GETTING TO KNOW YOUR VEHICLE

NOTE:



The Automatic High Beam Headlight system can

be turned on or off by selecting or deselecting

“Auto High Beam” within Uconnect Settings

page 204.



The headlight switch must also be turned to the

AUTO position after Automatic High Beams is

enabled within Uconnect Settings for the

feature to activate.



Automatic High Beams will only activate when

the vehicle speed is above 22 mph (35 km/h).



Broken, muddy, or obstructed headlights and

taillights of vehicles in the field of view will

cause headlights to remain on longer (closer to

the vehicle). Also, dirt, film, and other obstruc

tions on the windshield or camera lens will

cause the system to function improperly.

If the windshield or Automatic High Beam

Headlight Control mirror is replaced, the mirror

must be re-aimed to ensure proper performance.

See a local authorized dealer.

LASH

-T

-P

ASS

You can signal another vehicle with your headlights

by lightly pulling the multifunction lever toward you.

This will cause the high beam headlights to turn on,

and remain on, until the lever is released.

UTOMATIC

EADLIGHTS

This system automatically turns the headlights on

or off according to ambient light levels. To turn the

system on, rotate the headlight switch

counterclockwise to the AUTO position. When the

system is on, the headlight time delay feature is

also on. This means the headlights will stay on for

up to 90 seconds after you place the ignition into

the OFF position. The headlight time delay can be

programmed 0/30/60/90 seconds within the

Uconnect system

page 204.

To turn the automatic system off, move the

headlight switch out of the AUTO position.

NOTE:

The engine must be running before the headlights

will come on in the automatic mode.

ARKING

IGHTS

ANEL

IGHTS

To turn on the parking lights and instrument panel

lights, rotate the headlight switch clockwise. To

turn off the parking lights, rotate the headlight

switch back to the O (off) position.

NOTE:

Vehicles sold in Canada are equipped with a head

light switch with an AUTO and ON detent but

without an OFF detent. Headlights will be deacti

vated when the headlight switch is placed in the

parking lights position. However, the Daytime

Running Lights (DRLs) will be activated along with

the front and rear marker lights. The DRLs may be

deactivated when the parking brake is engaged.

EADLIGHTS

UTOMATICALLY

ITH

IPERS

If your vehicle is equipped with Automatic

Headlights, it also has this

customer-programmable feature. When your

headlights are in the automatic mode and the

engine is running, they will automatically turn on

when the wiper system is on. This feature is

programmable through the Uconnect system

page 204.

NOTE:

When your headlights come on during the daytime,

the vehicle will monitor outside brightness and

decide if the instrument panel needs to be dimmed

or not

page 63.

GETTING TO KNOW YOUR VEHICLE

EADLIGHT

LLUMINATION

PPROACH

When enabled, the headlights, exterior door

handle pocket lights (if equipped), and interior

lights will illuminate when the unlock button on the

key fob is pushed as the operator is approaching

the vehicle. This feature can be turned on/off, and

the length of time the headlights stay on can be

programmed for up to 90 seconds within Uconnect

Settings

page 204.

Proximity Wake-Up — If Equipped
This feature is enabled/disabled within the

Uconnect system, and is activated when the

operator approaches the driver’s door,

passenger’s door, or liftgate with a valid key fob on

their person. Some exterior and interior lights will

illuminate in order to provide an increased sense

of welcome and security as the operator

approaches the vehicle in the dark. “Headlight

Illumination On Approach” must be selected and

set to a time value other than zero within Uconnect

Settings for Proximity Wake-Up to activate.
The doors may be locked or unlocked for this

feature to activate, as long as the ignition is in the

OFF position, or during a Remote Start event. It will

not activate if the doors are locked and the ignition

was placed in the ON/RUN position.

NOTE:

Proximity Wake-Up may not activate under the

following conditions:



After numerous consecutive activations, in

order to conserve the vehicle’s battery



After the vehicle’s engine has been off for

several days

Headlight Animation — If Equipped
When “Headlight Illumination On Approach” is

turned on, and set to a time value above zero, the

exterior lights illuminate in a theatrical manner

during approach to the vehicle. This feature is

activated in the following situations:



Proximity Wake-Up (if equipped) is activated



Remote Start is activated



The unlock button on the key fob is pushed

NOTE:

For Headlight Animation to activate with Remote

Start or with the push of the unlock button,

“Greeting Lights” must also be selected within the

Uconnect system.

