GETTING TO KNOW YOUR VEHICLE

OWER

OOR

OCKS

The power door lock buttons are located on each

front door panel. Push the lock button to lock all

doors and liftgate, or the unlock button to unlock

all doors and liftgate.
When the doors are locked, an indicator light in the

lock button will illuminate.

Power Door Lock Switches

The driver’s door will unlock automatically if the

keys are detected inside the vehicle when the door

lock button on the front door panel is used to lock

the door, then the door is closed. The horn will also

chirp to alert the driver. This will occur for two

attempts. On the third attempt, the doors will lock

even if the key is inside.

NOTE:

If the key fob is located next to a mobile phone,

laptop, or other electronic device, the wireless

signal may get blocked, and the driver’s door may

not unlock automatically.
If the door lock button is pushed while the ignition

is in the ON/RUN position and the driver's door is

open, the doors will not lock.

Rear Passenger Power Door Locks
Power door lock buttons are located on each rear

door trim panel. Push the lock button to lock all

doors and liftgate, and the unlock button to unlock

all doors and liftgate.

EYLESS

NTER

‘

™ — P

ASSIVE

NTRY

The Passive Entry system is an enhancement to

the vehicle’s Remote Keyless Entry (RKE) system

and a feature of Keyless Enter ‘n Go™. This feature

allows you to lock and unlock the vehicle’s door(s)

without having to push the key fob lock or unlock

buttons.
If equipped, the rear doors will also have Passive

Entry capabilities.

NOTE:



Passive Entry may be programmed on/off

through Uconnect Settings

page 204.



The key fob may not be detected by the vehicle

Passive Entry system if it is located next to a

mobile phone, laptop or other electronic device;

these devices may block the key fob's wireless

signal and prevent the Passive Entry handle

from locking/unlocking the vehicle.



Never leave children alone in a vehicle, or with

access to an unlocked vehicle. Allowing chil

dren to be in a vehicle unattended is

dangerous for a number of reasons. A child or

others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the gear

selector.



Do not leave the key fob in or near the vehicle,

or in a location accessible to children, and do

not leave the Keyless Enter ‘n Go™ Ignition in

the ON/RUN position. A child could operate

power windows, other controls, or move the

vehicle.

WARNING!

GETTING TO KNOW YOUR VEHICLE



Passive Entry unlock initiates illuminated

approach (low beams, license plate lamp,

parking lights, door handle pocket lights [if

equipped]) for whichever time duration is set

between 0, 30, 60 or 90 seconds. Passive Entry

unlock also initiates two flashes of the turn

signal lamps.



If wearing gloves, or if it has been raining/

snowing on the Passive Entry door handle, the

unlock and lock sensitivity can be affected,

resulting in a slower response time.



The doors may lock and unlock when water is

sprayed on the Passive Entry door handles, if

the key fob is located outside of the vehicle

within 5 ft (1.5 m) of the handle.



Passive Entry lock initiates one horn chirp and

one flash of turn signal lights. These settings

can be programmed on/off within Uconnect

Settings

page 204.



If the vehicle is unlocked by Passive Entry and

no door is opened within 60 seconds, the

vehicle will relock and will rearm the Vehicle

Security system (if equipped).

To Unlock From The Driver Or Passenger Side
With a valid Passive Entry key fob within 5 ft

(1.5 m) of the door handle, grab the handle to

unlock the vehicle. Grabbing the driver’s door

handle will unlock the driver door automatically.

Grabbing the front passenger door handle (or a

rear handle when equipped with four-door Passive

Entry) will unlock all doors and the liftgate

automatically.

Grab The Door Handle To Unlock

NOTE:



Either the driver door only or all doors will unlock

when you grab hold of the front driver’s door

handle, depending on the selected setting in the

Uconnect system

page 204.



All doors will unlock when the front passenger

(or a rear door when equipped with four-door

Passive Entry) door handle is grabbed regard

less of the driver’s door unlock preference

setting.

Frequency Operated Button Integrated Key

(FOBIK-Safe)
To minimize the possibility of unintentionally

locking a Passive Entry key fob inside your vehicle,

the Passive Entry system is equipped with an

automatic door unlock feature which will function if

the ignition switch is in the OFF position.
There are five situations that trigger a FOBIK-Safe

search in any Passive Entry vehicle:



A lock request is made by a valid Passive Entry

key fob while a door is open.



