I30 2001 – Quick Reference – Suspension

I30 2001

Quick Reference

Suspension

WHEEL ALIGNMENT (UNLADEN)

Toe-in

Range

Nominal

Total toe-in (A - B)

0 - 0.08 in (0 - 2 mm)

0.04 in (1 mm)

Total toe-in angle

0 -0.20

0.10

(left plus right)

(0’ - 12’)

(6’)

Front Wheel Turning Angle (full turn)

Equipped with 215/55

Equipped with 225/50

R16

R17 tires

In/Wheel Range

36.00

- 40.50

29.50

- 34.0

(36

00’ - 40

30’)

(29

30’ - 34

00’)

In/Wheel Nominal

39.50

(39

30’)

33.0

(33

00’)

Out/Wheel Nominal

32.00

(32

00’)

28.50

(28

30’)

Camber

Equipped with 225/50
R17 or 215/55 R16 tires

Range

-1.00

- 0.50

(-1

00’ - 0

30’)

Nominal

-0.25

(-0

15’)

Left/Right Difference

0.75

(45’) or less

Caster
Range

2.00

- 3.50

00’ - 3

30’)

Nominal

2.75

45’)

Left/Right Difference

0.75

(45’)

Kingpin Inclination

Equipped with 225/50
R17 or 215/55 R16 tires

Range

13.50

- 15.00

(13

30’ - 15

00’)

Nominal

14.25

(14

15’)

Set Back

0.0 in +/- (0.0 mm +/-)

Wheel base

108.3 in (2,750 mm)

Rear Wheel Alignment

Toe-in

Range

Nominal

Total toe-in (A - B)

-0.12 in - 0.20 in

0.04 in

(-3 - 5 mm)

(1 mm)

Total toe-in angle

-0.27

- 0.43

0.09

(left plus right)

(-0

16’ - 0

26’)

(5' 30”)

Camber
Range

-1.75

- -0.25

(-1

45' - -0

15')

Nominal

-1.00

(-1

00')

Thrust Angle

0.0

+/- (0

00' +/-)

Ball Joint Vertical End Play

0 in (0 mm)

I30 2001 – Quick Reference – Suspension

Front Wheel Bearing
Axial End Play

0.0020 in (0.05 mm) or less

Lock nut torque

188 - 245 ft-lb (26 - 34 kg-m)

Rear Wheel Bearing
Axial End Play

0.0020 in (0.05 mm) or less

Lock nut torque

138 - 188 ft-lb (19 - 26 kg-m)

Wheel Runout

Aluminum Wheel

Max. Lateral Runout:

0.012 in (0.3 mm)

Max. Radial Runout:

0.012 in (0.3 mm)

Wheel arch Height (Unladen)
Equipped with:

Front Height (Hf)

Rear Height (Hf)

215/55 R16 Tires

27.48 in (698 mm)

26.89 in (683 mm)

225/50 R17 Tires

27.80 in (706 mm)

27.32 in (694 mm)

W/Lug Nut Torque

72 - 87 ft-lb (10 - 12 kg-m)

I30 2001 – Quick Reference – Suspension

I30 2001

Quick Reference

Suspension

PRELIMINARY INSPECTION

•

Check tires for wear and proper inflation

•

Check wheel runout

•

Check front wheel bearings excessive play

•

Check front suspension for excessive play

•

Check steering linkage for excessive play

•

Check struts for leakage and condition

•

Check vehicle for proper ride height

Precautions

1. When installing rubber parts, final tightening must be carried out under unladen conditions with

the tires on the ground.

2. Recheck alignment after installing removed suspension components.

I30 2001 – Quick Reference – Brakes

I30 2001

Quick Reference

Brakes

BRAKE SYSTEM

Brake Model Code

Front Disc Brake

Rear Disc Brake

CLZ25VC

CL9HB

Brake Fluid

DOT 3 (Recommended)

Master Cyl. Bore Dia.

15/16 in (23.81 mm)

Cylinder Bore Dia.

2.252 in (57.2 mm)

1.3370 in (33.96 mm)

Brake Pad Dimensions
Length

4.94 in (125.6 mm)

3.508 in (89.1 mm)

Width

1.783 in (45.3 mm)

1.555 in (39.5 mm)

Thickness

0.43 in (11.0 mm)

0.39 in (10.0 mm)

Brake Pad Wear Limit
Min. Thickness

0.079 in (2.0 mm)

0.059 in (1.5 mm)

Brake Rotor Dimensions
Outer Diameter

11.02 in (280.0 mm)

10.94 in (278.0 mm)

Standard Thickness

1.02 in (26.0 mm)

0.35 in (9.0 mm)

Brake Rotor Repair/Wear Limits
Max. Runout

0.0028 in (0.07 mm)

Min. Thickness

0.945 in (24.0 mm)

0.31 in (8.0 mm)

Max. Thickness Variation (at least 8 positions)

0.0004 in (0.01 mm)

0.0008 in (0.02 mm)

Brake Pedal Dimensions

Auto Trans.

Free Height ’H’

6.57 - 6.85 in
(167 - 174 mm)

Depressed Height ’D’

3.248 in (82.5 mm)

Pedal Free Play ’A’
Switch Clearance ’C’

Brake Booster

Model M215T

Output Rod Length

0.4045 - 0.4144 in
(10.275 - 10.525 mm)

Clevis Length

Approx. 5.12 in (130 mm)

Dual Proportioning Valve
Applied Pressure (Front)

1067 psi (75 kg/cm

)

Output Pressure (Rear)

739 - 796 psi (52 - 56 kg/cm

)

Parking Brake Control

Pedal type
No. of Notches 3 - 4
[Under force of 44 lb (20 kg)]

ABS Wheel Sensor Clearance
Front

0.0107 - 0.0364 in (0.273 - 0.925 mm)

Rear

0.0252 - 0.0383 in (0.385 - 0.973 mm)

Resistance

0.8 - 1.85

Ω

Sensor Rotor

0.492 - 0.531 in (12.5 - 13.5 mm)

Wheel Lug Nut

72 - 87 ft lb (10 - 12 kg-m)