EADLIGHT

ELAY

To aid in your exit, your vehicle is equipped with a

headlight delay that will leave the headlights on for

approximately 90 seconds. This delay is initiated

when the ignition is placed in the OFF position

while the headlight switch is on, and then the

headlight switch is cycled off. Headlight delay can

be canceled by either turning the headlight switch

on then off, or by placing the ignition in the ON/

RUN position.

NOTE:

The headlight delay time is programmable through

Uconnect Settings

page 204.

IGHTS

-O

EMINDER

If the headlights or parking lights are left on after

the ignition is placed in the OFF position, a chime

will sound when the driver’s door is opened.

GETTING TO KNOW YOUR VEHICLE

IGHTS

— I

QUIPPED

To activate the front fog lights, turn on the parking

lights or the low beam headlights, and push the fog

light button on the headlight switch.

Fog Light Button

Fog Light Button (Vehicles Sold In Canada Only)

The fog lights will operate only when the parking

lights are on, or when the vehicle headlights are on

low beam. An indicator light located in the

instrument cluster display will illuminate when the

fog lights are on. The fog lights will turn off when

the button is pushed a second time, when the

headlight switch is rotated to the off position, or

the high beam is selected.
Cornering Lights
The cornering lights are a feature to improve

visibility at night while turning the vehicle. When

activated, a light incorporated in the front fog light

will illuminate on the side of the vehicle the

steering wheel is rotated or the turn signal

indicator is on. It can be activated through the

Uconnect system

page 204.

URN

IGNALS

Move the multifunction lever up or down and the

arrows on each side of the instrument cluster will

flash to show proper operation of the front and rear

turn signal lights.

NOTE:

If either light remains on and does not flash, or

there is a very fast cluster turn indicator flash rate,

check for a defective outside light bulb.

ANE

HANGE

SSIST

— I

QUIPPED

Tap the multifunction lever up or down once,

without moving beyond the detent, and the turn

signal (right or left) will flash three times then

automatically turn off.

UTOMATIC

EADLIGHT

EVELING

—

QUIPPED

This feature prevents the headlights from

interfering with the vision of oncoming drivers.

Headlight leveling automatically adjusts the height

of the headlight beam in reaction to changes in

vehicle pitch.

ATTERY

AVER

To protect the life of your vehicle’s battery, load

shedding is provided for both the interior and

exterior lights.
If the ignition is placed in the OFF position and any

door is left ajar for 10 minutes or the overhead

console Dome On switch is left on for 10 minutes,

the interior lights will automatically turn off.

NOTE:

Battery saver mode is canceled if the ignition is in

the ON/RUN position.

GETTING TO KNOW YOUR VEHICLE

If the headlights remain on while the ignition is

placed in the OFF position, the exterior lights will

automatically turn off after eight minutes. If the

headlights are turned on and left on for eight

minutes while the ignition is in the OFF position,

the exterior lights will automatically turn off.

INTERIOR LIGHTS

OURTESY

IGHTS

Courtesy and dome lights are turned on when the

front doors are opened or the Dome ON button is

pushed on the overhead console. If your vehicle is

equipped with Remote Keyless Entry and the

unlock button is pushed on the key fob, the

courtesy and dome lights will turn on. When a door

is open and the interior lights are on, pressing the

Dome Defeat button on the overhead console will

cause all of the interior lights to turn off.

Front Map/Reading Lights — If Equipped

The overhead console lights can also be operated

individually as reading lights by pushing the

corresponding buttons.

Courtesy Lights

Rear Courtesy/Reading Lights

Located above the rear passenger seating in both

second and third rows, along the trim, are

courtesy/reading lights. The courtesy lights turn on

when a door or the liftgate is opened. The lights will

also turn on when the unlock button on the key fob

is pushed.
The courtesy lights also function as reading lights.

Push the reading light button to turn these lights

on while inside the vehicle. Push the reading light

button a second time to turn each light off.

Dimmer Controls

The dimmer controls are inboard and adjacent to

the headlight switch located on the left side of the

instrument panel.
With the parking lights or headlights on, rotating

the right dimmer control upward will increase the

brightness of the instrument cluster lights.

Rotating the left dimmer control will adjust the

interior light levels of the ambient lighting on the

instrument panel and doors. Certain ambient lights

may be color customizable

page 64.

