GETTING TO KNOW YOUR INSTRUMENT PANEL

139

The light also will turn on when the parking brake

is applied with the ignition switch in the ON/RUN

position.

NOTE:

This light shows only that the parking brake is

applied. It does not show the degree of brake appli

cation.

Battery Charge Warning Light

This warning light will illuminate when the

battery is not charging properly. If it stays

on while the engine is running, there may

be a malfunction with the charging

system. Contact an authorized dealer as soon as

possible.
This indicates a possible problem with the

electrical system or a related component.

Door Open Warning Light

This indicator will illuminate when a door

is ajar/open and not fully closed.

NOTE:

If the vehicle is moving, there will also be a single

chime.

Electric Power Steering (EPS) Fault

Warning Light

This warning light will turn on when

there's a fault with the EPS system

page 177.

Electronic Throttle Control (ETC) Warning

Light

This warning light will illuminate to

indicate a problem with the ETC system.

If a problem is detected while the vehicle

is running, the light will either stay on or

flash depending on the nature of the problem.

Cycle the ignition when the vehicle is safely and

completely stopped and the transmission is placed

in the PARK position. The light should turn off. If

the light remains on with the vehicle running, your

vehicle will usually be drivable; however, see an

authorized dealer for service as soon as possible.

NOTE:

This light may turn on if the accelerator and brake

pedals are pressed at the same time.

If the light continues to flash when the vehicle is

running, immediate service is required and you

may experience reduced performance, an

elevated/rough idle, or engine stall and your

vehicle may require towing. The light will come on

when the ignition is placed in the ON/RUN or ACC/

ON/RUN position and remain on briefly as a bulb

check. If the light does not come on during starting,

have the system checked by an authorized dealer.

Engine Coolant Temperature Warning

Light

This warning light warns of an

overheated engine condition. If the

engine coolant temperature is too high,

this indicator will illuminate and a single

chime will sound. If the temperature reaches the

upper limit, a continuous chime will sound for four

minutes or until the engine is able to cool;

whichever comes first.
If the light turns on while driving, safely pull over

and stop the vehicle. If the Air Conditioning (A/C)

system is on, turn it off. Also, shift the transmission

into NEUTRAL and idle the vehicle. If the

temperature reading does not return to normal,

turn the engine off immediately and call for service

page 377.

WARNING!

Continued operation with reduced assist could

pose a safety risk to yourself and others. Service

should be obtained as soon as possible.

140

GETTING TO KNOW YOUR INSTRUMENT PANEL

Hood Open Warning Light

This indicator will illuminate when the

hood is ajar/open and not fully closed.

NOTE:

If the vehicle is moving, there will also be a single

chime.

Oil Pressure Warning Light

This warning light will illuminate, and a

chime will sound, to indicate low engine

oil pressure. If the light and chime turn on

while driving, safely stop the vehicle and

turn off the engine as soon as possible. After the

vehicle is safely stopped, restart the engine and

monitor the Oil Pressure Warning Light. If the Oil

Pressure Warning Light is still illuminated, turn the

engine OFF and contact an authorized dealer for

further assistance. Do not operate the vehicle until

the cause is corrected. If the lamp is no longer

illuminated, the engine can be operated but it is

recommended to take the vehicle to an authorized

dealer as soon as possible.
Do not operate the vehicle until the cause is

corrected. This light does not indicate how much oil

is in the engine. The engine oil level must be

checked under the hood.

Oil Temperature Warning Light

This warning light will illuminate to

indicate the engine oil temperature is

high. If the light turns on while driving,

stop the vehicle and shut off the engine

as soon as possible. Wait for oil temperature to

return to normal levels.

Seat Belt Reminder Warning Light

This warning light indicates when the

driver or passenger seat belt is

unbuckled. When the ignition is first

placed in the ON/RUN or ACC/ON/RUN

position and if the driver’s seat belt is unbuckled,

a chime will sound and the light will turn on. When

driving, if the driver or front passenger seat belt

remains unbuckled, the Seat Belt Reminder Light

will flash or remain on continuously and a chime

will sound

page 324.

Rear Seat Belt Reminder Indicator Light —

If Equipped With A Base Instrument

Cluster

This light indicates when a rear seat belt

is unbuckled in the second row. When

the ignition is first placed in the ON/RUN

or ACC/ON/RUN position, and if a seat

belt in the second row is unbuckled, a light

corresponding to the specific seat will turn on in

the upper right portion of the instrument cluster

display, momentarily replacing the configurable

corner information. If a second row seat belt that

was buckled at the start of the trip is unbuckled,

the Rear Seat Belt Reminder Light will change from

the buckled to the unbuckled symbol, and a chime

will sound

page 324.

Transmission Temperature Warning

Light — If Equipped

This warning light will illuminate to warn

of a high transmission fluid temperature.

