ELECTRICAL-BODY AND CHASSIS 8-189 DRIVER SEAT SIDE POWER WINDOW & DOOR LOCK SWITCH Removal 1. Remove the switch by pushing the spring with the tip of a screwdriver. 2. Disconnect the connector. Installation To install, follow the removal steps in the reverse order. FRONT PASSENGER’S POWER WINDOW & DOOR LOCK SWITCH Removal 1. Remove the switch by pushing the spring with the tip of a screwdriver. 2. Disconnect the connector. Installation To install, follow the removal steps in the reverse order. REAR POWER WINDOW & DOOR LOCK SWITCH-LH & RH Removal 1. Remove the switch by pushing the spring with the tip of a screwdriver. 2. Disconnect the connector. Installation To install, follow the removal steps in the reverse order. |