Dimmer Controls

1 — Reading Light On/Off Buttons
2 — Dome Defeat Button
3 — Ambient Light
4 — Dome ON Button

1 — Ambient Light Dimmer Control
2 — Instrument Panel Dimmer Control

GETTING TO KNOW YOUR VEHICLE

Dimmer Controls (Vehicles Sold In Canada Only)

NOTE:



Multicolor ambient lighting for first and second

rows, and overhead white ambient lighting in

the second and third row (if equipped) seating

areas, may not be equipped in the vehicle.



The dimming of lighting linked to the headlight

status (i.e. radio screen brightness) is program

mable through the Uconnect system

page 204.

Multicolor Ambient Lighting — If Equipped

The color of certain ambient lighting inside of the

vehicle can be selected within the Apps menu on

the radio screen, or within Uconnect Settings

page 204. Brightness is adjusted using the

ambient light dimmer control on the headlight

switch.
Five colors can be selected for the following two

zones inside of the vehicle:



Zone 1:



Instrument panel decorative ambient lights



Door panel decorative ambient lights



Zone 2:



Front seat footwell areas below the instru

ment panel



Lighting below the second row seats



Map pocket lighting on all four door panels

These areas can be set to different colors, or if the

SYNC button is selected within the settings menu,

all colored lights will be set to the same color

automatically.

NOTE:

All other ambient lighting inside of the vehicle will

remain white, and the ambient light dimmer

control switch will adjust all ambient lighting at the

same time.

WINDSHIELD WIPERS AND WASHERS

The windshield wiper/washer lever is located on

the right side of the steering column. The front

wipers are operated by rotating a switch, located

on the end of the lever.

Multifunction Lever

1 — Ambient Light Dimmer Control
2 — Instrument Panel Dimmer Control

1 — Pull For Front Washer
2 — Rotate For Rear Wiper Operation
3 — Rotate For Front Wiper Operation
4 — Push Forward For Rear Washer
5 — Push Up For Mist

GETTING TO KNOW YOUR VEHICLE

INDSHIELD

IPER

PERATION

The wipers and washers are operated by a switch

within the wiper lever. Rotate the switch at the end

of the lever upward, to the first detent past the

intermittent settings for low-speed wiper

operation. Rotate the switch at the end of the lever

upward to the second detent past the intermittent

settings for high-speed wiper operation. To turn the

windshield wipers off, rotate the switch within the

lever all the way down to OFF.

Intermittent Wiper System

Use the intermittent wiper when weather

conditions make a single wiping cycle with a

variable pause between cycles desirable. Rotate

the switch at the end of the wiper lever to the first

detent position, and then turn the switch at the end

of the lever to select the desired delay interval.

There are four delay settings, which allow you to

regulate the wipe interval from a minimum of one

cycle every second to a maximum of approximately

36 seconds between cycles. The delay intervals

will double in duration when the vehicle speed is

10 mph (16 km/h) or less.

NOTE:

If the vehicle is moving less than 10 mph

(16 km/h), delay times will be doubled.

Windshield Washer Operation

To use the washer, pull the lever rearward toward

you and hold. If the lever is pulled while on the

intermittent setting, the wipers will turn on and

operate for several wipe cycles after the lever is

released, and then resume the intermittent

interval previously selected. If the lever is pulled

while the wipers are in the off position, the wipers

will operate several cycles, then turn off.

NOTE:



As a protective measure, the pump will stop if

the switch is held for more than 20 seconds.

Once the switch is released the pump will

resume normal operation.



If the front window washer feature is activated,

all of the front cameras (if equipped) on the

vehicle will be washed as well.



Due to washer pump packaging, the front

camera washers will run out of fluid before the

Low Washer Fluid Warning Light is activated.

When the front camera washers stop func

tioning, add fluid to the washer fluid reservoir to

resume function.

Mist

Use the Mist feature when weather conditions

make occasional usage of the wipers necessary.

Push the lever upward to the MIST position and

release for a single wiping cycle.

NOTE:

The Mist feature does not activate the washer

pump; therefore, no washer fluid will be sprayed on

the windshield. The wash function must be used in

order to spray the windshield with washer fluid.
For information on wiper care and replacement,

see

page 349.

CAUTION!

Always remove any buildup of snow that

prevents the windshield wiper blades from

returning to the “park” position. If the windshield

wiper switch is turned off, and the blades cannot

return to the “park” position, damage to the

wiper motor may occur.

WARNING!

Sudden loss of visibility through the windshield

could lead to a collision. You might not see other

vehicles or other obstacles. To avoid sudden

icing of the windshield during freezing weather,

warm the windshield with the defroster before

and during windshield washer use.