A lock request is made by the Passive Entry door

handle while a door is open.



A lock request is made by the door panel switch

while the door is open.



When the Vehicle Security system is in pre-arm

or armed status and the liftgate transitions from

opened to closed.



When the liftgate transitions from open to

closed and Remote Start is active.

GETTING TO KNOW YOUR VEHICLE

When any of these situations occur, after all open

doors are shut, the FOBIK-Safe search will be

executed. If it detects a Passive Entry key fob

inside the vehicle, the vehicle will unlock and alert

the customer.

NOTE:

The vehicle will only unlock the doors when a valid

Passive Entry key fob is detected inside the

vehicle. The vehicle will not unlock the doors when

any of the following conditions are true:



The doors are manually locked using the emer

gency lock lever.



Three attempts are made to lock the doors

using the door panel switch and then the doors

are closed.



There is a valid Passive Entry key fob outside the

vehicle within 5 ft (1.5 m) of a Passive Entry

door handle.

To Lock The Vehicle’s Doors And Liftgate
With one of the vehicle’s Passive Entry key fobs

within 5 ft (1.5 m) of a Passive Entry door handle,

touch the lock icon on the door handle to lock all

four doors and liftgate.

Touch The Door Handle Lock Icon To Lock

NOTE:

Do NOT grab the door handle when touching the

lock icon. This could unlock the door(s).

Do NOT Grab The Door Handle When Locking

NOTE:



After touching the door handle lock icon, you

must wait two seconds before you can lock or

unlock the doors using any Passive Entry door

handle. This is done to allow you to check if the

vehicle is locked by pulling the door handle,

without the vehicle unlocking.



If Passive Entry is disabled using the Uconnect

Settings, the key protection described in

"Frequency Operated Button Integrated Key

(FOBIK-Safe)" remains active/functional.



The Passive Entry system will not operate if the

key fob battery is depleted.

To Unlock/Enter The Liftgate
The liftgate Passive Entry unlock feature is built

into the electronic liftgate release button. With a

valid Passive Entry key fob within 5 ft (1.5 m) of the

liftgate, push the electronic liftgate release button

for a power open on vehicles equipped with Power

Liftgate. Pull the electronic liftgate handle and lift

for Manual Liftgate vehicles.

GETTING TO KNOW YOUR VEHICLE

Electronic Liftgate Handle

To Lock The Liftgate
With a valid Passive Entry key fob within 5 ft

(1.5 m) of the liftgate, push the Passive Entry lock

button located on the outside liftgate door handle.

NOTE:

The liftgate Passive Entry lock button will lock all

doors and the liftgate

page 410.

UTOMATIC

NLOCK

OORS

XIT

The doors will unlock automatically on vehicles

with power door locks after the following sequence

of actions:
1. The Automatic Unlock Doors On Exit feature is

enabled within Uconnect Settings

page 204.

2. All doors are closed.
3. The gear selector was not in PARK, then is

placed in PARK.

4. Any door is opened.

UTOMATIC

OOR

OCKS

—

QUIPPED

The auto door lock feature default condition is

enabled. When enabled, the door locks will lock

automatically when the vehicle's speed exceeds

15 mph (24 km/h). The auto door lock feature is

enabled or disabled by an authorized dealer per

written request of the customer. Please see an

authorized dealer for service.

HILD

-P

ROTECTION

OOR

OCK

YSTEM

— R

EAR

OORS

To provide a safer environment for small children

riding in the rear seats, the rear doors are

equipped with a Child-Protection Door Lock

system.
To use the system, open each rear door, use a flat

blade screwdriver (or emergency key) and rotate

the dial to the lock or unlock position. When the

system on a door is engaged, that door can only be

opened by using the outside door handle even if

the inside door lock is in the unlocked position.

Child-Protection Door Lock Function

1 — Passive Entry Lock Button
2 — Electronic Liftgate Release Button

GETTING TO KNOW YOUR VEHICLE

NOTE:



When the Child-Protection Door Lock system is

engaged, the door can be opened only by using

the outside door handle even though the inside

door lock is in the unlocked position.



After disengaging the Child-Protection Door

Lock system, always test the door from the

inside to make certain it is in the unlocked

position.



After engaging the Child-Protection Door Lock

system, always test the door from the inside to

make certain it is in the locked position.

