Hyundai Tucson (2022 year). Manual in english - page 10

Convenient features

Sunvisor

Power outlet

„„

Front

OTM048089

ONX4E050166

To use the sunvisor, pull it downward.

„

Rear

To use the sunvisor to block the sun

from the side window, pull it downward,

release it from the bracket (1) and swing

it to the side (2) towards the window.

To use the vanity mirror, pull down the

sunvisor and slide the mirror cover (3).

Adjust the sunvisor forward or backward

(4) as needed (if equipped). Use the

ticket holder (5) to hold tickets.

Close the vanity mirror cover securely

ONX4E050167

and return the sunvisor to its original

The power outlet is designed to provide

position after use.

power for mobile telephones or other

devices designed to operate with vehicle

electrical systems. The devices should

WARNING

draw less than 180 watts with the engine

For your safety, do not block your view

running.

when using the sunvisor.

WARNING

NOTICE

Avoid electrical shocks. Do not place

The tab (5) adjacent to the vanity mirror

your fingers or foreign objects (pin, etc.)

on the sunvisor can be used for toll

into a power outlet or touch the power

road tickets or self parking tickets. Use

outlet with a wet hand.

caution when inserting tickets into the

ticket holder to avoid damage. Refrain

from putting several tickets in the ticket

holder as this could also damage the

retaining tab.

5-126

05

USB charger

CAUTION

„„

Front

To prevent damage to the power

outlets:

•

Use the power outlet only when the

engine is running and remove the

accessory plug after use. Using the

accessory plug for prolonged periods

of time with the engine off could

cause the battery to discharge.

•

Only use 12 volts electric accessories

which are less than 180 watts in

electric capacity.

ONX4E050168

•

Adjust the air-conditioner or heater

„

Rear (if equipped)

to the lowest operating level when

using the power outlet.

•

Close the cover when not in use.

•

Some electronic devices can

cause electronic interference

when plugged into a vehicle’s

power outlet. These devices may

cause excessive audio static and

malfunctions in other electronic

systems or devices used in your

ONX4050054

vehicle.

The USB charger is designed to recharge

•

Push the plug in as far as it will go. If

batteries of small size electrical devices

good contact is not made, the plug

using a USB cable.

may overheat and the fuse may open.

The electrical devices can be recharged

•

Plug in battery equipped electrical/

when the Engine Start/Stop button is in

electronic devices with reverse

the ACC or ON (or START) position.

current protection. The current

from the battery may flow into the

The battery charging state may be

vehicle’s electrical/electronic system

monitored on the electrical device.

and cause system malfunction.

Disconnect the USB cable from the USB

port after use.

• A smart phone or a tablet PC may

get warmer during the re-charging

process. It does not indicate any

malfunction with the charging system.

• A smart phone or a tablet PC, which

adopts a different re-charging

method, may not be properly re-

charged. In this case, use an exclusive

charger of your device.

• The charging terminal is only to

recharge a device. Do not use the

charging terminal either to turn ON

an audio or to play media In the

infotainment system.

5-127

Convenient features

Wireless smart phone charging

To charge a cellular phone

system (if equipped)

The wireless smart phone charging

system charges only the Qi-enabled

smart phones (

). Read the label on

the smart phone accessory cover or

visit your smart phone manufacturer’s

website to check whether your smart

phone supports the Qi technology.

The wireless charging process starts

when you put a Qi-enabled smart phone

on the wireless charging unit.

1. Remove other items, including the

smart key, from the wireless charging

ONX4050055

unit. If not, the wireless charging

process may be interrupted. Place

the smart phone on the center of the

charging pad.

2. The indicator light is orange when the

smart phone is charging. The indicator

light will turn blue when phone

charging is complete.

3. You can turn ON or OFF the wireless

charging function from the Settings

menu on the instrument cluster.

Select:

ONX4E050169

--

Setup → User settings →

[A] : Indicator light, [B] : Charging pad

Convenience → Wireless Charging

On certain models, the vehicle comes

equipped with a wireless smart phone

If your smart phone is not charging:

charger.

--

Slightly change the position of the

The system is available when all doors

smart phone on the charging pad.

are closed, and when the Engine Start/

--

Make sure the indicator light is

Stop button is in the ON (or START)

orange.

position.

