Changing Oil Filter.....................................................18
Changing Spark Plugs...............................................18
Checking EVAP Vapor Lines .....................................20

CHASSIS AND BODY MAINTENANCE .......................21

Checking Exhaust System.........................................21
Checking A/T Fluid ....................................................21
Changing A/T Fluid ....................................................22
Balancing Wheels (Bonding Weight Type) ................22

REMOVAL

...............................................................22

WHEEL BALANCE ADJUSTMENT

............................22

Tire Rotation ..............................................................24
Checking Brake Fluid Level and Leaks.....................24
Checking Brake Lines and Cables ............................24
Checking Disc Brake .................................................24

ROTOR

...................................................................24

CALIPER

.................................................................25

PAD

........................................................................25

Checking Steering Gear and Linkage .......................25

STEERING GEAR

....................................................25

STEERING LINKAGE

...............................................25

Checking Power Steering Fluid and Lines ................25
Lubricating Locks, Hinges and Hood Latches...........26
Checking Seat Belts, Buckles, Retractors,
Anchors and Adjusters...............................................26

SERVICE DATA AND SPECIFICATIONS (SDS) .........27

Engine Maintenance ..................................................27

BELT DEFLECTION AND TENSION

..........................27

SPARK PLUG

..........................................................27

Chassis and Body Maintenance................................27

WHEEL BALANCE

...................................................27

IDX

Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT
PRE-TENSIONER”

NHMA0034

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER” used along with
a seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of
collision. The SRS system composition which is available to INFINITI I30 is as follows (The composition var-
ies according to optional equipment.):

For a frontal collision
The Supplemental Restraint System consists of driver air bag module (located in the center of the steer-
ing wheel), front passenger air bag module (located on the instrument panel on passenger side), seat belt
pre-tensioners, a diagnosis sensor unit, crash zone sensor, warning lamp, wiring harness and spiral cable.

For a side collision
The Supplemental Restraint System consists of front side air bag module (located in the outer side of front
seat), satellite sensor, diagnosis sensor unit (one of components of air bags for a frontal collision), wiring
harness, warning lamp (one of components of air bags for a frontal collision).

Information necessary to service the system safely is included in the RS section of this Service Manual.

WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance should be per-
formed by an authorized INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the RS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified with yellow harness connector (and with
yellow harness protector or yellow insulation tape before the harness connectors).

PRECAUTIONS

Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT BELT PRE-TENSIONER”

MA-2

Special Service Tool

NHMA0002

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

Tool number
(Kent-Moore No.)
Tool name

Description

KV10115801
(J38956)
Oil filter cap wrench

NT375

Removing oil filter
a: 64.3 mm (2.531 in)

Commercial Service Tool

NHMA0003

Tool name
(Kent-Moore No.)

Description

Belt tension gauge
(BT3373-F)

AMA126

Checking drive belt tension

IDX

PREPARATION

Special Service Tool

MA-3

NHMA0004

General maintenance includes those items which should be checked during the normal day-to-day operation
of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform
checks and inspections themselves or have their INFINITI dealers do them.
OUTSIDE THE VEHICLE

The maintenance items listed here should be performed from time to time, unless otherwise specified.

Item

Reference page

Tires

Check the pressure with a gauge periodically when at a service station,
including the spare, and adjust to the specified pressure if necessary. Check
carefully for damage, cuts or excessive wear.

—

Wheel nuts

When checking the tires, make sure no nuts are missing, and check for any
loose nuts. Tighten if necessary.

—

Tire rotation

Tires should be rotated every 12,000 km (7,500 miles).

MA-24

Wheel alignment and
balance

If the vehicle pulls to either side while driving on a straight and level road, or
if you detect uneven or abnormal tire wear, there may be a need for wheel
alignment. If the steering wheel or seat vibrates at normal highway speeds,
wheel balancing may be needed.

MA-22,

SU-7, “Preliminary

Inspection”

Windshield wiper
blades

Check for cracks or wear if they do not wipe properly.

—

Doors and engine
hood

Check that all doors and the engine hood operate smoothly as well as the
trunk lid and back hatch. Also make sure that all latches lock securely. Lubri-
cate if necessary. Make sure that the secondary latch keeps the hood from
opening when the primary latch is released.
When driving in areas using road salt or other corrosive materials, check
lubrication frequently.

MA-26

Lamps

Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and
other lamps are all operating properly and installed securely. Also check
headlamp aim.

—

INSIDE THE VEHICLE

The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the
vehicle, etc.

Item

Reference page

Warning lamps and
chimes

Make sure that all warning lamps and chimes are operating properly.

—

Windshield wiper and
washer

Check that the wipers and washer operate properly and that the wipers do
not streak.

—

Windshield defroster

Check that the air comes out of the defroster outlets properly and in suffi-
cient quantity when operating the heater or air conditioner.

—

Steering wheel

Check that it has the specified play. Be sure to check for changes in the
steering condition, such as excessive play, hard steering or strange noises.
Free play: Less than 35 mm (1.38 in)

—

Seats

Check seat position controls such as seat adjusters, seatback recliner, etc. to
make sure they operate smoothly and that all latches lock securely in every
position. Check that the head restrains move up and down smoothly and that
the locks (if equipped) hold securely in all latched positions. Check that the
latches lock securely for folding-down rear seatbacks.

—

Seat belts

Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters
and retractors) operate properly and smoothly and are installed securely.
Check the belt webbing for cuts, fraying, wear or damage.

MA-26

RS-9, “Seat Belt

Inspection”

Accelerator pedal

Check the pedal for smooth operation and make sure the pedal does not
catch or require uneven effort. Keep the floor mats away from the pedal.

—

Brakes

Check that the brake does not pull the vehicle to one side when applied.

—

GENERAL MAINTENANCE

MA-4