NOTE:

Always use this device when carrying children.

After engaging the child lock on both rear doors,

check for effective engagement by trying to open a

door with the internal handle. Once the

Child-Protection Door Lock system is engaged, it is

impossible to open the doors from inside the

vehicle. Before getting out of the vehicle, be sure to

check that there is no one left inside.

STEERING WHEEL

ANUAL

ILT

ELESCOPING

TEERING

OLUMN

— I

QUIPPED

This feature allows you to tilt the steering column

upward or downward. It also allows you to lengthen

or shorten the steering column. The tilt/

telescoping lever is located below the steering

wheel at the end of the steering column.

Manual Tilt/Telescoping Steering Column Handle

To unlock the steering column, push the lever

downward (toward the floor). To tilt the steering

column, move the steering wheel upward or

downward as desired. To lengthen or shorten the

steering column, pull the steering wheel outward

or push it inward as desired. To lock the steering

column in position, push the lever upward until

fully engaged.

OWER

ILT

ELESCOPING

TEERING

OLUMN

— I

QUIPPED

This feature allows you to tilt the steering column

upward or downward. It also allows you to lengthen

or shorten the steering column. The power tilt/

telescoping steering column lever is located below

the multifunction lever on the steering column.

Power Tilt/Telescoping Steering Control Location

WARNING!

Avoid trapping anyone in a vehicle in a collision.

Remember that the rear doors can only be

opened from the outside with the

Child-Protection locks engaged (locked).

WARNING!

Do not adjust the steering column while driving.

Adjusting the steering column while driving or

driving with the steering column unlocked, could

cause the driver to lose control of the vehicle.

Failure to follow this warning may result in

serious injury or death.

GETTING TO KNOW YOUR VEHICLE

Use the four-way control to adjust the steering

column.

NOTE:

For vehicles equipped with Driver Memory

Settings, you can use your key fob or the memory

switch on the driver's door trim panel to return the

tilt/telescopic steering column to saved positions

page 34.

EATED

TEERING

HEEL

—

QUIPPED

The steering wheel contains a heating

element that helps warm your hands in

cold weather. The heated steering wheel

has only one temperature setting. Once

the heated steering wheel has been turned on, it

will stay on until the operator turns it off. The

heated steering wheel may not turn on when it is

already warm.

The heated steering wheel button is located on the

center of the instrument panel below the radio

screen, and within the climate or controls screen of

the touchscreen.



Push the heated steering wheel button once to

turn the heating element on.



Push the heated steering wheel button a second

time to turn the heating element off.

NOTE:

The engine must be running for the heated

steering wheel to operate.
For information on use with the Remote Start

system, see

page 25.

UCONNECT VOICE RECOGNITION

QUICK TIPS — IF EQUIPPED

NTRODUCING

OICE

ECOGNITION

Start using Uconnect Voice Recognition with these

helpful quick tips. It provides the key Voice

Commands and tips you need to know to control

your vehicle’s Voice Recognition (VR) system.

ASIC

OICE

OMMANDS

The basic Voice Commands below can be given at

any point while using your Uconnect system.
Push the VR button or say the vehicle’s Wake

Up word, “Hey Uconnect” or “Hey Jeep®”. The

factory default Wake Up word is set to “Hey

Uconnect” and can be reprogrammed through the

Uconnect Settings. After the beep, say:



“Cancel” to stop a current voice session.



“Help” to hear a list of suggested Voice

Commands.



“Repeat” to listen to the system prompts again.

Notice the visual cues that inform you of your Voice

Recognition system’s status.

WARNING!

Do not adjust the steering column while driving.

Adjusting the steering column while driving or

driving with the steering column unlocked, could

cause the driver to lose control of the vehicle.

Failure to follow this warning may result in

serious injury or death.

WARNING!



Persons who are unable to feel pain to the

skin because of advanced age, chronic illness,

diabetes, spinal cord injury, medication,

alcohol use, exhaustion, or other physical

conditions must exercise care when using the

steering wheel heater. It may cause burns

even at low temperatures, especially if used

for long periods.



Do not place anything on the steering wheel

that insulates against heat, such as a blanket

or steering wheel covers of any type and mate

rial. This may cause the steering wheel heater

to overheat.

