Seats & Safety System

Forward and rearward adjustment

• Seat height (2)

To change the height of the seat cushion:

Push the rear portion of the control switch

up to raise or down to lower the height of

the seat cushion.

Release the switch once the seat reaches

the desired position.

Seatback angle adjustment

B3000204

To move the seat forward or rearward:

1. Push the control switch forward or

rearward.

2. Release the switch once the seat

reaches the desired position.

Seat cushion tilt/height adjustment

B3000205

To recline the seatback:

1. Push the control switch forward or

rearward.

2. Release the switch once the seatback

reaches the desired position.

Reclining seatback

Sitting in a reclined position when the

vehicle is in motion can be dangerous.

B3000206

Even when buckled up, the protections of

• Seat cushion tilt (1)

your restraint system (seat belts and

To change the angle of the front part of

airbags) is greatly reduced by reclining

the seat cushion:

your seatback.

Push the front portion of the control

WARNING

switch up to raise or down to lower the

front part of the seat cushion.

NEVER ride with a reclined seatback

when the vehicle is moving.

Release the switch once the seat reaches

the desired position.

Riding with a reclined seatback increases

your chance of serious or fatal injuries in

the event of a collision or sudden stop.

Driver and passengers should ALWAYS sit

well back in their seats, properly belted,

and with the seatbacks upright.

3-8

Seat belts must be snug against your hips

Seatback pocket

and chest to work properly. When the

seatback is reclined, the shoulder belt

cannot do its job because it will not be

snug against your chest. Instead, it will be

in front of you. During an accident, you

could be thrown into the seat belt,

causing neck or other injuries.

The more the seatback is reclined, the

greater chance the passenger’s hips will

slide under the lap belt or the passenger’s

neck will strike the shoulder belt.

B3000222

Lumbar support

The seatback pocket is provided on the

back of the front seatbacks.

CAUTION

Do not put heavy or sharp objects in the

seatback pockets. In an accident they

could come loose from the pocket and

injure occupants.

Rear Seats

B3000207

WARNING

To adjust the lumbar support:

Take the following precautions:

• Press the front portion of the switch (1)

to increase support or the rear portion

• Folding the seats

of the switch (2) to decrease support.

- Do not fold the seatback when the

seat is occupied (for example,

NOTICE

passenger, pets or luggage). It may

Do not continue to operate the lumbar

injure the passenger or pet, or

support when the lumbar support

damage the luggage.

provides its maximum support. Damage

- Never allow passengers to sit on top

to the lumbar support motor could occur.

of the folded down seatback while

the vehicle is moving. This is not a

proper seating position and no seat

belts are available for use. This could

result in serious injury or death in

case of an accident or sudden stop.

- Objects carried on the folded down

seatback should not extend higher

than the top of the front seatbacks.

This could allow cargo to slide

forward and cause injury or damage

during sudden stops.

3-9

Seats & Safety System

- When returning the rear seatback

NOTICE

from a folded to an upright position,

hold the seatback and return it

To prevent damage to the vehicle:

slowly. Ensure that the seatback is

• Rear seat belts

completely locked into its upright

position by pushing on the top of the

Before folding the seatback, insert the

seatback. In an accident or sudden

seat belt buckle in the holder between

stop, the unlocked seatback could

the seatback and cushion. And insert

allow cargo to move forward with

the seat belt webbing in the guide to

great force and enter the passenger

prevent the seat belt from being

compartment, which could result in

damaged.

serious injury or death.

• Cargo

- When folding the seatback, slightly

Be careful when loading cargo through

push the seatback or head restraint

the rear passenger seats to prevent

against the folding direction to

damage to the vehicle interior.

control the folding speed. Without

the push, the seatback may abruptly

fold down and cause injuries when

Folding the rear seats

the lever is pulled.

The rear seatbacks can be folded to

•

Loading cargo

facilitate carrying long items or to

increase the luggage capacity of the

- Make sure the vehicle is off, the gear

vehicle.

shifted to P (Park), and the parking

brake is securely applied whenever

To fold down the rear seatback:

loading or unloading cargo. Failure to

1. Set the front seatback to the upright

take these steps may allow the

position and if necessary, slide the front

vehicle to move if the shift button or

seat forward.

shift dial is inadvertently pressed or

2. Lower the rear head restraints to the

rotated to another position.

lowest position.

- When cargo is loaded through the

rear passenger seats, ensure the

cargo is properly secured to prevent

it from moving while driving.

•

Do not place objects in the rear seats

since they cannot be properly secured

and may hit vehicle occupants in a

collision causing serious injury or

death.

CAUTION

B3000301

Do not allow your hands or fingers to get

caught in the seat mechanisms while

adjusting the seats.

3-10

3. Route the seat belt webbing to the

Armrest

outward of the rear seat to prevent the

belts from being trapped behind or

under the seats.

B3000311

The armrest is located in the center of the

rear seat. Pull the armrest down from the

B3000302

seatback to use it.

4. Fold the seatback toward the front of

the vehicle.

CAUTION

The armrest handle may be pressed when

folding the rear seatback, but it will be

restored after a certain period of time.

Head Restraint

The vehicle’s front and rear seats have

adjustable head restraints. The head

restraints provide comfort for

passengers, but more importantly they

are designed to help protect passengers

B3000303

from whiplash and other neck and spinal

5. To use the rear seat, lift and pull the

injuries during an accident, especially in a

seatback rearward. Pull the seatback

rear impact collision.

firmly until it clicks in to place. Make

sure the seatback is locked in place.

WARNING

To help reduce the risk of serious injury or

death in an accident, take the following

precautions when adjusting your head

restraints:

• Always properly adjust the head

restraints for all passengers BEFORE

starting the vehicle.

• NEVER let anyone ride in a seat with the

head restraint removed or reversed.

B3000305

3-11

Seats & Safety System

• Adjust the head restraints so the middle

CAUTION

of the head restraint is at the same

height as the height of the top of the

When there is no occupant in the rear

eyes.

seats, adjust the height of the head

restraint to the lowest position. The rear

seat head restraint can reduce the

visibility of the rear area.

NOTICE

To prevent damage, NEVER hit or pull on

the head restraints.

OHI039190N

Front seat head restraints

• NEVER adjust the head restraint

position of the driver’s seat when the

vehicle is in motion.

• Adjust the head restraint as close to the

passenger’s head as possible. Do not

use a seat cushion that holds the body

away from the seatback.

• Make sure the head restraint locks into

position after adjusting it.

B3000213

WARNING

The driver’s and front passenger’s seats

are equipped with adjustable head

When sitting in the rear seat, do not adjust

restraints for the passengers safety and

the height of the head restraint to the

comfort.

lowest position.

B3000310

3-12

Adjusting the height up and down

Removal/Reinstallation

Manual adjustment seat

B3000216

B3000217

To raise the head restraint:

Power adjustment seat

1. Pull it up to the desired position (1).

To lower the head restraint:

1. Push and hold the release button (2) on

the head restraint support.

2. Lower the head restraint to the desired

position (3).

NOTICE

B3000218

To remove the head restraint:

1. Recline the seatback (2) with the

seatback angle switch (1).

2. Pull up the head restraint to the upmost

position and press the release button

(3) to remove the head restraint (4).

WARNING

B3000215

If you recline the seatback towards the

NEVER allow anyone to travel in a seat

front with the head restraint and seat

with the head restraint removed.

cushion raised, the head restraint may

come in contact with the sunvisor or

other parts of the vehicle.

3-13

Seats & Safety System

Manual adjustment seat

Rear seat head restraints

B3000219

B3000306

Power adjustment seat

The rear seats are equipped with head

restraints in all the seating positions for

the passenger’s safety and comfort.

Adjusting the height up and down

B3000218_1

To reinstall the head restraint :

1. Recline the seat back by pressing

seatback angle lever or switch (3).

2. Put the head restraint poles (2) into the

B3000307

holes while pressing the release button

To raise the head restraint:

(1).

1. Pull it up to the desired position (1).

3. Adjust the head restraint to the

appropriate height.

To lower the head restraint:

4. Adjust the seatback angle (4) with the

1. Push and hold the release button (2) on

seatback angle switch (3).

the head restraint support.

2. Lower the head restraint to the desired

WARNING

position (3).

Always make sure the head restraint locks

into position after reinstalling and

adjusting it properly.

3-14

Removal/Reinstallation

Seat Warmers

Seat warmers are provided to warm the

seats during cold weather.

During mild weather or under conditions

where the operation of the seat warmer is

not needed, keep the seat warmers off.

WARNING

The seat warmers can cause a SERIOUS

BURN, even at low temperatures and

especially if used for long periods of time.

B3000308

Passengers must be able to feel if the seat

To remove the head restraint:

is becoming too warm so they can turn it

1. Raise the head restraint as far as it can

off, if needed.

go.

Seat warmer consume large amounts of

2. Press the head restraint release button

electricity. Please avoid using seat

(1) while pulling the head restraint up

warmers while the vehicle is off in order

(2).

to prevent battery discharge.

People who cannot detect temperature

change or pain to the skin should use

extreme caution, especially the following

types of passengers:

• Infants, children, elderly or disabled

persons, or hospital outpatients.

• People with sensitive skin or who burn

easily.

• Fatigued individuals.

• Intoxicated individuals.

B3000309

• People taking medication that can

To reinstall the head restraint:

cause drowsiness or sleepiness.

1. Put the head restraint poles into the

holes (2) while pressing the release

button (1).

WARNING

2. Adjust the head restraint to the

NEVER place anything on the seat that

appropriate height.

insulates against heat when the seat

warmer is in operation, such as a blanket

or seat cushion. This may cause the seat

warmer to overheat, causing a burn or

damage to the seat.

3-15

Seats & Safety System

NOTICE

To prevent damage to the seat warmers

and seats:

• Never use a solvent such as paint

thinner, benzene, alcohol or gasoline to

clean the seats.

• Do not place heavy or sharp objects on

seats equipped with seat warmers.

• Do not change the seat cover. It may

damage the seat warmer.

ONE1031080L

To activate seat warmer of each front

seats, touch

icon on the infotainment

Front seat warmers

system. Adjust the temperature by

if equipped

pressing either

icons.

Infotainment system

The seat warmer will automatically stop

when the seat temperature reaches

certain level and will automatically

reactivate when the seat temperature

drops below certain temperature.

• Automatic temperature control

The seat warmer starts to automatically

control the seat temperature in order to

prevent low temperature burns after

being manually turned on.

ONE1031085L

OFF → HIGH ( 3 ) → MEDIUM ( 2 ) → LOW ( 1 )

While the vehicle is running, touch

Heating/Ventilation icon in the

30 min

60 min

infotainment system.

Table_text_Arrow_3-25-2

Climate control panel

You may manually touch the icon to

increase seat temperature. However,

the seat temperature is automatically

adjusted again.

• Auto. Controls That Use Climate

Control Settings (for driver’s seat)

The seat warmer automatically controls

the seat temperature depending on the

ambient temperature when the vehicle

is on (

indicator on).

To use this function, it can be enabled

B3000602

from the Settings menu in the

infotainment system. Select: Setup >

Press

in the front climate control

Vehicle > Seat > Heated/Ventilated

panel.

Features > Auto. Controls That Use

Climate Control Settings > Seat

Warmer/Ventilation

3-16

• The seat warmer defaults to the OFF

• Automatic temperature control

position whenever the Start/Stop

The seat warmer starts to automatically

button is pressed to the ON position.

control the seat temperature in order to

However, if the Auto. Controls That Use

prevent low temperature burns after

Climate Control Settings function is on,

being manually turned on.

the driver’s seat warmer turns on and

OFF → HIGH (

) → LOW (

)

off depending on the ambient

NJO

temperature.

NEW_NE_10

You may manually push the switch to

Information

increase seat temperature. However,

The infotainment system may change

the seat temperature is automatically

after software updates. For more

adjusted again.

information, refer to the user's manual

• The seat warmer defaults to the OFF

provided in the infotainment system and

position whenever the Start/Stop

the quick reference guide.

button is pressed to the ON position.

• The rear seat warmers can be adjusted

from the infotainment system.

Rear seat warmers

if equipped

ONE1031082L

• Touch rear heat icon in the

B3000604

Heating/Ventilation infotainment

• While the vehicle is running, press seat

system.

warmer switches located in each seats

to warm the rear seat.

• The seat warmer will automatically stop

when the seat temperature reaches

certain level and will automatically

reactivate when the seat temperature

drops below certain temperature.

• Manual temperature control

Each time you press the switch, the

temperature setting of the seat is

changed as follows :

ONE1031078L

OFF → HIGH (

) → LOW (

)

To activate seat warmer of each rear

NEW_NE_1

seats, touch

icon on the infotainment

system. Adjust the temperature by

pressing either

icons.

3-17

Seats & Safety System

Front air ventilation seats

Information

if equipped

The infotainment system may change

Infotainment system

after software updates. For more

information, refer to the user's manual

provided in the infotainment system and

the quick reference guide.

Air Ventilation Seats

The air ventilation seats are provided to

cool the front seats by blowing air

through small vent holes on the surface of

the seat cushions and seatbacks.

ONE1031085L

When the operation of the air ventilation

While the vehicle is running, touch

seat is not needed, keep the air

Heating/Ventilation icon in the

ventilation seats off.

infotainment system.

NOTICE

Climate control panel

To prevent damage to the air ventilation

seats:

• Never use a solvent such as paint

thinner, benzene, alcohol or gasoline to

clean the seats.

• Avoid spilling liquids on the surface of

the front seats and seatbacks; this may

cause the air vent holes to block and

not work properly.

• Do not place materials such as plastic

B3000602

bags or newspapers under the seats.

Press

in the front climate control

They may block the air intake causing

panel.

malfunction of the air vent.

• Do not change the seat covers. It may

damage the air ventilation seat.

• If the air vents do not operate, restart

the vehicle. If there is no change, have

the vehicle inspected by an authorized

HYUNDAI dealer.

ONE1031080L

To activate air ventilation of each front

seats, touch

icon on the infotainment

system. Adjust the airflow by pressing

either

icons.

3-18

• If the air ventilation seat is position to

Seat Belts

'HIGH', fan speed increases depending

on the vehicle speed and driving time.

This section describes how to use the seat

belts properly. It also describes some of

• Use the air ventilation seat with the air

the things not to do when using seat belts.

conditioning on for more effective

ventilation.

• It may take 3-5 minutes after switch

Seat Belt Safety Precautions

operation to feel the temperature

Always fasten your seat belt and make

change.

sure all passengers have fastened their

• Auto. Controls That Use Climate

seat belts before starting any trip. Airbags

Control Settings (for driver’s seat)

are designed to supplement the seat belt

The air ventilation seat automatically

as an additional safety device, not a

controls the seat temperature

replacement. Most states require all

depending on the ambient temperature

occupants of a vehicle to wear seat belts.

when the vehicle is on (

indicator

WARNING

on).

To use this function, it can be enabled

Seat belts must be used by ALL

from the Settings menu in the

passengers whenever the vehicle is

infotainment system. Select: Setup >

moving. Take the following precautions

Vehicle > Seat > Heated/Ventilated

when adjusting and wearing seat belts:

Features > Auto. Controls That Use

• Children under the age of 13 should be

Climate Control Settings > Seat

properly restrained in the rear seats.

Warmer/Ventilation

• Never allow children to ride in the front

• The air ventilation seats defaults to the

passenger seat, unless the airbag is

OFF position whenever the Start/Stop

deactivated. If a child is seated in the

button is pressed to the ON position.

front passenger seat, move the seat as

However, if the Auto. Controls That Use

far back as possible. And the child must

Climate Control Settings function is on,

always be restrained in the seat

the driver’s air ventilation seat turns on

properly.

and off depending on the ambient

• NEVER allow an infant or child to be

temperature.

carried on an occupant’s lap.

Information

• NEVER ride with the seatback reclined

when the vehicle is moving.

The infotainment system may change

• Do not allow children to share a seat or

after software updates. For more

seat belt.

information, refer to the user's manual

provided in the infotainment system and

• Do not wear the shoulder belt under

the quick reference guide.

your arm or behind your back.

• NEVER place a seat belt over fragile

objects. If there is a sudden stop or

impact, the seat belt can damage it.

• Do not use the seat belt if it is twisted. A

twisted seat belt will not protect you

properly in an accident.

• Do not use a seat belt if the webbing or

hardware is damaged.

3-19

Seats & Safety System

• Do not latch the seat belt into the

Seat Belt Warning Light

buckles of other seats.

• NEVER unfasten the seat belt while

Driver’s seat belt warning

driving. This may cause loss of vehicle

Instrument cluster

control resulting in an accident.

• Make sure there is nothing in the buckle

interfering with the seat belt latch

mechanism, because any materials in

the buckle can cause the seat belt not

to be fastened securely.

• No modifications or additions should

be made by the user which will either

prohibit the seat belt adjusting devices

from operating to remove slack, or

prohibit the seat belt assembly from

being adjusted to remove slack.

B3001502

As a reminder to the driver, the driver’s

seat belt warning lights will illuminate for

about 6 seconds each time the Start/Stop

WARNING

button is in the ON position regardless of

Damaged seat belts and seat belt

belt fastening. If the seatbelt is not

assemblies will not operate properly.

fastened, the warning chime will sound

Always replace:

for about 6 seconds.

