Cooling System 6B-19 Radiator core 1. If the radiator fin is deformed, the radiation effect deteriorates causing overheating. Therefore, • Eliminate dust or other foreign matter. Washing the radiator 1. Wash the internal parts of the radiator and cooling water passage using water and detergent. Installation 1. Ensure that no damage occurs to the radiator core because of the fan blade. Mount the brackets on Tighten: Bolts to 55 N ⋅m (5.6 kg⋅m / 41 lb⋅ft) Legend 1. Flange Nut
2. Mount the reserve tank hose of the coolant on the radiator. 3. Mount the radiator lower hose. • Fill the cooling water. 5. Install the 2 transmission oil pipes on the underside of the radiator. 6. Install the intake pipe from the turbocharger and inter-cooler (left side). 7. Install the intake pipe from the intake manifold and inter-cooler (right side). Reference • Confirm that the engine has cooled. reserve tank. • Close the radiator cap and the reserve tank cap and start the engine. Stop the engine after running WARNING: • After tightening the radiator cap, warm up the engine by running it at about 2000 rpm. Also, • When the pointer of the thermometer crosses the median and the thermostat has activated, run at • After the engine has cooled down sufficiently, check the water level in the filler neck part and N6A6247E |
