Hyundai Tucson (2022 year). Manual in english - page 13

06

The Loading Information Label

Vehicle capacity weight

„„

For example

5 persons : 926 lbs (420 kg)

Vehicle capacity weight is the maximum

combined weight of occupants and

cargo. If your vehicle is equipped with a

trailer, the combined weight includes the

tongue load.

Seating capacity

Total : 5 persons (Front seat : 2 persons,

Rear seat : 3 persons)

Seating capacity is the maximum

ONX4060021N

number of occupants including a driver,

The label located on the driver’s door

your vehicle may carry. However, the

sill gives the original tire size, cold

seating capacity may be reduced based

tire pressures recommended for your

upon the weight of all of the occupants,

vehicle, the number of people that can

and the weight of the cargo being carried

be in your vehicle and vehicle capacity

or towed. Do not overload the vehicle as

weight.

there is a limit to the total weight, or load

limit including occupants and cargo, the

vehicle can carry.

Towing capacity

With brake system : 3,500 lbs (1,588 kg)

Towing capacity is the maximum trailer

weight including its cargo weight, your

vehicle can tow.

Cargo capacity

The cargo capacity of your vehicle will

increase or decrease depending on the

weight and the number of occupants

and the tongue load, if your vehicle is

equipped with a trailer.

6-75

06

Example 1

≥

+

Maximum Load

Passenger Weight

Cargo Weight

(1400 lbs.)

(150 lbs. × 2 = 300 lbs.)

(1100 lbs.)

(635 kg)

(68 kg × 2 = 136 kg)

(499 kg)

Example 2

≥

+

Maximum Load

Passenger Weight

Cargo Weight

(1400 lbs.)

(150 lbs. × 5 = 750 lbs.)

(650 lbs.)

(635 kg)

(68 kg × 5 = 340 kg)

(295 kg)

Example 3

≥

+

Maximum Load

Passenger Weight

Cargo Weight

(1400 lbs.)

(172 lbs. × 5 = 860 lbs.)

(540 lbs.)

(635 kg)

(78 kg × 5 = 390 kg)

(245 kg)

6-77

Driver assistance system

FORWARD COLLISION-AVOIDANCE ASSIST (FCA)

(FRONT VIEW CAMERA ONLY) (IF EQUIPPED)

Basic function

CAUTION

Take the following precautions to

maintain optimal performance of the

detecting sensor:

• NEVER disassemble the detecting

sensor or sensor assembly, or apply

any impact on it.

• If the detecting sensor have been

replaced or repaired, we recommend

that you have your vehicle inspected

by an authorized HYUNDAI dealer.

OTM070237

• NEVER install any accessories or

Forward Collision-Avoidance Assist is

stickers on the front windshield, or

designed to help detect and monitor the

tint the front windshield.

vehicle ahead or help detect a pedestrian

• Pay extreme caution to keep the

or cyclist in the roadway and warn the

front view camera dry.

driver that a collision is imminent with

• NEVER place any reflective objects

a warning message and an audible

(i.e. white paper, mirror) over the

warning, and if necessary, apply

dashboard.

emergency braking.

Detecting sensor

ONX4E050146

[1] : Front view camera

Refer to the picture above for the

detailed location of the detecting sensor.

7-2

07

Forward Collision-Avoidance

The driver can monitor Forward

Collision-Avoidance Assist ON/OFF

Assist Settings

status from the Settings menu. If the

Setting features

warning light remains ON when Forward

Collision-Avoidance Assist is ON, we

recommend that you have the vehicle

inspected by an HYUNDAI dealer.

WARNING

When the engine is restarted, Forward

Collision-Avoidance Assist will always

turn on. However, if ‘Off’ is selected

after the engine is restarted, the

driver should always be aware of the

OTM070090N

surroundings and drive safely.

Forward Safety

With the engine on, select or deselect

CAUTION

‘Driver Assistance → Forward Safety’ from

the Settings menu to set whether or not

If ‘Warning Only’ is selected, braking is

not assisted.

to use each function.