• Frayed, contaminated, or damaged

If you start to drive without the seat belt

webbing.

fastened or you unfasten the seat belt

when you drive under 12 mph (20 km/h) or

• Damaged hardware.

stop, the corresponding warning light will

• The entire seat belt assembly after it

illuminate.

has been worn in an accident, even if

If you start to drive without the seat belt

damage to webbing or assembly is not

fastened or you unfasten the seat belt

apparent.

when you drive 12 mph (20 km/h) and

faster, the warning light will blink and

warning chime will sound for about 100

seconds.

When the seat belt is unfastened during

driving, the warning light will illuminate

when the speed is under 12 mph (20

km/h).

When the speed is 12 mph (20 km/h) and

faster, the warning light will blink and

warning chime will sound for about 100

seconds.

3-20

Front passenger’s seat belt warning

Rear passenger’s seat belt warning

As a reminder to the front passenger, the

front passenger’s seat belt warning lights

will illuminate for about 6 seconds each

time the Start/Stop button is in the ON

position regardless of belt fastening.

If you start to drive without the seat belt

fastened or you unfasten the seat belt

when you drive under 12 mph (20 km/h) or

stop, the corresponding warning light will

illuminate.

If you start to drive without the seat belt

B3001503

fastened or you unfasten the seat belt

when you drive 12 mph (20 km/h) and

For rear left and right side seat

faster, the warning light will blink and

warning chime will sound for about 100

• As a reminder to the rear passenger, the

seconds.

rear passenger’s seat belt warning

lights will illuminate for about 6

When the seat belt is unfastened during

seconds each time the Start/Stop

driving, the warning light will illuminate

button is in the ON position regardless

when the speed is under 12 mph (20

of belt fastening.

km/h). When the speed is 12 mph (20

km/h) and faster, the warning light will

• If you unfasten the seat belt when you

blink and warning chime will sound for

drive under 12 mph (20 km/h), the

about 100 seconds.

corresponding warning light will

continue to illuminate until you fasten

WARNING

the seat belt.

• If you unfasten the seat belt when you

Riding in an improper position adversely

drive 12 mph (20 km/h) and faster, the

affects the front passenger’s seat belt

seat belt warning chime will sound for

warning system. It is important for the

about 35 seconds and the

driver to instruct the passenger to

corresponding warning light will blink.

properly be seated as instructed in this

manual.

• When the seat belt is unfastened during

driving, the warning lights will

illuminate when the speed is under 12

mph (20 km/h).

Information

• When the speed is 12 mph (20 km/h)

• Although the front passenger seat is not

and faster, the warning light will blink

occupied, the seat belt warning light

and warning chime will sound for about

will blink or illuminate for 6 seconds.

35 seconds.

• The front passenger’s seat belt warning

may operate when luggage is placed on

the front passenger seat.

3-21

Seats & Safety System

For rear center seat

Seat Belt Restraint System

•

As a reminder to the rear passenger, the

rear passenger’s seat belt warning

WARNING

lights will illuminate for about 6

seconds each time the Start/Stop

button is in the ON position regardless

of belt fastening.

•

If you unfasten the seat belt when you

drive under 12 mph (20 km/h), the

corresponding warning light will

continue to illuminate for about 70

seconds.

•

If you unfasten the seat belt when you

drive over 12 mph (20 km/h), the seat

belt warning chime will sound for about

B3001505

35 seconds and the corresponding

Improperly positioned seat belts may

warning light will blink.

increase the risk of serious injury in an

accident. Take the following precautions

•

If the rear door is opened under 6 mph

when adjusting the seat belt:

(10 km/h), warning light and warning

sound does not work even if driving

• Position the lap portion of the seat belt

over 12 mph (20 km/h).

as low as possible across your hips, not

on your waist, so that it fits snugly. This

allows your strong pelvic bones to

absorb the force of the crash, reducing

the chance of internal injuries.

• Position one arm under the shoulder

belt and the other over the belt, as

shown in the illustration.

• Always position the shoulder belt

anchor into the locked position at the

appropriate height.

• Never position the shoulder belt across

your neck or face.

3-22

Driver's Seat Belt - 3-point system

Information

with emergency locking retractor

If you cannot smoothly pull the seat belt

To fasten your seat belt:

out from the retractor, firmly pull the seat

belt out and release it. After release, the

belt may be pulled out smoothly.

Height adjustment

You can adjust the height of the shoulder

belt anchor to one of the four different

positions for maximum comfort and

safety.

The shoulder portion should be adjusted

so it lies across your chest and midway

B3001504

over your shoulder nearest the door, not

Pull it out of the retractor and insert the

over your neck.

metal tab (1) into the buckle (2). An

Front seat

audible “click” sounds when the tab locks

into the buckle. Make sure the seat belt is

not twisted.

B3001506

To adjust the height of the seat belt

anchor, lower or raise the height adjuster

B3001501

into an appropriate position.

Place the lap belt (1) portion across your

To raise the height adjuster, pull it up (1).

hips and the shoulder belt (2) portion

To lower it, push it down (3) while

across your chest.

pressing the height adjuster button (2).

The seat belt automatically adjusts to the

Release the button to lock the anchor into

proper length after the lap belt portion is

position. Try sliding the height adjuster to

adjusted manually so that it fits snugly

make sure that it has locked into position.

around your hips.

If you lean forward in a slow, easy motion,

the belt extends and moves with you. If

there is a sudden stop or collision, the belt

is locked in place. It also locks if you try to

lean forward too quickly.

3-23

Seats & Safety System

To release your seat belt:

When the seat belt has been fully

extended from the retractor to allow for

the installation of a child restraint system,

the seat belt operation changes to allow

the belt to retract, but not to extend

(Automatic Locking Retractor Type). For

more information, refer to the “Child

Restraint System (CRS)” section in this

chapter.

To release your seat belt:

B3001507

Press the release button (1) in the locking

buckle.

The belt should automatically draw back

into the retractor. If this does not happen,

check the belt is not twisted, then try

again.

Rear Seat Belts - 3-point system

with convertible locking retractor

B3001507_1

This type of seat belt combines both an

Press the release button (1) in the locking

emergency locking retractor and an

buckle.

automatic locking retractor. Convertible

The belt should automatically draw back

retractor type seat belts are installed in

into the retractor. If this does not happen,

the rear seat positions to help

check the belt is not twisted, then try

accommodate the installation of child

again.

restraint systems.

A convertible retractor is also installed in

Information

the front passenger seat position,

• The emergency locking mode allows

children should always be seated in the

seated passengers to move freely in

rear and never place any infant/child

their seats while keeping some tension

restraint system in the front seat.

on the belt. During a collision or sudden

stop, the retractor automatically locks

To fasten your seat belt:

the belt to help restrain the passengers.

Pull the seat belt out of the retractor and

• To deactivate the automatic locking

insert the metal tab into the buckle. An

mode, unbuckle the seat belt and allow

audible “click” sounds when the tab locks

the belt to fully retract.

into the buckle. Pull the shoulder portion

of the belt to snug the belt across your

hips and remove slack. Make sure the seat

belt is not twisted. When not securing a

child restraint, the seat belt automatically

adjusts to the proper length only after the

lap belt portion of the seat belt is adjusted

manually so that it fits snugly across your

hips.

3-24

Rear center seatbelt (3-point rear

Pretensioner seat belt

center seat belt)

B3001601

ONE1031087L

(1) Retractor Pretensioner

Insert the tongue plate (1) into the buckle

Your vehicle is equipped with driver’s and

until an audible “click" is heard, indicating

front passenger’s and rear passengers

the latch is locked. Pull the shoulder

Pretensioner Seat Belts (Retractor

portion of the belt to snug the belt across

Pretensioner). The purpose of the

your hips and remove slack.

pretensioner is to make sure the seat

Make sure the seat belt is not twisted.

belts fit tightly against the occupant’s

body in certain frontal or side collision(s).

When using the rear center seat belt, use

The Retractor Pretensioner may be

the buckle with the “CENTER” mark.

activated in certain crashes where the

frontal collision(s) is severe enough.

Information

When the vehicle stops suddenly, or if the

If you cannot pull out the safety belt from

occupant tries to lean forward too

the retractor, firmly pull the belt out and

quickly, the seat belt retractor will lock

release it. After release, pull out the belt

into position. In certain frontal or side

smoothly.

collision(s), the pretensioner will activate

and pull the seat belt into tighter contact

against the occupant’s body.

WARNING

If the system senses excessive tension on

the driver or passenger’s seat belt when

Make sure that the seatback is locked in

the pretensioner system activates, the

place when using the rear center seat

load limiter inside the retractor

belt.

pretensioner will release some of the

If not, the seatback may move when there

pressure on the affected seat belt.

is a sudden stop or collision, which could

result in serious injury.

WARNING

• Always wear your seat belt and sit

properly in your seat.

• Do not use the seat belt if it is loose or

twisted. A loose or twisted seat belt will

not protect you properly in an accident.

• Do not place anything near the buckle.

This may adversely affect the buckle

and cause it to function improperly.

3-25

Seats & Safety System

• Always replace your pretensioners after

activation or an accident.

• NEVER inspect, service, repair or

replace the pretensioners yourself.

Have the pretensioners inspected,

serviced, repaired or replaced by an

authorized HYUNDAI dealer.

• Do not hit the seat belt assemblies.

WARNING

ONE1031086L

Do not touch the pretensioner seat belt

The Pretensioner Seat Belt System

assemblies for several minutes after they

consists mainly of the following

have been activated. When the

components. Their locations are shown in

pretensioner seat belt mechanism

the illustration above:

deploys during a collision, the

(1) SRS airbag warning light

pretensioner can become hot and can

(2) Retractor pretensioner

burn you.

(3) SRS control module

(4) Rear retractor pretensioner

NOTICE

CAUTION

The sensor that activates the SRS control

Body work on the front area of the vehicle

module is connected with the

may damage the pretensioner seat belt

pretensioner seat belts. The SRS airbag

system. Therefore, have the system

warning light on the instrument cluster

serviced by an authorized HYUNDAI

will illuminate for about 3-6 seconds after

dealer.

the Start/Stop button is in the ON

position, and then it should turn off.

If the pretensioner is not working

properly, the warning light will illuminate

even if the SRS airbag is not

malfunctioning. If the warning light does

not illuminate, stays illuminated or

illuminates when the vehicle is being

driven, have the pretensioner seat belts

and/or SRS control module inspected by

an authorized HYUNDAI dealer as soon as

possible.

OHL038175L

3-26

Seat belt use and children

Information

• Pretensioner seat belts may be

Infant and small children

activated in certain frontal or side

Most states have Child Restraint System

collisions or rollover situations.

laws which require children to travel in

• When the pretensioner seat belts are

approved Child Restraint System devices,

activated, a loud noise may be heard

including booster seats. The age at which

and fine dust, which may appear to be

seat belts can be used instead of Child

smoke, may be visible in the passenger

Restraint System differs among states, so

compartment. These are normal

you should be aware of the specific

operating conditions and are not

requirements in your state, and where

hazardous.

you are travelling. Infant and Child

Restraint System must be properly placed

• Although it is non-toxic, the fine dust

and installed in a rear seat.

may cause skin irritation and should not

be inhaled for prolonged periods. Wash

For more information refer to the “Child

all exposed skin areas thoroughly after

Restraint System (CRS)” section in this

an accident in which the pretensioner

chapter.

seat belts were activated.

WARNING

ALWAYS properly restrain infants and

Additional Seat Belt Safety

small children in a Child Restraint System

Precautions

appropriate for the child’s height and

weight.

To reduce the risk of serious injury or

Seat belt use during pregnancy

death to a child and other passengers,

The seat belt should always be used

NEVER hold a child in your lap or arms

during pregnancy. The best way to

when the vehicle is moving. The violent

protect your unborn child is to protect

forces created during an accident will tear

yourself by always wearing the seat belt.

the child from your arms and throw the

Pregnant women should always wear a

child against the interior of the vehicle.

lap-shoulder seat belt. Place the shoulder

belt across your chest, routed between

your breasts and away from your neck.

Small children are best protected from

Place the lap belt below your belly so that

injury in an accident when properly

it fits SNUGLY across your hips and pelvic

restrained in the rear seat by a child

bone, under the rounded part of the belly.

restraint system that meets the

requirements of the Federal Motor

WARNING

Vehicle Safety Standards. Before buying

any child restraint system, make sure that

To reduce the risk of serious injury or

it has a label certifying that it meets

death to an unborn child during an

Federal Motor Vehicle Safety Standard

accident, pregnant women should NEVER

FMVSS 213. The restraint must be

place the lap portion of the seat belt

appropriate for your child’s height and

above or over the area of the abdomen

weight. Check the label on the child

where the unborn child is located.

restraint for this information. For more

information, refer to the “Child Restraint

System (CRS)” section in this chapter.

3-27

Seats & Safety System

Larger children

Do not lie down

Children under age 13 and who are too

Sitting in a reclined position when the

large for a booster seat should always

vehicle is in motion can be dangerous.

occupy the rear seat and use the available

Even when buckled up, the protections of

lap/shoulder belts. A seat belt should lie

your restraint system (seat belts and/or

across the upper thighs and be snug

airbags) is greatly reduced by reclining

across the shoulder and chest to restrain

your seatback.

the child safely. Check belt fit

Seat belts must be snug against your hips

periodically. A child’s squirming could put

and chest to work properly.

the belt out of position. In the event of an

During an accident, you could be thrown

accident, children are afforded the best

into the seat belt, causing neck or other

safety restrained by a proper Child

injuries.

Restraint System in the rear seats.

The more the seat back is reclined, the

If a larger child over age 13 must be seated

greater the chance for the passenger’s

in the front seat, the child must be

hips to slide under the lap belt or the

securely restrained by the available

passenger’s neck to strike the shoulder

lap/shoulder belt and the seat should be

belt.

placed in the rearmost position.

If the shoulder belt portion slightly

WARNING

touches the child’s neck or face, try

placing the child closer to the center of

• NEVER ride with a reclined seatback

the vehicle. If the shoulder belt still

when the vehicle is moving.

touches their face or neck, they need to

• Riding with a reclined seatback

be returned to an appropriate booster

increases your chance of serious or

seat in the rear seat.

fatal injuries in the event of a collision or

sudden stop.

WARNING

• Driver and passengers should always sit

• Always make sure larger children’s seat

well back in their seats with the

belts are worn and properly adjusted.

seatbacks upright and should be belted

properly.

• NEVER allow the shoulder belt to

contact the child’s neck or face.

• Do not allow more than one child to use

a single seat belt.

Seat belt use and injured people

A seat belt should be used when an

injured person is being transported.

Consult a physician for specific

recommendations.

One person per belt

Two people (including children) should

never attempt to use a single seat belt.

This could increase the severity of injuries

in case of an accident.

3-28

Care of Seat Belts

Child Restraint System

Seat belt systems should never be

(CRS)

disassembled or modified. In addition,

care should be taken to assure that seat

belts and belt hardware are not damaged

Children Always in the Rear

by seat hinges, doors or other abuse.

WARNING

Periodic inspection

Always properly restrain children in the

All seat belts should be inspected

rear seats of the vehicle. Children of all

periodically for wear or damage of any

ages are safer when restrained in the rear

kind. Any damaged parts should be

seat. A child riding in the front passenger

replaced as soon as possible.

seat can be forcefully struck by an

inflating airbag resulting in SERIOUS

Keep belts clean and dry

INJURY or DEATH.

Seat belts should be kept clean and dry. If

belts become dirty, they can be cleaned

Children under age 13 should always ride

by using a mild soap solution and warm

in the rear seats and must always be

water. Bleach, dye, strong detergents or

properly restrained to minimize the risk of

abrasives should not be used because

injury in an accident, sudden stop or

they may damage and weaken the fabric.

sudden maneuver.

According to accident statistics, children

When to replace seat belts

are safer when properly restrained in the

The entire seat belt assembly or

rear seats than in the front seat. Even with

assemblies should be replaced if the

airbags, children can be seriously injured

vehicle has been involved in an accident.

or killed. Children too large for a Child

This should be done even if no damage is

Restraint System must use the seat belts

visible. Consult an authorized HYUNDAI

provided.

dealer.

All 50 states have child restraint laws

which require children to travel in

approved Child Restraint Systems.

The laws governing the age or

height/weight restrictions at which seat

belts can be used instead of Child

Restraint System differ among states, so

you should be aware of the specific

requirements in your state, and where

you are travelling.

Child Restraint Systems must be properly

placed and installed in the rear seat. You

must use a commercially available Child

Restraint System that meets the

requirements of the Federal Motor

Vehicle Safety Standards (FMVSS 213).

3-29

Seats & Safety System

Child Restraint Systems are generally

Selecting a Child Restraint

designed to be secured in a vehicle seat

System (CRS)

by lap belt portion of a lap/shoulder belt,

When selecting a Child Restraint System

or by a LATCH system in the rear seats of

for your child, always:

the vehicle.

• Make sure the Child Restraint System

has a label certifying that it meets

Child Restraint System (CRS)

applicable Federal Motor Vehicle

Infants and younger children must be

Safety Standards (FMVSS 213).

restrained in an appropriate

• Select a Child Restraint System based

rearward-facing or forward-facing CRS

on your child’s height and weight. The

that has first been properly secured to the

required label or the instructions for use

seat of the vehicle. Read and comply with

typically provide this information.

the instructions for installation and use

provided by the manufacturer of the Child

• Select a Child Restraint System that fits

Restraint System.

the vehicle seating position where it will

be used.

WARNING

• Read and comply with the warnings

and instructions for installation and use

An improperly secured child restraint can

provided with the Child Restraint

increase the risk of SERIOUS INJURY or

System.

DEATH in an accident. Always take the

following precautions when using a Child

Restraint System:

Child Restraint System types

• NEVER install a child or infant restraint

There are three main types of Child

in the front passenger's seat.

