Convenient features of your vehicle
Battery replacement
If you suspect your smart key might
i
Information
have sustained some damage, or
Changes or modifications not express-
you feel your smart key is not work-
ly approved by the party responsible
ing correctly, it is recommended that
for compliance could void the user’s
you contact an authorized HYUNDAI
authority to operate the equipment. If
dealer.
the keyless entry system is inoperative
due to changes or modifications not
i
Information
expressly approved by the party
responsible for compliance, it will not
An inappropriately disposed
be covered by your manufacturer’s
battery can be harmful to the
vehicle warranty.
environment and human
health. Dispose the battery
NOTICE
OLF044008
according to your local law(s)
and regulation.
If the Smart Key is not working prop-
Keep the smart key away from
erly, try replacing the battery with a
electromagnetic materials that
new one.
blocks electromagnetic waves to
the key surface.
Battery Type: CR2032
To replace the battery:
1. Pry open the rear cover of the
smart key.
2. Remove the old battery and insert
the new battery. Make sure the
battery position is correct.
3. Reinstall the rear cover of the
smart key.
3-12
Immobilizer system
If the system repeatedly does not
NOTICE
(if equipped)
recognize the coding of the key, it is
recommended that you contact your
The transponder in your key is an
The immobilizer system protects your
HYUNDAI dealer.
important part of the immobilizer
vehicle from theft. If an improperly
system. It is designed to give
Do not attempt to alter this system or
coded key (or other device) is used,
years of trouble-free service, how-
the engine’s fuel system is disabled.
add other devices to it. Electrical
ever you should avoid exposure to
problems could result that may make
When the ignition switch is placed in
moisture, static electricity and
your vehicle inoperable.
3
the ON position, the immobilizer sys-
rough handling. Immobilizer sys-
tem indicator should come on briefly,
tem malfunction could occur.
then go off. If the indicator starts to
WARNING
blink, the system does not recognize
the coding of the key.
In order to prevent theft of your
vehicle, do not leave spare keys
Place the ignition switch to the
anywhere in your vehicle. Your
LOCK/OFF position, then place the
immobilizer password is a cus-
ignition switch to the ON position
tomer unique password and
again.
should be kept confidential.
The system may not recognize your
key’s coding if another immobilizer
key or other metal object (i.e., key
chain) is near the key. The engine
may not start because the metal may
interrupt the transponder signal from
transmitting normally.
3-13
Convenient features of your vehicle
DOOR LOCKS
Operating door locks from
If you lock/unlock the driver's door
Remote key
outside the vehicle
with a key, all vehicle doors will
lock/unlock automatically. (if equipped
Mechanical key
with the central door lock system)
■ Left-hand drive
Once the doors are unlocked, they
• Type A
• Type B
may be opened by pulling the door
handle.
When closing the door, push the
door by hand. Make sure that doors
are closed securely.
OHG040006L
OAD045002
To lock the doors, press the Door
■ Right-hand drive
Lock button (1) on the remote key.
• Type A
• Type B
To unlock the doors, press the Door
Unlock button (2) on the remote key.
Once the doors are unlocked, they
may be opened by pulling the door
handle.
When closing the door, push the
door by hand. Make sure that doors
are closed securely.
OAD045002R
Turn the key toward the rear of the
vehicle to unlock and toward the front
of the vehicle to lock.
3-14
Smart key
To lock the doors, press the button on
i
Information
the outside door handle while carry-
■ Left-hand drive
•
In cold and wet climates, door lock
ing the smart key with you or press
and door mechanisms may not work
the door lock button on the smart key.
properly due to freezing conditions.
To unlock the doors, press the button
•
If the door is locked/unlocked multi-
on the outside door handle while car-
ple times in rapid succession with
rying the smart key with you or press
either the vehicle key or door lock
Lock / Unlock
the door unlock button on the smart
3
switch, the system may stop operat-
key.
ing temporarily in order to protect
Once the doors are unlocked, they
the circuit and prevent damage to
OAD045001
may be opened by pulling the door
system components.
■ Right-hand drive
handle.
When closing the door, push the
door by hand. Make sure that doors
are closed securely.
Lock / Unlock
i
Information
• In cold and wet climates, door lock
OAD045001R
and door mechanisms may not work
properly due to freezing conditions.
