Hyundai Tucson (2022 year). Manual in english - page 12

06

Auto stop

In the Auto Stop mode, if the engine

hood is opened, ISG system will be

When ISG is on the engine will be

deactivated.

stopped automatically when both of the

following occurs:

„„

Type A

1. Vehicle speed decreases to 0 mph (0

km/h) full stop condition.

2. Brake pedal is depressed and gear is

in D (Drive) or N (Neutral).

The Auto Stop (

) indicator illuminates

in green on the instrument cluster, when

the engine stops.

Information

ONX4060016

Idle stop cannot reoccur again until the

„„

Type B

vehicle speed goes above 3 mph (5 km/h)

and then returns again to the automatic

stop conditions as previously mentioned.

ONX4E060033

When the system is deactivated, the ISG

off button indicator will illuminate and

a message ‘Auto Stop is off. Shift to P or

N to start engine manually’ appears on

the cluster LCD display with a warning

sound.

If this occurs, depress the brake pedal

and restart the engine manually.

6-45

Driving your vehicle

Auto start

LCD display messages

When the engine stops automatically by

The messages are displayed on the

ISG, the engine will restart if one of the

instrument cluster to help use ISG

following is done.

system.

--

Release the brake pedal.

--

When Auto Hold is activated, take

your foot off the brake pedal and then

depress the accelerator pedal.

--

While depressing the brake pedal,

shift the gear from N (Neutral) or D

(Drive) to R (Reverse) or P (Park).

--

While depressing the brake pedal,

shift the gear from N (Neutral) to D

(Drive).

The Auto Stop (

) indicator goes to

OJX1069042L

white on the instrument cluster, when

Auto Stop is Off. Shift to P or N to start

the engine is restarted.

engine

When the system is deactivated, the ISG

off button indicator will illuminate and

a message will appear on the cluster

LCD display with a warning sound in the

following situations.

--

When the engine hood is opened.

--

When ISG system is not working

normally.

If this occurs, depress the brake pedal

and restart the engine manually. For your

safety, restart the vehicle in the P (Park)

position.

6-46

Driving your vehicle

Forced to restart engine

ISG malfunction

The engine is automatically restarted in

ISG system may not operate when there

the following situations.

is a malfunction with the ISG sensors or

• The brake vacuum pressure is low

ISG system.

The following will occur, when there is a

• The engine has stopped for about 5

malfunction with the ISG system:

minutes

• The Auto Stop (

) indicator will

• The air conditioning is ON with the fan

illuminate in yellow on the instrument

speed set to a certain high level

cluster.

• The front defroster is ON

• The light on the ISG OFF button will

• The battery is weak

illuminate.

• The cooling and heating performance

We recommend that you contact an

of the climate control system is

authorized HYUNDAI dealer.

unsatisfactory

• The vehicle is shifted to P (Park) or R

NOTICE

(Reverse) when Auto Hold is activated

If the AGM battery is reconnected or

• The door is opened or the seatbelt

replaced, ISG system will not operate

is unfastened when Auto Hold is

immediately. If you want to use the

activated

system, the battery sensor needs to be

• The EPB switch is pressed when Auto

calibrated for approximately 4 hours

Hold is activated

with the engine off.

The Auto Stop (

) indicator blinks in

After calibration, turn the engine on and

green for 5 seconds on the instrument

off 2 or 3 times.

cluster when the engine is restarted.

WARNING

When the engine is in Idle Stop mode,

the engine may restart without the

driver taking any action. Before leaving

the vehicle or working on the engine

compartment, turn off the engine by

pressing the ENGINE START/STOP

button to the OFF position.

6-48

06

DRIVE MODE INTEGRATED CONTROL SYSTEM

„„

Type A

The mode changes, as below, whenever

the DRIVE MODE button is pressed or

toggled.

NORMAL ↔ SPORT ↔ SMART ↔ SNOW

(AWD)

NORMAL - SPORT - SMART (2WD)

When NORMAL mode is selected, it is

not displayed on the instrument cluster.

ONX4060019

NORMAL mode : NORMAL mode

„„

Type B

provides smooth driving and comfortable

riding.

SPORT mode : SPORT mode provides

sporty but firm riding

The driving mode will be set to NORMAL

mode when the engine is restarted.