This may occur with strenuous usage

such as trailer towing. If this light turns

on, stop the vehicle and run the engine at idle or

slightly faster, with the transmission in PARK (P) or

NEUTRAL (N), until the light turns off. Once the light

turns off, you may continue to drive normally. If

Manual transmission equipped, this warning will

illuminate to warn of high clutch temperature. This

may occur with driver misuse of clutch pedal or

resting foot on the clutch pedal or partially

engaging the clutch for longer duration. If the light

turns on, it will be with an additional CLUTCH HOT

message. Stop the vehicle safely and run the

engine at idle with transmission gear in NEUTRAL

(N) until the light turns off. Once the light turns off,

follow the message displayed in the instrument

cluster.

GETTING TO KNOW YOUR INSTRUMENT PANEL

141

Vehicle Security Warning

Light — If Equipped

This light will flash at a fast rate for

approximately 15 seconds when the

vehicle security system is arming, and

then will flash slowly until the vehicle is

disarmed.

ELLOW

ARNING

IGHTS

Anti-Lock Brake System (ABS) Warning

Light

This warning light monitors the ABS. The

light will turn on when the ignition is

placed in the ON/RUN or ACC/ON/RUN

position and may stay on for as long as

four seconds.
If the ABS light remains on or turns on while

driving, then the Anti-Lock portion of the brake

system is not functioning and service is required as

soon as possible. However, the conventional brake

system will continue to operate normally,

assuming the Brake Warning Light is not also on.
If the ABS light does not turn on when the ignition

is placed in the ON/RUN or ACC/ON/RUN position,

have the brake system inspected by an authorized

dealer.

Electronic Stability Control (ESC) Active

Warning Light — If Equipped

This warning light will indicate when the

Electronic Stability Control system is

Active. The ESC Indicator Light in the

instrument cluster will come on when the

ignition is placed in the ON/RUN or ACC/ON/RUN

position, and when ESC is activated. It should go

out with the engine running. If the ESC Indicator

Light comes on continuously with the engine

running, a malfunction has been detected in the

ESC system. If this warning light remains on after

several ignition cycles, and the vehicle has been

driven several miles (kilometers) at speeds greater

than 30 mph (48 km/h), see an authorized dealer

as soon as possible to have the problem

diagnosed and corrected.



The ESC OFF Indicator Light and the ESC Indi

cator Light come on momentarily each time the

ignition is placed in the ON/RUN or ACC/ON/

RUN position.



The ESC system will make buzzing or clicking

sounds when it is active. This is normal; the

sounds will stop when ESC becomes inactive.



This light will come on when the vehicle is in an

ESC event.

WARNING!

If you continue operating the vehicle when the

Transmission Temperature Warning Light is

illuminated you could cause the fluid to boil over,

come in contact with hot engine or exhaust

components and cause a fire. If you continue to

operate the vehicle when the CLUTCH HOT

message is displayed or Transmission

Temperature Warning Light is illuminated, you

could cause the clutch to overheat and cause a

fire.

CAUTION!

Continuous driving with the Transmission

Temperature Warning Light illuminated will

eventually cause severe transmission damage

or transmission failure. If you continue to

operate the vehicle when the CLUTCH HOT

message is displayed or Transmission

Temperature Warning Light is illuminated, you

could cause the clutch to overheat and cause

severe clutch damage, transmission damage or

failure.

142

GETTING TO KNOW YOUR INSTRUMENT PANEL

Electronic Stability Control (ESC) OFF

Warning Light — If Equipped

This warning light indicates the Electronic

Stability Control (ESC) is off.
Each time the ignition is turned to ON/

RUN or ACC/ON/RUN, the ESC system will be on,

even if it was turned off previously.

Loose Fuel Filler Cap Warning

Light — If Equipped

This warning light will illuminate when the

fuel filler cap is loose. Properly close the

filler cap to disengage the light. If the

light does not turn off, please see an

authorized dealer.

Low Fuel Warning Light

When the fuel level reaches

approximately 2.0 gal (7.5 L), this light

will turn on and a chime will sound. The

light will remain on until fuel is added.

Low Washer Fluid Warning

Light — If Equipped

This warning light will illuminate when the

windshield washer fluid is low

page 395.

Engine Check/Malfunction Indicator

Warning Light (MIL)

The Engine Check/Malfunction Indicator

Light (MIL) is a part of an Onboard

Diagnostic System called OBD II that

monitors engine and automatic

transmission control systems. This warning light

will illuminate when the ignition is in the ON/RUN

position before engine start. If the bulb does not

come on when turning the ignition switch from OFF

to ON/RUN, have the condition checked promptly.
Certain conditions, such as a loose or missing gas

cap, poor quality fuel, etc., may illuminate the light

after engine start. The vehicle should be serviced if

the light stays on through several typical driving

styles. In most situations, the vehicle will drive

normally and will not require towing.
When the engine is running, the MIL may flash to

alert serious conditions that could lead to

immediate loss of power or severe catalytic

converter damage. The vehicle should be serviced

by an authorized dealer as soon as possible if this

occurs.

Service 4WD Warning Light — If Equipped

This warning light will illuminate to signal

a fault with the 4WD system. If the light

stays on or comes on during driving, it

means that the 4WD system is not

functioning properly and that service is required. It

is recommend you drive to the nearest service

center and have the vehicle serviced immediately.