• If the door is locked/unlocked multi-
ple times in rapid succession with
either the vehicle key or door lock
switch, the system may stop operat-
ing temporarily in order to protect
the circuit and prevent damage to
system components.
OBA043224IN
3-15
Convenient features of your vehicle
Operating door locks from
•
To unlock a door, pull the door lock
i
Information
inside the vehicle
button (1) to the “Unlock” position.
The red mark (2) on the door lock
If a power door lock ever fails to func-
With the door lock button
button will be visible.
tion while you are in the vehicle try
■ Left-hand drive
one or more of the following tech-
•
To lock a door, push the door lock
niques to exit:
button (1) to the “Lock” position. If
the door is locked properly, the red
Operate the door unlock feature
Unlock / Lock
mark (2) on the door lock button
repeatedly (both electronic and manu-
will not be visible.
al) while simultaneously pulling on the
door handle.
•
To open a door, pull the door han-
dle (3) outward.
Operate the other door locks and han-
dles, front and rear.
•
If the inner door handle of the dri-
ver’s (or front passenger’s) door is
Lower a front window and use the
pulled when the door lock button is
mechanical key to unlock the door
OAD045003
■ Right-hand drive
in the lock position, the button is
from outside.
unlocked and door opens.
•
Front doors cannot be locked if the
key is in the ignition switch and any
front door is open.
•
Doors cannot be locked if the
smart key is in the vehicle and any
Lock / Unlock
door is open.
OAD045003R
3-16
With the central door lock
• If the key is in the ignition switch
WARNING
switch
and any door is opened, the doors
will not lock even though the lock
■ Left-hand drive
The doors should always be
button (1) of the central door lock
fully closed and locked while
switch is pressed.
the vehicle is in motion. If the
• If the smart key is in the vehicle
doors are unlocked, the risk of
and any door is opened, the doors
being thrown from the vehicle in
will not lock even though the lock
3
a crash is increased.
button (1) of the central door lock
Unlock / Lock
switch is pressed.
When pressing the (
) portion (2) of
WARNING
the switch, all vehicle doors will
OAD045004
unlock.
Do not leave children or animals
■ Right-hand drive
unattended in your vehicle. An
enclosed vehicle can become
extremely hot, causing death or
serious injury to unattended
children or animals who cannot
escape the vehicle. Children
Lock / Unlock
might operate features of the
vehicle that could injure them,
or they could encounter other
harm, possibly from someone
OAD045004R
gaining entry to the vehicle.
When pressing the (
) portion (1) of
the switch, all vehicle doors will lock.
3-17
Convenient features of your vehicle
Auto door lock/unlock features
WARNING
WARNING
Impact sensing door unlock
Always secure your vehicle
Opening a door when something
system (if equipped)
is approaching may cause dam-
All doors will be automatically
Leaving your vehicle unlocked
age or injury. Be careful when
unlocked when an impact causes the
increases the potential risk to
opening doors and watch for
air bags to deploy.
you or others from someone
vehicles, motorcycles, bicycles
hiding in your vehicle.
or pedestrians approaching the
To secure your vehicle, while
Speed sensing door lock system
vehicle in the path of the door.
depressing the brake, move the
(if equipped)
shift lever to the P (Park) posi-
All doors will be automatically locked
tion
(for automatic transmis-
when vehicle speed exceeds
15
sion/dual clutch transmission)
km/h (9 mph).
or first gear or R (Reverse, for
manual transmission), engage
the parking brake, and place the
You can activate or deactivate the
Auto Door Lock/Unlock features from
ignition switch in the LOCK/OFF
position, close all windows,
the User Settings Mode on the LCD
display. For more details, refer to
lock all doors, and always take
the key with you.
"LCD Display" in this chapter.
3-18
Child-protector rear door locks
To lock the child safety lock, insert a
key (or screwdriver) (1) into the hole
and turn it to the lock position.
To allow a rear door to be opened
from inside the vehicle, unlock the
child safety lock.
3
WARNING
If children accidently open the
rear doors while the vehicle is
in motion, they could fall out of
the vehicle. The rear door safety
OAD045005N
locks should always be used
The child safety lock is provided to
whenever children are in the
help prevent children seated in the
vehicle.
rear from accidentally opening the
rear doors. The rear door safety locks
should be used whenever children
are in the vehicle.