5-128

Convenient features

•

When charging some smart phones

Information

with a self-protection feature,

the wireless charging speed may

If the Ignition switch is in the OFF

decrease and the wireless charging

position, the charging also stops.

may stop.

•

If the smart phone has a thick cover,

Information

the wireless charging may not be

This device complies with Part 15 of the

possible.

FCC rules. Operation is subject to the

•

If the smart phone is not completely

following three conditions:

contacting the charging pad,

1. This device may not cause harmful

wireless charging may not operate

properly.

interference, and

2. This device must accept any

•

Some magnetic items like credit

cards, phone cards or rail tickets may

interference received, including

interference that may cause undesired

be damaged if left with the smart

phone during the charging process.

operation.

3. Changes or modifications not expressly

•

When any smart phone without

approved by the party responsible

a wireless charging function or a

for compliance could void the user’s

metallic object is placed on the

authority to operate the device.

charging pad, a small noise may

sound. This small sound is due to the

vehicle discerning compatibility of

Clock

the object placed on the charging

The clock can be set from the

pad. It does not affect your vehicle or

infotainment system.

the smart phone in any way.

For detailed information, refer to the

separately supplied infotainment

system manual.

WARNING

Do not attempt to adjust the clock

while driving. Doing so may result in

distracted driving which may lead to

an accident involving personal injury or

death.

5-130

05

Coat hook

Floor mat anchor(s)

ALWAYS use the Floor Mat Anchors to

attach the front floor mats to the vehicle.

The anchors on the front floor carpet

keep the floor mats from sliding forward.

WARNING

Do not overlay additional mats or liners

over the floor mats. If using All Weather

mats, remove the carpeted floor mats

before installing them. Only use floor

OTM048095

mats designed to connect to the

anchors.

These hooks are not designed to hold

large or heavy items.

WARNING

WARNING

The following must be observed when

installing ANY floor mat to the vehicle.

• Ensure to remove a protective

film attached on the carpet

before attaching a floor mat on

the front floor carpet. Otherwise,

the floor mat may move freely on

the protective film and it could

result in unintentional braking or

accelerating.

• Ensure that the floor mats are

securely attached to the vehicle’s

floor mat anchor(s) before driving

the vehicle.

OTM048096

• Do not use ANY floor mat that cannot

Do not hang other objects such

be firmly attached to the vehicle’s

as hangers or hard objects except

floor mat anchors.

clothes. Also, do not put heavy, sharp

• Do not stack floor mats on top of one

or breakable objects in the clothes

pockets. In an accident or when the

another (e.g. all-weather rubber mat

on top of a carpeted floor mat). Only

curtain air bag is inflated, it may cause

vehicle damage or personal injury.

a single floor mat should be installed

in each position.

IMPORTANT - Your vehicle was

manufactured with driver’s side floor

mat anchors that are designed to

securely hold the floor mat in place.

To avoid any interference with pedal

operation, HYUNDAI recommends that

the HYUNDAI floor mat designed for use

in your vehicle be installed.

5-131

Convenient features

Luggage net holder (if equipped)

Cargo security screen (if

equipped)

ONX4E050080

To keep items from shifting in the

ONX4E050170

luggage compartment, you can use the 4

Use the cargo security screen to cover

holders located in the luggage side trim

items stored in the cargo area.

to attach the luggage net.

Make sure the luggage net is securely

attached to the holders in the luggage

board.

If necessary, we recommend that you

contact your authorized HYUNDAI dealer

to obtain a luggage net.

WARNING

Avoid eye injury. DO NOT overstretch

the luggage net. ALWAYS keep your

face and body out of the luggage net’s

recoil path. DO NOT use the luggage net

when the strap has visible signs of wear

or damage.

Use the luggage net to keep only light

items from shifting in the luggage

compartment.

5-132

05

Using the cargo security screen

When the cargo security screen is not in

use:

1. Pull the cargo security screen

backward and up to release it from

the guides.

2. The cargo security screen will

automatically slide back in.

Information

The cargo security screen may not

automatically slide back in if the cargo

ONX4E050171

security screen is not fully pulled out. Pull

1. Pull the cargo security screen towards

the cargo screen out all the way and then

the rear of the vehicle by the handle

slowly allow the screen to retract back in.