WARNING!

A malfunctioning catalytic converter, as

referenced above, can reach higher

temperatures than in normal operating

conditions. This can cause a fire if you drive

slowly or park over flammable substances such

as dry plants, wood, cardboard, etc. This could

result in death or serious injury to the driver,

occupants or others.

CAUTION!

Prolonged driving with the Malfunction Indicator

Light (MIL) on could cause damage to the

vehicle control system. It also could affect fuel

economy and driveability. If the MIL is flashing,

severe catalytic converter damage and power

loss will soon occur. Immediate service is

required.

GETTING TO KNOW YOUR INSTRUMENT PANEL

143

Service Forward Collision Warning (FCW)

Light — If Equipped

This warning light will illuminate to

indicate a fault in the Forward Collision

Warning System. Contact an authorized

dealer for service

page 317.

Service Stop/Start System Warning

Light — If Equipped

This warning light will illuminate when the

Stop/Start system is not functioning

properly and service is required. Contact

an authorized dealer for service.

Cruise Control Fault Warning Light

This warning light will illuminate to

indicate the Cruise Control System is not

functioning properly and service is

required. Contact an authorized dealer.

Sway Bar Fault Warning

Light — If Equipped

This light will illuminate when there is a

fault in the sway bar disconnect system

page 175.

Tire Pressure Monitoring System (TPMS)

Warning Light

The warning light switches on and a

message is displayed to indicate that the

tire pressure is lower than the

recommended value and/or that slow

pressure loss is occurring. In these cases, optimal

tire life and fuel consumption may not be

guaranteed.
Should one or more tires be in the condition

mentioned above, the display will show the

indications corresponding to each tire.

Each tire, including the spare (if provided), should

be checked monthly when cold and inflated to the

inflation pressure recommended by the vehicle

manufacturer on the vehicle placard or tire

inflation pressure label. If your vehicle has tires of

a different size than the size indicated on the

vehicle placard or tire inflation pressure label, you

should determine the proper tire inflation pressure

for those tires.
As an added safety feature, your vehicle has been

equipped with a TPMS that illuminates a low tire

pressure telltale when one or more of your tires is

significantly underinflated. Accordingly, when the

low tire pressure telltale illuminates, you should

stop and check your tires as soon as possible and

inflate them to the proper pressure. Driving on a

significantly underinflated tire causes the tire to

overheat and can lead to tire failure. Underinflation

also reduces fuel efficiency and tire tread life, and

may affect the vehicle’s handling and stopping

ability.

WARNING!

Do not continue driving with one or more flat

tires as handling may be compromised. Stop the

vehicle, avoiding sharp braking and steering. If a

tire puncture occurs, repair immediately using

the dedicated tire repair kit and contact an

authorized dealer as soon as possible.

144

GETTING TO KNOW YOUR INSTRUMENT PANEL

Please note that the TPMS is not a substitute for

proper tire maintenance, and it is the driver’s

responsibility to maintain correct tire pressure,

even if underinflation has not reached the level to

trigger illumination of the TPMS low tire pressure

telltale.
Your vehicle has also been equipped with a TPMS

malfunction indicator to indicate when the system

is not operating properly. The TPMS malfunction

indicator is combined with the low tire pressure

telltale. When the system detects a malfunction,

the telltale will flash for approximately one minute

and then remain continuously illuminated. This

sequence will continue upon subsequent vehicle

start-ups as long as the malfunction exists. When

the malfunction indicator is illuminated, the

system may not be able to detect or signal low tire

pressure as intended. TPMS malfunctions may

occur for a variety of reasons, including the

installation of replacement or alternate tires or

wheels on the vehicle that prevent the TPMS from

functioning properly. Always check the TPMS

malfunction telltale after replacing one or more

tires or wheels on your vehicle to ensure that the

replacement or alternate tires and wheels allow

the TPMS to continue to function properly.

AdBlue® (UREA) Injection System Failure

Warning Light — If Equipped

This warning light will illuminate along

with a dedicated message on the display

(if equipped) if an unknown fluid not

conforming with acceptable

characteristics is inserted, or if an average

consumption of AdBlue® (UREA) over 50% is

detected. Contact an authorized dealer as soon as

possible.

If the problem is not solved, a specific message will

appear on the Instrument Cluster Display

whenever a certain threshold is reached until it will

no longer be possible to start the engine.
When about 125 miles (200 km) are remaining

before the AdBlue® (UREA) tank is empty, a

continuous dedicated message will appear on the

instrument panel, accompanied by a buzzer sound

(if equipped).

ELLOW

NDICATOR

IGHTS

4WD Indicator Light — If Equipped

This light alerts the driver that the vehicle

is in the four-wheel drive mode, and the

front and rear driveshafts are

mechanically locked together forcing the

front and rear wheels to rotate at the same speed.

4WD Low Indicator Light — If Equipped

This light alerts the driver that the vehicle

is in the 4WD Low mode. The front and

rear driveshafts are mechanically locked

together forcing the front and rear

wheels to rotate at the same speed. Low range

provides a greater gear reduction ratio to provide

increased torque at the wheels.