Restraint Systems: rearward-facing,

• Always properly secure the child

forward-facing and booster Child

restraint to a rear seat of the vehicle.

Restraint Systems.

• Always follow the child restraint system

They are classified according to the

manufacturer's instructions for

child’s age, height and weight.

installation and use.

• Always properly restrain your child in

the child restraint.

• If the vehicle head restraint prevents

proper installation of a child seat (as

described in the child restraint system

manual), the head restraint of the

respective seating position shall be

readjusted or entirely removed.

• Do not use an infant carrier or a child

safety seat that "hooks" over a

seatback, it may not provide adequate

protection in an accident.

• After an accident, have an authorized

HYUNDAI dealer check the child

restraint system, seat belts, tether

anchors and lower anchors.

3-30

Rearward-facing Child Restraint System

Forward-facing Child Restraint System

B3002201

B3002202

A rearward-facing Child Restraint System

A forward-facing Child Restraint System

provides restraint with the seating

provides restraint for the child’s body

surface against the back of the child. The

with a harness. Keep children in a

harness system holds the child in place,

forward-facing Child Restraint System

and in an accident, acts to keep the child

with a harness until they reach the top

positioned in the Child Restraint Systems

height or weight limit allowed by your

and reduce the stress to the fragile neck

Child Restraint System’s manufacturer.

and spinal cord.

Once your child outgrows the

All children under the age of one year

forward-facing Child Restraint System,

must always ride in a rearward-facing

your child is ready for a booster seat.

Child Restraint System. Convertible and

3-in-1 Child Restraint Systems typically

Booster seats

have higher height and weight limits for

A booster seat is a Child Restraint System

the rearward-facing position, allowing

designed to improve the fit of the

you to keep your child rearward-facing

vehicle’s seat belt system. A booster seat

for a longer period of time.

positions the seat belt so that it fits

Keep using Child Restraint Systems in the

properly over the stronger parts of your

rearward-facing position as long as

child’s body. Keep your children in

children fit within the height and weight

booster seats until they are big enough to

limits allowed by the Child Restraint

fit in a seat belt properly.

System’s manufacturer. It’s the best way

For a seat belt to fit properly, the lap belt

to keep them safe.

must lie comfortable across the upper

Once your child has outgrown the

thighs, not the stomach. The shoulder

rearward-facing Child Restraint System,

belt should lie comfortable across the

your child is ready for a forward-facing

shoulder and chest and not across the

Child Restraint System with a harness.

neck or face. Children under age 13 must

always be properly restrained to minimize

WARNING

the risk of injury in an accident, sudden

stop or sudden maneuver.

NEVER install a child or infant restraint in

the front passenger's seat.

Placing a rearward-facing child restraint

in the front seat can result in SERIOUS

INJURY or DEATH if the child restraint is

struck by an inflating airbag.

3-31

Seats & Safety System

Installing a Child Restraint

• Make sure the Child Restraint System

is firmly secured. After installing a

System (CRS)

Child Restraint System to the vehicle,

push and pull the seat forward and from

WARNING

side-to-side to verify that it is securely

Before installing your Child Restraint

attached to the seat. A Child Restraint

System always:

System secured with a seat belt should

Read and follow the instructions provided

be installed as firmly as possible.

by the manufacturer of the Child

However, some side-to-side

Restraint System.

movement can be expected. When

installing a Child Restraint System,

Failure to follow all warnings and

adjust the vehicle seat and seatback

instructions could increase the risk of the

(up and down, forward and rearward)

SERIOUS INJURY or DEATH if an accident

so that your child fits in the Child

occurs.

Restraint System in a comfortable

manner.

• Secure the child in the Child Restraint

WARNING

System. Make sure the child is properly

strapped in the Child Restraint System

If the vehicle head restraint prevents

according to the Child Restraint System

proper installation of a Child Restraint

manufacturer’s instructions.

System, the head restraint of the

respective seating position shall be

CAUTION

readjusted or entirely removed.

A Child Restraint System in a closed

vehicle can become very hot. To prevent

After selecting a proper Child Restraint

burns, check the seating surface and

System for your child and checking that

buckles before placing your child in the

the Child Restraint System fits properly

Child Restraint System.

on the seating position, there are three

general steps for a proper installation:

• Properly secure the Child Restraint

System to the vehicle. All Child

Restraint Systems must be secured to

the vehicle with the lap belt or lap part

of a lap/shoulder belt or with the lower

anchor and/or tether anchor and/or

with the support leg.

3-32

Lower Anchors and Tether for

WARNING

Children (LATCH System)

The LATCH system holds a Child Restraint

Do not attempt to install a Child Restraint

System during driving and in an accident.

System using LATCH anchors in the rear

This system is designed to make

center seating position. There are no

installation of the Child Restraint System

LATCH anchors provided for this seat.

easier and reduce the possibility of

Using the outboard seat anchors can

improperly installing your Child Restraint

damage the anchors which may break or

System. The LATCH system uses anchors

fail in a collision resulting in serious injury

in the vehicle and attachments on the

or death.

Child Restraint System. The LATCH

system eliminates the need to use seat

belts to secure the Child Restraint System

to the rear seats.

Lower anchors are metal bars built into

the vehicle. There are two lower anchors

for each LATCH seating position that will

accommodate a Child Restraint System

with lower attachments.

To use the LATCH system in your vehicle,

you must have a Child Restraint System

with LATCH attachments.

The Child Restraint System manufacturer

B3002211

will provide you with instructions on how

[A] Lower Anchor Position Indicator

to use the Child Restraint System with its

[B] Lower Anchor

attachments for the LATCH anchorages.

The lower anchor position indicator

symbols are located on the left and right

rear seat backs to identify the position of

the lower anchors in your vehicle (see

arrows in illustration).

The LATCH anchors are located between

the seatback and the seat cushion of the

rear seat left and right outboard seating

positions.

WARNING

Before installing the Child Restraint

B3002210

System, make sure that there are no

LATCH anchors have been provided in the

objects (for example, toy, pen, wire)

left and right outboard rear seating

around the lower anchor area. Those

positions. Their locations are shown in the

objects may damage either the seat belt

illustration. There are no LATCH anchors

system or the Child Restraint System

provided for the center rear seating

during the installment procedure. If

position.

necessary, have the vehicle inspected by

an authorized HYUNDAI dealer.

3-33

Seats & Safety System

Securing a Child Restraint System

NOTICE

with the “LATCH Anchors System”

To install a LATCH-compatible Child

Make sure that the combined weight of

Restraint System in either of the rear

the child and the child restraint system is

outboard seating positions:

less than 65 lbs. (30 kg) for each LATCH

system.

1. Move the seat belt buckle away from

the lower anchors.

2. Move any other objects away from the

Securing a Child Restraint System

anchorages that could prevent a secure

seat with “Top-tether Anchorage”

connection between the Child Restraint

system

System and the lower anchors.

3. Place the Child Restraint System on the

vehicle seat, then attach the seat to the

lower anchors according to the

instructions provided by the Child

Restraint System manufacturer.

4. Follow the instructions of the Child

Restraint System’s manufacturer for

proper installation and connection of

the lower attachments on the Child

Restraint System to the lower anchors.

B3002208

WARNING

First secure the child restraint with the

Take the following precautions when

LATCH lower anchors or the seat belt. If

using the LATCH system:

the child restraint manufacturer

recommends that the top tether strap be

• Read and follow all installation

attached, attach and tighten the top

instructions provided with your Child

tether strap to the top tether strap

Restraint System.

anchor.

• To prevent the child from reaching and

Child restraint hook holders are located

taking hold of unretracted seat belts,

on the rear of the seatbacks.

buckle all unused rear seat belts and

retract the seat belt webbing behind

WARNING

the child. Children can be strangled if a

shoulder belt becomes wrapped

Take the following precautions when

around their neck and the seat belt

installing the top-tether:

tightens.

• Read and follow all installation

• NEVER attach more than one Child

instructions provided with your Child

Restraint System to a single anchorage.

Restraint System.

This could cause the anchor or

• NEVER attach more than one Child

attachment to come loose or break.

Restraint System to a single tether

• Always have the LATCH system

anchor. This could cause the anchorage

inspected by your dealer after an

or attachment to come loose or break.

accident. An accident can damage the

• Do not attach the tether strap to

LATCH system and may not properly

anything other than the correct

secure the Child Restraint System.

top-tether anchor. It may not work

properly if attached to something else.

3-34

• Child Restraint System anchors are

Securing a Child Restraint System with a

designed to withstand only those loads

lap/shoulder belt

imposed by correctly fitted Child

When not using the LATCH system, all

Restraint System.

Child Restraint Systems must be secured

Under no circumstances are the

to a rear seat with the lap part of a

anchors to be used for adult seat belts

lap/shoulder belt.

or harnesses or for attaching other

items or equipment to the vehicle.

WARNING

ALWAYS place a rearward-facing Child

Restraint System in the rear seat of the

vehicle.

Placing a rearward-facing child restraint

in the front seat can result in serious injury

or death if the Child Restraint System is

struck by an inflating airbag.

Automatic locking mode

Since all passenger seat belts move freely

under normal conditions and only lock

under extreme or emergency conditions

B3002209

(emergency locking mode), you must

To install the tether anchor:

manually pull the seat belt all the way out

1. Route the Child Restraint System

to shift the retractor to the "Automatic

top-tether strap over the seatback.

Locking" mode to secure a Child Restraint

Route the tether strap under the head

System.

restraint and between the head

The "Automatic Locking" mode will help

restraint posts, or route the tether strap

prevent the normal movement of the

over the top of the vehicle seatback.

child in the vehicle from causing the seat

Make sure the strap is not twisted.

belt to loosen and compromise the Child

2. Connect the tether strap hook to the

Restraint System. To secure a Child

tether anchor, then tighten the

Restraint System, use the following

top-tether strap according to the

procedure.

instructions of your Child Restraint

System’s manufacturer to firmly attach

the Child Restraint System to the seat.

3. Check that the Child Restraint System

is securely attached to the seat by

pushing and pulling the seat

forward-and-back and side-to-side.

3-35

Seats & Safety System

To install a Child Restraint System on the

rear seats, do the following:

1. Place the Child Restraint System on a

rear seat and route the lap/shoulder

belt around or through the Child

Restraint System, following the Child

Restraint System manufacturer’s

instructions. Make sure the seat belt

webbing is not twisted.

Information

B3002207

When using the rear center seat belt,

you should also refer to the "Rear Seat

3. Pull the shoulder portion of the seat belt

Belts - 3-point system with convertible

all the way out. When the shoulder

locking retractor" section in this

portion of the seat belt is fully

chapter.

extended, it will shift the retractor to

the "Automatic Locking" (child

restraint) mode.

4. Slowly allow the shoulder portion of the

seat belt to retract and listen for an

audible "clicking" or "ratcheting"

sound. This indicates that the retractor

is in the "Automatic Locking" mode. If

no distinct sound is heard, repeat steps

3 and 4.

5. Remove as much slack from the belt as

possible by pushing down on the Child

Restraint System while feeding the

shoulder belt back into the retractor.

B3002204

6. Push and pull on the Child Restraint

2. Fasten the lap/shoulder belt latch into

System to confirm that the seat belt is

the buckle. Listen for the distinct “click”

holding it firmly in place. If it is not,

sound.

release the seat belt and repeat steps 2

through 6.

Information

7. Double check that the retractor is in the

Position the release button so that it is

"Automatic Locking" mode by

easy to access in case of an emergency.

attempting to pull more of the seat belt

out of the retractor. If you cannot, the

retractor is in the "Automatic Locking"

mode.

If your Child Restraint System

manufacturer instructs or recommends

you to use a tether anchor with the lap/

shoulder belt, refer to the "Installing a

Child Restraint System (CRS)" section in

this chapter.

3-36

Information

When the seat belt is allowed to retract to

its fully stowed position, the retractor will

automatically switch from the “Automatic

Locking” mode to the emergency lock

mode for normal adult usage.

WARNING

If the retractor is not in the “Automatic

Locking” mode, the child restraint can

move when your vehicle turns or stops

suddenly. A child can be seriously injured

or killed if the child restraint is not

properly anchored in the car, including

manually pulling the seat belt all the way

out to shift the retractor to the

“Automatic Locking” mode.

To remove the Child Restraint System,

press the release button on the buckle

and then pull the lap/shoulder belt out of

the Child Restraint System and allow the

seat belt to retract fully.

3-37

Your vehicle is equipped with a Supplemental Airbag System for the driver’s seat and

front passenger’s seats.

The front airbags are designed to supplement the three-point seat belts. For these

airbags to provide protection, the seat belts must be worn at all times when driving.

You can be severely injured or killed in an accident if you are not wearing a seat belt.

Airbags are designed to supplement seat belts, but do not replace them. Also, airbags are

not designed to deploy in every collision. In some accidents, the seat belts are the only

restraint protecting you.

WARNING

AIRBAG SAFETY PRECAUTIONS

ALWAYS use seat belts and Child Restraint Systems - every trip, every time, everyone!

Even with airbags, you can be seriously injured or killed in a collision if you are improperly

belted or not wearing your seat belt when the airbag inflates.

NEVER place a child in any Child Restraint System or booster seat in the front passenger

seat, unless the airbag is deactivated.

An inflating airbag could forcefully strike the infant or child causing serious or fatal

injuries.

ABC - Always Buckle Children under age 13 in the back seat. It is the safest place for

children of any age to ride. If a child age 13 or older must be seated in the front seat, he

or she must be properly belted and the seat should be moved as far back as possible.

All occupants should sit upright with the seatback in an upright position, centered on the

seat cushion with their seat belt on, legs comfortably extended and their feet on the floor

until the vehicle is parked and the vehicle is turned off. If an occupant is out of position

during an accident, the rapidly deploying airbag may forcefully contact the occupant

causing serious or fatal injuries.

You and your passengers should never sit or lean unnecessarily close to the airbags or

lean against the door or center console.

Move your seat as far back as possible from front airbags, while still maintaining control

of the vehicle. The U.S. National Highway Traffic Safety Administration (NHTSA)

recommends that drivers allow at least 10 in. (25 cm) between the center of the steering

wheel and the chest.

3-39

Seats & Safety System

Where are the Airbags?

The seat belt buckle sensors determine if

the driver and front passenger's seat belts

are fastened. These sensors provide the

Driver’s and passenger’s front

ability to control the SRS deployment

airbags

based on whether or not the seat belts are

Driver’s front airbag

fastened, and how severe the impact is.

The advanced SRS offers the ability to

control the airbag inflation within two

levels. A first stage level is provided for

moderate-severity impacts. A second

stage level is provided for more severe

impacts.

According to the impact severity, and

seat belt usage, the SRS Control Module

(SRSCM) controls the airbag inflation.

Failure to properly wear seat belts can

increase the risk or severity of injury in an

B3002801

accident.

Passenger’s front airbag

WARNING

To reduce the risk of serious injury or

death from inflating front airbags, take

the following precautions:

• Seat belts must be worn at all times to

help keep occupants positioned

properly.

• Move your seat as far back as possible

from front airbags, while still

maintaining control of the vehicle.

B3003001

Your vehicle is equipped with a

• Never lean against the door or center

Supplemental Restraint System (SRS) and

console.

lap/shoulder belts at both the driver and

• Do not allow the front passenger to

passenger seating positions.

place their feet or legs on the

The SRS consists of airbags which are

dashboard.

located in the center of the steering

• Never place any objects (such as

wheel and the passenger’s side front

dashboard cover, mobile phone holder,

panel pad above the glove box.

cup holder, perfume or stickers) over or

The airbags are labeled with the letters

near the airbag modules on the steering

“AIRBAG” embossed on the pad covers.

wheel, instrument panel, windshield

glass, and the front passenger’s panel

The purpose of the SRS is to provide the

above the glove box. Such objects may

vehicle’s driver and front passengers with

cause harm if the vehicle is in a collision

additional protection than that offered by

severe enough to cause the airbags to

the seat belt system alone in case of a

deploy.

frontal impact of sufficient severity.

• Do not attach any objects on the front

windshield and inside mirror.

3-40

Side airbags

For vehicles equipped with a rollover

Side airbag

sensor the side and/or curtain airbags and

pretensioners on both sides of the vehicle

may deploy if a rollover or possible

rollover is detected.

The side airbags are not designed to

deploy in all side impact or rollover

situations.

WARNING

To reduce the risk of serious injury or

death from an inflating side airbag, take

the following precautions:

B3003202

•

Seat belts must be worn at all times to

help keep occupants positioned

properly.

•

Do not allow passengers to lean their

heads or bodies onto doors, put their

arms on the doors, stretch their arms

out of the window, or place objects

between the doors and seats.

•

Hold the steering wheel at the 9 o’clock

and 3 o’clock positions, to minimize the

risk of injuries to your hands and arms.

B3003203

•

Do not use any accessory seat covers.

Your vehicle is equipped with a side

This could reduce or prevent the

airbag in each front seat. The purpose of

effectiveness of the system.

the airbag is to provide the vehicle’s

•

Do not hang other objects except

driver and the front passenger with

clothes. In an accident it may cause

additional protection than that offered by

vehicle damage or personal injury

the seat belt alone.

especially when airbag is inflated.

The side airbags are designed to deploy

•

Do not place any objects over the

during certain side impact collisions,

airbag or between the airbag and

depending on the crash severity, angle,

yourself. Also, do not attach any objects

speed and point of impact.

around the area the airbag inflates such

The side airbags on both sides of the

as the door, side door glass, front and

vehicle are designed to deploy when a

rear pillar.

rollover is detected by a rollover sensor.