GETTING TO KNOW YOUR VEHICLE

TARTED

The VR button is used to activate/deactivate

your Voice Recognition system. You can also use

the system’s “Wake Up” word to activate voice

recognition. The “Wake Up” word can be set

through the Uconnect Settings

page 204.

Helpful hints for using Voice Recognition:



Reduce background noise. Wind noise and

passenger conversations are examples of noise

that may impact recognition.



Speak clearly at a normal pace and volume

while facing straight ahead.



Each time you give a Voice Command, first push
the VR button or say the “Wake Up” word,

wait until after the beep, then say your Voice

Command.



You can interrupt the help message or system

prompts by pushing the VR button and saying a

Voice Command from the current category.



You can also interrupt the help message or

system prompts by speaking. This feature is

called “barge-in” and can be set through the

Uconnect Settings

page 204.

Uconnect Voice Command Buttons

DDITIONAL

NFORMATION

Uconnect are registered trademarks and Mopar

Owner Connect is a trademark of FCA US LLC.

SiriusXM® and all related marks and logos are

trademarks of SiriusXM® Radio Inc.

page 410.

For Uconnect system support, call

1-877-855-8400 (24 hours a day 7 days a week)

or visit

DriveUconnect.com

(US) or

DriveUconnect.ca

(Canada).

DRIVER AND PASSENGER MEMORY

SETTINGS — IF EQUIPPED

This feature allows the driver, and if equipped, also

the front passenger to save up to two different

memory profiles for easy recall through a memory

switch. Each memory profile saves desired position

settings for the following features:
Driver’s Side



Seat position



Easy Entry/Exit seat (if equipped)



Side mirrors



Power tilt and telescopic steering column

(if equipped)



A set of desired radio station presets

1 — For Vehicles Equipped With Navigation: Push

The Voice Recognition Button To Begin Radio, Me

dia, Navigation, Climate, Start Or Answer A Phone

Call, And Send Or Receive A Text

1 — For Vehicles Not Equipped With Navigation:

Push The Phone Button To Answer An Incoming

Phone Call
2 — Push To Access Tile Mode On The Instrument

Cluster
3 — Push The Hang Up Button To End A Call

Currently In Progress

GETTING TO KNOW YOUR VEHICLE

Passenger’s Side (If Equipped)



Seat Position

The memory settings switches are located on the

front door panels, next to the door handle, and

consists of three buttons:



The set (S) button, which is used to activate the

memory save function.



The (1) and (2) buttons which are used to recall

either of two saved memory profiles.

Memory Setting Buttons

NOTE:



Your vehicle is equipped with two key fobs, each

can be linked to either driver’s side memory

position 1 or 2.



Front passenger memory settings cannot be

linked to a key fob.

ROGRAMMING

EMORY

EATURE

To create a new memory profile, perform the

following:

NOTE:

Saving a new memory profile will erase the

selected profile from memory.
1. Place the vehicle’s ignition in the ON/RUN

position (do not start the engine).

2. Adjust all memory profile settings to desired

preferences (i.e., seat, side mirror, power

tilt/telescopic steering column [if equipped],

and radio station presets).

3. Push and release the set (S) button on the

memory switch.

4. Within five seconds, push and release either of

the memory buttons (1) or (2). The instrument

cluster display will indicate which memory

position has been set.

NOTE:

Memory profiles can be set without the vehicle

in PARK, but the vehicle must be below 5 mph

(8 km/h) to recall a memory profile.

INKING

NLINKING

EMORY

Your key fobs can be programmed to recall one of

two saved driver’s side memory profiles.

NOTE:

Before programming your key fobs you must select

the “Personal Settings Linked To Key Fob” feature

through the Uconnect Settings

page 204.

To program your key fobs, perform the following:
1. Place the vehicle’s ignition in the OFF

position.

2. Select a desired driver’s side memory profile,

1 or 2.

3. Once the profile has been recalled, push and

release the set (S) button on the memory

switch.

4. Within five seconds, push and release button

(1) or (2) accordingly. “Memory Profile Set”

(1 or 2) will display in the instrument cluster.

5. Push and release the lock button on the key

fob within 10 seconds.

NOTE:

Your key fobs can be unlinked from your driver’s

side memory settings by pushing the set (S) button,

and within 10 seconds, pushing the unlock button

on the key fob.