GETTING TO KNOW YOUR VEHICLE

AIN

ENSING

IPERS

— I

QUIPPED

This feature senses rain or snowfall on the

windshield and automatically activates the wipers.

Rotate the end of the windshield wiper lever to one

of the four detent positions to activate this feature.
The sensitivity of the system is adjustable from the

windshield wiper lever. Wiper sensitivity position

1 is the least sensitive, and wiper sensitivity

position 4 is the most sensitive.

NOTE:



The Rain Sensing feature will not operate when

the wiper switch is in the low, high, or OFF posi

tion. Only in one of the intermittent positions.



The Rain Sensing feature may not function prop

erly when ice or dried saltwater is present on the

windshield.



Use of Rain-X or products containing wax or sili

cone may reduce rain sensor performance.



The Rain Sensing feature can be turned on and

off through the Uconnect system

page 204.

The Rain Sensing system has protective features

for the wiper blades and arms. It will not operate

under the following conditions:



Low Temperature Wipe Inhibit — The Rain

Sensing feature will not operate when the igni

tion is first placed in the ON/RUN position, when

the vehicle is stationary and the outside

temperature is below 32°F (0°C), unless the

wiper control on the windshield wiper lever is

moved, the vehicle speed becomes greater than

3 mph (5 km/h) or the outside temperature

rises above freezing.



Neutral Wipe Inhibit — The Rain Sensing feature

will not operate when the ignition is placed in

the ON/RUN position, when the transmission

gear selector is in the NEUTRAL position and the

vehicle speed is less than 3 mph (5 km/h),

unless the wiper control on the windshield wiper

lever is moved, the vehicle speed is greater than

3 mph (5 km/h) or the gear selector is moved

out of the NEUTRAL position.



Remote Start Mode Inhibit — On vehicles

equipped with the Remote Start system, Rain

Sensing wipers are not operational when the

vehicle is in the Remote Start mode. Once the

operator is in the vehicle and has placed the

ignition switch in the ON/RUN position, rain

sensing wiper operation can resume, if it has

been selected, and no other inhibit conditions

(mentioned previously) exist.

EAR

IPER

ASHER

The rear wiper/washer is operated by rotating a

switch, located at the middle of the lever.

Rotate the center portion of the lever

upward to the first detent for intermittent

operation and to the second detent for

continuous rear wiper operation.

Rear Window Washer Operation

Pushing the windshield wiper lever

forward activates the rear window

washer. If the lever is pushed while on

the intermittent setting, the wipers will

turn on and operate for several wipe cycles after

the lever is released, and then resume the

intermittent interval previously selected. If the

lever is pushed while the wipers are in the off

position, the wipers will operate several wipe

cycles, then turn off.

NOTE:

If equipped with a backup camera washer, when

the rear window washer is activated, the rear

backup camera and digital rearview mirror

(if equipped) cameras are also washed.

GETTING TO KNOW YOUR VEHICLE

INDSHIELD

IPER

-I

CER

—

QUIPPED

Your vehicle may be equipped with a Windshield

Wiper De-Icer feature that may be activated under

the following conditions:



Activation By Front Defrost — The Windshield

Wiper De-Icer shall be activated automatically in

the case of a cold weather manual start with full

front defrost, and when the ambient tempera

ture is below 33°F (0.6°C).



Activation By Rear Defrost — The Windshield

Wiper De-Icer shall be activated automatically

when the rear defrost is turned on and when the

ambient temperature is below 33°F (0.6°C).



Activation By Remote Start Operation — When

Remote Start is active and the outside ambient

temperature is less than 33°F (0.6°C), the

Windshield Wiper De-Icer will activate. Exiting

Remote Start will resume its previous operation.

If the Windshield Wiper De-Icer was active, the

timer and operation will continue.

CLIMATE CONTROLS

The Climate Control system allows you to regulate

the temperature, air flow, and direction of air

circulating throughout the vehicle. The controls are

located on the touchscreen and on the instrument

panel below the radio.

UTOMATIC

LIMATE

ONTROL

ESCRIPTIONS

UNCTIONS

Uconnect 5 NAV With 10.1–inch Display

Temperature Controls

Uconnect 5/5 NAV With 8.4–inch Display

Temperature Controls

Max A/C Button

Press and release to change the current

setting. The MAX A/C indicator

illuminates when MAX A/C is ON.

