TROUBLE DIAGNOSIS AT-95 D E F G H I J K L M A B AT ● If “NG” appears on the screen, malfunction may exist. Go to Display Items List *: Do not use, but displayed. Diagnostic Procedure Without CONSULT-II NCS000C7 OBD-II SELF-DIAGNOSTIC PROCEDURE (WITH GST) Refer to EC-133, "Generic Scan Tool (GST) Function" OBD-II SELF-DIAGNOSTIC PROCEDURE (NO TOOLS) Refer to EC-62, "Malfunction Indicator Lamp (MIL)" TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS) Description As a method for locating the suspect circuit, when the self-diagnostics start signal is input, the memory for the Operation Procedure 1. CHECK A/T CHECK INDICATOR LAMP 1. Start the engine with selector lever in “P” position. Warm engine to normal operating temperature. 2. Turn ignition switch ON and OFF at least twice, then leave it in the OFF position. 3. Wait 10 seconds. 4. Turn ignition switch ON. (Do not start engine.) Does A/T CHECK indicator lamp come on for about 2 seconds? YES >> GO TO 2. NO AT-181, "A/T CHECK Indicator Lamp Does Not Come On" SCIA5162E DTC work support item Description Check item I/C SOL FUNCTN CHECK* — — FR/B SOL FUNCTN CHECK* — — D/C SOL FUNCTN CHECK* — — HLR/C SOL FUNCTN CHECK* — — LC/B SOL FUNCTN CHECK* — — TCC SOL FUNCTN CHECK Following items for “TCC solenoid function (lock-up) ” can be con- ● Self-diagnosis status (whether the diagnosis is being performed ● Self-diagnosis result (OK or NG) ● TCC solenoid valve ● Hydraulic control circuit |