GETTING TO KNOW YOUR VEHICLE

(Continued)

EMORY

OSITION

ECALL

NOTE:

Memory Recall is available when not in PARK, if the

vehicle speed is below 5 mph (8 km/h).



To recall a memory settings profile using the

memory switches, push memory button (1) or

(2) on the memory switch.



To recall the driver’s side memory settings using

the key fob, push the unlock button on the key

fob linked to memory position 1 or 2.

A recall can be canceled by pushing any of the

memory buttons during a recall (S, 1, or 2), or by

pushing any of the seat adjustment switches.

When a recall is canceled, the seat and power tilt/

telescopic steering column (if equipped) will stop

moving. A delay of one second will occur before

another recall can be selected.

SEATS

Seats are a part of the Occupant Restraint system

of the vehicle.

ANUAL

DJUSTMENT

RONT

EATS

) — I

QUIPPED

Manual Front Passenger Seat Forward/

Rearward Adjustment

Some models may be equipped with a manual

front passenger seat. The passenger seat can be

adjusted forward or rearward by using a bar

located by the front of the seat cushion, near the

floor.

Adjustment Bar

WARNING!



It is dangerous to ride in a cargo area, inside

or outside of a vehicle. In a collision, people

riding in these areas are more likely to be seri

ously injured or killed.



Do not allow people to ride in any area of your

vehicle that is not equipped with seats and

seat belts. In a collision, people riding in these

areas are more likely to be seriously injured or

killed.



Be sure everyone in your vehicle is in a seat

and using a seat belt properly.

WARNING!



Adjusting a seat while the vehicle is moving is

dangerous. The sudden movement of the seat

could cause you to lose control. The seat belt

might not be adjusted properly and you could

be injured. Adjust the seat only while the

vehicle is parked.



Do not ride with the seatback reclined so that

the shoulder belt is no longer resting against

your chest. In a collision you could slide under

the seat belt and be seriously or even fatally

injured. Use the recliner only when the vehicle

is parked.

WARNING!

GETTING TO KNOW YOUR VEHICLE

While sitting in the seat, lift up on the bar located

under the seat cushion and move the seat forward

or rearward. Release the bar once you have

reached the desired position. Then, using body

pressure, move forward and rearward on the seat

to be sure that the seat adjusters have latched.

Manual Front Passenger Seatback

Adjustment — Recline

To recline, lean forward slightly and lift the lever

located on the outboard side of the seat. Then,

push the seat rearward to the desired position and

release the lever. To return the seatback to its

normal position, lean forward and lift the lever. To

ensure the seatback is latched, use body pressure

to lean forward and rearward.

Recline Lever

ANUAL

DJUSTMENT

EAR

EATS

)

Vehicles equipped with third row seating may have

a second row bench seat, or second row captain’s

chairs. Vehicles equipped with only second row

seating, will have a second row bench seat.

NOTE:

You may experience deformation in the seat

cushion from the seat belt buckles if the seats are

left folded for an extended period of time. This is

normal and by simply unfolding the seats to the

open position, over time the seat cushion will

return to its normal shape.

WARNING!



Adjusting a seat while driving may be

dangerous. Moving a seat while driving could

result in loss of control which could cause a

collision and serious injury or death.



Seats should be adjusted before fastening the

seat belts and while the vehicle is parked.

Serious injury or death could result from a

poorly adjusted seat belt.

WARNING!

Do not ride with the seatback reclined so that

the shoulder belt is no longer resting against

your chest. In a collision you could slide under

the seat belt, which could result in serious injury

or death.

WARNING!

Do not pile luggage or cargo higher than the top

of the seatback. This could impair visibility or

become a dangerous projectile in a sudden stop

or collision.

GETTING TO KNOW YOUR VEHICLE

Second Row Bench Seat — If Equipped

SECOND ROW BENCH SEAT FORWARD/REAR

WARD ADJUSTMENT — IF EQUIPPED

Lift up on the adjusting bar located at the front of

the seat near the floor and release it when the seat

is at the desired position. Then, using body

pressure, move forward and rearward on the seat

to be sure that the seat adjusters have latched.

Rear Seat Adjustment Bar

SECOND ROW BENCH SEAT RECLINE ADJUST

MENT

To recline, lean forward slightly and lift the lever

located on the outboard side of the seat. Then,

push the seat rearward to the desired position and

release the lever.

