidified air will flow

through the outlets into the cabin.
If your air conditioning performance seems lower

than expected, check the front of the A/C

condenser (located in front of the radiator), for an

accumulation of dirt or insects. Clean with a gentle

water spray from the front of the radiator and

through the condenser. If the problem persists,

please contact an authorized dealer.

Recirculation Button

Press and release this button on the

touchscreen, or push the button on the

faceplate, to change the system between

recirculation mode and outside air mode.

The Recirculation indicator and the A/C indicator

illuminate when the Recirculation button is

pressed. Recirculation can be used when outside

conditions such as smoke, odors, dust, or high

humidity are present. Recirculation can be used in

all modes. Recirculation may be unavailable

GETTING TO KNOW YOUR VEHICLE

(button on the touchscreen grayed out) if

conditions exist that could create fogging on the

inside of the windshield. The A/C can be

deselected manually without disturbing the mode

control selection. Continuous use of the

Recirculation mode may make the inside air stuffy

and window fogging may occur. Extended use of

this mode is not recommended. Recirculation

mode may automatically adjust to optimize

customer experience for warming, cooling,

dehumidification, etc.
In cold weather, use of Recirculation mode may

lead to excessive window fogging. The

Recirculation feature may be unavailable if

conditions exist that could create fogging on the

inside of the windshield.

AUTO Button

Press and release this button on the

touchscreen, or push the button on the

faceplate, to change the current setting.

The AUTO indicator illuminates when

AUTO is on. This feature automatically controls the

interior cabin temperature by adjusting distribution

and amount of airflow. Air Conditioning (A/C) may

be active during AUTO operation to improve

performance. Toggling this function will cause the

system to switch between manual override mode

and automatic modes

page

47.

Front Defrost Button

Press and release the touchscreen

button, or push and release the button

on the faceplate, to change the current

airflow setting to Defrost mode. The Front

Defrost indicator illuminates when Front Defrost is

on. Air comes from the windshield and side window

demist outlets. When the defrost button is

selected, the blower level may increase. Use

Defrost mode with maximum temperature settings

for best windshield and side window defrosting

and defogging. When toggling the front defrost

mode button, the Climate Control system will

return to the previous setting.

Rear Defrost Button

Press and release the button on the

touchscreen, or push and release the

button on the faceplate, to turn on the

rear window defroster and the heated

outside mirrors (if equipped). The Rear Defrost

indicator illuminates when the rear window

defroster is on. The rear window defroster

automatically turns off after 20

minutes.

Driver And Passenger Up And Down

Buttons

These buttons provide the driver and passenger

with independent temperature control.

Push the red button on the faceplate or

touchscreen or press and slide the

temperature bar towards the red arrow

button on the touchscreen for warmer

temperature settings.

CAUTION!

Failure to follow these cautions can cause

damage to the heating elements:



Use care when washing the inside of the rear

window. Do not use abrasive window cleaners

on the interior surface of the window. Use a

soft cloth and a mild washing solution, wiping

parallel to the heating elements. Labels can

be peeled off after soaking with warm water.



Do not use scrapers, sharp instruments, or

abrasive window cleaners on the interior

surface of the window.



Keep all objects a safe distance from the

window.

GETTING TO KNOW YOUR VEHICLE

Push the blue button on the faceplate or

touchscreen or press and slide the

temperature bar towards the blue arrow

button on the touchscreen for cooler

temperature settings.

SYNC Button

Press the SYNC button on the

touchscreen to toggle the Sync feature

on/off. The SYNC indicator is illuminated

when SYNC is on. SYNC is used to

synchronize the passenger temperature setting

with the driver temperature setting. Changing the

passenger temperature setting while in SYNC will

automatically exit this feature.
NOTE:

The SYNC button is only available on the touch

screen.

Blower Control

Blower Control is used to regulate the

amount of air forced through the Climate

Control system. There are seven blower

speeds available. Adjusting the blower

will cause automatic mode to switch to manual

operation. The speeds can be selected using either

the blower control knob on the faceplate or the

buttons on the touchscreen.

Faceplate
The blower speed increases as you turn the blower

control knob clockwise from the lowest blower

setting. The blower speed decreases as you turn

the blower control knob counterclockwise.
Touchscreen
Use the small blower icon to reduce the blower

setting and the large blower icon to increase the

blower setting. Blower can also be selected by

pressing the blower bar area between the icons.