--

If ‘Active Assist’ is selected, Forward

Collision-Avoidance Assist will warn

Information

the driver with a warning message

Forward Collision-Avoidance Assist

and an audible warning depending on

will turn off when ESC is turned off by

the collision risk levels. Braking assist

pressing and holding the ESC OFF button

will be applied depending on the

for more than 3 seconds. The

warning

collision risk.

light will illuminate on the cluster.

--

If ‘Warning Only’ is selected, Forward

Collision-Avoidance Assist will warn

the driver with a warning message

and an audible warning depending on

the collision risk levels. Braking will

not be assisted. The driver must apply

the brake pedal or steer the vehicle if

necessary.

--

If ‘Off’ is selected, Forward Collision-

Avoidance Assist will turn off. The

warning light will illuminate on the

cluster.

7-3

Driver assistance system

OTM070140N

OTM070141N

Warning Timing

Warning Volume

With the engine on, select ‘Driver

With the engine on, select ‘Driver

Assistance → Warning Timing’ from the

Assistance → Warning Volume’ from the

Settings menu to change the initial

Settings menu to change the Warning

warning activation time for Forward

Volume to ‘High’, ‘Medium’ or ‘Low’ for

Collision-Avoidance Assist.

Forward Collision-Avoidance Assist.

When the vehicle is first delivered,

If you change the Warning Volume,

Warning Timing is set to ‘Normal’. If you

the Warning Volume of other Driver

change the Warning Timing, the warning

Assistance systems may change.

time of other Driver Assistance systems

may change.

CAUTION

• The setting of the Warning Timing

and Warning Volume applies to

all functions of Forward Collision-

Avoidance Assist.

• Even though, ‘Normal’ is selected for

Warning Timing if the front vehicle

suddenly stops the initial warning

activation time may not seem late.

• Select ‘Late’ for Warning Timing

when traffic is light and when driving

speed is slow.

Information

If the engine is restarted, Warning Timing

and Warning Volume will maintain the

last setting.

7-4

07

Forward Collision-Avoidance

WARNING

Assist Malfunction and

• Even if there is a problem with

Limitations

Forward Collision-Avoidance

Assist, the vehicle’s basic braking

Forward Collision-Avoidance Assist

performance will operate normally.

malfunction

• During emergency braking, braking

„„

Type A

„

Type B

control by Forward Collision-

Avoidance Assist will automatically

cancel when the driver excessively

depresses the accelerator pedal or

sharply steers the vehicle.

CAUTION

Depending on the condition of the

vehicle, pedestrian and cyclist in front

and the surroundings, the speed range

OTM070094N

OTM070094L

to operate Forward Collision-Avoidance

When Forward Collision-Avoidance

Assist may reduce. Forward Collision-

Assist is not working properly, the ‘Check

Avoidance Assist may only warn the

Forward Safety system(s)’ warning

driver, or it may not operate.

message will appear, and the and

warning lights will illuminate on the

cluster. Have the vehicle inspected by an

Information

authorized HYUNDAI dealer.

In a situation where collision is imminent,

braking may be assisted by Forward

Collision-Avoidance Assist when braking

is insufficient by the driver.

7-7

Driver assistance system

Forward Collision-Avoidance Assist

Limitations of Forward Collision-

disabled

Avoidance Assist

Forward Collision-Avoidance Assist may

not operate normally, or it may operate

unexpectedly under the following

circumstances:

•

The detecting sensor or the

surroundings are contaminated or

damaged

•

The temperature around the front

view camera is high or low

•

The camera lens is contaminated due

OTM070093N

to tinted, filmed or coated windshield,

damaged glass, or sticky foreign

When the front windshield where the

material (sticker, bug, etc.) on the

front view camera is located or the

glass

sensor is covered with foreign material,

such as snow or rain, it can reduce the

•

Moisture is not removed or frozen on

the windshield

detecting performance and temporarily

limit or disable Forward Collision-

•

Washer fluid is continuously sprayed,

Avoidance Assist.

or the wiper is on

If this occurs the ‘Forward Safety

•

Driving in heavy rain or snow, or thick

system(s) disabled. Camera obscured’

fog

warning message, and the and

•

The field of view of the front view

warning lights will illuminate on the

camera is obstructed by sun glare

cluster.

