ELECTRICAL-BODY AND CHASSIS 8-185 CheckpointTrouble Cause Count ermeasure Replace the driver seat side power window & door lock SW. SW. malfunction OK NG Driver seat side power window & door lock SW. function Continued from the previous page 2. Lock switch does not function CheckpointTrouble Cause Count ermeasure Replace the driver seat side power window & door lock SW. SW. malfunction NG Driver seat side power window & door lock SW. function 3. Window on the driver’s side does not operate CheckpointTrouble Cause Count ermeasure Replace the driver seat side power window & door lock SW. SW. malfunction NG Replace the driver seat side power window motor Motor malfunction NG OK Driver seat side power window & door lock SW. function OK Repair open circuit or connector contact Open circuit or poor connector contact NG Continuity between 1 D-5 and 2 D-1 , or 10 D-5 and 1 D-1 1. Driver seat side power window motor function D-1 to the battery (+) terminal, and 1 D-1 to the (-) terminal (Should the motor rotate in 2. Driver seat side power window motor function D-1 to the battery (+) terminal, and 2 D-1 to the (-) terminal (Should the motor rotate in |