CAUTION!

The TPMS has been optimized for the original

equipment tires and wheels. TPMS pressures

and warning have been established for the tire

size equipped on your vehicle. Undesirable

system operation or sensor damage may result

when using replacement equipment that is not

of the same size, type, and/or style. Aftermarket

wheels can cause sensor damage. Using

aftermarket tire sealants may cause the Tire

Pressure Monitoring System (TPMS) sensor to

become inoperable. After using an aftermarket

tire sealant it is recommended that you take

your vehicle to an authorized dealer to have your

sensor function checked.

GETTING TO KNOW YOUR INSTRUMENT PANEL

145

4WD Part Time Indicator

Light — If Equipped

This light alerts the driver that the vehicle

is in the four-wheel drive part time mode,

and the front and rear driveshafts are

mechanically locked together forcing the

front and rear wheels to rotate at the same speed.

Axle Locker Fault Indicator

Light — If Equipped

This light indicates when front and/or

rear axle locker fault has been detected.

Rear Axle Lock Indicator

Light — If Equipped

This light indicates when the rear axle

lock has been activated

page 169.

Front And Rear Axle Lock Indicator

Light — If Equipped

This light indicates when the front, rear,

or both axles have been locked. The

telltale will display the lock icon on the

front and rear axles to indicate the

current lock status.

Forward Collision Warning OFF Indicator

Light — If Equipped

This indicator light illuminates to indicate

that Forward Collision Warning is off

page 317.

Neutral Indicator Light — If Equipped

This light alerts the driver that the vehicle

is in the neutral mode

page 163.

Service Adaptive Cruise Control Warning

Light — If Equipped

This light will turn on when the ACC is not

operating and needs service

page 184.

Sway Bar Indicator Light — If Equipped

This indicator light will illuminate when

the front sway bar is disconnected.

Off Road+ Indicator Light — If Equipped

This indicator light will illuminate when

Off Road+ has been activated.

Cargo Light On Indicator Light

This indicator light will illuminate when

the Bed Lamp has been activated.

Wait To Start Light — If Equipped

This indicator light will illuminate for

approximately two seconds when the

ignition is turned to the ON/RUN position.

Its duration may be longer based on

colder operating conditions. Vehicle will not initiate

start until telltale is no longer displayed.

NOTE:

The Wait To Start Light may not illuminate if the

intake manifold temperature is warm enough.

Low Diesel Exhaust Emissions

Additive AdBlue® (UREA) Indicator

Light — If Equipped

The Low Diesel Exhaust Emissions

Additive AdBlue® (UREA) indicator light

illuminates when the AdBlue® (UREA)

level is low.

Fill the AdBlue® (UREA) tank as soon as possible

with at least 1.3 gallons (5 liters) of AdBlue®

(UREA).
If filling the tank is done with a remaining range of

AdBlue® (UREA) in the tank equal to zero, you may

need to wait two minutes before starting the

vehicle.

146

GETTING TO KNOW YOUR INSTRUMENT PANEL

Water In Fuel Indicator Light — If Equipped

The Water In Fuel Indicator Light will

illuminate when there is water detected

in the fuel filter. If this light remains on,

DO NOT start the vehicle before you drain

the water from the fuel filter to prevent engine

damage, and please see an authorized dealer.

REEN

NDICATOR

IGHTS

Adaptive Cruise Control (ACC) Set With

No Target Detected Indicator

Light — If Equipped

This light will turn on when the Adaptive

Cruise Control is set and there is no

vehicle in front detected

page 184.

Adaptive Cruise Control (ACC) Set With

Target Light — If Equipped

This will display when the ACC is set and

a vehicle in front is detected

page 184.

4WD Auto Indicator Light — If Equipped

This light alerts the driver that the vehicle

is in the four-wheel drive auto mode. The

system will provide power to all four

wheels and shift the power between the

front and rear axles as needed. This will provide

maximum traction in dry and slippery conditions.

Cruise Control SET Indicator

Light — If Equipped With A Premium

Instrument Cluster

This indicator light will illuminate when

the cruise control is set to the desired

speed

page 183.

Front Fog Indicator Light — If Equipped

This indicator light will illuminate when

the front fog lights are on

page 59.

Parking/Headlights On Indicator Light

This indicator light will illuminate when

the parking lights or headlights are

turned on.

Stop/Start Active Indicator

Light — If Equipped

This indicator light will illuminate when

the Stop/Start function is in “Autostop”

mode.

Turn Signal Indicator Lights

When the left or right turn signal is

activated, the turn signal indicator will

flash independently and the

corresponding exterior turn signal lamps

will flash. Turn signals can be activated when the

multifunction lever is moved down (left) or up

(right).

NOTE:



A continuous chime will sound if the vehicle is

driven more than 1 mile (1.6 km) with either

turn signal on.



Check for an inoperative outside light bulb if

either indicator flashes at a rapid rate.

CAUTION!