•

Street light or light from an oncoming

Forward Collision-Avoidance Assist will

vehicle is reflected on the wet road

operate normally when such snow, rain

surface, such as a puddle on the road

or foreign material is removed.

•

An object is placed on the dashboard

If Forward Collision-Avoidance Assist

•

Your vehicle is being towed

does not operate normally after

obstruction (snow, rain, or foreign

•

The surrounding is very bright

material) is removed, have the vehicle

•

The surrounding is very dark, such as

inspected by an authorized HYUNDAI

in a tunnel, etc.

dealer.

•

The brightness changes suddenly, for

example when entering or exiting a

WARNING

tunnel

•

The brightness outside is low, and the

• Even though the warning message or

headlamps are not on or are not bright

warning light does not appear on the

cluster, Forward Collision-Avoidance

Assist may not properly operate.

• Forward Collision-Avoidance Assist

may not properly operate in an

area (e.g. open terrain), where any

substance are not detected after

turning ON the engine.

7-8

Driver assistance system

•

There is a group of pedestrians,

WARNING

cyclists or a large crowd in front

•

Driving on a curve

•

The pedestrian or cyclist is wearing

clothing that easily blends into the

background, making it difficult to

detect

•

The pedestrian or cyclist is difficult to

distinguish from the similar shaped

structure in the surroundings

•

You are driving by a pedestrian,

cyclist, traffic sign, structure, etc. near

the intersection

•

Driving in a parking lot

•

Driving through a tollgate,

OADAS003

construction area, unpaved road,

partial paved road, uneven road,

speed bumps, etc.

•

Driving on an incline road, curved

road, etc.

•

Driving through a roadside with trees

or streetlights

•

The adverse road conditions cause

excessive vehicle vibrations while

driving

•

Your vehicle height is low or high

OADAS002

due to heavy loads, abnormal tire

pressure, etc.

•

Driving through a narrow road where

trees or grass are overgrown

•

There is interference by

electromagnetic waves, such as

driving in an area with strong radio

waves or electrical noise

OADAS001

Forward Collision-Avoidance Assist

may not detect other vehicles,

pedestrians or cyclists in front of you

on curved roads adversely affecting

the performance of the sensors. This

may result in no warning or braking

assist when necessary.

7-10

07

When driving on a curve, you must

• Driving on a slope

maintain a safe braking distance,

and if necessary, steer the vehicle

and depress the brake pedal to

reduce your driving speed in order to

maintain a safe distance.

OADAS009

OADAS006

OADAS008

OADAS005

OADAS007

Forward Collision-Avoidance Assist

may not detect other vehicles,

pedestrians or cyclists in front of

you while driving uphill or downhill

OADAS004

adversely affecting the performance

of the sensors.

Forward Collision-Avoidance Assist

may detect a vehicle, pedestrian or

cyclist in the next lane or outside the

lane when driving on a curved road.

If this occurs, Forward Collision-

Avoidance Assist may unnecessarily

warn the driver and control the

brake. Always check the traffic

conditions around the vehicle.

7-11

Driver assistance system

This may result in unnecessary

• Changing lanes

warning or braking assist, or no

warning or braking assist when

necessary.

Also, vehicle speed may rapidly

decrease when a vehicle, pedestrian

or cyclist ahead is suddenly

detected.

Always have your eyes on the road

while driving uphill or downhill and

if necessary, steer the vehicle and

depress the brake pedal to reduce

your driving speed in order to

maintain a safe distance.

OADAS032

[A] : Your vehicle,

[B] : Lane changing vehicle

When a vehicle moves into your lane

from an adjacent lane, it cannot

be detected by the sensor until it

is in the sensor's detection range.