The child safety lock is located on
the edge of each rear door. When the
child safety lock is in the lock posi-
tion, the rear door will not open if the
inner door handle is pulled.
3-19
Convenient features of your vehicle
THEFT-ALARM SYSTEM
This system helps to protect your
Once the security system is set, open-
vehicle and valuables. The horn will
ing any door, the trunk, or the hood
sound and the hazard warning lights
without using the remote key or smart
will blink continuously if any of the
key will cause the alarm to activate.
following occurs:
The Theft Alarm System will not set if
- A door is opened without using the
the hood, the trunk, or any door is
remote key or smart key.
not fully closed. If the system will not
set, check the hood, the trunk, or the
- The trunk is opened without using
doors are fully closed.
the remote key or smart key.
- The engine hood is opened.
Do not attempt to alter this system or
add other devices to it.
The alarm continues for 30 seconds,
OJC040170
then the system resets. To turn off
the alarm, unlock the doors with the
i
Information
i
Information
remote key or smart key.
•
Do not lock the doors until all pas-
Vehicles equipped with a theft alarm
The Theft Alarm System automati-
sengers have left the vehicle. If the
system will have a label attached to
cally sets 30 seconds after you lock
remaining passenger leaves the
the vehicle with the following words:
the doors and the trunk. For the sys-
vehicle when the system is armed,
1. WARNING
tem to activate, you must lock the
the alarm will be activated.
2. SECURITY SYSTEM
doors and the trunk from outside the
•
If the vehicle is not disarmed with
vehicle with the remote key or smart
the remote key or smart key, open
key or by pressing the button on the
the doors by using the mechanical
outside of the door handles with the
key and place the ignition switch in
smart key in your possession.
the ON position (for remote key) or
The hazard warning lights will blink
start the engine (for smart key) and
and the chime will sound once to
wait for 30 seconds.
indicate the system is armed.
•
When the system is disarmed but a
door or trunk is not opened within 30
seconds, the system will be rearmed.
3-20
DRIVER POSITION MEMORY SYSTEM (IF EQUIPPED)
Storing memory positions
WARNING
1. Move the shift lever into P
(for
automatic transmission/dual clutch
Never attempt to operate the driv-
er position memory system while
transmission) or Neutral (for manu-
al transmission) while the ignition
the vehicle is moving.
switch or the Engine Start/Stop
This could result in loss of con-
button is in the ON position.
trol, and an accident causing
3
death, serious injury, or property
2. Adjust the driver's seat position,
outside rearview mirror position
damage.
and instrument panel illumination
intensity to the desired position.
OAD045043L
i
Information
3. Press the SET button. The system
The Driver Position Memory System
• If the battery is disconnected, the
will beep once and notify you
is provided to store and recall the fol-
memory settings will be erased.
"Press button to save settings"on
lowing memory settings with a sim-
the LCD display.
• If the Driver Position Memory
ple button operation.
System does not operate normally,
4. Press one of the memory buttons
- Driver's seat position
we recommend that you have the
(1 or 2) within 5 seconds. The sys-
- Outside rearview mirror position
system checked by an authorized
tem will beep twice when the mem-
- Instrument panel illumination intensity
HYUNDAI dealer.
ory has been successfully stored.
5.
OLF044403L/OLF044404L
"Driver 1 (or 2) settings saved" will
appear on the LCD display.
3-21
Convenient features of your vehicle
Recalling memory position
Easy access function
i
Information
1. Move the shift lever into P (for auto-
(if equipped)
•
While recalling the "1" memory
matic transmission/dual clutch
The system will move the driver's
position, pressing the SET or 1 but-
transmission) or Neutral (for manu-
seat automatically as follows:
ton temporarily stops the adjust-
al transmission) while the ignition
ment of the recalled memory posi-
The shift lever is in P or N (for auto-
switch or the Engine Start/Stop but-
tion. Pressing the 2 button recalls
matic transmission/dual clutch trans-
ton is in the ON position.
the "2" memory position.
mission) or Neutral (for manual trans-
2. Press the desired memory button
mission).