To return the seatback to its normal position, lean

forward and lift the lever. To ensure the seatback

is latched, use body pressure to lean forward and

rearward.

Rear Seat Recline Lever

SECOND ROW BENCH FOLD FLAT SEAT

To provide additional storage area, each rear seat

can be folded flat. This allows for extended cargo

space and still maintains some rear seating room.

NOTE:

Prior to folding the rear seat, it may be necessary

to position the front seat to its mid-track position.

Also, be sure that the front seats are fully upright

and positioned forward. This will allow the rear seat

to fold down easily.
To lower the seatback, pull upward on the recline

lever located on the outboard side of the seat, and

let the seatback fold forward automatically.

Second Row Bench Seat Folded Flat

To raise the seatback, fold the seatback up into its

original position and lock it into place.

WARNING!

Do not ride with the seatback reclined so that

the shoulder belt is no longer resting against

your chest. In a collision you could slide under

the seat belt, which could result in serious injury

or death.

GETTING TO KNOW YOUR VEHICLE

SECOND ROW BENCH SEAT EASY ACCESS FOR

THIRD ROW — IF EQUIPPED

If the vehicle is equipped with third row seating, the

second row seats can tip forward to allow

passengers to easily access the third row seats.
Pull upward on the easy entry lever located on the

outboard side of the seatback, then tip and slide

the entire seat forward.

Easy Entry Lever Location

Access To Third Row Seats

To return the seat to a sitting position, unfold the

seatback upright until it locks and push the seat

rearward until the track locks.

Second Row Captain’s Chairs —

If Equipped

Vehicles equipped with third row seating may be

equipped with second row captain’s chairs.

SECOND ROW CAPTAIN’S CHAIRS FORWARD/

REARWARD ADJUSTMENT

Lift up on the adjusting bar located at the front of

the seat near the floor and release it when the seat

is at the desired position. Then, using body

pressure, move forward and rearward on the seat

to be sure that the seat adjusters have latched.

Rear Seat Adjustment Bar

WARNING!

Be certain that the seatback is securely locked

into position. If the seatback is not securely

locked into position the seat will not provide the

proper stability for child seats and/or

passengers. An improperly latched seat could

cause serious injury.

GETTING TO KNOW YOUR VEHICLE

SECOND ROW CAPTAIN’S CHAIRS RECLINE

ADJUSTMENT

To recline, lean forward slightly and lift the lever

located on the outboard side of the seat. Then,

push the seat rearward to the desired position and

release the lever. To return the seatback to its

normal position, lean forward and lift the lever. To

ensure the seatback is latched, use body pressure

to lean forward and rearward.

Rear Seat Recline Lever

SECOND ROW CAPTAIN’S CHAIRS FOLD FLAT

SEATS

The second row seatbacks can be folded flat to

carry cargo.
Pull upward on the recline lever located on the

outboard side of each second row seat, and guide

the seatback down into the folded position.

Second Row Captain’s Chairs Folded Flat

To Raise The Rear Seats
Fold the seatbacks upward to their original

position, and lock them into place.

SECOND ROW CAPTAIN’S CHAIR EASY ACCESS

FOR THIRD ROW

The second row seats can tip forward to allow

passengers to easily access the third row seats.
Pull upward on the easy entry lever located on the

outboard side of the seatback, then tip and slide

the entire seat forward.

WARNING!

Do not ride with the seatback reclined so that

the shoulder belt is no longer resting against

your chest. In a collision you could slide under

the seat belt, which could result in serious injury

or death.

WARNING!

Be certain that the seatback is securely locked

into position. If the seatback is not securely

locked into position the seat will not provide the

proper stability for child seats and/or

passengers. An improperly latched seat could

cause serious injury.

GETTING TO KNOW YOUR VEHICLE

Easy Entry Lever Location

Access To Third Row Seats

To return the seat to a sitting position, unfold the

seatback upright until it locks and push the seat

rearward until the track locks.

Manual Folding Third Row — If Equipped

Both third row seats can be folded forward to

increase the cargo area. To lower either seat, pull

on the release handle located on the back of the

seat and lower the seat using the pull strap located

next to the release handle.

NOTE:

The second row seats must be in their full upright

position or folded flat when folding the third row

seats.

Release Handles

Third Row Folded

To raise the seat, pull the seat toward you using

the strap located on the back of the seat.

