Hyundai H-1 / Grand Starex (2016 year). Instruction - part 15

Driving your vehicle

E040101AUN

✽ NOTICE - A2 2.5 Diesel Engine

Starting the diesel engine

Glow indicator light

If the accelerator is pressed for a long

time while standing still, the engine

To start the diesel engine when the

power will be limited to prevent the

engine is cold, it has to be pre-heated

exhaust parts from overheating.

before starting the engine and then have

to be warmed up before starting to drive.

1. Make sure the parking brake is

applied.

2. Manual Transmission - Depress the

clutch pedal fully and shift the trans-

mission into Neutral. Keep the clutch

pedal and brake pedal depressed

W-60

while turning the ignition switch to the

3. Turn the ignition switch to the ON posi-

start position.

tion to pre-heat the engine. Then the

Automatic Transmission - Place the

glow indicator light will illuminate.

transmission shift lever in P(park).

4. If the glow indicator light goes out, turn

Depress the brake pedal fully.

the ignition switch to the START posi-

You can also start the engine when the

tion and hold it there until the engine

shift lever is in the N(neutral) position.

starts (a maximum of 10 seconds),

then release the key.

✽ NOTICE

If the engine were not started within 10

seconds after the preheating is complet-

ed, turn the ignition switch once more to

the LOCK position during 10 seconds,

and then to the ON position, in order to

preheat again.

5 7

Driving your vehicle

Starting and stopping the engine for tur-

bocharger intercooler

1. Do not race or accelerate the engine

immediately after starting.

If the engine is cold, idle for several

seconds before sufficient lubrication is

ensured in the turbocharger unit.

2. After high speed or extended driving,

requiring a heavy engine load, run the

engine on idle condition about 1 minute

before turning it off.

This idle time will allow the tur-

bocharger to cool prior to shutting the

engine off.

CAUTION

Do not turn the engine off immedi-

ately after it has been subjected to

a heavy load. Doing so may cause

severe damage to the engine or tur-

bocharger unit.

5 8

Driving your vehicle

MANUAL TRANSMISSION (IF EQUIPPED)

■ Type A

E050100DTQ

Manual transmission operation

CAUTION

•

When downshifting from fifth

The manual transmission has 5 (or 6, if

gear to fourth gear, caution

equipped) forward gears.

This shift pattern is imprinted on the shift

should be taken not to inadver-

knob. The transmission is fully synchro-

tently press the gear shift lever

sideways in such a manner that

nized in all forward gears so shifting to

second gear is engaged. Such a

either a higher or a lower gear is easily

drastic downshift may cause the

accomplished.

N

Press the clutch pedal down fully while

engine speed to increase to the

shifting, then release it slowly.

point that the tachometer will

enter the red-zone. Such over-

If your vehicle is equipped with an igni-

revving of the engine may possi-

tion lock switch, the engine will not start

■ Type B

when starting the engine without

bly cause engine damage.

depressing the clutch pedal. (if equipped)

•

Do not downshift more than 2

The gearshift lever must be returned to

gears or downshift the gear when

the neutral position before shifting into R

the engine is running at high

(Reverse).

speed

(5,000 RPM or higher).

Make sure the vehicle is completely

Such a downshifting may damage

stopped before shifting into R (Reverse).

the engine, clutch and the trans-

mission.

Never operate the engine with the

tachometer (rpm) in the red zone.

The shift lever can be moved without

pulling the ring (1).

The ring (1) must be pulled up while

moving the shift lever.

OTQ057004/OCM050003

5 9

Driving your vehicle

• During cold weather, shifting may be

E050101AUN

difficult until the transmission lubricant

WARNING

Using the clutch

is warmed up. This is normal and not

•

Before leaving the driver’s seat,

The clutch should be pressed all the way

harmful to the transmission.

always set the parking brake fully

to the floor before shifting, then released

• If you've come to a complete stop and

and shut the engine off. Then

slowly. The clutch pedal should always be

it's hard to shift into 1st or R(Reverse),

make sure the transmission is

fully released while driving. Do not rest

leave the shift lever at N(Neutral) posi-

shifted into

1st gear when the

your foot on the clutch pedal while driv-

tion and release the clutch. Press the

vehicle is parked on a level or

ing. This can cause unnecessary wear.

clutch pedal back down, and then shift

uphill grade, and shifted into R

Do not partially engage the clutch to hold

into 1st or R(Reverse) gear position.