• If it is in NORMAL/SPORT mode,

NORMAL mode will be set, when the

engine is restarted.

ONX4E060034

The drive mode may be selected

according to the driver’s preference or

road condition.

The system resets to be in the NORMAL

mode, when the engine is restarted.

Information

If there is a problem with the instrument

cluster, the drive mode will be in

NORMAL mode and may not change to

SPORT mode.

6-49

Driving your vehicle

SPORT mode

SMART mode

SPORT mode provides sporty

SMART mode selects the proper

but firm riding.

driving mode among ECO,

In SPORT mode, the fuel

NORMAL and SPORT by judging

the driver's driving habits (i.e.

efficiency may decrease.

mild or dynamic) from the

•

When SPORT mode is selected, the

brake pedal depression or the

SPORT indicator will illuminate on the

steering wheel operation.

instrument cluster.

•

Press the DRIVE MODE button to

•

Whenever the engine is restarted,

activate SMART mode. When SMART

the drive mode will revert back to

mode is activated, the indicator

NORMAL mode. If SPORT mode is

illuminates on the instrument cluster.

desired, re-select SPORT mode.

•

The vehicle starts in SMART mode,

•

When SPORT mode is activated:

when the engine was turned OFF in

--

The engine RPM will tend to remain

SMART mode.

raised over a certain length of time

•

SMART mode automatically controls

even after releasing the accelerator

gear shifting patterns, engine torque,

--

Upshifts are delayed when

in accordance with the driver's driving

accelerating

habits.

Information

•

When your vehicle drive mode

is selected to SMART mode, the

driving mode varies according to

your acceleration pedal input. When

your vehicle is in SMART mode and

your driving style is such that your

acceleration pedal input is gradual,

the drive mode will maximize fuel

efficiency. Note, however, the actual

fuel efficiency may vary according

to certain driving conditions (uphill/

downhill grade) and vehicle speed.

•

When your vehicle is in SMART

mode and your driving style is more

aggressive such that your acceleration

pedal input is more abrupt, the drive

mode will change to reflect a more

SPORT driving characteristic. Note

that while you are driving this way, fuel

economy may be adversely affected.

6-50

Driving your vehicle

ALL WHEEL DRIVE (AWD) (IF EQUIPPED)

„„

Type A

WARNING

To reduce the risk of SERIOUS INJURY

or DEATH:

• Do not drive in conditions that

exceed the vehicles intended

design such as challenging off-road

conditions.

• Avoid high speeds when cornering or

turning.

• Do not make quick steering wheel

ONX4060013

movements, such as sharp lane

„„

Type B

changes or fast, sharp turns.

• The risk of a rollover is greatly

increased if you lose control of your

vehicle at highway speeds.

• Loss of control often occurs if two or

more wheels drop off the roadway

and the driver over steers to reenter

the roadway.

• In the event your vehicle leaves

the roadway, do not steer sharply.

ONX4E060031

Instead, slow down before pulling

The All Wheel Drive (AWD) System

back into the travel lanes.

delivers engine power to all front and

rear wheels for maximum traction. AWD

NOTICE

is useful when extra traction is required

on roads such slippery, muddy, wet, or

• Do not drive in water if the level

snow-covered roads.

is higher than the bottom of the

vehicle.

Occasional off-road use such as

• Check your brake condition once

established unpaved roads and trails are

you are out of mud or water. Depress

OK. It is always important that the driver

the brake pedal several times as you

carefully reduces the speed to a level

move slowly until you feel normal

that does not exceed the safe operating

braking return.

speed for those conditions.

• Shorten your scheduled

maintenance interval if you drive in

off-road conditions such as sand,

mud or water (see "Maintenance

Under Severe Usage Conditions" in

chapter 7).

• Always wash your vehicle thoroughly

after off road use, especially the

bottom of the vehicle.

• Be sure to equip the vehicle with four

tires of the same size and type.

• Make sure that a full time AWD

vehicle is towed by a flat bed tow

truck.

6-52

06

AWD operation

Four Wheel Drive (AWD) mode selection

Transfer

Selection

Indicator light

Description

mode

button

• AWD Auto is used when driving on

roads in normal conditions, roads in

urban areas, and on highways.