The presence of water in the fuel system circuit

may cause severe damage to the injection

system and irregular engine operation. If the

indicator light is illuminated, contact an

authorized dealer as soon as possible to bleed

the system. If the above indications come on

immediately after refueling, water or AdBlue®

(UREA) have probably been poured into the tank:

switch the engine off immediately and contact

an authorized dealer.

GETTING TO KNOW YOUR INSTRUMENT PANEL

147

Rear Seat Belt Fastened Indicator

Light — If Equipped With A Premium

Instrument Cluster

This light indicates when a rear seat belt

has been buckled in the second row. A

telltale will display in the upper right

corner of the instrument cluster display

to correspond to the specific seating position once

the seat belt has been buckled

page 324.

HITE

NDICATOR

IGHTS

Adaptive Cruise Control (ACC) Ready

Light — If Equipped With a Premium

Instrument Cluster

This light will turn on when the vehicle

equipped with Adaptive Cruise Control

(ACC) has been turned on, but not set.

Adaptive Cruise Control (ACC) Ready Light

— If Equipped With a Base Instrument

Cluster

This light will turn on when the vehicle

equipped with ACC has been turned on,

but not set.

Adaptive Cruise Control (ACC) Set Light — If

Equipped With a Base Instrument Cluster

This light will turn on when the vehicle

equipped with ACC has been turned on,

but not set.

Two Wheel Drive High Indicator

Light — If Equipped With A Premium

Instrument Cluster

This light alerts the driver that the vehicle

is in the two wheel drive high mode.

Rear Seat Belt Fastened Indicator Light —

If Equipped With A Base Instrument

Cluster

This light indicates when a rear seat belt

has been buckled in the second row. A

telltale will display in the upper right

corner of the instrument cluster display

to correspond to the specific seating position once

the seat belt has been buckled.

Rear Seat Belt Reminder Indicator

Light — If Equipped With A Base Instrument

Cluster

This light indicates when a rear seat belt

is unbuckled in the second row. When

the ignition is first placed in the ON/RUN

or ACC/ON/RUN position, and if a seat

belt in the second row is unbuckled, a light

corresponding to the specific seat will turn on in

the upper right portion of the instrument cluster

display, momentarily replacing the configurable

corner information. If a second row seat belt that

was buckled at the start of the trip is unbuckled,

the Rear Seat Belt Reminder Light will change from

the buckled to the unbuckled symbol, and a chime

will sound.

Rear Seat Unoccupied Indicator

Light — If Equipped

This light indicates when the rear

passenger seats are unoccupied, and will

illuminate in the upper right portion of

the instrument cluster display,

momentarily replacing the configurable corner

information.

148

GETTING TO KNOW YOUR INSTRUMENT PANEL

Cruise Control Ready Indicator

Light — If Equipped With A Premium

Instrument Cluster

This light will turn on when the cruise

control has been turned on, but not set.

Cruise Control SET Indicator

Light — If Equipped With A Base Instrument

Cluster

This indicator light will illuminate when

the cruise control is set.

Cruise Control Ready Indicator

Light — If Equipped With A Base Instrument

Cluster

This light will turn on when cruise control

has been turned on, but not set.

Selec - Speed Control (SSC) Indicator

Light — If Equipped

This light will turn on when Selec - Speed

Control is activated. Selec - Speed

Control is available in 4WD Low ONLY.

LUE

NDICATOR

IGHTS

High Beam Indicator Light

This indicator light will illuminate to

indicate that the high beam headlights

are on. With the low beams activated,

push the multifunction lever forward

(toward the front of the vehicle) to turn on the high

beams. Pull the multifunction lever rearward

(toward the rear of the vehicle) to turn off the high

beams. If the high beams are off, pull the lever

toward you for a temporary high beam on, "flash to

pass" scenario.

ONBOARD DIAGNOSTIC SYSTEM — OBD II

Your vehicle is equipped with a sophisticated

Onboard Diagnostic system called OBD II. This

system monitors the performance of the

emissions, engine, and transmission control

systems. When these systems are operating

properly, your vehicle will provide excellent

performance and fuel economy, as well as engine

emissions well within current government

regulations.

If any of these systems require service, the OBD II

system will turn on the Malfunction Indicator Light

(MIL). It will also store diagnostic codes and other

information to assist your service technician in

making repairs. Although your vehicle will usually

be drivable and not need towing, see an authorized

dealer for service as soon as possible.

NBOARD

IAGNOSTIC

YSTEM

(OBD II) C

YBERSECURITY

Your vehicle is required to have an OBD II and a

connection port to allow access to information

related to the performance of your emissions

controls. Authorized service technicians may need

to access this information to assist with the

diagnosis and service of your vehicle and

emissions system

page 227.

CAUTION!



Prolonged driving with the MIL on could cause

further damage to the emission control

system. It could also affect fuel economy and

driveability. The vehicle must be serviced

before any emissions tests can be performed.



If the MIL is flashing while the vehicle is

running, severe catalytic converter damage

and power loss will soon occur. Immediate

service is required.

GETTING TO KNOW YOUR INSTRUMENT PANEL

149

EMISSIONS INSPECTION AND

MAINTENANCE PROGRAMS

In some localities, it may be a legal requirement to

pass an inspection of your vehicle's emissions

control system. Failure to pass could prevent

vehicle registration.