(Reverse) on a downhill grade.

the car on an incline. This causes unnec-

Unexpected and sudden vehicle

essary wear. Use the foot brake or park-

movement can occur if these pre-

ing brake to hold the car on an incline. Do

CAUTION

cautions are not followed in the

not operate the clutch pedal rapidly and

•

To avoid premature clutch wear

order identified.

repeatedly.

and damage, do not drive with

•

If your vehicle has a manual

your foot resting on the clutch

transmission not equipped with a

E050102AUN

pedal. Also, don’t use the clutch

ignition lock switch, it may move

Downshifting

to hold the vehicle stopped on an

and cause a serious accident

When you must slow down in heavy traf-

uphill grade, while waiting for a

when starting the engine without

fic or while driving up steep hills, down-

traffic light, etc.

depressing the clutch pedal while

shift before the engine starts to labor.

•

Do not use the shift lever as a

the parking brake is released and

Downshifting reduces the chance of

handrest during driving, as this

the shift lever not in the N

stalling and gives better acceleration

can result in premature wear of

(Neutral) position.

when you again need to increase your

the transmission shift forks.

•

Do not use the engine brake

speed. When the vehicle is traveling

•

To prevent possible damage to

(shifting from a high gear to

down steep hills, downshifting helps

the clutch system, do not start

lower gear) rapidly on slippery

maintain safe speed and prolongs brake

with the

2nd

(second) gear

roads. The vehicle may slip caus-

life.

engaged except when you start

ing an accident.

on a slippery road.

5 10

Driving your vehicle

E050200AUN

•

Exercise extreme caution when driving

Good driving practices

on a slippery surface. Be especially

WARNING

careful when braking, accelerating or

•

Never take the car out of gear and

•

Always buckle-up! In a collision,

shifting gears. On a slippery surface,

coast down a hill. This is extremely

an unbelted occupant is signifi-

hazardous. Always leave the car in

an abrupt change in vehicle speed can

cantly more likely to be seriously

gear.

cause the drive wheels to lose traction

injured or killed than a properly

and the vehicle to go out of control.

belted occupant.

•

Don't "ride" the brakes. This can cause

them to overheat and malfunction.

•

Avoid high speeds when corner-

Instead, when you are driving down a

ing or turning.

long hill, shift to a lower gear. When

•

Do not make quick steering

you do this, engine braking will help

wheel movements, such as sharp

slow the car.

lane changes or fast, sharp turns.

•

Slow down before shifting to a lower

•

The risk of rollover is greatly

gear. This will help avoid over-revving

increased if you lose control of

the engine, which can cause damage.

your vehicle at highway speeds.

•

Slow down when you encounter cross

•

Loss of control often occurs if

winds. This gives you much better con-

two or more wheels drop off the

trol of your car.

roadway and the driver over-

•

Be sure the car is completely stopped

steers to reenter the roadway.

before you attempt to shift into reverse.

•

In the event your vehicle leaves

The transmission can be damaged if

the roadway, do not steer sharply.

you do not. To shift into reverse,

Instead, slow down before pulling

depress the clutch, move the shift lever

back into the travel lanes.

to neutral, wait 3 seconds, then shift to

•

Never exceed posted speed lim-

the reverse position.

its.

5 11

Driving your vehicle

AUTOMATIC TRANSMISSION

■ Type A

■ Type B

Lock release button prevents shift lever move-

Lock release button prevents shift lever move-

ment without first depressing the button.

ment without first depressing the button.

O/D button

Automatic mode

Sports mode

Depress the brake pedal and lock release button when shifting, if your vehicle is

equipped with shift lock system

The lock release button must be depressed while moving the shift lever.

The shift lever can be moved without depressing the lock release button.

OTQ057006G/OTQ057006

5 12

Driving your vehicle

E060100BTQ

For smooth operation, depress the brake

Automatic transmission operation

pedal when shifting from N (Neutral) to a

CAUTION

forward or reverse gear.

•

To avoid damage to your trans-

The automatic transmission has 5 (or 4)

mission, do not accelerate the

forward speeds and one reverse speed.