•
While recalling the "2" memory
(1 or
2). The system will beep
position, pressing the SET or 2 but-
•
Without smart key system
once, then the driver’s seat posi-
ton temporarily stops the adjust-
tion, outside rearview mirror and
- It will move the driver’s seat rear-
ment of the recalled memory posi-
ward when the ignition key is
instrument panel illumination will
tion. Pressing the 1 button recalls
automatically adjust to the stored
removed.
the "1" memory position.
position (if equipped).
- It will move the driver’s seat forward
•
While recalling the stored positions,
3.
when the ignition key is inserted.
pressing one of the control buttons
•
With smart key system
for the driver's seat, outside
- It will move the driver’s seat rear-
rearview mirror, or instrument
panel illumination will cause the
ward when the Engine Start/Stop
button is changed to the OFF
movement of that component to stop
and move in the direction that the
position.
control button is pressed.
- It will move the driver’s seat for-
OLF044401L/OLF044402L
ward when the Engine Start/Stop
"Driver 1(or 2) settings is applied"
button is changed to the ACC or
will appear on the LCD display.
START position.
You can activate or deactivate the
Easy Access Function from the User
Settings Mode on the LCD display.
For more details, refer to "LCD
Display" in this chapter.
3-22
STEERING WHEEL
Electric power steering (EPS)
NOTICE
(Continued)
The system assists you with steering
•
A click noise may be heard from the
If the Electric Power Steering
the vehicle. If the engine is off or if
EPS relay after the ignition switch is
System does not operate normal-
the power steering system becomes
placed to the ON or LOCK/OFF
ly, the warning light (
) will illu-
inoperative, the vehicle may still be
position (Without Smart key system).
minate on the instrument cluster.
steered, but it will require increased
A click noise may be heard from the
The steering wheel may become
steering effort.
EPS relay after the Engine Start/Stop
difficult to control or operate. Take
button is in the ON or OFF position.
3
Also, the steering effort becomes
your vehicle to an authorized
heavier as the vehicle’s speed
HYUNDAI dealer and have the sys-
(With Smart key system)
increases and becomes lighter as
tem checked as soon as possible.
•
Motor noise may be heard when the
the vehicle’s speed decreases for
vehicle is at a stop or at a low driv-
better control of the steering wheel.
ing speed.
i
Information
Should you notice any change in the
•
When you operate the steering
The following symptoms may occur
effort required to steer during normal
wheel in low temperature, abnormal
during normal vehicle operation:
vehicle operation, we recommend
noise may occur. If temperature
that the system be checked by an
• The steering effort may be high
rises, the noise will disappear. This
authorized HYUNDAI dealer.
immediately after placing the igni-
is a normal condition.
tion switch or the Engine Start/Stop
•
When the vehicle is stationary, if
button in the ON position.
you turn the steering wheel all the
This happens as the system per-
way to the left or right continuously,
forms the EPS system diagnostics.
the steering wheel effort increases.
When the diagnostics is completed,
This is not a system malfunction. As
the steering wheel will return to its
time passes, the steering wheel
normal condition.
effort will return to its normal con-
(Continued)
dition.
3-23
Convenient features of your vehicle
Tilt steering / Telescope steering
■ Left-hand drive
Make sure you can see the instrument
panel warning lights and gauges.
WARNING
After adjusting, pull up the lock-
release lever (1) to lock the steering
Never adjust the steering wheel
wheel in place. Push the steering
while driving. You may lose
wheel both up and down to be cer-
steering control and cause
tain it is locked in position. Always
severe personal injury, death or
adjust the position of the steering
accidents.
wheel before driving.
i
Information
OAD045006
■ Right-hand drive
After adjustment, sometimes the lock-
release lever may not lock the steering
wheel.
It is not a malfunction. This occurs
when two gears are not engaged cor-
rectly. In this case, adjust the steering
wheel again and then lock the steering
wheel.
OAD045006R
Pull down the lock-release lever (1) on
the steering wheel column and adjust
the steering wheel angle (2) and posi-
tion (3, if equipped). Move the steer-
ing wheel, so it points toward your
chest, not toward your face.
3-24
Heated steering wheel
Horn
i
Information
(if equipped)
The heated steering wheel will turn off
automatically approximately 30 min-
utes after the heated steering wheel is
turned on.
When the engine is turned off during
the engine and the heated steering
3
wheel is on, the timer function of heat-
ed steering wheel will be reset.