Forward Collision-Avoidance Assist

may not immediately detect the

vehicle when the vehicle changes

lanes abruptly. In this case, you must

maintain a safe braking distance,

and if necessary, steer the vehicle

and depress the brake pedal to

reduce your driving speed in order to

maintain a safe distance.

7-12

07

• Detecting vehicle

ONX4E070004

If the vehicle in front of you has

cargo that extends rearward from

the cab, or when the vehicle in front

of you has higher ground clearance,

additional special attention is

required. Forward Collision-

Avoidance Assist may not be able

to detect the cargo extending from

the vehicle. In these instances,

you must maintain a safe braking

OADAS033

[A] : Your vehicle,

distance from the rearmost object,

and if necessary, steer the vehicle

[B] : Lane changing vehicle,

[C] : Same lane vehicle

and depress the brake pedal to

reduce your driving speed in order to

When a vehicle in front of you

maintain distance.

merges out of the lane, Forward

Collision-Avoidance Assist may not

immediately detect the vehicle that

is now in front of you.

In this case, you must maintain a safe

braking distance, and if necessary,

steer the vehicle and depress the

brake pedal to reduce your driving

speed in order to maintain a safe

distance.

7-13

07

FORWARD COLLISION-AVOIDANCE ASSIST (FCA) (SENSOR

FUSION) (IF EQUIPPED)

Basic function

Detecting sensor

OJX1070255L

ONX4E050146

Forward Collision-Avoidance Assist is

designed to help detect and monitor the

vehicle ahead or help detect a pedestrian

or cyclist in the roadway and warn the

driver that a collision is imminent with

a warning message and an audible

warning, and if necessary, apply

emergency braking.

Junction Turning function (if equipped)

ONX4070005

[1] : Front view camera,

[2] : Front radar

Refer to the picture above for the

detailed location of the detecting

sensors.

ONX4070083

Junction Turning function will help avoid

a collision with an oncoming vehicle in

an adjacent lane when turning left (left-

hand drive) or right (right-hand drive) at

a crossroad with the turn signal on by

applying emergency braking.

7-15

07

Forward Collision-Avoidance

The driver can monitor Forward

Collision-Avoidance Assist ON/OFF

Assist Settings

status from the Settings menu. If the

Setting features

warning light remains ON when Forward

Collision-Avoidance Assist is ON, have

the vehicle inspected by an authorized

HYUNDAI dealer.

WARNING

When the engine is restarted, Forward

Collision-Avoidance Assist will always

turn on. However, if ‘Off’ is selected

after the engine is restarted, the

driver should always be aware of the

OTM070090N

surroundings and drive safely.

Forward Safety

With the engine on, select ‘Driver

CAUTION

Assistance → Forward Safety’ from the

Settings menu to set whether or not to

• If ‘Warning Only’ is selected, braking

is not assisted.

use each function.

--

If ‘Active Assist’ is selected, Forward

• The settings for Forward Safety

include ‘Basic function’ and ‘Junction

Collision-Avoidance Assist will warn

the driver with a warning message

Turning’ (if equipped).

and an audible warning depending on

the collision risk levels. Braking assist

Information

will be applied depending on the

collision risk.

Forward Collision-Avoidance Assist

will turn off when ESC is turned off by

--

If ‘Warning Only’ is selected, Forward

pressing and holding the ESC OFF button

Collision-Avoidance Assist will warn

for more than 3 seconds. The

warning

the driver with a warning message

light will illuminate on the cluster.

and an audible warning depending on

the collision risk levels. Braking will

not be assisted. The driver must apply

the brake pedal or steer the vehicle if

necessary.

--

If ‘Off’ is selected, Forward Collision-

Avoidance Assist will turn off. The

warning light will illuminate on the

cluster.