The individual speeds are selected auto-

engine in R (Reverse) or any for-

WARNING - Automatic

ward gear position with the

matically, depending on the position of

transmission

brakes on.

the shift lever.

•

Always check the surrounding

•

When stopped on an incline, do

areas near your vehicle for peo-

not hold the vehicle stationary

✽ NOTICE

ple, especially children, before

with engine power. Use the serv-

The first few shifts on a new vehicle, if

shifting a car into D (Drive) or R

ice brake or the parking brake.

the battery has been disconnected, may

(Reverse).

•

Do not shift from N (Neutral) or P

be somewhat abrupt. This is a normal

•

Before leaving the driver’s seat,

(Park) into D

(Drive), or R

condition, and the shifting sequence will

always make sure the shift lever

(Reverse) when the engine is

adjust after shifts are cycled a few times

is in the P (Park) position; then

above idle speed.

by the TCM (Transmission Control

set the parking brake fully and

Module) or PCM (Powertrain Control

shut the engine off. Unexpected

Module).

and sudden vehicle movement

can occur if these precautions

are not followed in the order iden-

tified.

•

Do not use the engine brake

(shifting from a high gear to

lower gear) rapidly on slippery

roads. The vehicle may slip caus-

ing an accident.

5 13

Driving your vehicle

E060101DTQ

R (Reverse)

Transmission ranges

CAUTION

Use this position to drive the vehicle

The indicator in the instrument cluster

The transmission may be damaged

backward.

displays the shift lever position when the

if you shift into P (Park) while the

ignition switch is in the ON position.

vehicle is in motion.

CAUTION

Always come to a complete stop

P (Park)

before shifting into or out of R

Always come to a complete stop before

(Reverse); you may damage the

shifting into P (Park). This position locks

transmission if you shift into R

the transmission and prevents the drive

while the vehicle is in motion,

wheels from rotating.

except as explained in “Rocking the

vehicle” in this section.

WARNING

• Shifting into P (Park) while the

N (Neutral)

vehicle is in motion will cause the

The wheels and transmission are not

drive wheels to lock which will

engaged. The vehicle will roll freely even

cause you to lose control of the

on the slightest incline unless the parking

vehicle.

brake or service brakes are applied.

• Do not use the P (Park) position

in place of the parking brake.

WARNING

Always make sure the shift lever

Do not drive with the shift lever in N

is latched in the P (Park) position

and set the parking brake fully.

(Neutral).

The engine brake will not work and

• Never leave a child unattended in

lead to an accident.

a vehicle.

5 14

Driving your vehicle

D (Drive)

L (Low, if equipped)

This is the normal forward driving posi-

Move the shift lever to this position in

tion. The transmission will automatically

hard pulling situations and for climbing

shift through a 5 (or 4)-gear sequence,

steep grades.

providing the best fuel economy and

power.

CAUTION

Do not exceed the recommended

For extra power when passing another

maximum speeds in

2

(Second

vehicle or climbing grades, depress the

Gear) or L

(Low). Operating the

accelerator fully, at which time the trans-

vehicle at speeds above the maxi-

mission will automatically downshift to

mum recommended, for 2 (Second

the next lower gear.

Gear) or L (Low) may cause exces-

OTQ057007G

sive heat to develop which could

✽ NOTICE

result in damage to or failure of the

O/D (Over Drive) system

Always come to a complete stop before

automatic transmission.

(if equipped)

shifting into D (Drive).

Pressing the O/D system button cancels

and engages the overdrive system.

2 (Second Gear, if equipped)

When the O/D system is cancelled, the

Use 2 (Second Gear) for more power

O/D OFF indicator illuminates and the

when climbing hills and for increased

transmission gear range is limited to 1st

braking when going down hills. This posi-

through 3rd.

tion also helps reduce wheel spin on slip-

pery surfaces. When the shift lever is

placed in 2 (Second Gear), the transmis-

sion will automatically shift from first to

second gear.