•

Do not place any objects between the

(if equipped with rollover sensor)

door and the seat. They may become

The side airbags are not designed to

dangerous projectiles if the side airbag

deploy in all side impact or rollover

inflates.

situations.

•

Do not install any accessories on the

The side airbags are designed to deploy

side or near the side airbags.

during certain side impact collisions,

•

Do not impact the doors when the

depending on the crash severity.

Start/Stop button is in the ON or START

position as this may cause the side

airbags to inflate.

3-41

Seats & Safety System

• If the seat or seat cover is damaged,

The curtain airbags are not designed to

have the system serviced by an

deploy in all side impact or rollover

authorized HYUNDAI dealer.

situations.

WARNING

Curtain airbags

To reduce the risk of serious injury or

death from an inflating curtain airbag,

take the following precautions:

•

All occupants must wear seat belts at all

times to help keep occupants

positioned properly.

•

Properly secure Child Restraint System

as far away from the door as possible.

•

Do not place any objects over the

airbag. Also, do not attach any objects

around the area the airbag inflates such

B3003301

as the door, side door glass, front and

rear pillar, roof side rail.

•

Do not hang other objects except

clothes, especially hard or breakable

objects.

In an accident, it may cause vehicle

damage or personal injury.

•

Do not allow passengers to lean their

heads or bodies onto doors, put their

arms on the doors, stretch their arms

out of the window, or place objects

between the doors and seats.

B3003302

•

Do not attempt to open or repair the

Curtain airbags are located along both

side curtain airbags yourself. If

sides of the roof rails above the front and

necessary, have the airbag inspected

rear doors.

by an authorized HYUNDAI dealer.

They are designed to help protect the

heads of the front seat occupants and the

rear outboard seat occupants in certain

side impact collisions.

The curtain airbags are designed to

deploy during certain side impact

collisions, depending on the crash

severity.

For vehicles equipped with a rollover

sensor the side and/or curtain airbags and

pretensioners on both sides of the vehicle

may deploy if a rollover or possible

rollover is detected.

3-42

How does the Airbags System

SRS warning light

Operate?

B3002501

The SRS (Supplemental Restraint System)

airbag warning light on the instrument

cluster the airbag symbol depicted in the

A3002401

illustration. The system checks the airbag

The SRS consists of the following

electrical system for malfunctions. The

components:

light indicates that there is a potential

(1) Driver’s front airbag module

problem with your airbag system, which

(2) Passenger’s front airbag module

could include your side and/or curtain

(3) Side airbag modules

airbags used for rollover protection.

(4) Curtain airbag modules

WARNING

(5) Retractor pretensioner

(6) Airbag warning light

If your SRS malfunctions, the airbag may

(7) SRS control module

not inflate properly during an accident

(SRSCM)/Rollover sensor

increasing the risk of serious injury or

(8) Front impact sensors

death.

(9) Side impact sensors (acceleration)

If any of the following conditions occur,

(10)Side impact sensors (pressure)

your SRS is malfunctioning:

(11) Occupant classification system

• The light does not turn on for about 3-6

(12)Driver’s and front passenger’s seat

seconds when the Start/Stop button is

belt buckle sensors.

in the ON position.

The SRSCM (Supplemental Restraint

• The light stays on after illuminating for

System Control Module) continually

about three to 6 seconds.

monitors all SRS components while the

• The light comes on while the vehicle is

Start/Stop button is ON to determine if a

in motion.

crash impact is severe enough to require

• The light blinks when the

(ready

airbag deployment or pretensioner seat

indicator) is displayed on the

belt deployment.

instrument cluster.

Have an authorized HYUNDAI dealer

inspect the SRS as soon as possible if any

of these conditions occur.

3-43

Seats & Safety System

During a moderate to severe frontal

• To help provide protection, the airbags

collision, sensors will detect the vehicle’s

must inflate rapidly. The speed of

rapid deceleration. If the rate of

airbag inflation is a consequence of

deceleration is high enough, the control

extremely short time in which to inflate

unit will inflate the front airbags, at the

the airbag between the occupant and

time and with the force needed.

the vehicle structures before the

occupant impacts those structures.

The front airbags help protect the driver

This speed of inflation reduces the risk

and front passenger by responding to

of serious or life-threatening injuries

frontal impacts in which seat belts alone

and is thus a necessary part of airbag

cannot provide adequate restraint. When

design.

needed, the side airbags help provide

protection in the event of a side impact or

However, the rapid airbag inflation can

rollover by supporting the side upper

also cause injuries which can include

body area.

facial abrasions, bruises and broken

bones because the inflation speed also

•

Airbags are activated (able to inflate if

causes the airbags to expand with a

necessary) only when the Start/Stop

great deal of force.

button is in the ON or START position,

and it can be activated within about 3

• There are even circumstances under

minutes after the vehicle is turned off.

which contact with the airbag can

cause fatal injuries, especially if the

•

Airbags inflate in the event of certain

occupant is positioned excessively

frontal or side collisions to help protect

close to the airbag.

the occupants from serious physical

injury.

You can take steps to reduce the risk of

being injured by an inflating airbag. The

•

Generally, airbags are designed to

greatest risk is sitting too close to the

inflate based upon the severity of a

airbag. An airbag needs about 10 in. (25

collision, its direction, or etc. These two

cm) of space to inflate. NHTSA

factors determine whether the sensors

recommends that drivers allow at least 10

produce an electronic

in. (25 cm) between the center of the

deployment/inflation signal.

steering wheel and the chest.

•

The front airbags will completely inflate

and deflate in an instant. It is virtually

WARNING

impossible for you to see the airbags

inflate during an accident. It is much

To reduce the risk of serious injury or

more likely that you will simply see the

death from an inflating airbag, take the

deflated airbags hanging out of their

following precautions:

storage compartments after the

• NEVER place a child restraint in the

collision.

front passenger seat.

•

In addition to inflating in serious side

Always properly restrain children under

collisions, vehicles equipped with a

age 13 in the rear seats of the vehicle.

rollover sensor, side and/or curtain

• Adjust the front passenger’s and

airbags will inflate if the sensing system

driver's seats as far to the rear as

detects a rollover.

possible while allowing you to maintain

When a rollover is detected, curtain

full control of the vehicle.

airbags will remain inflated longer to

• Hold the steering wheel with hands at

help provide protection from ejection,

the 9 o'clock and 3 o'clock positions.

especially when used in conjunction

with the seat belts. (if equipped with a

rollover sensor)

3-44

• Never place anything or anyone

A fully inflated airbag, in combination

between the airbag and the seat

with a properly worn seat belt, slows the

occupant.

driver’s or the front passenger’s forward

motion, reducing the risk of head and

• Do not allow the front passenger to

chest injury.

place their feet or legs on the

dashboard.

Driver’s front airbag (3)

Driver’s front airbag (1)

OLMB033056

Passenger’s front airbag

OLMB033054

When the SRSCM detects a sufficiently

severe impact to the front of the vehicle,

it will automatically deploy the front

airbags.

Driver’s front airbag (2)

OLMB033057

After complete inflation, the airbag

immediately starts deflating, enabling the

driver to maintain forward visibility and

the ability to steer or operate other

controls.

OLMB033055

Upon deployment, tear seam molded

directly into the pad cover will separate

under pressure from the expansion of the

airbags. Further opening of the covers

allows full inflation of the airbags.

3-45

Seats & Safety System

Noise and smoke from inflating

WARNING

airbag

To prevent objects from becoming

When the airbags inflate, they make a

dangerous projectiles when the

loud noise and may produce smoke and

passenger’s airbag inflates:

powder in the air inside of the vehicle.

• Do not install or place any objects (drink

This is normal and is a result of the

holder, CD holder, stickers, etc.) on the

ignition of the airbag inflator. After the

front passenger’s panel above the

airbag inflates, you may feel substantial

glove box where the passenger’s airbag

discomfort in breathing because of the

is located.

contact of your chest with both the seat

belt and the airbag, as well as from

• Do not install a container of liquid air

breathing the smoke and powder. The

freshener near the instrument cluster or

powder may aggravate asthma for some

on the instrument panel surface.

people. If you experience breathing

problems after an airbag deployment,

seek medical attention immediately.

What to Expect After an

Though the smoke and powder are

Airbag Inflates

nontoxic, they may cause irritation to the

After a frontal or side airbag inflates, it will

skin, eyes, nose, throat, etc. If this is the

deflate very quickly. Airbag inflation will

case, wash and rinse with cold water

not prevent the driver from seeing out of

immediately and seek medical attention if

the windshield or being able to steer.

the symptoms persist.

Curtain airbags may remain partially

inflated for some time after they deploy.

Occupant Classification

WARNING

System (OCS)

After an airbag inflates, take the following

precautions:

• Open your windows and doors as soon

as possible after impact to reduce

prolonged exposure to the smoke and

powder released by the inflating airbag.

• Do not touch the airbag storage area’s

internal components immediately after

an airbag has inflated. The parts that

come into contact with an inflating

airbag may be very hot.

B3003102

• Always wash exposed skin areas

Your vehicle is equipped with an

thoroughly with cold water and mild

Occupant Classification System (OCS) in

soap.

the front passenger’s seat.

• Have an authorized HYUNDAI dealer

replaced the airbag immediately after

deployment. Airbags are designed to

be used only once.

3-46

Main components of the Occupant

You will find the “PASSENGER AIRBAG

Classification System

OFF” indicator on the overhead console

panel. This system detects the conditions

• A detection device located within the

1-4 in the following table and activates or

front passenger seat cushion.

deactivates the front passenger airbag

• Electronic system to help determine

based on these conditions.

whether the passenger airbag systems

Always be sure that you and all vehicle

should be activated or deactivated.

occupants are seated properly and

• An indicator light located on the

wearing the seat belt properly for the

overhead console which illuminates the

most effective protection by the airbag

words “PASSENGER AIRBAG OFF”

and the seat belt.

indicating the front passenger airbag

The OCS may not function properly if the

system is deactivated.

passenger takes actions which can affect

• The instrument cluster airbag indicator

the classification system. These include:

light is interconnected with the OCS.

• Failing to sit in an upright position.

The OCS is designed to help detect the

• Leaning against the door or center

presence of a properly-seated front

console.

passenger and determine if the

passenger’s front airbag should be

• Sitting towards the sides of the front of

enabled (may inflate) or not.

the seat.

The purpose is to help reduce the risk of

• Putting their legs on the dashboard or

injury or death from an inflating airbag to

resting them on other locations which

certain front passenger seat occupants,

reduce the passenger weight on the

such as children, by requiring the airbag

front seat.

to be automatically turned off.

• Wearing the seat belt improperly.

For example, if a child restraint of the type

• Reclining the seatback.

specified in the regulations is on the seat,

• Wearing thick clothing like ski wear or

the occupant classification sensor can

hip protection wear.

detect it and cause the airbag to turn off.

• Putting an additional thick cushion on

Front passenger seat adult occupants

the seat.

who are properly seated and wearing the

seat belt properly, should not cause the

• Putting electrical devices (for example,

passenger airbag to be automatically

notebook, satellite radio) on the seat

turned off. For smaller adults it may turn

with inverter charging.

off, however, if the occupant does not sit

in the seat properly (for example, by not

sitting upright, by sitting on the edge of

the seat, or by otherwise being out of

position), this could cause the sensor to

turn the airbag off.

3-47

Seats & Safety System

Condition and operation in the front passenger Occupant Classification System

Indicator/Warning Light

Devices

Condition Detected by the

“PASSENGER

Occupant Classification System

SRS Warning

Front Passenger

AIRBAG OFF”

Light

Airbag

Indicator Light

Adult ^*1

Off

Activated

Infant ^*2 or child restraint system

Off

Deactivated

with 12 months old ^*3*4

Unoccupied

Off

Deactivated

Malfunction in the system

Off

Activated

*1 The system judges a person of adult size as an adult. When a smaller adult sits in the front passenger seat, the

system may recognize him/her as a child depending on his/her physique and posture.

*2 Do not allow children to ride in the front passenger seat. When a larger child who has outgrown a child restraint

system sits in the front passenger seat, the system may recognize him/her as an adult depending upon his/her

physique or sitting position.

*3 Never install a child restraint system on the front passenger seat.

*4 The PASSENGER AIRBAG “OFF” indicator may turn on or off when a child above 12 months to 12 years old (with

or without child restraint system) sits in the front passenger seat. This is a normal condition.

3-48

Seats & Safety System

• NEVER lean on the door or center

• Do not place electronic devices such as

console or sit on one side of the front

laptops, DVD player, or conductive

passenger seat.

materials such as water bottles on the

passenger seat. Do not use electronic

devices such as laptops and satellite

radios which use inverter chargers.

B3003109

• Do not sit on the passenger seat

wearing heavily padded clothes such as

ski wear or hip protector.

B3003111

• If large quantity of liquid has been

spilled on the passenger seat, the

airbag warning light may illuminate or

malfunction. Therefore, make sure the

seat has been completely dried before

driving the vehicle.

B3003110

• Do not use car seat accessories such as

thick blankets and cushions which

cover up the car seat surface.

B3003113

• Do not place sharp objects on the front

passenger seat. These may damage the

occupant detection system, if they

puncture the seat cushion.

• Do not place any items under the front

passenger seat.

B3003112

3-50

• When changing or replacing the seat

WARNING

only use Genuine Hyundai Parts. The

OCS has been developed based on

NEVER allow an adult passenger to ride in

using original HYUNDAI car seats only.

the front passenger seat when the

Altering or changing the authentic parts

“PASSENGER AIRBAG OFF” indicator is

may result in system malfunction and

illuminated. During a collision, the airbag

increase risk of injury when in collision.

will not inflate if the indicator is

Any of the above could interfere with

illuminated. Have your passenger

the proper operation of the OCS sensor

reposition themselves in the seat. If the

thereby increasing the risk of an injury

“PASSENGER AIRBAG OFF” indicator

in an accident.

remains illuminated after the passenger

repositions themselves properly and the

vehicle is restarted, have the passenger

Proper seated position for OCS

move to the rear seat because the airbag

will not inflate.

NOTICE

The “PASSENGER AIRBAG OFF” indicator

generally illuminates for about 4 seconds

after the Start/Stop button is in the ON or

START position. But, if the Start/Stop

button is pressed to the ON or START

position within 3 minutes after the vehicle

B3003103

is turned OFF, the indicator does not

If the “PASSENGER AIRBAG OFF”

illuminate. If the front passenger seat is

indicator is on when an adult is seated in

occupied, the OCS will then classify the

the front passenger seat, place the

front passenger after several more

Start/Stop button in the OFF position and

seconds.

ask the passenger to sit properly (sitting

upright with the seat back in an upright

position, centered on the seat cushion

with their seat belt on, legs comfortably

extended and their feet on the floor).

Restart the vehicle and have the person

remain in that position. This will allow the

system to detect the person and to enable

the passenger airbag. If the “PASSENGER

AIRBAG OFF” indicator is still on, ask the

passenger to move to the rear seat.

3-51

Seats & Safety System

Do not install a Child Restraint

Airbag collision sensors

System on the Front Passenger’s

Seat

WARNING

To reduce the risk of an airbag deploying

unexpectedly and causing serious injury

or death:

•

Do not hit or allow any objects to

impact the locations where airbags or

sensors are installed.

•

Do not perform maintenance on or

around the airbag sensors. If the

location or angle of the sensors is

altered, the airbags may deploy when

they should not or may not deploy

B3002401

when they should.

Even though your vehicle is equipped

•

Installing bumper guards with

with the OCS, never install a child

non-genuine Hyundai parts may

restraint in the front passenger’s seat. An

adversely affect the collision and airbag

inflating airbag can forcefully strike a

deployment performance.

child or child restraint resulting in serious

or fatal injury.

To ensure correct function of the airbag

system, have the bumper replaced with

WARNING

genuine Hyundai part specified for your

vehicle.

NEVER use a rearward facing Child

Restraint on a seat protected by an

•

Press the Start/Stop button to the OFF

ACTIVE AIRBAG in front of it, DEATH or

or ACC position and wait for 3 minutes

SERIOUS INJURY to the CHILD can occur.

when the vehicle is being towed to

prevent inadvertent airbag

deployment.

Why didn’t My Airbag Go Off in

•

Have all airbag repairs conducted by an

authorized HYUNDAI dealer.

a Collision?

There are certain types of accidents in

which the airbag would not be expected

to provide additional protection. These

include rear impacts, second or third

collisions in multiple impact accidents, as

well as low speed impacts. Damage to the

vehicle indicates collision energy

absorption, and is not an indicator of

whether or not an airbag should have

inflated.

3-52

Seats & Safety System

Airbag inflation conditions

Although the driver and front passenger

airbags are designed to inflate in frontal

Front airbags

collisions, they also may inflate in other

types of collisions if the front impact

sensors detect a sufficient impact. Side

and curtain airbags are designed to inflate

in side impact collisions, but they may

inflate in other collisions if the side impact

sensors detect a sufficient impact.

Also, the side and curtain airbags are

designed to inflate when a rollover is

detected by a rollover sensor.

If the vehicle chassis is impacted by

bumps or objects on unimproved roads,

B3003401

the airbags may deploy. Drive carefully on

Front airbags are designed to inflate in a

unimproved roads or on surfaces not

frontal collision depending on the

designed for vehicle traffic to prevent

severity of impact of the front collision.

unintended airbag deployment.