(1).

2. Insert the guide pin (2) into the guide

NOTICE

(3).

Since the cargo security screen may

be damaged or malformed, do not put

luggage on it when it is used.

Information

Pull out the cargo security screen with the

handle in the center to prevent the guide

WARNING

pin from falling out of the guide.

• Do not place objects on the cargo

security screen. Such objects may be

thrown about inside the vehicle and

possibly injure vehicle occupants

during an accident or when braking.

• Never allow anyone to ride in the

luggage compartment. It is designed

for luggage only.

• Maintain the balance of the vehicle

and locate the weight as forward as

possible.

5-133

Convenient features

Removing the cargo security screen

ONX4E050172

1. Push one side of the cargo screen

inward to compress the spring and

release the screen from the vehicle.

2. While the spring is compressed, pull

out the cargo security screen.

3. Open the luggage tray and keep the

cargo security screen in the tray.

5-134

05

EXTERIOR FEATURES

Roof rack (if equipped)

WARNING

•

The following specification is the

maximum weight that can be loaded

onto the roof side rails. Distribute the

load as evenly as possible onto the

roof side rails and secure the load

firmly.

Loading cargo or luggage in excess

of the specified weight limit on the

roof side rails may damage your

vehicle.

ONX4050057

ROOF SIDE

220 lbs. (100 kg)

RAILS

EVENLY DISTRIBUTED

Your vehicle may come equipped with

roof rack rails. If your vehicle is equipped

•

The vehicle center of gravity will be

with roof rack rails, you may be able to

higher when items are loaded onto

add roof rack crossbars as an accessory

the roof side rails. Avoid sudden

(not shown).

starts, braking, sharp turns, abrupt

maneuvers or high speeds that may

NOTICE

result in loss of vehicle control or

rollover resulting in an accident.

If the vehicle is equipped with a

sunroof, be sure not to position cargo

•

Always drive slowly and turn corners

onto the roof side rails in such a way

carefully when carrying items on the

that it could interfere with sunroof

roof side rails. Severe wind updrafts,

operation.

caused by passing vehicles or natural

causes, can cause sudden upward

pressure on items loaded on the

NOTICE

roof side rails. This is especially true

• When carrying cargo on the roof side

when carrying large, flat items such

rails, take the necessary precautions

as wood panels or mattresses. This

to make sure the cargo does not

could cause the items to fall off the

damage the roof of the vehicle.

roof side rails and cause damage to

your vehicle or others around you.

• When carrying large objects on the

roof side rails, make sure they do

•

To prevent damage or loss of cargo

not exceed the overall roof length or

while driving, check frequently

width.

before or while driving to make sure

the items on the roof side rails are

securely fastened.

5-135

Convenient features

INFOTAINMENT SYSTEM

NOTICE

Antenna

• If you install an aftermarket HID

Shark fin antenna

head lamp, your vehicle’s audio and

electronic devices may not function

properly.

• Prevent chemicals such as perfume,

cosmetic oil, sun cream, hand

cleaner, and air freshener from

contacting the interior parts

because they may cause damage or

discoloration.

USB Port

ONX4050058

The shark fin antenna receives

transmitted data. (for example: AM/FM,

DAB, GPS)

Steering wheel remote controls

ONX4E050173

You can use an USB cable to connect

audio devices to the vehicle USB port.

Information

When using a portable audio device

OCN7050073L

connected to the power outlet, noise may

occur during playback. If this happens,

NOTICE

use the portable audio device’s power

source.

Do not operate multiple audio remote

control buttons simultaneously.

5-136

05

VOLUME (VOL + / VOL -) (1)

Infotainment system

• Rotate the VOLUME scroll up to

(if equipped)

increase volume.

For detailed information, refer to the

• Rotate the VOLUME scroll down to

separately supplied infotainment system

decrease volume.

manual.

SEEK/PRESET (

/

) (2)

Voice recognition

If the SEEK/PRESET switch is pressed up

or down and held for 0.8 second or more,

it will function in the following modes:

• RADIO mode

It will function as the AUTO SEEK

select button. It will SEEK until you

release the button.

• MEDIA mode

It will function as the FF/RW button.

If the SEEK/PRESET switch is pressed up

OCN7050081

or down, it will function in the following

For detailed information, refer to the

modes:

separately supplied infotainment

• RADIO mode

system manual.