To reuse heated steering wheel, press
button again.
OAD045008
NOTICE
OAD045007
To sound the horn, press the area
Do not install any cover or acces-
When the ignition switch is in the ON
indicated by the horn symbol on your
sory on the steering wheel. This
position or when the engine is running,
steering wheel (see illustration). The
cover or accessory could cause
press the heated steering wheel but-
horn will operate only when this area
damage to the heated steering
ton to warm the steering wheel. The
is pressed.
wheel system.
indicator on the button will illuminate.
To turn the heated steering wheel off,
NOTICE
press the button again. The indicator
Do not strike the horn severely to
on the button will turn off.
operate it, or hit it with your fist.
Do not press on the horn with a
sharp-pointed object.
3-25
Convenient features of your vehicle
MIRRORS
Inside rearview mirror
Day/night rearview mirror
WARNING
(if equipped)
Before you start driving, adjust the
rearview mirror to the center on the
NEVER adjust the mirror while
view through the rear window.
driving. This may cause loss of
vehicle control resulting in an
WARNING
accident.
Night
Make sure your line of sight is
NOTICE
not obstructed. Do not place
objects in the rear seat, cargo
When cleaning the mirror, use a
area, or behind the rear head-
paper towel or similar material
rests which could interfere with
dampened with glass cleaner. Do
your vision through the rear
not spray glass cleaner directly on
Day
window.
the mirror as that may cause the
OAD045009
liquid cleaner to enter the mirror
Make this adjustment before you
housing.
start driving and while the day/night
WARNING
lever is in the day position.
Pull the day/night lever toward you to
To prevent serious injury during
reduce glare from the headlights of
an accident or deployment of
the vehicles behind you during night
the air bag, do not modify the
driving.
rearview mirror and do not
install a wide mirror.
Remember that you lose some
rearview clarity in the night position.
3-26
Electric Chromic Mirror (ECM)
Outside rearview mirror
(if equipped)
The electric rearview mirror automati-
cally controls the glare from the head-
lamp of the car behind you in night-
time or low light driving conditions.
When the engine is running, the
Indicator
glare is automatically controlled by
3
the sensor mounted in the rearview
mirror. The sensor detects the light
level around the vehicle, and auto-
OAD045010
matically adjusts to control the head-
lamp glare from vehicles behind you.
To operate the electric rearview
OAD045014
Whenever the shift lever is placed in
mirror:
Be sure to adjust mirror angles
R (Reverse), the mirror will automat-
• Press the ON/OFF button (1) to
before driving.
ically go to the brightest setting in
turn the automatic dimming func-
order to improve the drivers view
tion off. The mirror indicator light
Your vehicle is equipped with both
behind the vehicle.
will turn off.
left-hand and right-hand outside
rearview mirrors.
Press the ON/OFF button (1) to
turn the automatic dimming func-
The mirror can be adjusted remotely
tion on. The mirror indicator light
with the remote switch.
will illuminate.
The mirror heads can be folded to
• The mirror defaults to the ON posi-
prevent damage during an automatic
tion whenever the ignition switch or
car wash or when passing through a
the Engine Start/Stop button is in
narrow street.
the ON position.
3-27
Convenient features of your vehicle
■ Left-hand drive
WARNING
CAUTION
• The right outside rearview mir-
•
Do not scrape ice off the mir-
ror is convex. In some coun-
ror face; this may damage the
tries, the left outside rearview
surface of the glass.
mirror is also convex. Objects
•
If the mirror is jammed with
seen in the mirror are closer
ice, do not adjust the mirror
than they appear.
by force. Use an approved
• Use your interior rearview
spray de-icer
(not radiator
mirror or turn your head and
antifreeze) spray, or a sponge
OAD045015
■ Right-hand drive
look to determine the actual
or soft cloth with very warm
distance of following vehicles
water, or move the vehicle to a
when changing lanes.
warm place and allow the ice
to melt.
WARNING
Do not adjust or fold the outside
rearview mirrors while driving.
This may cause loss of vehicle
OAD045015R
control resulting in an accident.
Adjusting the rearview mirrors:
Move the lever (1) to the L (Left) or R
(Right) to select the rearview mirror
you would like to adjust.
Use the mirror adjustment control to
position the selected mirror up,
down, left or right.
3-28
