86420 Figure 65 Figure 66 ADDITIONAL HEATER UNIT Set the container for collecting engine coolant near the - Disconnect the heater fan power cable electrical connection (3) and release it from the anchoring clips, if - Loosen clamp (7) and disconnect the additional heater engine coolant delivery pipe (6). Plug the pipe end - Loosen clamp (5) and disconnect the additional heater engine coolant delivery pipe (4). Plug the pipe end - Loosen the fastening screws (1) and remove the additional heater (2) from the vehicle. - Release the anchoring clips (1) and remove rear seat lower side upholstery (2). - Loosen the fastening screws (3) and remove the additional heater rear protection (4). For refitting, reverse the removal procedure and top up engine Set the vehicle on level ground taking the required safety Removal 86421 Refitting 58 PASSENGER’S COMPARTMENT HEATING AND VENTILATION SYSTEM D AILY |