Side and curtain airbags

Airbag non-inflation conditions

B3003402

B3003404

In certain low-speed collisions the

airbags may not deploy. The airbags are

designed not to deploy in such cases

because they may not provide benefits

beyond the protection of the seat belts.

B3003403

Side and curtain airbags are designed to

inflate when an impact is detected by side

collision sensors depending on the

severity of impact resulting from a side

collision.

3-54

B3003405

B3003407

Front airbags are not designed to inflate

In an angled collision, the force of impact

in rear collisions, because occupants are

may direct the occupants in a direction

moved backward by the force of the

where the airbags would not be able to

impact. In this case, inflated airbags

provide any additional benefit, and thus

would not provide any additional benefit.

the sensors may not deploy any airbags.

B3003406

B3003408

Front airbags may not inflate in side

Just before impact, drivers often brake

impact collisions, because occupants

heavily. Such heavy braking lowers the

move in the direction of the collision, and

front portion of the vehicle causing it to

thus in side impacts, front airbag

“ride” under a vehicle with a higher

deployment would not provide additional

ground clearance. Airbags may not inflate

occupant protection.

in this “underride” situation because

deceleration forces that are detected by

However, side and curtain airbags may

sensors may be significantly reduced by

inflate depending on the severity of

such “underride” collisions.

impact.

3-55

Seats & Safety System

SRS Care

The SRS is virtually maintenance-free and

there are no parts you can safely service

by yourself. If the SRS airbag warning

light does not illuminate when the

Start/Stop button is in the ON position, or

continuously remains on, have the

system be immediately inspected by an

authorized HYUNDAI dealer.

Any work on the SRS system, such as

removing, installing, repairing, or any

B3003409

work on the steering wheel, the front

Front airbags may not inflate in rollover

passenger’s panel, front seats and roof

accidents because front airbag

rails be performed by an authorized

deployment would not provide additional

HYUNDAI dealer. Improper handling of

occupant protection.

the SRS system may result in serious

The side and curtain airbags may inflate in

personal injury.

a rollover situation, when it is detected by

the rollover sensor.

WARNING

To reduce the risk of serious injury or

death take the following precautions:

• Do not attempt to modify or disconnect

the SRS components or wiring,

including the addition of any kind of

badges to the pad covers or

modifications to the body structure.

• Do not place objects over or near the

airbag modules on the steering wheel,

instrument panel, and the front

passenger’s panel above the glove box.

B3003410

Airbags may not inflate if the vehicle

• Clean the airbag pad covers with a soft

collides with objects such as utility poles

cloth moistened with plain water.

or trees, where the point of impact is

Solvents or cleaners could adversely

concentrated and the collision energy is

affect the airbag covers and proper

absorbed by the vehicle structure.

deployment of the system.

• Have the inflated airbags replaced by

an authorized HYUNDAI dealer.

• If components of the airbag system

must be discarded, or if the vehicle

must be scrapped, certain safety

precautions must be observed. Consult

an authorized HYUNDAI dealer for the

necessary information. Failure to follow

these precautions could increase the

risk of personal injury.

3-56

Additional Safety Precautions

Airbag Warning Labels

Passengers should not move out of or

change seats while the vehicle is

moving. A passenger who is not wearing

a seat belt during a crash or emergency

stop can be thrown against the inside of

the vehicle, against other occupants, or

be ejected from the vehicle.

Do not use any accessories on seat belts.

Devices claiming to improve occupant

comfort or reposition the seat belt can

reduce the protection provided by the

seat belt and increase the chance of

B3003601

serious injury in a crash.

Airbag warning labels, required by the

U.S. National Highway Traffic Safety

Do not modify the front seats.

Administration (NHTSA), are attached to

Modification of the front seats could

alert the driver and passengers of

interfere with the operation of the

potential risks of the airbag system. Be

supplemental restraint system sensing

sure to read all of the information about

components or side airbags.

the airbags that are installed on your

Do not place items under the front seats.

vehicle in this Owners Manual.

Placing items under the front seats could

interfere with the operation of the

supplemental restraint system sensing

components and wiring harnesses.

Do not cause impact to the doors.

Impact to the doors when the Start/Stop

button is in the ON or START position may

cause the airbags to inflate.

Modifications to accommodate

disabilities. If you require modification to

your vehicle to accommodate a disability,

contact the HYUNDAI Customer Connect

Center at 800-633-5151.

Adding equipment to or modifying

your airbag equipped vehicle

If you modify your vehicle by changing

your vehicle’s frame, bumper system,

front end or side sheet metal or ride

height, this may affect the operation of

your vehicle’s airbag system.

3-57

Instrument Cluster Control

Gauges and Meters

Instrument panel illumination

Speedometer

.1)

ONE1041044L

B4000301

When the vehicle’s parking lights or

The speedometer indicates the speed of

headlights are on, press the illumination

the vehicle and is calibrated in mi. per

control switch to adjust the brightness of

hour (MPH).

the instrument panel illumination.

When pressing the illumination control

Power/Charge Gauge

switch, the interior switch illumination

intensity is also adjusted.

WARNING

Never adjust the instrument panel

illumination while driving to prevent

death, serious injury, or vehicle damage.

B4000306

The Power/Charge gauge shows the

energy consumption rate of the vehicle

and the charge/discharge status of the

regenerative brakes.

• POWER :

The discharging status of the electric

motor is shown when the vehicle is

accelerating or driving on an uphill

ONE1041056N

road. As the electric energy discharged

• The brightness of the instrument panel

increases, the gauge level also

illumination is displayed.

increases.

• When the brightness setting reaches

either the minimum or maximum level,

a chime sounds.

4-3

Instrument Cluster

• CHARGE :

The charging status of the electric

motor is shown when the vehicle is

decelerating or driving on a downhill

road (being charged by the

regenerative brakes). As more electric

energy charges, the lower the gauge

level.

State of Charge (SOC) Gauge

for High Voltage Battery

B4000308

1. When the remaining battery is lower

than 10 % on the SOC gauge, the High

Voltage Battery Level (

) warning

light Illuminates, to alert you of the

battery level.

2. When the High Voltage Battery Level

(

) warning light Illuminates, the

vehicle can drive an additional 18-25 mi.

(30-40 km) depending on the driving

speed, heater/air conditioner, weather,

B4000307

driving style, and other factors.

Charging is required.

• The SOC gauge shows the charging

status of the high voltage battery.

NOTICE

• The low percentage number on the

indicator indicates that there is not

When the high voltage battery level is

enough energy in the high voltage

low, the Power Down (

) indicator light

battery. 100 % indicates that the high

illuminates and the vehicle power is

voltage battery is fully charged.

limited.

• When driving on highways, make sure

Charge the battery immediately since

to check in advance if the high voltage

your vehicle may not be driven, or may

battery is charged enough.

roll back on a slope with the indicator light

illuminated.

4-4

Outside temperature gauge

Odometer

B4000304

B4000302

The temperature reads in Fahrenheit or

The odometer indicates the total distance

Celsius depending on the units selected

that the vehicle has been driven and

from the Settings menu in the

should be used to determine when

infotainment system. The temperature

periodic maintenance is required.

indicated on the instrument cluster may

not change as quickly as the outside

Distance to empty

temperature.

Select: Setup > General > Units >

Temperature Unit > °F/°C

Both the temperature unit on the

instrument cluster and climate control

screen is changed.

Information

The infotainment system may change

after software updates. For more

information, refer to the user's manual

provided in the infotainment system and

B4000303

the quick reference guide.

The distance to empty is the estimated

distance the vehicle can be driven with

the remaining electric energy.

For more information, refer to the

"Factors affecting the distance to empty"

section in chapter 1.

Information

• The distance to empty may differ from

the actual driving distance because it is

only an estimate as it is an estimate of

the available driving distance.

• The distance to empty may differ

significantly based on driving

conditions, driving habits, and

condition of the vehicle.

4-5

Instrument Cluster

• If the vehicle is not on level ground or

Warning and Indicator Lights

the battery power has been

interrupted, the distance to empty

Information

function may not operate correctly.

Make sure that all warning lights are OFF

after starting the vehicle. If any light is still

ON, this indicates a situation that needs

Gear Shift Indicator

attention.

Ready Indicator Light

WL_ReadyLamp

B4000305

The Gear Shift Indicator indicates the

This indicator illuminates:

current gear or P (Park).

When the vehicle is ready to be driven.

• ON: Normal driving is possible.

Regenerative braking level indicator

• OFF: Normal driving is not possible, or a

problem has occurred.

• Blinking: Emergency driving.

When the

indicator goes off or blinks,

there is a problem with the system. In this

case, have your vehicle inspected by an

authorized HYUNDAI dealer.

B4000309

The selected regenerative braking level is

displayed on the instrument cluster. Also,

the Smart Regenerative System’s

operation status is displayed.

For more information, refer to the

"Regenerative Braking System (Paddle

Shifter)" section in chapter 6.

4-6

Service Warning Light

NOTICE

• Do not accelerate or start the vehicle

suddenly when the power down

indicator light is illuminated.

• When the power is limited for the safety

of high-powered parts of an electric

vehicle, the power down indicator light

WL_ServiceWarningLamp

illuminates. Your vehicle may not be

driven, or may roll back on a slope with

This warning light illuminates:

the indicator light illuminated due to

• When the Start/Stop button is in the ON

the limitation of vehicle power.

position. The Service warning light

illuminates for 3 seconds and then goes

off.

Information

• When there is a problem with related

parts of the electric vehicle control

Unless both the Service Warning Light

system, such as sensors, etc.

and Power Down Indicator Light

illuminate at the same time, it is not a

When the warning light illuminates while

failure.

driving, or does not go off after starting

the vehicle, have your vehicle inspected

by an authorized HYUNDAI dealer.

Charging Connector Indicator Light

Power Down Indicator Light

WL_ChargingConnectLamp

This warning light indicates the

WL_PowerDownLamp

connection status of the charging

connector. When the charging connector

This indicator light illuminates:

is connected to the vehicle, the green

When the power is limited for the safety

light illuminates for about 1 minute.

of the high-powered parts of an electric

vehicle. The power is limited for the

following reasons:

• The high voltage battery level is too low

or voltage is decreasing

• The temperature of the high voltage

battery is too high or too low

• The temperature of the motor is high

4-7

Instrument Cluster

High Voltage Battery Level Warning

Airbag Warning Light

Light

WL_AirbagWarningLamp

WL_BatteryLovelLowWarningLamp

This warning light illuminates:

• When the Start/Stop button is in the ON

When the high voltage battery level is

position. The Airbag warning light

low.

illuminates for 3-6 seconds and then

goes off.

Charge the high voltage battery as soon

as possible.

• When there is a malfunction with the

SRS.

If the Airbag warning light remains

Seat Belt Warning Light

illuminated while driving, have the

vehicle inspected by an authorized

HYUNDAI dealer.

Regenerative Brake Warning Light

WL_SeatBeltWarningLamp

This warning light informs the driver that

the seat belt is not fastened.

For more information, refer to the “Seat

Belts” section in chapter 3.

WL_RegenerativeBreakWarningLamp

This warning light illuminates:

When the regenerative brake does not

operate and the brake does not perform

well. This causes the Brake Warning light

(red) and Regenerative Parking Brake

Warning Light (yellow) to illuminate

simultaneously.

In this case, drive safely and have your

vehicle inspected by an authorized

HYUNDAI dealer.

The operation of the brake pedal may be

more difficult than normal and the

braking distance can increase.

4-8

Parking Brake and Brake Fluid

Dual-diagonal braking system

Warning Light

Your vehicle is equipped with the

dual-diagonal braking system. This

means you still have braking on two

wheels even if one of the dual systems

fails.

With only one of the dual systems

working, more than normal pedal travel

and greater pedal force are required to

WL_BreakWarningLamp

stop the vehicle.

This warning light illuminates:

Also, the vehicle does not stop in a short

distance if only a portion of the braking

When the Start/Stop button is in the ON

system is working.

position. The Parking Brake warning light

illuminates for about 3 seconds and then

WARNING

goes off once the parking brake is

released.

If the Parking Brake and Brake Fluid

warning light illuminates with the parking

• Whenever the parking brake is applied.

brake released, it indicates that the brake

• Whenever the brake fluid level in the

fluid level is low.

reservoir is low.

Have the vehicle inspected by an

- If the warning light illuminates with

authorized HYUNDAI dealer.

the parking brake released, it

indicates the brake fluid level in the

reservoir is low.

Anti-lock Brake System (ABS)

• When the regenerative brake does not

Warning Light

operate.

If the brake fluid level in the reservoir is

low:

1. Drive carefully to the nearest safe

location and stop your vehicle.

2. With the motor stopped, check the

brake fluid level immediately and add

WL_ABSWarningLamp

fluid as required (For more information,

This warning light illuminates:

refer to the “Brake Fluid” section in

chapter 9). After adding brake fluid,

• When the Start/Stop button is in the ON

check all brake components for fluid

position. The ABS warning light

leaks. If a brake fluid leak is found, or if

illuminates for about 3 seconds and

the warning light remains on, or if the

then goes off.

brakes do not operate properly, do not

• Whenever there is a malfunction with

drive the vehicle. Have the vehicle

the ABS.

inspected by an authorized HYUNDAI

The hydraulic braking system still

dealer.

operates even if there is a malfunction

with the ABS.

If the ABS warning light remains

illuminated while driving, have the

vehicle inspected by an authorized

HYUNDAI dealer.

4-9

Instrument Cluster

Electronic Brake Force Distribution

Motor Driven Power Steering

(EBD) System Warning Light

(MDPS) Warning Light

WL_EBDWarningLamp

WL_PowerStreeringWarningLamp

When the ABS warning and Parking Brake

This warning light illuminates:

warning lights are on simultaneously, it

may indicate a problem with the

• When the Start/Stop button is in the ON

Electronic Brake Force Distribution

position. The Motor Driven Power

system.

Steering warning light illuminates for

about 3 seconds and then goes off.

If both the ABS warning light and the

Parking Brake warning light remain

• Whenever there is a malfunction with

illuminated while driving, have the

Motor Driven Power Steering.

vehicle inspected by an authorized

If the MDPS warning light remains

HYUNDAI dealer.

illuminated while driving, have the

vehicle inspected by an authorized

WARNING

HYUNDAI dealer.

When both ABS and Parking Brake and

Brake Fluid warning lights are on, the

Master Warning Light

braking system does not work normally

and you may experience an unexpected

and dangerous situation during sudden

braking. Avoid high speed driving and

abrupt braking.

WL_MasterWarningLamp

Have the vehicle inspected by an

authorized HYUNDAI dealer as soon as

This warning light illuminates:

possible.

If a malfunction is detected in any of the

following:

• Forward Collision-Avoidance Assist

Information

malfunction

• Forward Collision-Avoidance Assist

When the ABS warning light is on or both

radar blocked

ABS and Parking Brake and Brake Fluid

warning lights are on, the speedometer,

• Blind-Spot Collision-Avoidance Assist

odometer, or tripmeter may not work.

malfunction

Also, the MDPS warning light may

• Blind-Spot Collision-Avoidance Assist

illuminate and the steering effort may

radar blocked

increase or decrease.

• LED headlight malfunction

• High Beam Assist malfunction

• Smart Cruise Control malfunction

• Smart Cruise Control radar blocked

4-10

• Tire Pressure Monitoring System

Low Tire Pressure Warning Light

(TPMS) malfunction

If the issue is resolved, the Master

Warning Light turns off.

Electronic Parking Brake (EPB)

Warning Light

WL_TPMSWarningLamp

This warning light illuminates:

• When the Start/Stop button is in the ON

position. The low tire pressure warning

light illuminates for about 3 seconds

and then goes off.

WL_EPBWarningLamp

• When one or more tires are significantly

This warning light illuminates:

underinflated. (The location of the

underinflated tire appears on the

• When the Start/Stop button is in the ON

instrument cluster.)

position. The EPB warning light

illuminates for about 3 seconds and

For more information, refer to the “Tire

then goes off.

Pressure Monitoring System (TPMS)”

section in chapter 8.

• Whenever there is a malfunction with

EPB.

This warning light remains ON after

If the EPB warning light remains

blinking for about 60 seconds, or

illuminated while driving, have the

repeatedly blinks ON and OFF in 3 second

vehicle inspected by an authorized

intervals:

HYUNDAI dealer.

When there is a malfunction with the

TPMS.

Information

If this occurs, have the vehicle inspected

The Electronic Parking Brake (EPB)

by an authorized HYUNDAI dealer as soon

warning light may illuminate when the

as possible.

Electronic Stability Control (ESC)

For more information, refer to the “Tire

indicator light comes on to indicate that

Pressure Monitoring System (TPMS)”

ESC is not working properly. This does not

section in chapter 8.

indicate malfunction of EPB.

WARNING

• The TPMS cannot alert you to severe

and sudden tire damage caused by

external factors.

• If you notice any vehicle instability,

immediately take your foot off the

accelerator pedal, apply the brakes

gradually with light force, and slowly

move to a safe position off the road.

4-11

Instrument Cluster

Driver Attention Warning Light

Forward Safety Warning Light

WL_DriverAttentionWarningLamp

WL_FrontSafetyWarningLamp

This warning light illuminates:

• When you set the ignition switch to the

• When the Start/Stop button is in the ON

ON position, the yellow indicator light

position. The Forward Safety warning

illuminates for about 3 seconds and

light illuminates for about 3 seconds

then goes off

and then goes off.