Mode Control

Select Mode by pressing one of the Mode

buttons on the touchscreen to change

the airflow distribution mode. The airflow

distribution outlets are: instrument panel

outlets, floor outlets, defrost outlets, and demist

outlets.

Panel Mode

Air comes from the outlets in the

instrument panel. Each of these outlets

can be individually adjusted to direct the

flow of air. The air vanes of the center

outlets and outboard outlets can be moved up and

down or side to side to regulate airflow direction.

There is a shut-off wheel located below the air

vanes to shut off or adjust the amount of airflow

from these outlets.

Bi-Level Mode

Air comes from the instrument panel

outlets and floor outlets. A slight amount

of air is directed through the defrost and

side window demister outlets.

NOTE:

Bi-Level mode is designed under comfort condi

tions to provide cooler air out of the panel outlets

and warmer air from the floor outlets.

Floor Mode

Air comes from the floor outlets. A slight

amount of air is directed through the

defrost, side window demister outlets,

and panel outboard outlets.

Mix Mode

Air is directed through the floor, defrost,

and side window demister outlets. This

setting works best in cold or snowy

conditions that require extra heat to the

windshield. This setting is good for maintaining

comfort while reducing moisture on the

windshield. A slight amount of air is also directed

through the panel outboard outlets.

Climate Control OFF Button

Press and release this button to turn the

Climate Control ON/OFF.

GETTING TO KNOW YOUR VEHICLE

UTOMATIC

EMPERATURE

ONTROL

(ATC)

Automatic Operation

1. Push the AUTO button on the faceplate, or the

AUTO button on the touchscreen on the

Automatic Temperature Control (ATC) Panel.

2. Adjust the temperature you would like the

system to maintain, by adjusting the driver,

and passenger temperatures. Once the

desired temperature is displayed, the system

will achieve and automatically maintain that

comfort level.

3. When the system is set up for your comfort

level, it is not necessary to change the

settings. You will experience the greatest

efficiency by simply allowing the system to

function automatically.

NOTE:



It is not necessary to move the temperature

settings. The system automatically adjusts the

temperature, mode, and fan speed to provide

comfort as quickly as possible.



The temperature can be displayed in U.S. or

Metric units by selecting the U.S./Metric

customer programmable feature within

Uconnect Settings.

To provide you with maximum comfort in the

automatic mode, during cold start-ups, the blower

fan will remain on low until the engine warms up.

The fan will engage immediately if the Defrost

mode is selected, or by changing the front blower

knob setting.

Manual Operation Override

This system offers a full complement of manual

override features. The AUTO symbol in the front

ATC display will be turned off when the system is

being used in the manual mode.

LIMATE

OICE

OMMANDS

Adjust vehicle temperatures hands-free and keep

everyone comfortable while you keep moving

ahead.
Push the VR button on the steering wheel. After the

beep, say one of the following commands:



“Set the driver temperature to 70 degrees”



“Set the passenger temperature to 70 degrees”

Did You Know: Voice Command for Climate may

only be used to adjust the interior temperature of

your vehicle. Voice Command will not adjust the

heated seats or steering wheel if equipped.

PERATING

IPS

Refer to the chart at the end of this section for

suggested control settings for various weather

conditions.

Summer Operation

The engine cooling system must be protected with

a high-quality antifreeze coolant to provide proper

corrosion protection and to protect against engine

overheating. OAT coolant (conforming to

MS.90032) is recommended.

Winter Operation

To ensure the best possible heater and defroster

performance, make sure the engine cooling

system is functioning properly and the proper

amount, type, and concentration of coolant is

used. Use of the Air Recirculation mode during

Winter months is not recommended, because it

may cause window fogging.

Vacation/Storage

For information on maintaining the Climate Control

system when the vehicle is being stored for an

extended period of time, see

page

338.

Window Fogging

Vehicle windows tend to fog on the inside in mild,

rainy, and/or humid weather. To clear the

windows, select Defrost or Mix mode and increase

the front blower speed. Do not use the

Recirculation mode without A/C for long periods,

as fogging may occur.