Performing this function again will cause

the MAX A/C operation to switch into manual mode

and the MAX A/C indicator will turn off. Pressing

other setting buttons will also cause the MAX A/C

to turn off.
MAX A/C sets the control for maximum cooling

performance.

NOTE:

The MAX A/C button is only available on the touch

screen.

GETTING TO KNOW YOUR VEHICLE

A/C Button

Press and release to change the current

setting. The A/C indicator illuminates

when A/C is on.

Recirculation Button

Press and release the Recirculation

button to change the system between

recirculation mode and outside air mode.

Recirculation can be used when outside

conditions such as smoke, odors, dust, or high

humidity are present. Recirculation can be used in

all modes. Recirculation may be unavailable if

conditions exist that could create fogging on the

inside of the windshield. The A/C can be

deselected manually without disturbing the mode

control selection. Continuous use of Recirculation

mode may make the inside air stuffy and window

fogging may occur. Extended use of this mode if

not recommended. Recirculation mode may

automatically adjust to optimize customer

experience for warming, cooling, dehumidification,

etc.
In cold weather, use of Recirculation mode may

lead to excessive window fogging. The

Recirculation feature may be unavailable if

conditions exist that could create fogging on the

inside of the windshield.

AUTO Button

The AUTO button automatically controls

the interior cabin temperature by

adjusting distribution and amount of

airflow. Air Conditioning (A/C) may be

active during AUTO operation to improve

performance. Performing this function will cause

the system to switch between manual mode and

automatic modes

page 73. AUTO mode is highly

recommended for efficiency.

MAX Defrost Button

Push the MAX Defrost button to change

the current airflow setting to Defrost

mode. The indicator illuminates when

this feature is on. Performing this

function will cause the automatic climate controls

to change to manual mode, and the following

settings will occur:



The blower speed increases to full (all LEDs on)



The rear blower is off



The air conditioning compressor is turned on

(A/C LED off)



Both driver and passenger temperature controls

are set to HI



Defrost mode is selected (LED on)



Rear defroster is turned on (LED on)



The air recirculation is turned off (LED off)

If MAX Defrost mode is turned off, the Climate

Control system will return to the previous setting.

MAX Defrost automatically turns off after

20 minutes.

Rear Defrost Button

Press and release the button on the

touchscreen, or push and release the

button on the faceplate, to turn on the

rear window defroster and the heated

outside mirrors (if equipped). The Rear Defrost

indicator illuminates when the rear window

defroster is on. The rear window defroster

automatically turns off after 10 minutes.

CAUTION!

Failure to follow these cautions can cause

damage to the heating elements:



Use care when washing the inside of the rear

window. Do not use abrasive window cleaners

on the interior surface of the window. Use a

soft cloth and a mild washing solution, wiping

parallel to the heating elements. Labels can

be peeled off after soaking with warm water.



Do not use scrapers, sharp instruments, or

abrasive window cleaners on the interior

surface of the window.



Keep all objects a safe distance from the

window.

GETTING TO KNOW YOUR VEHICLE

Rear Climate Control Button

Press and release this button on the

climate control touchscreen to access

the rear climate controls. The Rear

Climate indicator will illuminate when the

rear climate controls are ON.

Driver And Passenger Temperature

Switches

These switches provide the driver and passenger

with independent temperature control.

Lift the driver’s or passenger’s side

toggle switch on the faceplate upward, or

press and slide the temperature bar

towards the red arrow button on the

touchscreen for warmer temperature settings.

Depress the driver’s or passenger’s side

toggle switch on the faceplate downward,

or press and slide the temperature bar

towards the blue arrow button on the

touchscreen for cooler temperature settings.

SYNC Button

Press the SYNC button on the

touchscreen to toggle the SYNC feature

on/off. The SYNC indicator illuminates

when SYNC is on. SYNC is used to

synchronize the front passenger temperature and

rear passenger temperature, mode, and blower

settings with the driver temperature, mode, and

blower settings. Changing the front passenger

temperature or rear passenger temperature,

mode, and blower settings while in SYNC will

automatically exit this feature.

NOTE:

The SYNC setting is only available on the touch

screen.

Blower Control

Blower Control is used to regulate the

amount of air forced through the Climate

Control system. There are several blower

speeds available.

Blower speed can be controlled by lifting blower

toggle on the instrument panel to increase blower

speed, or depress the toggle for lower blower

speed.

The speed can also be selected using the blower

control buttons on the touchscreen. Use the small

blower icon to reduce the blower setting and the

large blower icon to increase the blower setting.