WARNING!

Be certain that the seatback is securely locked

into position. If the seatback is not securely

locked into position the seat will not provide the

proper stability for child seats and/or

passengers. An improperly latched seat could

cause serious injury.

GETTING TO KNOW YOUR VEHICLE

OWER

DJUSTMENT

RONT

EATS

) —

QUIPPED

Some models may be equipped with 12-way power

driver and front passenger seats. The power seat

switches are located on the outboard side of the

seat. There are three switches that control the

movement of the seat cushion and the seatback.

Power Seat Switches

Adjusting The Seat Forward Or Rearward

The seat can be adjusted both forward and

rearward. Push the seat switch forward or

rearward. The seat will move in the direction of the

switch. Release the switch when the desired

position has been reached.

Adjusting The Seat Up Or Down

The height of the seats can be adjusted up or

down. Pull upward or push downward on the rear of

seat switch, the seat will move in the direction of

the switch. Release the switch when the desired

position has been reached.

Tilting The Seat Up Or Down

The angle of the seat cushion can be adjusted in

two directions. Pull upward or push downward on

the front of the seat switch, the front of the seat

cushion will move in the direction of the switch.

Release the switch when the desired position has

been reached.

Reclining The Seatback

The angle of the seatback can be adjusted forward

or rearward. Push the seatback switch forward or

rearward, the seat will move in the direction of the

switch. Release the switch when the desired

position is reached.

1 — Cushion Extender Switch
2 — Seat Switch
3 — Seatback And Bolster Adjustment Switch

WARNING!



Adjusting a seat while driving may be

dangerous. Moving a seat while driving could

result in loss of control which could cause a

collision and serious injury or death.



Seats should be adjusted before fastening the

seat belts and while the vehicle is parked.

Serious injury or death could result from a

poorly adjusted seat belt.



Do not ride with the seatback reclined so that

the shoulder belt is no longer resting against

your chest. In a collision you could slide under

the seat belt, which could result in serious

injury or death.

CAUTION!

Do not place any article under a power seat or

impede its ability to move as it may cause

damage to the seat controls. Seat travel may

become limited if movement is stopped by an

obstruction in the seat's path.

GETTING TO KNOW YOUR VEHICLE

Seatback Bolster Adjustment

The front driver and passenger seatback bolsters

can be extended outward, or retracted inward by

pushing the bolster adjustment button located in

the center of the seatback switch.
Push the top of the button to extend the bolsters,

or push the bottom of the button to retract the

bolsters.

Seatback Bolster Adjustment Button

Cushion Extender

The cushion can be extended forward a few inches

(centimeters) to increase thigh support. Push the

cushion extender switch forward or rearward to

extend or retract the cushion. Release the switch

when the desired position has been reached.

Power Lumbar — If Equipped

Vehicles equipped with power driver or passenger

seats may also be equipped with power lumbar.

The power lumbar switch is located on the

outboard side of the power seat. Push the switch

forward to increase the lumbar support. Push the

switch rearward to decrease the lumbar support.

Pushing upward or downward on the switch will

raise and lower the position of the support.

Power Lumbar Switch

Easy Entry/Exit Seat — If Equipped

This feature provides automatic driver seat

positioning to enhance driver mobility when

entering and exiting the vehicle.
The distance the driver seat moves depends on

where you have the driver seat positioned when

you place the vehicle’s ignition in the OFF position.



When you place the vehicle’s ignition in the OFF

position, the driver seat will move about

2.4 inches (6 cm) rearward if the driver seat

position is greater than or equal to 2.7 inches

(6.8 cm) forward of the rear stop. The seat will

return to its previously set position when you

place the vehicle’s ignition in the ON/RUN posi

tion.



The Easy Entry/Easy Exit feature is disabled

when the driver seat position is less than 0.9 of

an inch (2.3 cm) forward of the rear stop. At this

position, there is no benefit to the driver by

moving the seat for Easy Exit or Easy Entry.

When enabled in Uconnect Settings, Easy Entry

and Easy Exit positions are stored in each memory

setting profile

page 34.

NOTE:

The Easy Entry/Exit feature is enabled or disabled

within the Uconnect system

page 204.

1 — Extend Seatback Bolsters
2 — Retract Seatback Bolsters

Jeep Grand Cherokee (2022 year). Manual in english - page 2