• [Continuously Yellow] When the front

• [Yellow] When Forward Safety is

view camera is blocked or Driver

deselected or Forward

Attention Warning is

Collision-Avoidance Assist

disable/malfunction

• [Blinking Yellow] When the function

• [Blinking Red] When Forward

suggest that the driver take a break

Safety/Forward Cross-Traffic Safety of

If the yellow warning light is still on even

Forward Collision-Avoidance Assist is

after removing foreign material from the

operating

front of the sensor, have the vehicle

If the yellow warning light is still on even

inspected by an authorized HYUNDAI

after removing foreign material from the

dealer as soon as possible

front of the sensors after Forward Safety

For more information, refer to the “Driver

select in settings, have the vehicle

Attention Warning (DAW)” section in

inspected by an authorized HYUNDAI

chapter 7

dealer as soon as possible.

For more information, refer to the

“Forward Collision-Avoidance Assist

(FCA)” section in chapter 7.

4-12

Emergency Steering Warning Light

Lane Safety Indicator Light

if equipped

WL_LaneSafetyWarningLamp

WL_EmergencySteeringWarningLamp

This indicator light illuminates:

• When you set the ignition switch to the

• When you set the Start/Stop button to

ON position, the yellow indicator light

the ON position, the yellow warning

illuminates for about 3 seconds and

light illuminates for about 3 seconds

then goes off

and then goes off

• [Gray] When Lane Keeping Assist

• [Continuously Yellow] When

operational conditions are not met

Forward/Side Safety is deselected or

• [Continuously Green] When Lane

Forward Collision-Avoidance Assist

Keeping Assist operational conditions

disable/malfunction

are met

• [Blinking Red] When Forward/Side

• [Blinking Green] When Lane Keeping

Safety of Forward Collision-Avoidance

Assist is operating

• [Yellow] When Lane Safety is

If the yellow warning light is still on even

deselected or Lane Keeping Assist

after removing foreign material from the

disable/malfunction

front of the sensors after Forward Safety

If the yellow warning light is still on even

select in settings, have the vehicle

after removing foreign material from the

inspected by an authorized HYUNDAI

front of the sensor after Lane Safety

dealer as soon as possible.

select in settings, have the vehicle

For more information, refer to the

inspected by an authorized HYUNDAI

“Forward Collision-Avoidance Assist

dealer as soon as possible.

(FCA)” section in chapter 7.

For more information, refer to the “Lane

Keeping Assist (LKA)” section in chapter

4-13

Instrument Cluster

All Wheel Drive (AWD) Warning Light

NOTICE

if equipped

Continuous driving with the LED

Headlight warning light on or blinking can

reduce LED headlight life.

Icy Road Warning Light

if equipped

WL_4WDWarningLamp

This warning light illuminates:

Whenever a malfunction with the AWD

system is detected.

If this occurs frequently, have the vehicle

inspected by an authorized HYUNDAI

dealer.

WL_IcyLoadWarningLamp

For more information, refer to the "All

This indicator light illuminates:

Wheel Drive (AWD)" section in chapter 6.

To warn the driver the road may be icy.

When the outside temperature on the

LED Headlight Warning Light

temperature gauge is below 40 °F (4 °C),

a single chime sounds, both the outside

temperature gauge and Icy Road Warning

indicator blink several times, and then

they remain illuminated.

You can activate or deactivate Icy Road

Warning function from the Settings menu

in the infotainment system.

WL_LEDHeadlampWarningLamp

Select: Setup > Vehicle > Cluster >

This warning light illuminates:

Content Selection > Icy Road Warning

• When the Start/Stop button is in the ON

Information

position. The LED headlight warning

light illuminates for about 3 seconds

• If the Icy Road warning light appears

and then goes off.

while driving, avoid speeding, rapid

acceleration, sudden braking, or sharp

• Whenever there is a malfunction with

turning.

the LED headlight.

• The infotainment system may change

If the LED headlight warning light

after software updates. For more

remains illuminated while driving, have

information, refer to the user's manual

the vehicle inspected by an authorized

provided in the infotainment system

HYUNDAI dealer.

and the quick reference guide.

This warning light blinks:

Whenever there is a malfunction with a

LED headlight related part.

If this occurs, have the vehicle inspected

by an authorized HYUNDAI dealer.

4-14

Door open indicator light

This indicator light blinks:

While ESC is operating.

For more information, refer to the

“Electronic Stability Control (ESC)”

section in chapter 6.

Electronic Stability Control (ESC)

WL_DoorOpenWarning

OFF Indicator Light

This indicator light illuminates:

When any door or trunk is left open.

WARNING

Before driving the vehicle, confirm the

door and trunk are fully closed.

WL_ESCOffLamp

This indicator light illuminates:

CAUTION

• When the Start/Stop button is in the ON

position. The Electronic Stability

The 12 V battery may discharge if you

Control indicator light illuminates for

leave the vehicle with the Door Open

about 3 seconds and then goes off.

indicator light illuminated.

• When you deactivate ESC system by

pressing the ESC OFF button.

Electronic Stability Control (ESC)

For more information, refer to the

Indicator Light

“Electronic Stability Control (ESC)”

section in chapter 6.

Immobilizer Indicator Light

WL_ESCOnLamp

This indicator light illuminates:

• When the Start/Stop button is in the ON

WL_ImmobilizerLamp

position. The Electronic Stability

Control indicator light illuminates for

This indicator light illuminates for up to 30

about 3 seconds and then goes off.

seconds:

• Whenever a malfunction with ESC

When the vehicle detects the smart key in

system is detected.

the vehicle with the Start/Stop button in

If this occurs, have the vehicle

the ACC or ON position.

inspected by an authorized HYUNDAI

• At this time, you can start the vehicle.

dealer.

• The indicator light goes off after

starting the vehicle.

4-15

Instrument Cluster

This indicator light blinks for a few

High Beam Indicator Light

seconds:

When the smart key is not in the vehicle,

you cannot start the vehicle.

This indicator light illuminates for 2

seconds and goes off:

If the smart key is in the vehicle and the

WL_HighBeamLamp

Start/Stop button is ON, but the vehicle

cannot detect the smart key, have the

This indicator light illuminates:

vehicle inspected by an authorized

HYUNDAI dealer.

• When the headlights are on and in the

high beam position.

This indicator light blinks:

• When the turn signal lever is pulled into

Whenever there is a malfunction with the

the Flash-to-Pass position.

immobilizer system, have the vehicle

inspected by an authorized HYUNDAI

Light ON Indicator Light

dealer.

Turn Signal Indicator Light

WL_LightOnLamp

This indicator light illuminates:

WL_TurnSignalLamp

When the Parking lights or headlights are

on.

This indicator light blinks:

When you operate the turn signal lever.

If any of the following occur, there may be

a malfunction with the turn signal system.

• The turn signal indicator light

illuminates but does not blink.

• The turn signal indicator light blinks

rapidly.

• The turn signal indicator light does not

illuminate at all.

If any of these occur, have the vehicle

inspected by an authorized HYUNDAI

dealer.

4-16

High Beam Assist Indicator Light

For more information, refer to the

“Electronic Parking Brake (EPB)” section

in chapter 6.

Cluster Display Messages

Shift to P

WL_HBALamp

This message is displayed if you try to turn

off the vehicle without the gear in the P

This indicator light illuminates:

(Park) position.

When the high beam is on with the light

If this occurs, the Start/Stop button turns

switch in the AUTO position.

to the ACC position.

• [White] When High Beam Assist is ready

to operate.

Low key battery

• [Green] When High Beam Assist is

When the Start/Stop button is pressed to

operating.

the OFF position, a message may appear,

If your vehicle detects oncoming vehicles

indicating the internal battery of the

in front of you, High Beam Assist switches

Smart Key is low.

the high beam to low beam automatically.

Replace the Smart Key battery.

For more information, refer to the “High

Beam Assist (HBA)” section in chapter 5.

Press START button while turning

wheel

AUTO HOLD Indicator Light

if equipped

This message is displayed if the steering

wheel does not unlock normally when the

Start/Stop button is pressed.

You should press the Start/Stop button

while turning the steering wheel right and

left.

WL_AutoHoldWarningLamp

Press brake pedal to start vehicle

This indicator light illuminates:

This message is displayed if the

• [White] When you activate Auto Hold by

Start/Stop button changes to the ACC

pressing the AUTO HOLD switch.

position twice by pressing the button

• [Green] When you stop the vehicle

repeatedly without depressing the brake

completely by depressing the brake

pedal.

pedal with Auto Hold activated.

You can start the vehicle by depressing

• [Yellow] Whenever a malfunction with

the brake pedal and then pressing the

the Auto Hold is detected. If the AUTO

Start/Stop button.

HOLD indicator light remains YELLOW

while driving, have the vehicle

inspected by an authorized HYNDAI

dealer.

4-17

Instrument Cluster

Key not in vehicle

Shift to P to start vehicle

This message is displayed if the smart key

This message is displayed if you try to

is not in the vehicle when you leave the

start the vehicle in any other position

vehicle with the Start/Stop button in the

except P (Park).

ON or Start position.

Information

Always turn off the vehicle before leaving

your vehicle.

For your safety, You start the vehicle with

the gear shifted to P (Park).

Key not detected

This message is displayed if the smart key

Check smart key system

is not detected when you press the

This message is displayed when there is a

Start/Stop button.

problem with the smart key system. Have

the vehicle inspected by an authorized

Press START button again

HYUNDAI dealer.

If you cannot start the vehicle after the

Start/Stop button is pressed, attempt to

Door, Hood, Trunk open indicator

start the vehicle by pressing the

Start/Stop button again.

If the warning message appears each

time you press the Start/Stop button,

have the vehicle inspected by an

authorized HYUNDAI dealer.

Press START button with key

This message is displayed and the

immobilizer indicator blinks if you press

the Start/Stop button while the warning

message, “Key not detected” appears.

B4000521

This warning is displayed if any door or

At this time, the immobilizer indicator

hood or trunk is left open. The warning

light blinks.

indicates which door is on the cluster

display.

Check BRAKE SWITCH fuse

This message is displayed if the brake

CAUTION

switch fuse is disconnected.

Before driving the vehicle, confirm the

Replace the fuse with a new one before

door, hood, and trunk are fully closed.

starting the vehicle.

Also, check there are no door, hood, and

trunk open warning lights or messages

If that is not possible, start the vehicle by

displayed on the instrument cluster.

pressing the Start/Stop button for 10

seconds in the ACC position.

4-18

Low tire pressure

Wiper

-PX UJSF QSFTTVSF

'SPOU 8JQFS

-PX

"650

-PX

ONE1081021L

ONE1041004L

This warning message is displayed if the

This indicator displays which wiper speed

tire pressure is low. The corresponding

is selected using the wiper control.

tire on the vehicle illuminates.

You can activate or deactivate

For more information, refer to the “Tire

Wiper/Lights display function from the

Pressure Monitoring System (TPMS)”

Settings menu in the infotainment

section in chapter 8.

system.

Select: Setup > Vehicle > Cluster >

Lights

Content Selection > Wiper/Lights

Display

Information

-JHIUT

The infotainment system may change

after software updates. For more

information, refer to the user's manual

provided in the infotainment system and

the quick reference guide.

Low washer fluid

ONE1041032L

This message is displayed if the washer

This indicator displays which exterior light

fluid level in the reservoir is nearly empty.

is selected using the lighting control.

Have the washer fluid reservoir refilled.

You can activate or deactivate

Wiper/Lights display function from the

Check haptic steering wheel system

Settings menu in the infotainment

if equipped

system.

This message is displayed if there is a

Select: Setup > Vehicle > Cluster >

problem with the haptic steering wheel

Content Selection > Wiper/Lights

system. Have the vehicle inspected by an

Display

authorized HYUNDAI dealer.

4-19

Instrument Cluster

Check headlight LED

Remaining time

This message is displayed if there is a

AC charge

problem with the LED headlight. Have the

vehicle inspected by an authorized

HYUNDAI dealer.

Shift to P to charge

4IJGU UP 1 UP DIBSHF

ONE1Q011058E

DC charge

OOSEV040497L

This message is displayed if you connect

the charging cable without the gear in the

P (Park) position.

Shift to P (Park) before connecting the

charging cable.

ONE1Q011059E

This message is displayed to notify the

remaining time to charge the battery to

the selected target battery charge level.

Unplug vehicle to start

This message is displayed when you start

the vehicle without unplugging the

charging cable. Unplug the charging

cable, and then turn on the vehicle.

Charging door open

This message is displayed when the

vehicle is driven with the charging door

opened. Close the charging door and then

start driving.

4-20

Charging stopped. Check the AC/DC

Check regenerative brakes

charger

This warning message is displayed when

charging is stopped for the following

reasons:

$IFDL

SFHFOFSBUJWF CSBLFT

• There is a problem with the external AC

charger or DC charger charger

• The external AC charger stops charging

• The charging cable is damaged

In this case, check whether there is any

problem with the external AC or DC

charger and charging cable.

OOSEV040503E

If the same problem occurs when

These warning messages are displayed

charging the vehicle with a normally

when the regenerative brake system does

operating AC charger or genuine

not work properly.

HYUNDAI portable charger, have your

In this case, have the vehicle inspected by

vehicle inspected by an authorized

an authorized HYUNDAI dealer.

HYUNDAI dealer.

Low EV battery

Charging stopped. Check the cable

When the high voltage battery level

connection

reaches below about 20 %, this warning

This warning message is displayed when

message is displayed.

charging is stopped because the charging

connector is not correctly connected to

The High Voltage Battery Level (

)

the charging inlet

warning light illuminates simultaneously.

In this case, separate the charging

Charge the high voltage battery

connector and reconnect it and check

immediately.

whether there is any problem (external

damage, foreign substances, etc.) with

Charge immediately. Power limited

the charging connector and charging

When the high voltage battery level

inlet.

reaches below about 10 %, this warning

If the same problem occurs when

message is displayed.

charging the vehicle with a replaced

charging cable or genuine HYUNDAI

The High Voltage Battery Level (

)

portable charger, have your vehicle

warning light illuminates simultaneously.

inspected by an authorized HYUNDAI

The vehicle’s power will be reduced to

dealer.

minimize the energy consumption of the

high voltage battery. Charge the battery

immediately.

4-21

Instrument Cluster

Battery discharging due to external

Charging the battery before driving helps

electrical devices

increase power.

NOTICE

If these warning messages are still

displayed even after the ambient

#BUUFSZ EJTDIBSHJOH

temperature has increased, have the

EVF UP FYUFSOBM

vehicle inspected by an authorized

FMFDUSJDBM EFWJDFT

HYUNDAI dealer.

Power limited

This Indicator light illuminates:

ONE1041054L

• This warning message is displayed to

This warning message is displayed when

ensure the safety of high-powered

a battery discharge due to excessive

components of electric vehicles. The

current is detected by mounting an

power is limited for the following

unauthorized electrical device such as a

reasons:

black box.

- The high voltage battery level is too

Be careful as it may cause battery

low or voltage is decreasing

discharge problems.

- The temperature of the high voltage

If the warning message is not

battery is too high or too low

disappeared after the external electrical

- The temperature of the motor is high

device is removed, have the vehicle

inspected by an authorized HYUNDAI

NOTICE

dealer.

• When this warning message is

displayed, do not accelerate or start the

Power limited due to low EV battery

vehicle suddenly.

temperature. Charge battery

• When the power is limited for the safety

of high-powered parts of an electric

vehicle, the warning message is

displayed. Your vehicle may not be

1PXFS MJNJUFE

driven, or may roll back on a slope with

EVF UP MPX &7

the warning message displayed due to

CBUUFSZ

the limitation of vehicle power.

UFNQFSBUVSF

$IBSHF CBUUFSZ

Information

Unless both the Service Warning Light

OOSEV040507L

and Power Down Indicator Light

Both warning messages are displayed to

illuminate at the same time, it is not a

protect electric vehicle system when

failure.

outside temperature is low. If the high

voltage battery charging level is low and

parked outside in low temperature for a

long time, vehicle power may be limited.

4-22

Stop vehicle and check power

Check virtual engine sound system

supply

This warning message is displayed when

a failure occurs in the power supply

$IFDL 7JSUVBM &OHJOF

system.

4PVOE 4ZTUFN

In this case, park the vehicle in a safe

location and tow your vehicle to the

nearest authorized HYUNDAI dealer and

have the vehicle inspected.

Check electric vehicle system

This warning message is displayed when

OOSEV040512L

there is a problem with the electric

This message is displayed when there is a

vehicle control system.

problem with the Virtual Engine Sound

Refrain from driving when the warning

System (VESS).

message is displayed.

In this case, have the vehicle inspected by

an authorized HYUNDAI dealer.

Check active air flap system

$IFDL "DUJWF

"JS 'MBQ 4ZTUFN

OOSEV040510L

This warning message is displayed in the

following situations:

• There is a malfunction with the actuator

flap

• There is a malfunction with the actuator

air flap controller

• The air flap does not open

When all of the above conditions are

fixed, the warning will disappear.

4-23

Instrument Cluster

Cluster Display

Cluster Display Control

B4000701

The cluster display modes can be changed by using the control switches.

Switch

Operation

Function

Press

MODE button for changing View modes

UP, DOWN switch for changing items in Utility view and Option

Press

SELECT/RESET switch for entering Option menu

SELECT/RESET switch for retrieving assist information or

Press and hold

resetting the selected item

View Modes

View modes

Explanation

Driving Assist view displays the status of the vehicle’s Driver

Driving Assist

Assistance systems.

Turn by Turn

Turn By Turn view displays the state of the navigation.

Utility view displays driving information such as the trip distance,

Utility

electric energy economy and etc.

The information provided may differ depending on which features are available to your

vehicle.