Blower speed can also be selected by pressing the

blower bar area between the icons on the

touchscreen.

Mode Control

Select Mode by pressing one of the Mode

buttons on the touchscreen, or the

faceplate, to change the airflow

distribution mode. The airflow

distribution mode can be adjusted so air comes

from the instrument panel outlets, floor outlets,

defrost outlets and demist outlets.

Panel Mode

Air comes from the outlets in the

instrument panel. Each of these outlets

can be individually adjusted to direct the

flow of air. The air vanes of the center

outlets and outboard outlets can be moved up and

down or side to side to regulate airflow direction.

There is a shut-off wheel located next to the air

vanes to shut off or adjust the amount of airflow

from these outlets.

GETTING TO KNOW YOUR VEHICLE

Bi-Level Mode

Air comes from the instrument panel

outlets and floor outlets. A slight amount

of air is directed through the defrost and

side window demister outlets.

NOTE:

Bi-Level mode is designed under comfort condi

tions to provide cooler air out of the panel outlets

and warmer air from the floor outlets.
For more information on selecting modes, see

page 70

Floor Mode

Air comes from the floor outlets. A slight

amount of air is directed through the

defrost and side window demister

outlets.

Mix Mode

Air is directed through the floor, defrost,

and side window demister outlets. This

setting works best in cold or snowy

conditions that require extra heat to the

windshield. This setting is good for maintaining

comfort while reducing moisture on the

windshield.

Combine Modes

Dual Level Combination
Front Defrost and Panel Mode
Tri-Level Combination
Front Defrost, Panel Mode, and Floor Mode

Climate Control OFF Button

Press and release this button to turn the

Climate Control ON/OFF.

Controlling The Rear Climate Controls

From The Front ATC Panel

Front ATC Panel Uconnect 5 NAV With 10.1–inch Display

Rear Controls

Front ATC Panel Uconnect 5/5 NAV With 8.4–inch Display

Rear Controls

The driver or front passenger can

combine two or three of the modes

described by selecting them

individually on their side of climate

control screen. Combine modes by

pressing each icon on the

touchscreen.

GETTING TO KNOW YOUR VEHICLE

The Three-Zone and Four-Zone ATC system allows

for adjustment of the rear climate controls from

the front ATC panel.
To change the rear system settings:



Press the “Rear” button on the touchscreen to

display the rear climate controls. The control

functions now operate the rear system.



Press the “Front” button on the touchscreen to

return to the front climate controls.

NOTE:

If equipped with a Four-Zone ATC system, the left

and right sides of the rear passenger zones can be

adjusted separately from the front or rear ATC

panel.

REAR AUTO BUTTON

Press and release this button on the

touchscreen to change the current

setting. The REAR AUTO indicator will

illuminate when REAR AUTO is on. This

feature automatically controls the rear interior

cabin temperature by adjusting airflow distribution

and amount. Toggling this function will cause the

rear system to switch between manual mode and

automatic modes

page 73.

REAR LOCK BUTTON

Press and release this button to lock out

the rear manual temperature controls

from adjusting the rear temperature and

blower settings. The LOCK REAR

indicator will illuminate when LOCK REAR is on.

FRONT CLIMATE BUTTON

Press and release to return to the Front

Climate Control Screen.

SYNC BUTTON

Press the SYNC button on the

touchscreen to toggle the SYNC feature

on/off. The SYNC indicator will illuminate

when SYNC is on. SYNC is used to

synchronize the front passenger temperature and

rear passenger temperature, mode, and blower

settings with the driver temperature, mode, and

blower settings. Changing the front passenger

temperature or rear passenger temperature,

mode, or blower settings while in SYNC will

automatically exit this feature.

NOTE:

The SYNC setting is only available on the

touchscreen.

REAR BLOWER CONTROL

Rear Blower Control is used to regulate

the amount of air forced through the rear

climate system. There are several blower

speeds available. The speeds can be

selected using the buttons on the touchscreen.

Use the small blower icon (or blower icon with the

downward arrow) to reduce the blower setting, and

the large blower icon (or blower icon with the

upward arrow) to increase the blower setting.

Blower can also be selected by pressing the blower

bar area between the icons.

REAR MODE CONTROL

REAR CLIMATE CONTROL OFF BUTTON

To manually set the rear blower controls

to off, press the Rear Climate Control/

Blower Off button.

The rear airflow distribution modes

can be adjusted so air comes from

the headliner outlets, the floor

outlets, or both. Select the arrow

icons individually on the front climate

control screen. Combine modes by

pressing both icons.