5 15

Driving your vehicle

The transmission will not shift to 4th gear

✽ NOTICE

until the O/D system button is pressed

•

In sports mode, the driver must exe-

again to release the switch.

cute upshifts in accordance with road

When driving down a sloping road with

conditions, taking care to keep the

the transmission in O/D (4th), you can

engine speed below the red zone.

decrease the vehicle speed without using

+ (UP)

•

In sports mode, only the 5 forward

the brakes by pressing the O/D button.

gears can be selected. To reverse or

When the ignition is switched OFF, O/D

Sports mode

park the vehicle, move the shift lever

OFF mode is automatically cancelled.

to the R (Reverse) or P (Park) position

as required.

O/D OFF Indicator

•

In sports mode, downshifts are made

- (DOWN)

automatically when the vehicle slows

This indicator light illuminates in the

OTQ057007

down. When the vehicle stops, 1st gear

instrument panel when the O/D mode is

E060102BTQ

is automatically selected.

cancelled.

Sports mode (if equipped)

•

In sports mode, when the engine rpm

approaches the red zone shift points

Whether the vehicle is stationary or in

are varied to upshift automatically.

motion, sports mode is selected by push-

•

To maintain the required levels of

ing the shift lever from the D (Drive) posi-

vehicle performance and safety, the

tion into the manual gate. To return to D

system may not execute certain

(Drive) range operation, push the shift

gearshifts when the shift lever is oper-

lever back into the main gate.

ated.

•

When driving on a slippery road,

In sports mode, moving the shift lever

push the shift lever forward into the

backwards and forwards will allow you to

+(up) position. This causes the trans-

make gearshifts rapidly. In contrast to a

mission to shift into the

2nd gear

manual transmission, the sports mode

which is better for smooth driving on

allows gearshifts with the accelerator

a slippery road. Push the shift lever to

pedal depressed.

the -(down) side to shift back to the 1st

Up (+)

: Push the lever forward once to

gear.

shift up one gear.

Down (-) : Pull the lever backwards once

to shift down one gear.

5

16

Driving your vehicle

E060200AEN

•

Exercise extreme caution when driving

(Continued)

Good driving practices

on a slippery surface. Be especially

• Loss of control often occurs if

careful when braking, accelerating or

•

Never move the gear shift lever from P

two or more wheels drop off the

shifting gears. On a slippery surface,

(Park) or N (Neutral) to any other posi-

roadway and the driver over-

an abrupt change in vehicle speed can

tion with the accelerator pedal

steers to reenter the roadway.

cause the drive wheels to lose traction

depressed.

and the vehicle to go out of control.

• In the event your vehicle leaves

•

Never move the gear shift lever into P

the roadway, do not steer sharply.

•

Optimum vehicle performance and

(Park) when the vehicle is in motion.

Instead, slow down before pulling

economy is obtained by smoothly

•

Be sure the car is completely stopped

back into the travel lanes.

depressing and releasing the accelera-

before you attempt to shift into R

tor pedal.

• Never exceed posted speed lim-

(Reverse).

its.

•

Never take the car out of gear and

coast down a hill. This may be

WARNING

extremely hazardous. Always leave the

•

Always buckle-up! In a collision,

car in gear when moving.

an unbelted occupant is signifi-

WARNING

•

Do not "ride" the brakes. This can

cantly more likely to be seriously

If your vehicle becomes stuck in

cause them to overheat and malfunc-

injured or killed than a properly

snow, mud, sand, etc., then you

tion. Instead, when you are driving

belted occupant.

may attempt to rock the vehicle free

down a long hill, shift to a lower gear.

•

Avoid high speeds when corner-

by moving it forward and backward.

When you do this, engine braking will

ing or turning.

Do not attempt this procedure if

help slow the car.

•

Do not make quick steering

people or objects are anywhere

•

Slow down before shifting to a lower

wheel movements, such as sharp

near the vehicle. During the rocking

gear. Otherwise, the lower gear may

lane changes or fast, sharp turns.

operation the vehicle may suddenly

not be engaged.

•

The risk of rollover is greatly

move forward of backward as it

•

Always use the parking brake. Do not

increased if you lose control of

becomes unstuck, causing injury

depend on placing the transmission in

your vehicle at highway speeds.

or damage to nearby people or

P (Park) to keep the car from moving.

objects.