Outside Air Intake

Make sure the air intake, located directly in front of

the windshield, is free of obstructions, such as

GETTING TO KNOW YOUR VEHICLE

leaves. Leaves collected in the air intake may

reduce airflow, and if they enter the air distribution

box, they could plug the water drains. In Winter

months, make sure the air intake is clear of ice,

slush, and snow.

Cabin Air Filter

The Climate Control system filters out dust and

pollen from the air. Contact an authorized dealer to

service your cabin air filter, and to have it replaced

when needed.
NOTE:

In the Red Special Series models, the cabin air

filter was treated with a biocide substance having

antibacterial and antiviral properties based on the

active ingredient, citric acid.

Stop/Start System — If Equipped

While in an Autostop, the Climate Control system

may automatically adjust airflow to maintain cabin

comfort. Customer settings will be maintained

upon return to an engine running condition.

Windshield Wiper De-Icer — If Equipped

The windshield wiper de-icer is a heating element

located at the base of the windshield.
It operates automatically once the following

conditions are met:



Activation By Front Defrost

The wiper de-icer activates automatically during

a cold weather manual start with full defrost,

and when the ambient temperature is below

40°F (4.4°C).



Activation By Rear Defrost

The wiper de-icer activates automatically when

the Rear Defrost is operating and the ambient

temperature is below 40°F (4.4°C).



Activation By Remote Start Operation

When Remote Start is active and the outside

ambient temperature is less than 40°F (4.4°C),

the Windshield Wiper De-Icer will activate.

Exiting Remote Start will resume its previous

operation. If the Windshield Wiper De-Icer was

active, the timer and operation will continue.

Operating Tips Chart

NOTE:

The following chart is for Manual Override Oper

ation, otherwise run in AUTO.

INTERIOR STORAGE AND EQUIPMENT

TORAGE

Glove Compartment

The glove compartment is located on the

passenger’s side of the instrument panel.
To open the glove compartment proceed as

follows:
1. Unlock the compartment using the vehicle

emergency key.

WEATHER

CONTROL SETTINGS

Hot Weather And

Vehicle Interior Is

Very Hot

Set the mode control to

(Panel Mode), (A/C) on,

and blower on high. Roll

down the windows for a

minute to flush out the hot

air. Adjust the controls as

needed to achieve comfort.

Warm Weather

Turn (A/C) on and set

the mode control to

(Panel Mode).

Cool Sunny

Operate in (Bi-Level

Mode).

Cool & Humid

Conditions

Set the mode control to

(Floor Mode) and turn

(A/C) on to keep windows

clear.

Cold Weather

Set the mode control to

(Floor Mode). If windshield

fogging starts to occur,

move the control to (Mix

Mode).

WEATHER

CONTROL SETTINGS

GETTING TO KNOW YOUR VEHICLE

2. Pull the handle to open the compartment.

Opening The Glove Compartment

Once the glove compartment is open, a light will

turn on to illuminate the compartment.
NOTE:



Do not insert objects in the glove compartment

that will not allow the compartment to fully

close.



The glove compartment should be completely

closed while the vehicle is in motion.

Console Storage Compartment

To open, push the storage handle and lift the

cover.
The center console can be adjusted by moving it

forward or rearward.

Front Armrest

Storage Compartment

Handle Grip

The handle grip is located on the passenger side of

the instrument panel. The handle can be used to

enter or exit the vehicle or when traveling on rough

terrain.

Handle Grip

1 — Glove Compartment Handle

WARNING!

Do not operate this vehicle with a console

compartment lid in the open position. Driving

with the console compartment lid open may

result in injury in a collision.

GETTING TO KNOW YOUR VEHICLE

USB/AUX C

ONTROL

This feature allows an external device to be

plugged into the USB port or AUX Jack.

Front USB Port And AUX Jack

Located below the heating ventilation and air

conditioning controls is the front USB port and AUX

jack.
Rear Center Console USB Port
Located on the rear of the center console is a

second USB port.
NOTE:

Depending on vehicle configuration, the USB port

may be charge only, or media file capable.

Rear Center Console USB (Charge Only) Port — If Equipped

OWER

UTLETS

The front power outlet is located under the center

stack of the instrument panel. It only operates with

the ignition in the ON/RUN position. The power

outlet can power mobile phones, electronics and

other low power devices.