• All wheels are in operation when a

vehicle travels at a constant speed.

AWD AUTO

Required tractions applying on front

(AWD

and rear wheels vary depending on

LOCK is

road driving conditions and driving

deactivated)

conditions, which will be automatically

controlled by the computing system.

(not

• When the cluster's AWD Auto display

illuminated)

mode is selected, the cluster displays

the status of how four wheels’ traction

forces are distributed.

• The main goal of AWD Lock mode is to

allow a driver to maximize the vehicle’s

traction under extreme driving

conditions such as unpaved off-road,

sandy roads, and muddy roads.

• AWD Lock mode is in operation only

when a vehicle travels at 60 km/h or

AWD LOCK

less. When traveling at 60 km/h or

faster, the mode will switch to AWD

Auto.

• When AWD Lock mode illuminates, the

(illuminated)

cluster does not display the front/rear

wheel traction force distribution status.

• Press the AWD Lock mode switch

again to switch back to AWD Auto.

6-53

Driving your vehicle

For safe AWD operation

WARNING

Before driving

If AWD warning light (

) stays on

the instrument cluster, your vehicle

• Make sure all passengers are wearing

may have a malfunction with the AWD

seat belts.

system. When the AWD warning light

• Sit upright and closer to the steering

(

) illuminates we recommend that

wheel than usual. Adjust the steering

the vehicle be checked by an authorized

wheel to a position comfortable for

HYUNDAI dealer as soon as possible.

you to drive.

NOTICE

Driving on snow-covered or icy roads

• Start off slowly by applying the

• Maintain AWD Auto mode when

driving on roads in normal

accelerator pedal gently.

conditions.

• Use snow tires or tire chains.

• When driving under normal road

• Keep sufficient distance between your

conditions (especially when

vehicle and the vehicle in front of you.

cornering) in AWD Lock mode, a

• Use engine braking during

driver may find minor mechanical

deceleration.

vibration or noise, which is extremely

• Avoid speeding, rapid acceleration,

normal phenomenon, not a

sudden brake applications, and sharp

malfunction. When AWD Lock mode

turns to prevent skids.

is released, such noise or vibration

will be immediately gone.

Driving in sand or mud

• Maintain slow and constant speed.

CAUTION

• Use tire chains driving in mud if

When driving on normal roads,

necessary.

deactivate the AWD LOCK mode by

• Keep sufficient distance between your

pushing the AWD LOCK button (AWD

vehicle and the vehicle in front of you.

LOCK indicator light goes off). Driving

on normal roads with the AWD LOCK

• Reduce vehicle speed and always

mode, especially, when cornering

check the road condition.

may cause mechanical noise or

• Avoid speeding, rapid acceleration,

vibration. The noise and vibration will

sudden brake applications, and sharp

disappear when the AWD LOCK mode

turns to prevent getting stuck.

is deactivated. Prolong driving with the

noise and vibration may damage some

parts of the power train.

CAUTION

When the vehicle is stuck in snow, sand

NOTICE

or mud, place a non-slip material under

the drive wheels to provide traction

When the AWD LOCK mode is

OR Slowly spin the wheels in forward

deactivated, a sensation may be felt as

and reverse directions which causes

the driving power is delivered entirely

a rocking motion that may free the

to the front wheels.

vehicle. However, avoid running the

engine continuously at high RPM, doing

so may damage the AWD system.

6-54

06

OLMB053017

OLMB053018

Driving up or down hills

• Driving uphill

WARNING

--

Before starting off, check if it is

Do not drive across the contour of steep

possible to drive uphill.

hills. A slight change in the wheel angle

--

Drive as straight as possible.

can destabilize the vehicle, or a stable

vehicle may lose stability if the vehicle

• Driving downhill

stops its forward motion. Your vehicle

--

Do not change gear while driving

may roll over and lead to a serious injury

downhill. Select gear before driving

or death.

downhill.

--

Drive as slowly using engine braking

Driving through water

while driving downhill.

• Try to avoid driving in deep standing

--

Drive straight as possible.

water. It may stall your engine and

clog your exhaust pipes.