(Continued)

5 17

Driving your vehicle

BRAKE SYSTEM

E070100BUN

(Continued)

Power brakes

WARNING - Brakes

• Always, confirm the position of

Your vehicle has power-assisted brakes

•

Do not drive with your foot rest-

the brake and accelerator pedal

that adjust automatically through normal

ing on the brake pedal. This will

before driving. If you do not

usage.

create abnormal high brake tem-

check the position of the acceler-

In the event that the power-assisted

peratures, excessive brake lining

ator and brake pedal before driv-

brakes lose power because of a stalled

and pad wear, and increased

ing, you may depress the acceler-

engine or some other reason, you can

stopping distances.

ator instead of the brake pedal. It

still stop your vehicle by applying greater

•

When descending a long or steep

may cause a serious accident.

force to the brake pedal than you normal-

hill, shift to a lower gear and

ly would. The stopping distance, howev-

avoid continuous application of

er, will be longer.

the brakes. Continuous brake

E070101AUN

When the engine is not running, the

application will cause the brakes

In the event of brake failure

reserve brake power is partially depleted

to overheat and could result in a

If service brakes fail to operate while the

each time the brake pedal is applied. Do

temporary loss of braking per-

vehicle is in motion, you can make an

not pump the brake pedal when the

formance.

emergency stop with the parking brake.

power assist has been interrupted.

•

Wet brakes may impair the vehi-

The stopping distance, however, will be

Pump the brake pedal only when neces-

cle’s ability to safely slow down;

much greater than normal.

sary to maintain steering control on slip-

the vehicle may also pull to one

pery surfaces.

side when the brakes are applied.

Applying the brakes lightly will

WARNING - Parking brake

indicate whether they have been

Applying the parking brake while

affected in this way. Always test

the vehicle is moving at normal

your brakes in this fashion after

speeds can cause a sudden loss of

driving through deep water. To

control of the vehicle. If you must

dry the brakes, apply them lightly

use the parking brake to stop the

while maintaining a safe forward

vehicle, use great caution in apply-

speed until brake performance

ing the brake.

returns to normal.

(Continued)

5 19

Driving your vehicle

E070102AUN

Disc brakes wear indicator

CAUTION

Your vehicle has disc brakes.

•

Driving with the parking brake

When your brake pads are worn and new

applied will cause excessive

pads are required, you will hear a high-

brake pad and brake rotor wear.

pitched warning sound from your front

•

Do not operate the parking brake

brakes or rear brakes (if equipped). You

while the vehicle is moving

may hear this sound come and go or it

except in an emergency situation.

may occur whenever you depress the

It could damage the vehicle sys-

brake pedal.

tem and make endanger driving

Please remember that some driving con-

safety.

ditions or climates may cause a brake

squeal when you first apply (or lightly

OTQ057008

apply) the brakes. This is normal and

Parking brake

does not indicate a problem with your

brakes.

E070201BFD

Applying the parking brake

CAUTION

To engage the parking brake, first apply

the foot brake and then without pressing

• To avoid costly brake repairs, do

the release button in, pull the parking

not continue to drive with worn

brake lever up as far as possible. In addi-

brake pads.

tion it is recommended that when parking

• Always replace brake pads as

the vehicle on a gradient, the shift lever

complete front or rear axle sets.

should be positioned in the appropriate

low gear on manual transmission vehi-

cles or in the P (Park) position on auto-

WARNING - Brake wear

matic transmission vehicles.

This brake wear warning sound

means your vehicle needs service.

If you ignore this audible warning,

you will eventually lose braking

performance, which could lead to a

serious accident.

5 20

Driving your vehicle

■ Type A

■ Type B

WARNING

•

To prevent unintentional move-

ment when stopped and leaving

the vehicle, do not use the

gearshift lever in place of the

parking brake. Set the parking

brake AND make sure the

gearshift lever is securely posi-

tioned in

1st

(First) gear or R

(Reverse) for manual transmis-

sion equipped vehicles and in P

OTQ057009

(Park) for automatic transmission

W-75/WK-23

E070202AFD

equipped vehicles.

Check the brake warning light by turning

Releasing the parking brake

•

Never allow anyone who is unfa-

the ignition switch ON (do not start the

To release the parking brake, first apply

miliar with the vehicle to touch

engine). This light will be illuminated when

the foot brake and pull up the parking

the parking brake. If the parking

the parking brake is applied with the igni-

brake is released unintentionally,

tion switch in the START or ON position.

brake lever slightly. Secondly depress the

serious injury may occur.

release button (1) and lower the parking

Before driving, be sure the parking brake

brake lever (2) while holding the button.