GETTING TO KNOW YOUR VEHICLE

Rear Automatic Temperature Control

Rear Automatic Climate Controls

The rear ATC system has floor air outlets at the rear

right side of the third row seats and overhead

outlets at each outboard rear seating position. The

system provides heated air through the floor

outlets or cool, dehumidified air through the

headliner outlets.
The rear system temperature control buttons are

located on rear of the front center console.

NOTE:

If equipped with a Four-Zone ATC system, the left

and right sides of the rear passenger zones can be

adjusted separately from the front or rear ATC

panel.

AUTO BUTTON

The AUTO button automatically controls

the interior cabin temperature by

adjusting distribution and amount of

airflow. Performing this function will

cause the system to switch between manual mode

and automatic modes

page 73.

REAR TEMPERATURE CONTROL

These buttons provide the left and right side of the

rear seating area with independent temperature

control.

Push the Up button on the faceplate for

warmer temperature settings.

Push the Down button on the faceplate

for cooler temperature settings.

REAR BLOWER CONTROL

Use the blower button with the “down”

arrow to reduce the blower setting, and

the blower button with the “up” arrow to

increase the blower setting. The rear

blower setting is shown in the display.

REAR MODE CONTROL

Push the rear mode button to adjust

airflow distribution. The rear mode

settings are shown in the rear display.

The rear airflow distribution mode can be

adjusted so air comes from the headliner outlets,

the floor outlets, or both.

PANEL MODE

Air comes from the outlets in the

headliner. Each of these outlets can be

individually adjusted to direct the flow of

air. Moving the air vanes of the outlets to

one side will shut off the airflow.

BI-LEVEL MODE

Air comes from both the headliner outlets

and the floor outlets.

NOTE:

In many temperature positions, the Bi-Level mode

is designed to provide cooler air out of the head

liner outlets and warmer air from the floor outlets.

FLOOR MODE

Air comes from the floor outlets.

GETTING TO KNOW YOUR VEHICLE

REAR TEMPERATURE LOCK

The Rear Temperature Lock symbol on

the rear display is illuminated when the

rear controls are locked by the front

system.

Rear Lock

Pressing the Rear Temperature Lock button on the

Uconnect touchscreen will illuminate a lock symbol

in the rear display. The rear temperature and air

source are then controlled from the front Uconnect

system.
Rear seat occupants can only adjust the rear ATC

control when the Rear Temperature Lock button is

turned off.
The rear ATC is located on the rear of the front

center console.



Press the Rear Temperature Lock button on the

front Uconnect touchscreen a second time to

turn the Rear Temperature Lock icon off in the

rear display.



Push a rear blower button, adjust the tempera

ture using the rear up and down arrows, and

select a control mode to suit the rear occupant’s

needs.



ATC is selected by pushing the AUTO button on

the rear climate control faceplate.

Once the desired temperature is shown on the rear

display, the ATC System will automatically achieve

and maintain that comfort level. When the system

is set up for your comfort level, it is not necessary

to change the settings. You will experience the

greatest efficiency by simply allowing the system to

function automatically.

UTOMATIC

EMPERATURE

ONTROL

(ATC)

Automatic Operation

1. Push the AUTO button on the front Automatic

Temperature Control (ATC) Panel and the

word “AUTO” will illuminate in the front ATC

display, along with two temperatures for the

driver and front passenger. The system will

then automatically regulate the amount of

airflow.

2. Adjust the temperature you would like the

system to maintain, by adjusting the driver,

passenger, and rear temperatures. Once the

desired temperature is displayed, the system

will achieve and automatically maintain that

comfort level.

3. When the system is set up for your comfort

level, it is not necessary to change the

settings. You will experience the greatest

efficiency by simply allowing the system to

function automatically.

NOTE:

It is not necessary to move the temperature

settings. The system automatically adjusts the

temperature, mode and fan speed to provide

comfort as quickly as possible.
To provide you with maximum comfort in the

automatic mode, during cold start-ups, the blower

fan will remain on low until the engine warms up.

The fan will engage immediately if the Defrost

mode is selected, or by changing the front blower

knob setting.

Manual Operation Override

This system offers a full complement of manual

override features. The AUTO symbol in the front

ATC display will be turned off when the system is

being used in the manual mode.

NOTE:

The system will not automatically sense the

presence of fog, mist or ice on the windshield.

Defrost mode must be manually selected to clear

the windshield and side glass.

