SAT195F 7. Install thrust needle bearing on bearing retainer. I Apply petroleum jelly to thrust needle bearing. I Pay attention to direction of thrust needle bearing. SAT030F 8. Install overrun clutch hub. I Apply petroleum jelly to thrust washers. I Align teeth of overrun clutch drive plates before installing. SAT198F 9. Hold forward clutch hub and turn rear internal gear. I If not shown as illustrated, check installed direction of SAT199F 10. Install forward clutch hub and rear internal gear assembly. I Align teeth of forward clutch drive plates before installing. I Check that three hooks of thrust washer are correctly GI MA EM LC EC FE AX SU BR ST RS BT HA SC EL IDX ASSEMBLY Assembly (2) (Cont’d) AT-369 |