4-24

Turn By Turn (TBT) view

NJ L8I

ONE1041019L

Driving Assist, Turn by Turn, Utility view

B4000903

modes are displayed in the center of the

Turn-by-turn navigation, distance/time to

instrument cluster.

destination information is displayed when

Turn by Turn view is selected.

Driving Assist view

Utility view

In the Utility view, using the

(UP,

DOWN) switch, you may change through

items in the following order.

Drive info

B4000902

The status of Smart Cruise Control, Lane

Following Assist, Highway Driving Assist,

NJ L8I

etc., is displayed when Driving Assist view

is selected.

For more information, refer to each

function information section in chapter 7.

ONE1041047L_1

Trip distance, average electric energy

economy and total driving time are

displayed.

The driver’s door is opened after turning

off the vehicle or the vehicle is turned on

after 3 minutes have passed, the Drive

Info screen will reset.

4-25

Instrument Cluster

After Recharging

The accumulated driving information will

continue to be counted while the vehicle

is on (

indicator is on) (for example,

when the vehicle is in traffic or stopped at

a stop light).

Information

The vehicle must be driven for a minimum

NJ L8I

of 0.19 mi. (300 m) since the last ignition

key cycle before the accumulated driving

information is recalculated.

ONE1041062L

Trip distance, total driving time and

Tire pressure

average energy consumption after the

vehicle has been recharged are displayed.

To reset manually, press the OK button on

5JSF 1SFTTVSF

the steering wheel for more than 1 second

when ‘After Recharging’ is displayed.

Accumulated info

ONE1041010L

The tire pressure of each tire is displayed.

NJ L8I

For more information, refer to the “Tire

Pressure Monitoring System (TPMS)”

section in chapter 8.

Energy flow/Driving force distribution

ONE1041046L

if equipped

This display shows the accumulated trip

distance (1), the average energy

consumption (2), and the total driving

time (3).

The information is accumulated starting

from the last reset.

To manually reset the information, press

and hold the OK button when viewing the

Accumulated driving info. The trip

distance, the average energy

consumption, and total driving time will

reset simultaneously.

B4000909

• The electric vehicle system informs the

drivers its energy flow in various

operating modes.

4-26

• The distribution status of the driving

Vehicle Settings

power of the front and rear wheels are

displayed when Auto AWD mode is

(Infotainment System)

activated.

Vehicle Settings in the infotainment

For more information, refer to the "All

system provides user options for the

Wheel Drive (AWD)" section in chapter 6.

settings including door lock/unlock

features, convenience features, driver

Additional information display

assistance settings, etc.

Drive info

Vehicle Settings menu

• Driver Assistance

• Drive Mode

• EV

• Head-Up Display

• Cluster

• Climate

NJ L8I

• Seat

• Lights

• Door

ONE1041047L_1

• Convenience

Drive information is displayed for 4

The information provided may differ

seconds after the vehicle is turned off.

depending on which functions are

available to your vehicle.

Driving assist information

WARNING

80 NQI

Do not adjust the Vehicle Settings while

driving. You may be distracted from the

driving task and could crash.

B4000911

The current operation conditions of Smart

Cruise Control, Lane Following Assist,

Highway Driving Assist, etc., is displayed.

4-27

5. Convenience Features

Accessing Your Vehicle

5-5

Smart Key

5-5

Immobilizer System

5-11

Hyundai Digital Key

5-12

Digital key (smartphone)

5-12

Digital key (Card key)

5-16

Used vehicle/Digital key maintenance

5-21

Limitations of the System

5-21

Door Locks

5-22

Operating Door Unlocks from Outside the Vehicle (Manual type)

5-22

Operating Door Unlocks from Outside the Vehicle (Electric type)

5-22

Operating Door Locks from Outside the Vehicle (Manual type)

5-24

Operating Door Locks from Outside the Vehicle (Electric type)

5-24

Operating Door Lock/Unlock from Inside the Vehicle

5-27

Automatic Door Lock and Unlock Features

5-27

Child-Protector Rear Door Locks

5-28

Theft-Alarm System

5-29

Rear Occupant Alert (ROA)

5-30

System Setting

5-30

System Operation

5-30

Declaration of Conformity

5-32

Integrated Memory System

5-32

Storing Memory Positions

5-33

Recalling Memory Positions

5-33

Resetting the System

5-33

Seat Easy Access

5-34

Steering Wheel

5-35

Motor Driven Power Steering (MDPS)

5-35

Tilt/Telescopic Steering

5-35

Horn

5-36

Heated Steering Wheel

5-36

Mirrors

5-38

Inside Rearview Mirror

5-38

Side View Mirrors

5-47

Reverse Parking Aid

5-49

Windows

5-50

Power Windows

5-51

Wide Sunroof

5-54

Hood

5-57

Opening the Hood

5-57

Closing the Hood

5-58

Front Trunk

5-58

Opening the Front Trunk

5-58

Power Trunk

5-59

Power Trunk Operating Conditions

5-59

Operating the Power Trunk

5-60

Resetting the Power Trunk

5-62

Emergency Trunk Safety Release

5-63

Smart Trunk

5-64

Using Smart Trunk

5-64

Deactivating smart trunk

5-65

Detecting area

5-65

Electric Charging Door

5-66

Head-up Display

5-67

Head-up Display Settings

5-67

Head-up Display Information

5-68

Precautions while Using the Head-up Display

5-68

Over-The-Air Software Update

5-69

Downloading Software

5-69

Approving Software Update

5-69

Preparing Software Update

5-70

Updating Software

5-70

Lighting

5-72

Exterior Lights

5-72

Welcome system

5-75

5. Convenience Features

Interior Lights

5-76

Interior Light AUTO cut

5-76

Front lamps

5-76

Rear lamps

5-76

Vanity Mirror Lamp

5-77

Glove Box Lamp

5-77

Mood Lamp

5-77

Front Trunk Lamp

5-78

Luggage Compartment Lamp

5-79

High Beam Assist (HBA)

5-79

High Beam Assist Settings

5-80

High Beam Assist Operation

5-80

High Beam Assist Malfunction and Limitations

5-81

Wipers And Washers

5-82

Front Windshield Wipers

5-83

Front Windshield Washers

5-84

Automatic Climate Control System

5-85

Climate

5-87

Automatic Temperature Control Mode

5-87

Manual Temperature Control Mode

5-88

System Operation

5-96

System Maintenance

5-97

Windshield Defrosting And Defogging

5-99

To Defog Inside Windshield

5-100

To Defrost Outside Windshield

5-100

Defogging Logic

5-101

Rear Window Defroster

5-101

Climate Control Additional Features

5-102

A/C Automatic Drying

5-102

Auto Defogging System

5-102

Auto Dehumidify

5-104

Sunroof Inside Air recirculation

5-104

Recirculating Air When Washer Fluid Is Used

5-104

Recirculation Mode Plus

5-105

Automatic Controls Linked to Climate Control Settings (for driver’s seat)

5-105

Smart Ventilation

5-105

Locking your vehicle

Accessing Your Vehicle

Manual type

Smart Key

Type A

B5000203

To lock your vehicle using the door handle

button or the smart key:

B5000201

1. Close all doors, hood, and trunk.

Type B

2. Press the Door Lock button (1) on the

smart key. The hazard warning lights

blink with an alarm, and the doors lock.

3. In addition, touching the outer part of

the door handle on or near the handle

detent while having the smart key with

you locks all doors.

Electric type (if equipped)

B5000202

Your electric vehicle uses a smart key that

can be used to lock or unlock the doors,

trunk, and start the vehicle.

(1) Door lock

(2) Door unlock

(3) Trunk open

(4) Panic

B5000203_1

(5) Remote Start

To lock your vehicle using the door handle

(6) Forward / Backward (if equipped)

touch sensor or the smart key:

1. Close all doors, hood, and trunk.

2. Press the Door Lock button (1) on the

smart key. The hazard warning lights

blink with an alarm, and the handles

retract back.

5-5

Convenience Features

•

In addition, touching the outer part of

Information

the door handle on or near the handle

detent for about 1 second while having

• To fold/unfold the side view mirror

smart key with you locks all doors and

simultaneously when the door is

let the door handle to retract back.

locked/unlocked, select Setup >

Vehicle > Lights > Welcome

Information

Mirror/Light > Enable on Door Unlock

in the infotainment system.

•

The side view mirror will fold if ‘Enable

on Door Unlock’ is selected from the

• The door handle button will only

Settings menu in the infotainment

operate when the smart key is within

system. Select Setup > Vehicle > Lights

28-40 in. (0.7-1 m) from the outside

> Welcome Mirror/Light > Enable on

door handle. Other people can also

Door Unlock.

open the doors without the smart key in

possession.

•

The door handle touch sensor operates

when the smart key is within 28-40 in.

• After unlocking the doors, the doors will

(0.7-1 m) from the outside door handle.

lock automatically after 30 seconds

unless a door is opened.

•

If you lock the doors using the door

handle touch sensor, the doors are not

The infotainment system may change

locked under the following

after software updates. For more

circumstances:

information, refer to the user’s manual

provided in the infotainment system and

- The smart key is in the vehicle.

the quick reference guide.

- The Start/Stop button is from ACC or

ON position.

- Any door is open (except for the

Unlocking your vehicle

trunk).

Manual type

•

If this occurs, a chime sounds for a few

seconds. Check the vehicle before

attempting to lock the vehicle again.

WARNING

Do not leave the smart key in your vehicle

with children that are unattended or

unsupervised.

Children could unintentionally press the

B5000204

Start/Stop button or could operate the

To unlock your vehicle using the door

power windows or other vehicle controls

handle button or the smart key:

or even cause the vehicle to move. This

may result in serious injury or death.

1. Have the smart key with you.

2. Pushing the button on the door

handle(engraved part) or press the

Door Unlock button (2) on the smart

key. All doors handles will be unlocked

and the hazard warning lights will blink

twice.

5-6

3. After unlocking the doors, the doors will

• The door handle button or touch sensor

automatically re-lock after 30 seconds

only operates when the smart key is

unless a door is opened.

within 28-40 in. (0.7-1 m) from the

Electric type (if equipped)

outside door handle.

• If you do not open the door after

unlocking within 30 seconds, it returns

to the lock mode.

Setting the Two Press Unlock feature

You can activate or deactivate the Two

Press Unlock feature from the Settings

menu in the infotainment system.

SelectSetup > Vehicle > Door > Two

Press Unlock.

B5002804

Information

When you release the Two Press Unlock

function

The infotainment system may change

after software updates. For more

To unlock your vehicle using the door

information, refer to the user’s manual

handle touch sensor or the smart key:

provided in the infotainment system and

1. Have the smart key with you.

the quick reference guide.

2. Touch the touch sensor on the door

handle(engraved part) or press the

Door Unlock button (2) on the smart

Setting the door lock/unlock prevention

key. All door handles will pop out and

feature

the doors will be unlocked and the

The doors may lock or unlock if the touch

hazard warning lights will blink and the

sensor of the outside door handle is

chime will sound.

recognized while washing your vehicle or

• If you unlock the doors using the

due to heavy rain.

passenger side door handle, all the

To prevent unintentional door lock or

doors are unlocked. If you unlock the

unlock:

doors using the driver side door

Press the lock button on the smart key

handle, either the driver’s side door is

and immediately press the unlock button

unlocked or all the doors are

along with the lock button for more than

unlocked depending on the setting

4 seconds. The hazard warning lights

for the Two Press Unlock feature.

blink four times. At this time, the doors do

Change the Driver Door unlock mode

not lock or unlock even though the touch

by referring to “Setting the Two Press

sensor is touched on the outside door

Unlock feature”.

handle. To deactivate the function, press

the door lock or unlock button on the

Information

smart key.

• The side view mirror will unfold if

‘Enable on Door Unlock’ is selected

from the Settings menu in the

infotainment system. Select Setup >

Vehicle > Lights > Welcome

Mirror/Light > Enable on Door Unlock.

5-7

Convenience Features

• The vehicle turns off if you do not get on

Information

the vehicle within 10 minutes after

During a vehicle wash or rain, in order to

remotely starting the vehicle.

minimize unintentional operation of the

• The Remote Start button may not

touch sensor, the touch sensor may

operate if the smart key is not within 32

become insensitive. This is not a

ft. (10 m) from the vehicle.

malfunction.

• The vehicle does not remotely start if

the hood or trunk is open.

Opening the trunk

To open the trunk:

Remotely moving vehicle forward or

1. Have the smart key with you.

backward

2. Press the trunk handle switch on the

if equipped

vehicle or press and hold smart key

Some models are equipped with the

button(3) on the smart key for more

Remote Smart Parking Assist feature.

than one second. The hazard warning

With the smart key, the vehicle can be

lights blink twice and the trunk is

moved forward or backward remotely to

opened. If you release the button while

enter or exit a tight parking space.

the trunk is being closed, it will stop

For more information, refer to the

working and the chime will sound for

“Remote Smart Parking Assist 2 (RSPA 2)”

about 5 seconds.

section in chapter 7.

Information

Using panic alarm

The trunk open button only operates

The horn sounds and the hazard warning

when the smart key is within 28 in. (0.7 m)

lights blink for about 30 seconds if this

from the trunk.

button (4) is pressed for more than 1

second. To stop the horn and lights, press

any button on the smart key.

Remotely starting vehicle

1. Press the door lock button on the smart

Starting the vehicle

key. You must be within about 32 ft. (10

m) from the vehicle.

Your vehicle is equipped with a Start/Stop

button instead of a key cylinder. You can

2. Press and hold the Remote Start button

leave your smart key in your pocket or

(5) on your smart key. You must press

purse when you start your vehicle.

the button within 4 seconds from when

you have pressed the door lock button.

For more information, refer to the

The hazard warning lights blink and the

“Start/Stop Button” section in chapter 6.

vehicle starts (

indicator on).

Information

3. To turn off the vehicle, press the

Remote Start button (5) once.

If the smart key is not moved for some

time, the detection function for smart key

Information

operation will pause. Lift the smart key to

activate the detection again.

• The vehicle must be in P (Park) for the

remote start function to start.

• The vehicle turns off (

indicator off)

if you get inside the vehicle without a

registered smart key.

5-8

If the smart key is in close proximity to

NOTICE

your mobile phone, the signal could be

To prevent damaging the smart key:

blocked by your mobile phone’s normal

operational signals. This is specifically

• Keep the smart key in a cool, dry place

relevant when the phone is active such as

to avoid damage or malfunction.

making and receiving calls, text

Exposure to moisture or high

messaging, and/or sending/receiving

temperature may cause the internal

emails. When possible, avoid keeping the

circuit of the smart key to malfunction

smart key and your mobile phone in the

which may not be covered under

same location such as pants or jacket

warranty.

pocket in order to avoid interference

• Avoid dropping or throwing the smart

between the two devices.

key.

If your windows are tinted, especially with

• Protect the smart key from extreme

metallic window tint, it may cause

temperatures.

frequency interference, reducing the

smart key operating range.

Loss of a smart key

Information

A maximum of three smart keys can be

Changes or modifications not expressly

registered to a single vehicle. If you

approved by the party responsible for

happen to lose your smart key, it is

compliance could void the user’s

recommended that you should

authority to operate the equipment. If the

immediately take the vehicle and

keyless entry system is inoperative due to

remaining keys to your authorized

changes or modifications not expressly

HYUNDAI dealer or tow the vehicle, if

approved by the party responsible for

necessary.

compliance, it will not be covered by your

manufacturer’s vehicle warranty.

Smart key precautions

The smart key may not work if any of the

following occur:

Information

• The smart key is close to a radio

This device complies with Part 15 of the

transmitter such as a radio station or an

FCC rules.

airport which can interfere with normal

operation of the transmitter.

Operation is subject to the following three

conditions:

• The smart key is near a mobile two way

radio system or a mobile phone.

1. This device may not cause harmful

interference, and

• Another vehicle’s smart key is being

operated close to your vehicle.

2. This device must accept any

interference received, including

• The smart key is near any normal

interference that may cause undesired

electronic devices or credit cards.

operation.

If the smart key does not work correctly,

3. Changes or modifications not expressly

open and close the door with the

approved by the party responsible for

mechanical key. If you have a problem

compliance could void the user’s

with the smart key, contact an authorized

authority to operate the device.

HYUNDAI dealer.

5-9

Convenience Features

3. Reinstall the battery cover and smart

NOTICE

key cover.

• Keep the smart key away from

electromagnetic materials that blocks

electromagnetic waves to the key

surface.

• Always have the smart key with you

when leaving the vehicle. If the smart

key is left near the vehicle, the vehicle

battery may be discharged.

Battery replacement

B5000402

If the smart key is not working properly,

try replacing the battery with a new one.

If you suspect your smart key might have

sustained some damage, or you feel your

Battery Type: CR2450

smart key is not working correctly,

To replace the battery:

contact an authorized HYUNDAI dealer.

1. Put the slim tool into the key hole (1) to

pry open the rear cover of the smart

WARNING

key.

This product contains a button battery.

If swallowed, a lithium button battery can

cause severe or fatal injuries within 2

hours. Keep batteries out of reach of

children.

If you think batteries may have been

swallowed or placed inside any part of the

body, seek immediate medical attention.

Information

B5000401

2. Remove the old battery and insert the

new battery. Make sure the battery

position is correct.

WL_TakingCareOfBatteryWarning_7

An inappropriately disposed battery can

be harmful to the environment and

human health. Dispose of the battery

according to your local law(s) or

regulations.