For states and/or provinces that require

an Inspection and Maintenance (I/M),

this check verifies the Malfunction

Indicator Light (MIL) is functioning and is

not on when the engine is running, and that the

OBD II system is ready for testing.
The OBD II system may not be ready if your vehicle

was recently serviced, recently had a depleted

battery or a battery replacement. If the OBD II

system should be determined not ready for the I/M

test, your vehicle may fail the test.
Your vehicle has a simple ignition actuated test,

which you can use prior to going to the test station.

To check if your vehicle's OBD II system is ready,

you must do the following:
1. Cycle the ignition switch to the ON position,

but do not crank or start the engine.

NOTE:

If you crank or start the engine, you will have to

start this test over.
2. As soon as you cycle the ignition switch to the

ON position, you will see the Malfunction

Indicator Light (MIL) symbol come on as part of

a normal bulb check.

3. Approximately 15 seconds later, one of two

things will happen:



The MIL will flash for about 10 seconds and

then return to being fully illuminated until

you turn OFF the ignition or start the engine.

This means that your vehicle's OBD II

system is not ready and you should not

proceed to the I/M station.



The MIL will not flash at all and will remain

fully illuminated until you place the ignition

in the off position or start the engine. This

means that your vehicle's OBD II system is

ready and you can proceed to the I/M

station.

If your OBD II system is not ready, you should see

an authorized dealer or repair facility. If your

vehicle was recently serviced or had a battery

failure or replacement, you may need to do nothing

more than drive your vehicle as you normally would

in order for your OBD II system to update. A

recheck with the above test routine may then

indicate that the system is now ready.
Regardless of whether your vehicle's OBD II system

is ready, if the MIL is illuminated during normal

vehicle operation you should have your vehicle

serviced before going to the I/M station. The I/M

station can fail your vehicle because the MIL is on

with the engine running.

WARNING!



ONLY an authorized service technician should

connect equipment to the OBD II connection

port in order to read the VIN, diagnose, or

service your vehicle.



If unauthorized equipment is connected to the

OBD II connection port, such as a

driver-behavior tracking device, it may:



Be possible that vehicle systems,

including safety related systems, could be

impaired or a loss of vehicle control could

occur that may result in an accident

involving serious injury or death.



Access, or allow others to access, infor

mation stored in your vehicle systems,

including personal information.

150

STARTING AND OPERATING

STARTING THE ENGINE — GASOLINE

ENGINE (IF EQUIPPED)

Before starting your vehicle, adjust your seat,

adjust both inside and outside mirrors, and fasten

your seat belts.

ANUAL

RANSMISSION

— I

QUIPPED

Apply the parking brake, place the gear selector in

NEUTRAL, and press the clutch pedal before

starting the vehicle. This vehicle is equipped with a

clutch interlocking ignition system. It will not start

unless the clutch pedal is pressed to the floor.
Four-Wheel Drive Models Only
In 4L mode, if the vehicle is stalled, the engine will

start regardless of whether or not the clutch pedal

is pressed to the floor. This feature enhances

off-road performance by allowing the vehicle to

start when in 4L without having to press the clutch

pedal. The 4WD LOW Indicator Light will illuminate

when the transfer case has been shifted into this

mode.

UTOMATIC

RANSMISSION

—

QUIPPED

Start the vehicle with the gear selector in the PARK

position (vehicle can also be started in NEUTRAL).

Apply the brake before shifting to any driving

range.

ORMAL

TARTING

To Turn On The Engine Using The ENGINE START/

STOP Button
1. The transmission must be in PARK or

NEUTRAL.

2. Press and hold the brake pedal while pushing

the ENGINE START/STOP button once.

3. The system starts the vehicle. If the vehicle

fails to start, the starter will disengage

automatically after 10 seconds.

4. If you wish to stop the cranking of the engine

prior to the engine starting, push the ENGINE

START/STOP button again.

WARNING!



When exiting the vehicle, always remove the

key fob from the ignition and lock your vehicle.



Never leave children alone in a vehicle, or with

access to an unlocked vehicle.



Allowing children to be in a vehicle unattended

is dangerous for a number of reasons. A child

or others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the gear

selector.



Do not leave the key fob in or near the vehicle,

or in a location accessible to children. A child

could operate power windows, other controls,

or move the vehicle.



Do not leave children or animals inside parked

vehicles in hot weather. Interior heat build-up

may cause serious injury or death.

STARTING AND OPERATING

151

To Turn Off The Engine Using The ENGINE START/

STOP Button
1. Place the gear selector in PARK, then push

and release the ENGINE START/STOP button.

The ignition will return to the OFF position.

2. If the gear selector is not in PARK (with vehicle

stopped) and the ENGINE START/STOP button

is pushed once, the transmission will automat

ically select PARK and the engine will turn off,

however the ignition will remain in the ACC

position (NOT the OFF position). Never leave a

vehicle out of the PARK position, or it could roll.

