I30 2001 – Quick Reference – A/T
5
I30 2001
Quick Reference
A/T
PRECAUTIONS
•
Before performing any diagnostic test, vehicle should be driven for approximately 10 minutes
to raise transmission to the proper operating temperature of 122
°
to 176
°
.
•
During stall testing, never hold throttle wide open for more than 5 seconds at a time. Extended
stall testing can overheat transmission and cause serious damage.
•
Nissan
Matic
’D’ ATF is the only fluid accepted for warranty, service contracts and goodwill
repairs.
•
Before performing any internal repairs, thoroughly clean the outside of the transmission case
to prevent contamination.
•
Use lint free cloth or towels for wiping parts. Common shop towels can leave contaminating
fibers on the transmission parts and cause improper transmission operation.
•
When servicing the valve body, valves, sleeves, plugs, etc. should slide along the bores in the
valve body under their own weight.
•
Before assembly, apply a coat of ATF to all internal transmission parts. Use petroleum jelly to
protect o-rings and seals, or to hold bearings and washers in place during assembly.
Important Note: Nissan Matic ’D’ must be used in performing repairs paid by Nissan/Infiniti, such
as warranty, service contract, or good-will repairs. There will not be reimbursement for repairs
when non-genuine Nissan Matic ’D’ is used.