12 Volt Power Outlet

Models equipped with the optional "Smoker Kit”,

will have a cigar lighter instead of the power outlet

page

52.

1 — USB Port
2 — AUX Port

WARNING!

To avoid serious injury or death:



Only devices designed for use in this type of

outlet should be inserted into any 12 Volt

outlet.



Do not touch with wet hands.



Close the lid when not in use and while driving

the vehicle.



If this outlet is mishandled, it may cause an

electric shock and failure.

CAUTION!

Do not connect devices with power higher than

180 Watts (15 Amps) to the socket. Do not

damage the socket by using unsuitable

adaptors. If the 180 Watt (15 Amp) power rating

is exceeded the fuse protecting the system will

need to be replaced.

GETTING TO KNOW YOUR VEHICLE

F94 Fuse 15A Blue Instrument Panel Power Outlet

OWER

NVERTER

— I

QUIPPED

There is a 115 Volt, 150 Watt Power Inverter outlet

located on the back of the center console to

convert DC current to AC current. The Power

Inverter can power cellular phones, electronics

and other low power devices requiring up to

150 Watts. Certain video game consoles will

exceed this power limit, as will most power tools.

115 Volt Power Inverter

The Power Inverter will automatically turn on and

off when a device is plugged in or removed.
In order for the Power Inverter to work, the engine

must be running and there must be no faults

detected with the alternator.
The Power Inverter is designed with built-in

overload protection. If the power rating of

150 Watts is exceeded, the Power Inverter will

automatically shut down. Once the electrical

device has been removed from the Power Inverter

it will automatically reset. To avoid overloading the

circuit, check the power ratings on electrical

devices prior to using the Power Inverter.

CAUTION!



Many accessories that can be plugged in draw

power from the vehicle's battery, even when

not in use (i.e., cellular phones, etc.). Eventu

ally, if plugged in long enough, the vehicle's

battery will discharge sufficiently to degrade

battery life and/or prevent the engine from

starting.



Accessories that draw higher power (i.e.,

coolers, vacuum cleaners, lights, etc.) will

degrade the battery even more quickly. Only

use these intermittently and with greater

caution.



After the use of high power draw accessories,

or long periods of the vehicle not being started

(with accessories still plugged in), the vehicle

must be driven a sufficient length of time to

allow the generator to recharge the vehicle's

battery.

GETTING TO KNOW YOUR VEHICLE

IGAR

IGHTER

— I

QUIPPED

NOTE:

Cigar lighters can be purchased at an authorized

dealer through Mopar® parts.
The cigar lighter is located under the center stack of

the Instrument Panel. Push lighter inward to heat.

Cigar Lighter

After a few seconds, the lighter automatically

returns to its initial position and is ready to be

used.

SHTRAY

— I

QUIPPED

NOTE:

Ashtrays can be purchased at an authorized dealer

through Mopar® parts.
The ashtray is a plastic container that can be

placed into one of the cup holders.

Ashtray Location

WINDOWS

OWER

INDOW

ONTROLS

The window controls on the driver's door control all

the door windows.

Power Window Switches

WARNING!

To avoid serious injury or death:



Do not insert any objects into the receptacles.



Do not touch with wet hands.



Close the lid when not in use.



If this outlet is mishandled, it may cause an

electric shock and failure.

WARNING!

When the cigar lighter is in use it becomes very

hot. To avoid serious injury, handle the cigar

lighter with care. Always check that the cigar

lighter has turned off.

CAUTION!

Do not connect devices with power higher than

180 Watts (15 Amps) to the socket. Do not

damage the socket by using unsuitable

adaptors. If the 180 Watt (15 Amp) power rating

is exceeded the fuse protecting the system will

need to be replaced.

GETTING TO KNOW YOUR VEHICLE

The passenger door windows can also be operated

by using the single window controls on the

passenger door trim panel. The window controls

will operate only when the ignition is in the ACC or

ON/RUN position.
NOTE:

The power window switches will remain active for

up to three minutes after the ignition is placed in

the OFF position. Opening either front door will

cancel this feature.