3. If the gear selector is in NEUTRAL, and the

vehicle speed is below 5 mph (8 km/h),

pushing the ENGINE START/STOP button once

will turn the engine off. The ignition will remain

in the ACC position.

4. If the vehicle speed is above 5 mph (8 km/h),

the ENGINE START/STOP button must be held

for two seconds (or three short pushes in a

row) to turn the engine off. The ignition will

remain in the ACC position (NOT the OFF

position) if the engine is turned off when the

transmission is not in PARK.

NOTE:

The system will automatically time out and the

ignition will cycle to the OFF position after

30 minutes of inactivity if the ignition is left in the

ACC or RUN (engine not running) position and the

transmission is in PARK.
ENGINE START/STOP Button Functions — With

Driver’s Foot Off The Brake Pedal (In PARK Or

NEUTRAL Position)
The ENGINE START/STOP button operates similar

to an ignition switch. It has three modes: OFF, ACC,

and RUN. To change the ignition modes without

starting the vehicle and use the accessories, follow

these steps:
1. Starting with the ignition in the OFF position.
2. Push the ENGINE START/STOP button once to

place the ignition to the ACC position

(instrument cluster will display “ACC”).

3. Push the ENGINE START/STOP button a

second time to place the ignition to the

RUN position (instrument cluster will display

“ON/RUN”).

4. Push the ENGINE START/STOP button a third

time to return the ignition to the OFF position

(instrument cluster will display “OFF”).

UTO

ARK

AutoPark is a supplemental feature to assist in

placing the vehicle in PARK should the situations

on the following pages occur. It is a back-up system

and should not be relied upon as the primary

method by which the driver shifts the vehicle into

PARK.
The conditions under which AutoPark will engage

are outlined on the following pages.

WARNING!



Driver inattention could lead to failure to place

the vehicle in PARK. ALWAYS DO A VISUAL

CHECK that your vehicle is in PARK by verifying

that a solid (not blinking) “P” is indicated in

the instrument cluster display and on the gear

selector. If the "P" indicator is blinking, your

vehicle is not in PARK. As an added precau

tion, always apply the parking brake when

exiting the vehicle.



AutoPark is a supplemental feature. It is not

designed to replace the need to shift your

vehicle into PARK. It is a back-up system and

should not be relied upon as the primary

method by which the driver shifts the vehicle

into PARK.

152

STARTING AND OPERATING

If the vehicle is not in PARK and the driver turns off

the engine, the vehicle may AutoPark.
AutoPark will engage when all of these conditions

are met:



Vehicle is equipped with an 8-speed

transmission



Driver door is ajar or if the driver door is

removed and the driver is not on the seat (seat

pad sensor detects driver missing)



Vehicle is not in PARK



Vehicle speed is 1.2 mph (1.9 km/h) or less



Ignition is switched from ON/RUN to OFF

NOTE:

For Keyless Enter ‘n Go™ equipped vehicles, the

engine will turn off and the ignition will change to

ACC position. After 30 minutes the ignition

switches to OFF automatically, unless the driver

turns the ignition OFF.
If the vehicle is not in PARK and the driver exits the

vehicle with the engine running, the vehicle may

AutoPark.
AutoPark will engage when all of these conditions

are met:



Vehicle is equipped with an 8-speed

transmission



Driver door is ajar or if the driver door is

removed and the driver is not on the seat (seat

pad sensor detects driver missing)



Vehicle is not in PARK



Vehicle speed is 1.2 mph (1.9 km/h) or less



Driver seat belt is unbuckled



Brake pedal is not pressed

The message “AutoPark Engaged Shift to P then

Shift to Gear” will display in the instrument cluster.

NOTE:

In some cases the ParkSense graphic will be

displayed in the instrument cluster. In these cases,

the gear selector must be returned to “P” to select

desired gear.
If the driver shifts into PARK while moving, the

vehicle may AutoPark.
AutoPark will engage ONLY when vehicle speed is

1.2 mph (1.9 km/h) or less.
The message “Vehicle Speed is Too High to Shift to

P” will be displayed in the instrument cluster if

vehicle speed is above 1.2 mph (1.9 km/h).

4WD LOW
AutoPark will be disabled when operating the

vehicle in 4WD LOW.
The message “AutoPark Disabled” will be

displayed in the instrument cluster.
Additional customer warnings will be given when

both of these conditions are met:



Vehicle is not in PARK



Driver’s door is ajar

The message “AutoPark Not Engaged” will be

displayed in the instrument cluster. A warning

chime will continue until you shift the vehicle into

PARK or the driver’s door is closed.
ALWAYS DO A VISUAL CHECK that your vehicle is in

PARK by looking for the “P” in the instrument

cluster display and on the gear selector. As an

added precaution, always apply the parking brake

when exiting the vehicle.

XTREME

OLD

EATHER

ELOW

–22°F O

−30°C)

To ensure reliable starting at these temperatures,

use of an externally powered electric engine block

heater (available from an authorized dealer) is

recommended.

WARNING!