It will function as the PRESET STATION

UP/DOWN button.

• MEDIA mode

It will function as the TRACK UP/

DOWN button.

MODE (3)

Press the MODE button to toggle

through Radio or Media modes.

MUTE (

) (4)

• Press the MUTE button to mute the

sound.

• Press the MUTE button again to

activate the sound.

Information

See additional information in supplied

Infotainment Manual.

5-137

Driving your vehicle

Key ignition switch positions

Switch

Action

Notes

Position

To turn the ignition switch to the LOCK

position, push the key in at the ACC

position and turn the key towards the

LOCK position.

LOCK

The ignition key can be removed in

the LOCK position.

The steering wheel locks to protect

the vehicle from theft. (if equipped)

Some electrical accessories are

If difficulty is experienced turning the

usable. The steering wheel unlocks.

ignition switch to the ACC position,

ACC

turn the key while turning the steering

wheel right and left to release.

This is the normal key position when

Do not leave the ignition switch in the

the engine has started. All features

ON position when the engine is not

and accessories are usable.

running to prevent the battery from

ON

The warning lights can be checked

discharging.

when you turn the ignition switch

from ACC to ON.

To start the engine, turn the ignition

The engine will crank until you release

switch to the START position. The

the key.

START

switch returns to the ON position

when you let go of the key.

6-6

Driving your vehicle

ENGINE START/STOP BUTTON (IF EQUIPPED)

WARNING

•

NEVER press the Engine Start/Stop

button while the vehicle is in motion

except in an emergency. This will

result in the vehicle turning off and

loss of power assist for the steering

and brake systems. This may lead

to loss of directional control and

braking function, which could cause

an accident.

ONX4060001

•

Before leaving the driver’s seat,

Whenever the front door is opened, the

always make sure the gear is in the

Engine Start/Stop button will illuminate

P (Park) position, set the parking

and will go off 30 seconds after the door

brake, press the Engine Start/Stop

is closed.

button to the OFF position, and take

the Smart Key with you. Unexpected

vehicle movement may occur if these

WARNING

precautions are not followed.

To turn the vehicle off in an emergency:

•

NEVER reach through the steering

wheel for the Engine Start/Stop

Press and hold the Engine Start/Stop

button or any other control while the

button for more than two seconds OR

vehicle is in motion. The presence

Rapidly press and release the Engine

of your hand or arm in this area

Start/Stop button three times (within

may cause a loss of vehicle control

three seconds).

resulting in an accident.

If the vehicle is still moving, you can

restart the vehicle without depressing

the brake pedal by pressing the Engine

Start/Stop button with the gear in the N

(Neutral) position.

6-8

06

Engine Stop/Start button positions

Button

Action

Notes

Position

To turn off the engine, press the

If the steering wheel is not locked

Engine Start/Stop button with the

properly when you open the driver’s

vehicle shifted to P (Park).

door, the warning chime will sound.

Note if the Engine Start/Stop button

is pressed with the vehicle shifted to

D (Drive) or R (Reverse), the gear will

automatically shift to P (Park).

OFF

If the Engine Start/Stop button

is pressed with the gear shifted

to N (Neutral), the Engine Start/

Stop button will change to the ACC

position.

The steering wheel locks to protect

the vehicle from theft.

Press the Engine Start/Stop button

• If you leave the Engine Start/Stop

when the button is in the OFF position

button in the ACC position for more

without depressing the brake pedal.

than one hour, the battery power will

Some of the electrical accessories are

turn off automatically to prevent the

usable.

battery from discharging.

ACC

The steering wheel unlocks.

• If the steering wheel doesn’t

unlock properly, the Engine Start/

Stop button will not work. Press

the Engine Start/Stop button while

turning the steering wheel right and

left to release.

Press the Engine Start/Stop button

Do not leave the Engine Start/Stop

while it is in the ACC position without

button in the ON position when the

ON

depressing the brake pedal.

engine is not running to prevent the

The warning lights can be checked

battery from discharging.

before the engine is started.