UTOMATIC

INDOW

EATURES

Auto-Down Feature
The driver and front passenger door power window

switches have an Auto-Down feature. Push the

window switch down for a short period of time,

then release, and the window will go down

automatically.
To stop the window from going all the way down

during the Auto-Down operation, pull up on the

switch briefly.
Auto-Up Feature With Anti-Pinch Protection
Lift the window switch up for a short period of time

and release; the window will go up automatically.
To stop the window from going all the way up

during the Auto-Up operation, push down on the

switch briefly.
To close the window part way, lift the window

switch briefly and release it when you want the

window to stop.
If the window runs into any obstacle during

auto-closure, it will reverse direction and then go

back down. Remove the obstacle and use the

window switch again to close the window.

NOTE:

Any impact due to rough road conditions may

trigger the auto-reverse function unexpectedly

during auto-closure. If this happens, pull the switch

lightly and hold to close the window manually.

ESET

UTO

-U

Should the Auto-Up feature stop working, the

window probably needs to be reset. To reset

Auto-Up:
1. Pull the window switch up to close the window

completely and continue to hold the switch up

for an additional two seconds after the

window is closed.

2. Push the window switch down firmly to open

the window completely and continue to hold

the switch down for an additional two seconds

after the window is fully open.

WARNING!

Never leave children unattended in a vehicle,

and do not let children play with power windows.

Do not leave the key fob in or near the vehicle, or

in a location accessible to children, and do not

leave the ignition of a vehicle equipped with Key

less Enter ‘n Go™ in the ACC or ON/RUN posi

tion. Occupants, particularly unattended

children, can become entrapped by the windows

while operating the power window switches.

Such entrapment may result in serious injury or

death.

WARNING!

There is no anti-pinch protection when the

window is almost closed. To avoid personal

injury be sure to clear your arms, hands, fingers

and all objects from the window path before

closing.

GETTING TO KNOW YOUR VEHICLE

INDOW

OCKOUT

WITCH

The window lockout switch on the driver's door trim

panel allows you to disable the window controls on

the rear passenger doors. To disable the window

controls, push and release the window lockout

switch (the indicator light on the switch will turn

on). To enable the window controls, push and

release the window lockout switch again (the

indicator light on the switch will turn off).

Power Window Lockout Switch

IND

UFFETING

Wind buffeting can be described as the perception

of pressure on the ears or a helicopter-type sound

in the ears. Your vehicle may exhibit wind buffeting

with the windows down, or the sunroof (if

equipped) in certain open or partially open

positions. This is a normal occurrence and can be

minimized. If the buffeting occurs with the rear

windows open, open the front and rear windows

together to minimize the buffeting. If the buffeting

occurs with the sunroof open, adjust the sunroof

opening to minimize the buffeting or open any

window.

DUAL PANE PANORAMIC POWER SUNROOF

WITH POWER SHADE — IF EQUIPPED

The power sunroof switches are located between

the sun visors on the overhead console.

Power Sunroof Switches

1 — Power Sunshade Open/Close
2 — Power Sunroof Open/Close
3 — Venting Sunroof

WARNING!



Never leave children unattended in a vehicle,

or with access to an unlocked vehicle. Never

leave the key fob in or near the vehicle, or in a

location accessible to children. Do not leave

the ignition of a vehicle equipped with Keyless

Enter ‘n Go™ in the ON/RUN position. Occu

pants, particularly unattended children, can

become entrapped by the power sunroof while

operating the power sunroof switch. Such

entrapment may result in serious injury or

death.



In a collision, there is a greater risk of being

thrown from a vehicle with an open sunroof.

You could also be seriously injured or killed.

Always fasten your seat belt properly and

make sure all passengers are also properly

secured.



Do not allow small children to operate the

sunroof. Never allow your fingers, other body

parts, or any object, to project through the

sunroof opening. Injury may result.

GETTING TO KNOW YOUR VEHICLE

PENING

LOSING

UNROOF

To retract the sunroof to the open position, push

the Open/Close switch and the sunroof will fully

open. The sunroof can be stopped in any position

by pushing/pulling the switch a second time while

opening.
To close the sunroof completely, pull the Open/

Close switch and the sunroof will fully close. The

sunroof can be stopped in any position by pushing/

pulling the switch a second time while it is closing.