If vehicle speed is above 1.2 mph (1.9 km/h),

the transmission will default to NEUTRAL

until the vehicle speed drops below 1.2 mph

(1.9 km/h). A vehicle left in the NEUTRAL

position can roll. As an added precaution, always

apply the parking brake when exiting the vehicle.

STARTING AND OPERATING

153

(Continued)

NGINE

AILS

TART

If the engine fails to start after you have followed

the “Normal Starting” procedure, and had not

experienced an extended park condition (i.e.,

parked for more than 30 days), it may be flooded.

Push the accelerator pedal all the way to the floor

and hold it there while the engine is cranking. This

should clear any excess fuel in case the engine is

flooded. The starter motor will engage

automatically, run for 10 seconds, and then

disengage. Once this occurs, release the

accelerator pedal and the brake pedal, wait 10 to

15 seconds, then repeat the “Normal Starting”

procedure.

FTER

TARTING

The idle speed is controlled automatically and will

decrease as the engine warms up.

STARTING THE ENGINE — DIESEL ENGINE

(IF EQUIPPED)

Before starting your vehicle, adjust your seat, both

inside and outside mirrors, and fasten your seat

belts.
The starter is allowed to crank for up to 25-second

intervals. Waiting two minutes between such

intervals will protect the starter from overheating.

WARNING!



Never pour fuel or other flammable liquid into

the throttle body air inlet opening in an

attempt to start the vehicle. This could result

in flash fire causing serious personal injury.



Do not attempt to push or tow your vehicle to

get it started. Vehicles equipped with an auto

matic transmission cannot be started this

way. Unburned fuel could enter the catalytic

converter and once the engine has started,

ignite and damage the converter and vehicle.



If the vehicle has a discharged battery,

booster cables may be used to obtain a start

from a booster battery or the battery in

another vehicle. This type of start can be

dangerous if done improperly

page 373.

CAUTION!

To prevent damage to the starter, do not

continuously crank the engine for more than 10

seconds at a time. Wait 10 to 15 seconds before

trying again.

WARNING!



Before exiting a vehicle, always come to a

complete stop, then shift the automatic trans

mission into PARK and apply the parking

brake.



Always make sure the keyless ignition node is

in the OFF position, key fob is removed from

the vehicle and vehicle is locked.



Never leave children alone in a vehicle, or with

access to an unlocked vehicle. Leaving chil

dren in a vehicle unattended is dangerous for

a number of reasons. A child or others could

be seriously or fatally injured. Children should

be warned not to touch the parking brake,

brake pedal or the gear selector.



Do not leave the key fob in or near the vehicle,

or in a location accessible to children, and do

not leave the ignition of a vehicle equipped

with Keyless Enter ‘n Go™ in the ACC or ON/

RUN position. A child could operate power

windows, other controls, or move the vehicle.



Do not leave children or animals inside parked

vehicles in hot weather. Interior heat build-up

may cause serious injury or death.

154

STARTING AND OPERATING

NOTE:

Engine start-up in very low ambient temperature

could result in evident white smoke. This condition

will disappear as the engine warms up.

UTOMATIC

RANSMISSION

Start the engine with the transmission gear

selector in the PARK (P) position. Apply the brake

before shifting to any driving range.

XTREME

OLD

EATHER

The cartridge block heater clips into the engine

block near the water jacket and transfers heat to

the coolant. It requires a 110–115 Volt AC

electrical outlet with a grounded, three-wire

extension cord. Its use is recommended for

environments that routinely fall below -10°F

(-23°C). It should be used when the vehicle has not

been running overnight or longer periods and

should be plugged in two hours prior to start. Its

use is required for cold starts with temperatures

under -20°F (-28°C).

NOTE:

The engine block heater and heater cord are

factory installed options. If your vehicle is not

equipped, engine block heaters and heater cords

are available from an authorized Mopar® dealer.



A 12 Volt heater built into the fuel filter housing

aids in preventing fuel gelling. It is controlled by

a built-in thermostat.



A Diesel Pre-Heat system both improves engine

starting and reduces the amount of white

smoke generated by a warming engine.

ORMAL

TARTING

Observe the instrument cluster lights when

starting the engine.

NOTE:

Normal starting of either a cold or a warm engine is

obtained without pumping or pressing the accel

erator pedal.
1. Always apply the parking brake.
2. Press and hold the brake pedal while pushing

the ENGINE START/STOP button once.

NOTE:

A delay of the start of up to five seconds is possible

under very cold conditions. The “Wait to Start”

telltale will be illuminated during the preheat

process. When the engine “Wait To Start” telltale

turns off the engine will automatically crank.

CAUTION!



The engine is allowed to crank as long as 25

seconds. If the engine fails to start during this

period, please wait at least two minutes for

the starter to cool before repeating start

procedure.



If the Water in Fuel Indicator Light remains on,

DO NOT START engine before you drain the

water from the fuel filters to avoid engine

damage

page 399.

CAUTION!

If the Water in Fuel Indicator Light remains on,

DO NOT START the engine before you drain the

water from the fuel filters to avoid engine

damage

page 399.

Jeep Gladiator (2022 year). Manual in english - page 9
