Symptom
Possible cause
Repair order
Retained power operation does not
operate properly.
1. RAP signal circuit
2. Driver or passenger side door
switch circuit
3. Smart entrance control unit
1. Check RAP signal.
a. (With CONSULT-II)
Check RAP signal with CONSULT-II. Use “ACTIVE
TEST” mode, “RETAINED PWR” in “SMART
ENTRANCE”. (Refer to EL-223.)
If NG, go to the step b. below.
b. Verify 12 positive voltage from smart entrance control
unit is present at terminal 6 of sunroof motor:
I
Within 45 seconds after ignition switch turns off.
I
When front door LH and RH is closed.
2. Check harness between smart entrance control unit
and driver or passenger side door switch.
Check driver or passenger.
Check driver or passenger side door switch.
3. Check smart entrance control unit. (EL-406)
GI
MA
EM
LC
EC
FE
AT
AX
SU
BR
ST
RS
BT
HA
SC
IDX
POWER SUNROOF
Trouble Diagnoses (Cont’d)
EL-225