ENTING

UNROOF

To vent the sunroof push the vent switch.
NOTE:

The vent switch has the automatic function only at

the opening of the sunroof. During the closing of

the sunroof, the switch must be held until closed.

PENING

LOSING

OWER

UNSHADE

Express Open/Close
Push the shade switch for about one-half second

and the shade will automatically open. During the

automatic open operation, any movement of the

shade switch will stop the shade.

Pull the shade switch for about one-half second

and the shade will automatically close. During the

automatic close operation, any movement of the

shade switch will stop the shade.
Manual Open/Close
To open the shade part way, push the shade switch

briefly and release.
To close the shade part way, pull the shade switch

briefly and release.
NOTE:



The sunroof and the shade controls will operate

only when the ignition is in the ON/RUN posi

tion.



If the Remote Start functionality is active, it is

not possible to move the sunroof.

INCH

ROTECT

EATURE

This feature will detect an obstruction in the

opening of the sunroof during Express Close

operation. If an obstruction in the path of the

sunroof is detected, the sunroof will automatically

retract. Remove the obstruction if this occurs.

WARNING!



Do not let children play with the sunroof.

Never leave children unattended in a vehicle,

or with access to an unlocked vehicle. Do not

leave the key fob in or near the vehicle, and do

not leave the ignition of a vehicle equipped

with Keyless Enter ‘n Go™ in the ACC or ON/

RUN position. Occupants, particularly unat

tended children, can become entrapped by

the power sunroof while operating the power

sunroof switch. Such entrapment may result

in serious injury or death.



In a collision, there is a greater risk of being

thrown from a vehicle with an open sunroof.

You could also be severely injured or killed.

Always fasten your seat belt properly and

make sure all passengers are properly

secured.



Do not allow small children to operate the

sunroof. Never allow your fingers, other body

parts, or any object to project through the

sunroof opening. Injury may result.

GETTING TO KNOW YOUR VEHICLE

UNROOF

AINTENANCE

Use only a non-abrasive cleaner and a soft cloth to

clean the glass panel. Periodically check for and

clear out any debris that may have collected in the

tracks.

HOOD

PEN

OOD

Two latches must be released to open the hood.
1. Pull the hood release lever located under the

driver’s side of the instrument panel.

Hood Release Lever

2. Move to the outside of the vehicle and push

the safety latch release lever toward the

passenger side of the vehicle. The hood

release lever is located behind the center front

edge of the hood.

Safety Latch

Remove the support rod from the locking tab and

insert it into the seat key hole located on the

underside of the hood. Be sure the rod is locked

into position.

Locking Tab

Support Rod And Seat

1 — Safety Latch Location

1 — Support Rod
2 — Support Rod Seat

GETTING TO KNOW YOUR VEHICLE

LOSE

OOD

LIFTGATE

NLOCK

PEN

IFTGATE

To unlock the liftgate, use the key fob or activate

the power door lock switches located on the driver

door handle.
To open the liftgate, squeeze the electronic liftgate

release and pull the liftgate open with one fluid

motion.

Liftgate Handle Location

The Liftgate Passive Entry unlock feature is built

into the electronic liftgate release. With a valid

Passive Entry key fob within 5

ft (1.5

m) of the

liftgate, push the electronic liftgate release to open

with one fluid motion.
Emergency Opening
Proceed as follows:
1. Remove the rear shelf (if equipped).
2. Fold the rear seats forward.
3. Using the supplied screwdriver (located under

cargo floor in tool kit), remove the yellow tab.

Emergency Opening Tab Location

4. Insert the screwdriver into the release tab slot

to trigger the release tab of the liftgate.

Emergency Release Tab Slot Location

WARNING!

Be sure the hood is fully latched before driving

your vehicle. If the hood is not fully latched, it

could open when the vehicle is in motion and

block your vision. Failure to follow this warning

could result in serious injury or death.

CAUTION!

To prevent possible damage, do not slam the

hood to close it. Lower hood to approximately

inches (30 cm) and drop the hood to close.

Make sure hood is fully closed for both latches.

Never drive vehicle unless hood is fully closed,

with both latches engaged.

1 — Electronic Liftgate Release
2 — Passive Entry Lock Button

1 — Yellow Tab

1 — Release Tab Slot

Jeep Renegade (2022 year). Manual in english - page 3