GETTING TO KNOW YOUR VEHICLE

LIMATE

OICE

ECOGNITION

Adjust vehicle temperatures hands-free and keep

everyone comfortable while you keep moving

ahead (if vehicle is equipped with climate

controls).
Push the VR button. After the beep, say one of the

following commands:



“Set the driver temperature to 70 degrees”



“Set the passenger temperature to 70 degrees”

Did You Know: Voice Command for Climate may

only be used to adjust the interior temperature of

your vehicle. Voice Command will not work to

adjust the heated seats or steering wheel if

equipped.

PERATING

IPS

NOTE:

Refer to the chart at the end of this section for

suggested control settings for various weather

conditions.

Summer Operation

The engine cooling system must be protected with

a high-quality antifreeze coolant to provide proper

corrosion protection and to protect against engine

overheating. OAT coolant (conforming to

MS.90032) is recommended. For more

information, see

page 405.

Winter Operation

To ensure the best possible heater and defroster

performance, make sure the engine cooling

system is functioning properly and the proper

amount, type, and concentration of coolant is

used. Use of the Air Recirculation mode during

Winter months is not recommended, because it

may cause window fogging.

Vacation/Storage

For information on maintaining the Climate Control

system when the vehicle is being stored for an

extended period of time, see

page 396.

Window Fogging

Vehicle windows tend to fog on the inside in mild,

rainy, and/or humid weather. To clear the

windows, select Defrost or Mix mode and increase

the front blower speed. Do not use the

Recirculation mode without A/C for long periods,

as fogging may occur.

Outside Air Intake

Make sure the air intake, located directly in front of

the windshield, is free of obstructions, such as

leaves. Leaves collected in the air intake may

reduce airflow, and if they enter the air distribution

box, they could plug the water drains. In Winter

months, make sure the air intake is clear of ice,

slush, and snow.

Cabin Air Filter

The Climate Control system filters out dust and

pollen from the air. Contact an authorized dealer to

service your cabin air filter, and to have it replaced

when needed.

Stop/Start System — If Equipped

While in an Autostop, the Climate Control system

may automatically adjust airflow to maintain cabin

comfort. Customer settings will be maintained

upon return to an engine running condition.

CAUTION!

Interior air enters the Rear Automatic

Temperature Control system through an intake

grille, located in the right side trim panel behind

the third row seats. The heater outlets are

located in the right side trim panel, just behind

the rear doors. Do not block or place objects

directly in front of the inlet grille or heater

outlets. The electrical system could overload

causing damage to the blower motor.

GETTING TO KNOW YOUR VEHICLE

Windshield Wiper De-Icer — If Equipped

The Windshield Wiper De-Icer is a heating element

located at the base of the windshield.
It operates automatically once the following

conditions are met:



Activation By Front Defrost

The Windshield Wiper De-Icer activates auto

matically during a cold weather manual start

with full defrost, and when the ambient

temperature is below 33°F (0.6°C).



Activation By Rear Defrost

The Windshield Wiper De-Icer activates auto

matically when the Rear Defrost is operating

and the ambient temperature is below 33°F

(0.6°C).



Activation By Remote Start Operation

When the Remote Start is activated and the

outside ambient temperature is less than 33°F

(0.6°C) the Windshield Wiper De-Icer will acti

vate. Exiting Remote Start will resume its

previous operation. If the Windshield Wiper

De-Icer was active, the timer and operation will

continue.

Operating Tips Chart

INTERIOR STORAGE AND EQUIPMENT

TORAGE

Glove Compartment

The glove compartment is located on the

passenger side of the instrument panel.

Glove Compartment Release Handle

To open the glove compartment, pull the release

handle.

WEATHER

CONTROL SETTINGS

Hot Weather And

Vehicle Interior Is Very

Hot

Set the mode control to

(Panel Mode),

(MAX A/C) on, and

blower on high. Roll

down the windows for a

minute to flush out the

hot air. Adjust the

controls as needed to

achieve comfort.

Warm Weather

Turn (A/C) on and

set the mode control to

(Panel Mode).

Cool Sunny

Operate in (Bi-Level

Mode).

Cool & Humid

Conditions

Set the mode control to

(Floor Mode) and

turn (A/C) on to

keep windows clear.

Cold Weather

Set the mode control to

(Floor Mode). If

windshield fogging

starts to occur, move

the control to (Mix

Mode).

Jeep Grand Cherokee (2022 year). Manual in english - page 4