WARNING

• If you need to drive in water, stop

your vehicle, set the vehicle in AWD

Exercise extreme caution driving up or

LOCK mode and drive under 8 km/h

down steep hills. The vehicle may flip

(5 mph).

depending on the grade, terrain and

• Do not change gear while driving in

water/ mud conditions.

water.

Additional driving conditions

• Become familiar with the off-road

conditions before driving.

• Always pay attention when driving off-

road and avoid dangerous areas.

• Drive slowly when driving in heavy

wind.

• Reduce vehicle speed when

cornering. The center of gravity

of AWD vehicles is higher than

conventional 2WD vehicles, making

them more likely to roll over when you

rapidly turn corners.

6-55

Driving your vehicle

SPECIAL DRIVING CONDITIONS

Hazardous driving conditions

Rocking the vehicle

When hazardous driving elements

If it is necessary to rock the vehicle to

are encountered such as water, snow,

free it from snow, sand, or mud, first turn

ice, mud and sand, take the following

the steering wheel right and left to clear

precautions:

the area around your front wheels. Then,

• Drive cautiously and maintain a longer

shift back and forth between R (Reverse)

and a forward gear.

braking distance.

Try to avoid spinning the wheels, and do

• Avoid abrupt braking or steering.

not race the engine.

• When your vehicle is stuck in

To prevent transmission wear, wait until

snow, mud, or sand, use second

the wheels stop spinning before shifting

gear. Accelerate slowly to avoid

gears. Release the accelerator pedal

unnecessary wheel spin.

while shifting, and press lightly on the

• Put sand, rock salt, tire chains or other

accelerator pedal while the transmission

non-slip materials under the wheels to

is in gear. Slowly spinning the wheels in

provide additional traction while the

forward and reverse directions causes a

vehicle becomes stuck in ice, snow,

rocking motion that may free the vehicle.

or mud.

WARNING

WARNING

If the vehicle is stuck and excessive

Downshifting with an automatic

wheel spin occurs, the temperature

transmission while driving on slippery

in the tires can increase very quickly.

surfaces can cause an accident. The

If the tires become damaged, a tire

sudden change in tire speed could

blow out or tire explosion can occur.

cause the tires to skid. Be careful when

This condition is dangerous - you and

downshifting on slippery surfaces.

others may be injured. Do not attempt

this procedure if people or objects are

anywhere near the vehicle.

If you attempt to free the vehicle, the

vehicle can overheat quickly, possibly

causing an engine compartment fire

or other damage. Try to avoid spinning

the wheels as much as possible to

prevent overheating of either the tires

or the engine. DO NOT allow the vehicle

to spin the wheels above 35 mph (56

km/h).

Information

The ESC system must be turned OFF

before rocking the vehicle.

6-58

Driving your vehicle

Driving in flooded areas

Reducing the risk of a rollover

Avoid driving through flooded areas

Your multi-purpose passenger vehicle is

unless you are sure the water is no

defined as a Sports Utility Vehicle (SUV).

higher than the bottom of the wheel hub.

SUV’s have higher ground clearance

Drive through any water slowly. Allow

and a narrower track to make them

adequate stopping distance because

capable of performing in a wide variety

brake performance may be reduced.

of off-road applications. The specific

After driving through water, dry the

design characteristics give them a higher

center of gravity than ordinary vehicles

brakes by gently applying them several

times while the vehicle is moving slowly.

making them more likely to roll over if

you make abrupt turns. Utility vehicles

have a significantly higher rollover rate

Highway driving

than other types of vehicles. Due to this

Tires

risk, driver and passengers are strongly

Adjust the tire inflation, as specified.

recommended to buckle their seat belts.

Under-inflation may overheat or damage

In a rollover crash, an unbelted person

the tires.

is significantly more likely to die than a

Do not install worn-out or damaged tires,

person wearing a seat belt.

which may reduce traction or fail the

There are steps that a driver can make

braking operation.

to reduce the risk of a rollover. If at all

possible, avoid sharp turns or abrupt

maneuvers, do not load your vehicle

Information

with heavy cargo on the roof, and never

Never over-inflate your tires above the

modify your vehicle in any way.

maximum inflation pressure, as specified

on your tires.