•

All vehicles should always have

is fully released and the brake warning

the parking brake fully engaged

light is off.

when parking to avoid inadver-

If the brake warning light remains on after

tent movement of the car which

the parking brake is released while engine

can injure occupants or pedestri-

is running, there may be a malfunction in

ans.

the brake system. Immediate attention is

necessary.

If at all possible, cease driving the vehi-

cle immediately. If that is not possible,

use extreme caution while operating the

vehicle and only continue to drive the

vehicle until you can reach a safe loca-

tion or repair shop.

5 21

Driving your vehicle

E070300AEN-EE

The ABS continuously senses the speed

(Continued)

Anti-lock brake system (ABS)

of the wheels. If the wheels are going to

• On roads where the road surface

(if equipped)

lock, the ABS system repeatedly modu-

is pitted or has different surface

lates the hydraulic brake pressure to the

height.

wheels.

WARNING

The safety features of an ABS (or

When you apply your brakes under con-

ABS (or ESP) will not prevent acci-

ESP) equipped vehicle should not

ditions which may lock the wheels, you

dents due to improper or danger-

be tested by high speed driving or

may hear a “tik-tik’’ sound from the

ous driving maneuvers. Even

cornering. This could endanger the

brakes, or feel a corresponding sensation

though vehicle control is improved

safety of yourself or others.

in the brake pedal. This is normal and it

during emergency braking, always

means your ABS is active.

maintain a safe distance between

In order to obtain the maximum benefit

you and objects ahead. Vehicle

from your ABS in an emergency situa-

speeds should always be reduced

tion, do not attempt to modulate your

during extreme road conditions.

brake pressure and do not try to pump

The braking distance for cars

your brakes. Press your brake pedal as

equipped with an anti-lock braking

hard as possible or as hard as the situa-

system

(or Electronic Stability

tion warrants and allow the ABS to con-

Program System) may be longer

trol the force being delivered to the

than for those without it in the fol-

brakes.

lowing road conditions.

During these conditions the vehicle

should be driven at reduced

speeds:

• Rough, gravel or snow-covered

roads.

• With tire chains installed.

(Continued)

5 22

Driving your vehicle

✽ NOTICE

CAUTION

A click sound may be heard in the

engine compartment when the vehicle

•

When you drive on a road having

begins to move after the engine is start-

poor traction, such as an icy road,

ed. These conditions are normal and

and operate your brakes continu-

indicate that the anti-lock brake system

ously, the ABS will be active con-

is functioning properly.

tinuously and the ABS warning

light may illuminate. Pull your car

•

Even with the anti-lock brake system,

over to a safe place and stop the

your vehicle still requires sufficient

engine.

stopping distance. Always maintain a

•

Restart the engine. If the ABS

safe distance from the vehicle in front

warning light is off, then your

of you.

W-78

ABS system is normal.

•

Always slow down when cornering.

Otherwise, you may have a prob-

The anti-lock brake system cannot pre-

lem with the ABS. We recommend

CAUTION

vent accidents resulting from exces-

that you contact an authorized

•

If the ABS warning light is on and

sive speeds.

HYUNDAI dealer.

stays on, you may have a problem

•

On loose or uneven road surfaces,

with the ABS. In this case, howev-

operation of the anti-lock brake system

er, your regular brakes will work

may result in a longer stopping dis-

✽ NOTICE

normally.

tance than for vehicles equipped with a

When you jump start your vehicle

•

The ABS warning light will stay on

conventional brake system.

because of a drained battery, the engine

for approximately 3 seconds after

may not run as smoothly and the ABS

the ignition switch is ON. During

warning light may turn on at the same

that time, the ABS will go through

time. This happens because of the low

self-diagnosis and the light will go

battery voltage. It does not mean your

off if everything is normal. If the

ABS is malfunctioning.

light stays on, you may have a

• Do not pump your brakes!

problem with your ABS. We recom-

• Have the battery recharged before

mend that you contact an author-

driving the vehicle.

ized HYUNDAI dealer.

5 23

Content   ..  13  14  15  16   ..
