Wheels and Tires – Armoured

 WARNING: Do not mix different types of tires on the same vehicle such as radial, bias or bias belted tires except in

emergencies (temporary spare usage). Failure to follow these instructions may result in personal injury.



 WARNING: Never run the engine with one wheel off the ground, for example when changing a wheel. The wheel

resting on the ground may cause the vehicle to move. Failure to follow these instructions may result in personal injury.



 WARNING: Aftermarket aerosol tire sealants are extremely flammable. Always question the customer to make sure

these products have not been used. Failure to follow these instructions may result in personal injury.



 WARNING: Always wear safety goggles or a face shield when performing any work with wheel and tire assemblies.

Failure to follow these instructions may result in personal injury.



 WARNING: Retighten the wheel nuts at 800 km (500 miles) after any wheel change or anytime the wheel nuts are

loosened. Failure to follow these instructions may result in personal injury.



 WARNING: Failure to retighten the wheel nuts at the specified mileage could cause the wheels to come become

detached while the vehicle is in motion. Failure to follow these instructions may result in personal injury.



 WARNING: Each individual axle, wheel and tire has its own maximum weight or tire inflation rating. Do not

overload or over-inflate beyond the capacity of the lowest rated components of the system. Failure to follow these
instructions may result in personal injury.



 WARNING: When changing a wheel, make sure that the vehicle cannot move. Always apply the parking brake and

select the transmission park position. Failure to follow these instructions may result in personal injury.



 WARNING: Reduce air pressure as much as possible by pushing the valve core plunger in before removing the

valve core. Failure to follow these instructions may result in personal injury.



 CAUTION: Do not clean aluminium wheels with steel wool, abrasive type cleaners or detergents. Failure to follow

these instructions may result in damage to the vehicle.



 CAUTION: The vehicle is fitted with directional tires, which should always be fitted in accordance with the

direction of rotation symbol on the tire.


NOTE:



The maximum distance that can be driven on a punctured tire varies greatly depending on the type of terrain.


The vehicle is only available with 19 inch wheels, due to the specification of the brakes and tires fitted. The
vehicle is fitted with 255/45 ZR19 104Y Pirelli P Zero, which feature a run-flat capability. For additional

Published: Mar 12, 2014

Vehicles

information, refer to

Wheel and Tire

 (204-04)

In the event of a puncture, the vehicle can still be driven at a maximum speed of 50 kph (31 mile/h); for a
distance of approximately 100 kph (62 mile/h). Note: Care must be taken not to damage the tire low pressure
sensor when removing and installing the tire. For additional information, refer to

Wheel and Tire

 (204-04)



Rodgard Runflat Components

The Rodgard runflat system consist of two main components.




Item  Part Number  Description
1



Roller

2



Runner





Item  Part Number  Description
1



Retaining clip

2



Installation label



Rodgard Runflat

The Rodgard toolbox contains the equipment used in the installation.




Item  Part Number

Description

1



Torch

2



Bead stretcher/release bar

www.

3



Gauge

4



13mm Insulated spanner

5



13mm spanner

6



Nylon blocks



Tire Low Pressure Sensor Components

The tire low pressure sensors have 3 major components.




Item  Part Number

Description

1



Coloured washers

2



Tire low pressure sensors

3



Tire valves


NOTE:



The colour of the washer must match the colour of the mark on the tire low pressure sensor.





Item  Part Number

Description

1



Coloured washer

2



Coloured mark


For further information on the tire run flat system contact; Rodgard, 1355 Clinton Street, Buffalo, New York
14206, U.S.A Tel: (716)823-1411. Fax: (716)823 1607. www.rodgard.com.

Diagnosis and testing





Wheels and Tires - VIN Range: G00442-
>G45703

General notes

Factory installed tires and wheels are designed to operate satisfactory when inflated to the

recommended inflation pressures; refer to the Specifications sub-section. The recommended

pressures apply to vehicle loads up to and including full-rated load capacity.



Correct tire pressures and driving technique have an important influence on tire life. Heavy

cornering, excessively rapid acceleration and unnecessary sharp braking increase tire wear.



Replacement tires should follow the recommended:

•



size.

•



speed rating.

•



load range.

•



radial construction type.

The use of any other size or type may seriously affect:

•



safety.

•



ride.

•



handling.

•



speedometer and odometer calibration.

•



vehicle ground clearance.

•



tire clearance between body and chassis.

•



wheel bearing life.

•



brake cooling.

Wheels need to be renewed when:

•



impact damaged.

•



heavily corroded.

•



porous.

•



wheel stud holes or seats become damaged.

•



they have excessive radial or lateral runout.

Safety notes

  WARNING: Do not mix different types of tires on the same vehicle. Handling may be

seriously affected resulting in loss of control. Failure to follow these instructions may result in