WARNING

Fuel, engine coolant and engine oil

Utility vehicles have a significantly

higher rollover rate than other types of

Driving at higher speeds on the highway

vehicles. To prevent rollovers or loss of

consumes more fuel and is less efficient

control:

than driving at a slower, more moderate

speed. Maintain a moderate speed in

• Take corners at slower speeds than

order to conserve fuel when driving on

you would with a passenger vehicle.

the highway.

• Avoid sharp turns and abrupt

Be sure to check both the engine coolant

maneuvers.

level and the engine oil before driving.

• Do not modify your vehicle in any

way that you would raise the center

Drive belt

of gravity.

A loose or damaged drive belt may

• Keep tires properly inflated.

overheat the engine.

• Do not carry heavy cargo on the roof.

WARNING

In a rollover crash, an unbelted person

is significantly more likely to die than a

person wearing a seat belt. Make sure

all passengers are wearing their seat

belts.

6-60

Driving your vehicle

Tire chains

When using tire chains, attach them to

the drive wheels as follows.

„„

Type A

2WD : Front wheels

AWD : All four wheels

If a full set of chains is not

available for an AWD vehicle,

chains may be installed on the

front wheels only.

WARNING

The use of tire chains may adversely

ONX4060020

affect vehicle handling:

„„

Type B

•

Drive less than 20 mph (30 km/h)

or the chain manufacturer’s

recommended speed limit,

whichever is lower.

•

Drive carefully and avoid bumps,

holes, sharp turns, and other road

hazards, which may cause the

vehicle to bounce.

•

Avoid sharp turns or locked wheel

braking.

ONX4080023

Since the sidewalls of radial tires are

Information

thinner than other types of tires, they

may be damaged by mounting some

•

Install tire chains only in pairs and on

types of tire chains on them. Therefore,

the front tires. It should be noted that

the use of snow tires is recommended

installing tire chains on the tires will

instead of tire chains. If tire chains must

provide a greater driving force, but will

be used, use genuine HYUNDAI Parts

not prevent side skids.

and install the tire chain after reviewing

•

Do not install studded tires without

the instructions provided with the tire

first checking local and municipal

chains. Damage to your vehicle caused

regulations for possible restrictions

by improper tire chain use is not covered

against their use.

by your vehicle manufacturer’s warranty.

Wire chain (Under

235/65R17

12mm thickness) or

Fabric-type chain

235/55R19

Fabric-type

6-62

Driving your vehicle

Reference weight and distance when towing a trailer

Item

Smartstream G2.5 GDI

Maximum trailer weight

Without brake system

1,653 (750)

lbs. (kg)

With brake system

3,500 (1,588)

Maximum permissible static vertical load on the

coupling device

220 (100)

lbs. (kg)

Recommended distance from rear wheel center

to coupling point

43 (1,025)

inch (mm)

6-68

06

Trailer towing equipment

•

Any part of the rear number plate or

lighting devices of the vehicle must

Hitches

not be obscured by the mechanical

coupling device.

If the rear number plate and/or

lighting devices can be obscured

partially by any part of the mechanical

coupling device, mechanical coupling

devices that can not be easily

removed or repositioned without use

of any tools, except an easily operated

(i.e. an effort not exceeding 20Nm)

release key which is supplied by the

manufacturer of the coupling device,

ONX4E060024

are not permitted for use.

Please note that the mechanical

Information

coupling device that is fitted and

not in use must always be removed

The mounting hole for hitches are located

or repositioned if the rear number

on both sides of the underbody behind the

plate and/or rear lighting devices

rear tires.

are obscured by any part of the

mechanical coupling device.

It’s important to have the correct hitch

•

A HYUNDAI trailer hitch accessory is

equipment. Crosswinds, large trucks

available at an authorized HYUNDAI

going by, and rough roads are a few

dealer.

reasons why you’ll need the right hitch.

Here are some rules to follow:

• Do you have to make any holes in

the body of your vehicle when you

install a trailer hitch? If you do, then

be sure to seal the holes later when

you remove the hitch. If you don’t seal

them, carbon monoxide (CO) from

your exhaust can get into your vehicle,

as well as dirt and water.

• The bumpers on your vehicle are not

intended for hitches. Do not attach

rental hitches or other bumper-type

hitches to them. Use only a frame-

mounted hitch that does not attach to

the bumper.

6-69

Content      ..     10      11      12      13     ..