To start the engine, depress the brake

If you press the Engine Start/Stop

pedal and press the Engine Start/ Stop

button without depressing the brake

button with the gear shifted to the P

pedal, the engine does not start and

START

(Park) or the N (Neutral) position.

the Engine Start/Stop button changes

For your safety, start the engine

as follows:

with the gear shifted to the P (Park)

OFF → ACC → ON → OFF or ACC

position.

6-9

Driving your vehicle

Starting the engine

1.

Always carry the smart key with you.

2.

Make sure the parking brake is

applied.

WARNING

3.

Make sure the shift lever/button is in

•

Always wear appropriate shoes when

P(Park).

operating your vehicle. Unsuitable

4.

Depress the brake pedal.

shoes, such as high heels, ski boots,

sandals, flipflops, etc., may interfere

5.

Press the Engine Start/Stop button.

with your ability to use the brake and

accelerator pedals.

Information

•

Do not start the vehicle with the

•

Do not wait for the engine to warm up

accelerator pedal depressed.

while the vehicle remains stationary.

The vehicle can move which can lead

Start driving at moderate engine

to an accident.

speeds. Steep accelerating and

•

Wait until the engine RPM is normal.

decelerating should be avoided.

The vehicle may suddenly move if

•

Always start the vehicle with your foot

the brake pedal is released when the

on the brake pedal. Do not depress the

RPM is high.

accelerator while starting the vehicle.

Do not race the engine while warming

Information

it up.

•

The vehicle will start by pressing the

Engine Start/Stop button, only when

the smart key is in the vehicle.

•

Even if the smart key is in the vehicle,

and when it is far away from the driver,

the engine may not start.

•

When the Engine Start/Stop button

is in the ACC or ON position, if any

door is open, the system checks for the

smart key. When the smart key is not

in the vehicle, the “

” indicator

will blink and the warning 'Key not in

vehicle' will come on. When all doors

are closed, the chime will also sound for

about 5 seconds. Keep the smart key in

the vehicle.

6-10

06

NOTICE

To prevent damage to the vehicle:

• If the engine stalls while you are in

motion, do not attempt to shift the

gear to the P (Park) position.

If traffic and road conditions permit,

you may put the gear in N (Neutral)

while the vehicle is still moving and

press the Engine Start/Stop button in

an attempt to restart the engine.

ONX4060002

• Do not push or tow your vehicle to

start the vehicle.

Information

NOTICE

If the smart key battery is weak or the

To prevent damage to the vehicle:

smart key does not work correctly, you

can start the vehicle by pressing the

Do not press the Engine Start/Stop

Engine Start/Stop button with the smart

button for more than 10 seconds except

key in the direction of the picture above.

when the stop lamp fuse is blown.

When the stop lamp fuse is blown,

Turning off the engine

you cannot normally start the engine.

Replace the fuse with a new one. If you

1. Stop the vehicle and depress the

are not able to replace the fuse, you

brake pedal fully.

can start the engine by pressing and

2. Make sure the shift lever/button is in

holding the Engine Start/Stop button

P(Park).

for 10 seconds with the Engine Start/

3. Press the Engine Start/Stop button

Stop button in the ACC position.

to the OFF position and apply the

For your safety always depress the

parking brake.

brake pedal before starting the vehicle.

6-11

Driving your vehicle

Auto shut-off system (if equipped)

Remote start (if equipped)

To prevent accidents caused by carbon

„„

Type A

dioxide poisoning, the engine is turned

off automatically 60 minutes later when

the following conditions are satisfied.

The timer appears on the instrument

cluster 30 minutes before it turns off

automatically.

Operating conditions

• The driver does not fasten a seat belt

• No one in the passenger's seat

OTM060003

• Stop the vehicle and the speed is

„„

Type B

under 1.86mph and the gear shift is

in P

• While the brake or accelerator is not

working

• When AVN update is performing

Cluster timer reset conditions

• Release the accelerator or brake after

completing operation

• Press the OK button on the steering

OTM060004

wheel while the timer appears on the

You can start the vehicle using the

instrument cluster

Remote Start button of the smart key.

Off conditions

• The driver fastened the seat belt

• A passenger is in the pasenger's seat

• Driving over 1.86mph

• Shifting the gear in R, N or D

CAUTION

Please do not leave a passenger or a pet

in the vehicle since the air conditioning

system stops when the engine is off.

6-12

Content      ..     8      9      10      11     ..