7-17

Driver assistance system

OTM070140N

OTM070141N

Warning Timing

Warning Volume

With the engine on, select ‘Driver

With the engine on, select ‘Driver

Assistance → Warning Timing’ from the

Assistance → Warning Volume’ from the

Settings menu to change the initial

Settings menu to change the Warning

warning activation time for Forward

Volume to ‘High’, ‘Medium’ or ‘Low’ for

Collision-Avoidance Assist.

Forward Collision-Avoidance Assist.

When the vehicle is first delivered,

If you change the Warning Volume,

Warning Timing is set to ‘Normal’. If you

the Warning Volume of other Driver

change the Warning Timing, the warning

Assistance systems may change.

time of other Driver Assistance systems

may change.

CAUTION

• The setting of the Warning Timing

and Warning Volume applies to

all functions of Forward Collision-

Avoidance Assist.

• Even though ‘Normal’ is selected for

Warning Timing, if the front vehicle

suddenly stops, the initial warning

activation time may seem late.

• Select ‘Late’ for Warning Timing

when traffic is light and when driving

speed is slow.

Information

If the engine is restarted, Warning Timing

and Warning Volume will maintain the

last setting.

7-18

07

Forward Collision-Avoidance

CAUTION

Assist Malfunction and

• Forward Collision-Avoidance

Limitations

Assist operating speed range may

reduce due to the conditions of

Forward Collision-Avoidance Assist

the vehicle or pedestrian in front

malfunction

or surroundings. Depending on the

„„

Type A

„

Type B

speed, Forward Collision-Avoidance

Assist may only warn the driver, or it

may not operate.

• Forward Collision-Avoidance Assist

will operate under certain conditions

by judging the risk level based on

the condition of the oncoming

vehicle, driving direction, speed and

surroundings.

OTM070094N

OTM070094L

Information

When Forward Collision-Avoidance

In a situation where collision is imminent,

Assist is not working properly, the ‘Check

braking may be assisted by Forward

Forward Safety system(s)’ warning

Collision-Avoidance Assist when braking

message will appear, and the and

is insufficient by the driver.

warning lights will illuminate on the

cluster. Have the vehicle inspected by an

authorized HYUNDAI dealer.

7-23

Driver assistance system

Forward Collision-Avoidance Assist

WARNING

disabled

• Even though the warning message or

warning light does not appear on the

cluster, Forward Collision-Avoidance

Assist may not properly operate.

• Forward Collision-Avoidance Assist

may not properly operate in an

area (e.g. open terrain), where any

substance are not detected after

turning ON the engine.

Limitations of Forward Collision-

Avoidance Assist

OTM070093N

OTM070095N

Forward Collision-Avoidance Assist may

When the front windshield where the

not operate normally, or it may operate

front view camera is located, front radar

unexpectedly under the following

cover or sensor is covered with foreign

circumstances:

material, such as snow or rain, it can

reduce the detecting performance and

•

The detecting sensor or the

temporarily limit or disable Forward

surroundings are contaminated or

Collision-Avoidance Assist.

damaged

If this occurs the ‘Forward Safety

•

The temperature around the front

system(s) disabled. Camera obscured’ or

view camera is high or low

the ‘Forward Safety system(s) disabled.

•

The camera lens is contaminated due

Radar blocked’ warning message,

to tinted, filmed or coated windshield,

and the and warning lights will

damaged glass, or sticky foreign

illuminate on the cluster.

material (sticker, bug, etc.) on the

Forward Collision-Avoidance Assist will

glass

operate normally when when such snow,

•

Moisture is not removed or frozen on

rain or foreign material is removed.

the windshield

If Forward Collision-Avoidance Assist

•

Washer fluid is continuously sprayed,

does not operate normally after

or the wiper is on

obstruction (snow, rain, or foreign

•

Driving in heavy rain or snow, or thick

material) is removed, Have the vehicle

fog

inspected by an authorized HYUNDAI

dealer.

•

The field of view of the front view

camera is obstructed by sun glare

•

Street light or light from an oncoming

vehicle is reflected on the wet road

surface, such as a puddle on the road

•

An object is placed on the dashboard

7-24

Content      ..     11      12      13      14     ..
