6C-22 ENGINE FUEL 4. Install the pins (3), lift piece (2) and spacer (1) in the nozzle holder. 5. Install the pins (2) in the spacer. 7. Hand-tighten the adjustment retaining nut together with the gasket to the nozzle holder. 8. Tighten the adjustment retaining nut to the speci- fied torque. Tighten: ⋅m (3.0 — 4.0 kg⋅m) Legend 1. Second nozzle opening pressure adjusting shim 2. Second spring N6A3406E N6A3407E Legend 1. Retaining nut (Special tool) N6A3408E N6A3409E |