5-10

Immobilizer System

NOTICE

The immobilizer system helps protect

The transponder in your key is an

your vehicle from theft. If an improperly

important part of the immobilizer system.

coded key (or other device) is used, the

It is designed to give years of trouble-free

vehicle is disabled.

service, however you should avoid

When the Start/Stop button is pressed to

exposure to moisture, static electricity

the ON position, the immobilizer system

and rough handling. Immobilizer system

indicator should come on briefly, then go

malfunction could occur.

off. If the indicator starts to blink, the

system does not recognize the coding of

the key.

Press the Start/Stop button to the OFF

Information

position, then press the Start/Stop button

This device complies with Part 15 of the

to the ON position again.

FCC rules.

In some circumstances, the vehicle may

Operation is subject to the following three

not recognize your smart key if another

conditions:

smart key device is nearby or a metal

1. This device may not cause harmful

object such as a key chain is causing

interference.

interference with the smart key.

2. This device must accept any

If this occurs, your vehicle may not start.

interference received, including

Remove any metal objects or additional

interference that may cause undesired

keys near the smart key before

operation.

attempting to start the vehicle again.

3. Changes or modifications not expressly

If the system repeatedly does not

approved by the party responsible for

recognize the coding of the key, contact

compliance could void the user’s

an authorized HYUNDAI dealer.

authority to operate the device

Do not attempt to alter this system or add

other devices to it. Electrical problems

could result that may make your vehicle

inoperable.

WARNING

In order to prevent theft of your vehicle,

do not leave spare keys anywhere in your

vehicle. Your immobilizer password is a

customer unique password and should be

kept confidential.

5-11

Convenience Features

Registering your digital key

Hyundai Digital Key

(smartphone)

if equipped

Hyundai digital key provides convenience

to the driver, which the driver can use to

lock or unlock the driver and passenger

doors or the trunk and turn of the vehicle.

Digital key (smartphone)

Information

• Hyundai digital keys are only available

on smartphone that support digital key

B0901EU04

functions, and digital key functions of

smartphones are provide by

smartphone manufacturers.

• Available smartphone models can be

found on smartphone manufactures’

website or HYUNDAI website.

• Depending on the availability of service

on the vehicle, some functions may not

operated.

Setting your smartphone

B5026502

[A] Vehicle authentication pad (Wireless charging

To use the digital key (smartphone),

pad)

download the BlueLink App and sign up

1. Turn on the vehicle with a smart key

Hyundai account and service.

and have your smart key with you in the

For more information about BlueLink,

vehicle.

refer to the infotainment system guide.

Information

For Europe, both smart keys must be in

the vehicle to register the digital key.

5-12

2. After selecting Digital Key > Set Up

• NFC communication may not work

Digital Key from the My Hyundai App in

for some smartphones depending on

the smartphone, register the digital key

the internal structure of the

according to the guidance in the

smartphone. Move the smartphone

smartphone screen.

to the left or right of the indoor

authentication pad (wireless

Information

charging pad) to operate.

• The NFC Antenna position on

Samsung device can be found in the

3. From the infotainment system Settings

following path: Setup > Connections

menu, select Setup > Vehicle > Digital

> NFC and contactless payments.

key > Smartphone key and press the

Save button from the infotainment

system screen.

• When the digital key (smartphone) is

saved, a message appears on the

infotainment system screen.

Information

•

If you want to register a digital key

(smartphone) again, refer to "Deleting

your digital key (smartphone)" and

B5026403

delete the digital key (smartphone)

before re-registering.

• The NFC Antenna position on Apple

iPhone is located at the top of the

•

During the digital key saving process,

rear and Apple WATCH is located at

the process may cancel when:

the center of the screen.

- The smartphone is removed from the

• Place your smartphone on the vehicle

vehicle authentication pad (wireless

authentication pad (wireless

charging pad)

charging pad) with the screen facing

- The infotainment system screen is

up. (In case of Apple WATCH, need to

changed

touch the pad with WATCH screen

- The vehicle is turned off

face).

- The gear is shifted

• Ensure that the NFC Antenna position

on the smartphone is in contact with

•

The registering process does not start if

the vehicle authentication pad

a smart key is not in the vehicle.

(wireless charging pad).

•

Some smartphones may not start the

• The location of the NFC Antenna on

registering process depending on the

the smartphone may vary by phone

internal structure. Move the

model, so please contact the

smartphone to the left or right on the

smartphone manufacturer for

vehicle authentication pad (wireless

details.

charger pad) and try registering the

smartphone.

5-13

Convenience Features

Using the digital key (smartphone)

• The NFC Antenna position on Apple

iPhone is located at the top of the rear

The driver can lock or unlock the door by

(B) and Apple WATCH is located at the

placing the smartphone on the outside

center of the screen (C).

door handle, and the vehicle can be

started by placing the smartphone on the

vehicle authentication pad (wireless

charging pad).

Samsung smartphone

B5026403

• Touch the Door handle NFC Antenna

position with the back of your

smartphone. (In case of Apple WATCH,

B5026404

need to touch the pad with WATCH

[A] Door handle authentication pad

screen face).

[B] NFC Antenna

Apple iPhone

Locking/Unlocking the doors

• If the driver places the digital key

(smartphone) NFC antenna to the

driver’s or passenger’s door handle

authentication pad (A) for more than 2

seconds, the door locks or unlocks.

• After unlocking the doors, the doors are

automatically re-lock after 30 seconds

unless a door is opened.

• If the smartphone digital key does not

B5026405

operate, try again after moving the

[A] Door handle authentication pad

smartphone away from the door handle

[B] NFC Antenna

authentication pad (more than 0.1 m (4

in.)).

Information

• The location of the NFC Antenna on the

Information

smartphone may vary by phone model,

You cannot lock your vehicle using the

so please contact the smartphone

digital key (smartphone) if any of the

manufacturer for details.

following occurs:

• The NFC Antenna position on Samsung

• The smart key is in the vehicle.

device can be found in the following

• The Start/Stop button is in the ACC or

path: Setup > Connections > NFC and

ON position.

contactless payments.

• Any of the doors, hood, or trunk are

open.

5-14

Starting the vehicle

Deleting your digital key

(smartphone)

After placing your registered digital key

(smartphone) on the vehicle

Turn on the vehicle with a smart key. Have

authentication pad (wireless charging

your smart key with you in the vehicle.

pad), depress the brake pedal and press

the Start/Stop button.

Deleting all registered digital key

(smartphone)

After starting the vehicle, the digital key

(smartphone) may be removed from the

vehicle authentication pad (wireless

charging pad).

For more details on the basic way to start

the vehicle, refer to the “Start/Stop

Button” section in chapter 6.

Information

If a shared digital key (smartphone) is

used for the first time, the activating time

may take longer.

B0901EU05

• Place the shared digital key

To delete all the registered digital key

(smartphone) on the door handle

(smartphone), from the Settings menu

authentication pad until the vehicle

select Setup > Vehicle > Digital key >

door lock/unlock activates.

Smartphone Key > Delete all in the

• If a shared digital key (smartphone) is

infotainment system.

first used on the vehicle authentication

• The "Delete all" button is disabled if

pad (wireless charger pad), the initial

there is no registered digital key

start of the vehicle may fail.

(smartphone).

• If the door lock/unlock is activated

once with the shared digital key

Deleting my registered digital key

(smartphone) or the vehicle is started

(smartphone)

with the digital key (smartphone) on the

vehicle authentication pad, the digital

key (smartphone) is registered in the

vehicle.

WARNING

The vehicle can be started when the

registered smartphone is placed on the

vehicle authentication pad (wireless

2C_AVNDeleteMySmartPhone

charging pad). Therefore, do not leave

To delete only my registered digital key

unsupervised children or people who are

(smartphone), from the Settings menu

not aware of the system since it can result

select Setup > Vehicle > Digital key >

in serious injury or death. In addition,

Smartphone Key > My Smartphone Key

always have the registered smartphone

> Deletein the infotainment system.

with you to prevent vehicle theft when

• If a shared digital key (smartphone) is

leaving the vehicle.

registered, it cannot be deleted.

5-15

Convenience Features

• A new smartphone can be registered

Digital key (Card key)

after deleting the existing digital key

(smartphone) from "My Smartphone

How to register Digital key (Card

Key" menu.

Key)

Information

To use the card key as a digital key, follow

the following procedure.

• If the registered digital key

(smartphone) is deleted, the digital key

saved in the smartphone is also

deleted.

• If the digital key is deleted from the

smartphone, the digital key

(smartphone) registered in the vehicle

is also deleted.

• The shared digital key registered in the

vehicle cannot be deleted individually.

• Even though the BlueLink® App is

deleted from the smartphone, the

B0902EU01

digital key saved in the smartphone is

not deleted.

• Management of the digital key saved in

the smartphone is available from the

Digital Key App provided by the

smartphone manufacturer.

B5026502

[A] Vehicle authentication pad (Wireless charging

pad)

1. Have both of your smart keys with you

in the vehicle.

2. Select Setup > Vehicle > Digital Key >

Card Key from the Settings menu, and

check whether "Enabled card key" is

selected in the infotainment system.

3. Place your card key on the vehicle

authentication pad (wireless charging

pad) while the engine is on.

4. Register your card key by selecting

Setup > Vehicle > Digital Key > Card

Key > Save from the Settings menu in

the infotainment system.

5-16

Information

• When there is a digital key (card key)

You cannot lock your vehicle using the

already registered in the vehicle, a new

digital key (card key) if any of the

digital key (card key) cannot be

following occurs:

registered. Re-register a new digital key

• The smart key is in the vehicle.

(card key) after deleting the exiting

• The Start/Stop button is in the ACC or

digital key (card key).

ON position.

• To register a digital key (card key), both

• Any of the doors, hood, or trunk are

of your smart keys must be in the

open.

vehicle.

• A registered digital key (card key)

cannot be registered in other vehicles.

• Starting the vehicle

After placing your registered digital key

(card key) on the vehicle authentication

Using the digital key (card key)

pad (wireless charging pad), depress

The driver can lock or unlock the door by

the brake pedal and press the

placing the card key on the outside door

Start/Stop button.

handle, and the vehicle can be started by

For more details on the basic way to

placing the card key on the vehicle

start the vehicle, refer to "Start/Stop

authentication pad (wireless charging

Button" section in chapter 6.

pad).

WARNING

The vehicle can be started when the

registered card key is placed on the

vehicle authentication pad (wireless

charging pad). Therefore, do not leave

unsupervised children or people who are

not aware of the system since it can result

in serious injury or death. In addition,

always have the registered card key with

you to prevent vehicle theft when leaving

the vehicle.

B5026503

[A] Door handle authentication pad

[B] Card key NFC Antenna

• Locking/Unlocking the doors

NOTICE

- If the driver places the digital key

• The digital key (card key) may not work

(card key) to the driver’s or

under the following conditions:

passenger’s door handle

authentication pad (A) for more than

- The digital key (card key) is not

2 seconds, the door locks or unlocks.

placed on the door handle

authentication pad or vehicle

- After unlocking the doors, the doors

authentication pad (wireless

are automatically re-lock after 30

charging pad) correctly.

seconds unless a door is opened.

5-17

Convenience Features

- The digital key (card key) is near

Deleting your digital key (card key)

NFC-enabled cards such as credit

cards or smartphones.

If the digital key (card key) does not

work, try again after moving the

digital key (card key) away from the

door handle authentication pad

(more than (0.1 m (4 in.)).

•

The digital key (card key) can be

damaged by impacts. If the digital key

(card key) is damaged, replace the

digital key (card key) with a new one

and register it again.

B0902EU03

•

Long-time exposure to high

1. Turn on the vehicle with a smart key.

temperature may cause the digital key

Have your smart key with you in the

(card key) to malfunction. Be careful

vehicle.

not to expose the digital key (card key)

2. From the infotainment system Settings

to direct sunlight or high temperature.

menu, select Setup > Vehicle > Digital

•

Leaving the digital key (card key) on the

Key > Card Key > Delete.

in-vehicle authentication pad (wireless

• The "Delete" button is disabled if

charging pad) while driving may cause

there is no digital key (card key)

the digital key (card key) to

registered.

malfunction. Remove the digital key

(card key) from the in-vehicle

Personalized profile and vehicle

authentication pad (wireless charging

settings

pad) after starting the vehicle.

You can set the registered digital key

•

Remove the digital key (card key) from

(smartphone) profiles for Driver 1 and

the smartphone before charging the

Driver 2. When you use the digital key

smartphone. If the digital key (card key)

(smartphone), the vehicle can be set to

is placed between the smartphone and

the user-defined personalized profile

the in-vehicle authentication pad

(includes items such as vehicle settings

(wireless charging pad) while the

and audio preferences).

smartphone is being charged, the

digital key (card key) may malfunction.

For example, when charging

Linking/Unlinking profile

smartphone while the digital key (card

key) is attached to the back of the

How to link user profile

smartphone case.

1. Select Setup > User Profile > Profile

Settings > Link Digital Key

(Smartphone) from the Settings menu

in the infotainment system.

2. Select "Link" to connect the registered

smartphone’s digital key and the user’s

profile.

3. Follow the instructions according to the

message on the infotainment system

screen.

5-18

How to unlink user profile

Information

Select Setup > User Profile > Profile

Settings, and then deselect "Link Digital

User profile operation according to door

Key (Smartphone)" from Settings menu

lock/unlock system is as follows:

in the infotainment system.

• Unlinking is possible only when user

profile is linked.

Personalization

Item

Operation

Information

• User profile cannot be linked to both

Initial value

Guest

Driver 1 and Driver 2 that are connected

Profile linked

to single smartphone. Personalization

smartphone

Linked profile

operates with the recently linked user

key

profile, and the previously linked user

profile will be automatically canceled.

Profile

• User profile link works only when the

unlinked

digital key is registered to the vehicle.

smartphone

key

Recently activated

• Digital key (card key) cannot be linked

profile

with a user profile.

NFC card key

• If the user profile linked digital key in

Smart key

the smartphone is deleted, the digital

key should be re-registered and

personalized by linking the user profile

again.

Vehicle personalization operation

• The personalization function linked

with digital key works when the profile

linked smartphone is placed on the

outside door handle authentication pad

to lock or unlock the doors.

• The profile set by the digital key can be

changed manually from the

infotainment system.

• The personalization function using the

digital key can be operated after linking

the digital key in the infotainment

system profile menu.

• The personalization function works only

when the vehicle is OFF or when the

vehicle is started remotely. If the

vehicle is not started remotely, the

personalization function does not work

with the digital key.

5-19

Convenience Features

Vehicle personalization with digital key

The available personalization function in the vehicle is as follows:

System

Personalization Item

Lamp

Blink number of one-touch signal lamps

Information display on the cluster, Voice volume,

Cluster

Welcome sound

Infotainment

system vehicle

Seat position, Rearview mirror position, Easy Access

settings

Seat/Mirror

Intelligent driving posture assist (IMS)

Door

Automatic door lock/unlock

Preferred volume of the navigation system, Recent

Navigation

destination

Infotainment

User preset

My menu list settings, Radio preset

system

Phone

Bluetooth preferential connect

connectivity

CarPlay/Android Auto On/Off

Latest operation setup of the following functions:

Operating

Temperature, AUTO, air flow direction, air volume, air

Air conditioning

condition

conditioner, air intake control, SYNC, Front

windshield defroster, OFF

CAUTION

If you leave the digital key after locking or unlocking the doors or starting up the vehicle

with the smart key, the doors can be locked by the central door lock. Please carry around

the digital key all the time.

Information

The infotainment system may change after software updates. For more information,

refer to the user's manual provided in the infotainment system and the quick reference

guide.

5-20

Used vehicle/Digital key

• Smartphone’s mobile network setting is

off or airplane mode is activated.

maintenance

• The card key is in a wallet or card

holder, or overlapped with other cards.

Purchasing used vehicle

• If you use a smartphone cover that uses

If any of the digital key devices

wireless communication or is made of

(smartphone key, card key) are registered

metal, remove the smartphone cover.

in the vehicle, the "Digital key registered"

The vehicle may not be controlled by the

message appears once on the

smartphone if any of the following

infotainment system screen or

occurs:

instrument cluster when the Start/Stop

button is in the ON position after

•

Other smartphone functions

unlocking the doors. When purchasing a

(calls,urgent call, audio or NFC

used vehicle, make sure to check the

payment), apps, or wireless earphones

message and delete the smartphone key

are operating.

and card key registered by the previous

•

The digital key app function such as

user and inform the purchase of a used

basic setting or app launching is limited

vehicle through Hyundai Customer Care

by the prior policy according to the

Center.

manufacturer.

If the card key comes with the vehicle,

•

If you have changed the smartphone

check whether it operates properly.

number, modify the user account

information on the HYUNDAI customer

Digital Key maintenance

web site.

If you need to repaired or replaced your

•

If the vehicle owner has changed the

Digital Key system, make sure your

smartphone, register the new

smartphone key is still active. You may

smartphone in the vehicle after

have to pair your phone again using the

deleting the registered digital key

HYUNDAI Digital Key app.

(smartphone).

•

If a sharer have changed or reset the

smartphone, share the key again.

Limitations of the System

HYUNDAI Digital Key app on the

smartphone and card key may not work if:

• HYUNDAI Digital Key app is deleted.

• Account login information for HYUNDAI

Digital Key app has expired.

• Logged in with another smartphone

instead of the registered smartphone

with the same user account.

• Smartphone rooting or app hacking is

detected.

• Smartphone battery or the vehicle

battery is discharged.

• Smartphone screen is off or locked.

• NFC or Bluetooth is turned off on the

smartphone Setup.

5-21

Hyundai Ioniq 6 (2024 year). Manual in english - page 2
