Hyundai Equus (2016 year). Instruction - part 12
Convenient features of your vehicle
Indicator Lights
Immobilizer Indicator
Light
Electronic Stability
Control (ESC) Indicator
This indicator illuminates up to 30
Light
seconds:
This indicator light illuminates:
• When the vehicle detects the
• Once you turn ON the ignition
Smart Key in the vehicle while the
switch or the Engine Start/Stop
Engine Start/Stop button is the
button.
ACC or ON position.
- It illuminates for approximately 3
- At this time, you can start the
seconds and then goes OFF.
engine.
• When there is a malfunction with
- The indicator light goes off after
the ESC system.
starting the engine.
In this case, have your vehicle
inspected by an authorized
EQUUS dealer.
This indicator flashes for a few sec-
onds:
• When the smart key is out of the
This indicator flashes:
vehicle.
While the ESC is operating.
- At this time, you cannot start the
engine.
❈ For further information, refer to
"Electronic Stability Control (ESC)"
This indicator illuminates for 2 sec-
in the chapter 5.
onds and goes OFF:
• When the Smart Key is not detect-
Electronic Stability
ed inside the vehicle while the
Control (ESC) OFF
Engine Start/Stop button is ON.
Indicator Light
In this case, have your vehicle
This indicator light illuminates:
inspected by an authorized
• Once you turn ON the ignition
EQUUS dealer.
switch or the Engine Start/Stop
button.
This indicator flashes:
- It illuminates for approximately 3
• When the Smart Key battery is
seconds and then goes OFF.
weak.
• When you deactivate the ESC
- In this case, you cannot start the
system by pressing the ESC OFF
engine. However, by pressing the
button.
Engine Start/Stop button with the
smart key, you may start the
❈ For further information, refer to
engine. (For further information,
"Electronic
Stability
Control
refer to “Starting the Engine” in
(ESC)" in the chapter 5.
the chapter 5).
3-96
Convenient features of your vehicle
03
• When there is a malfunction with
Light ON Indicator
the immobilizer system.
Light
In this case, have your vehicle
inspected by an authorized
This indicator light illuminates:
EQUUS dealer.
• When the headlamps or tail lights
are ON.
Turn Signal Indicator
Light
Front Fog Indicator
Light
This indicator flashes:
• When you turn the turn signal light
This indicator light illuminates:
ON.
• When the front fog lights are ON.
When any of the followings occurs,
Cruise Indicator Light
there may a malfunction with the turn
signal system. In this case, have your
vehicle inspected by an authorized
EQUUS dealer.
This indicator light illuminates:
- The indicator light does not blink
• When the cruise control system is
but illuminates.
enabled.
- The indicator light blinks more
rapidly.
❈ For further information, refer to
- The indicator light does not illu-
“Cruise Control System” in the
minate at all.
chapter 5.
Low Beam Indicator
Cruise SET Indicator
Light (if equipped)
Light
This indicator light illuminates:
This indicator light illuminates:
• When the headlamps are ON.
• When the cruise control speed is
set.
High Beam Indicator
Light
❈ For further information, refer to
“Cruise Control System” in the
This indicator light illuminates:
chapter 5.
• When the headlamps are ON, or
in the high beam position.
• When the turn signal lever is in the
Flash-to-Pass position.
3-97
Convenient features of your vehicle
AUTO HOLD Indicator Light
Lane Departure Warning System
(if equipped)
(LDWS) Indicator Light
(if equipped)
This indicator light illuminates:
This indicator light illuminates:
•
[White] When you activate the
auto hold system by pressing the
•
[Green] When you activate the
AUTO HOLD button.
Lane Departure Warning System
•
[Green] When you completely stop
by pressing the LDWS button.
the vehicle by depressing the
•
[White] When system operating
brake pedal with the auto hold
conditions are not satisfied, or
system ON.
when the sensor does not detect
the lane line.
•
[Yellow] When there is a malfunc-
tion with the auto hold system.
•
[Yellow] When there is a malfunc-
tion with the Lane Departure
In this case, have your vehicle
inspected by an authorized
Warning System.
EQUUS dealer.
In this case, have your vehicle
inspected by an authorized
EQUUS dealer.
❈ For further information, refer to
“Auto Hold” in the chapter 5.
❈ For further information, refer to
“Lane Departure Warning System
(LDWS)” in the chapter 5.
3-98
Convenient features of your vehicle
03
Advanced Vehicle
i
Information
Safety Management
If you activate the Driving Mode
(AVSM) OFF Indicator
Theme on the User Settings Mode of
Light (if equipped)
the LCD display (if equipped), the
This indicator light illuminates:
SPORT and SNOW indicators will not
• Once you turn ON the Engine
turn on the instrument cluster.
Start/Stop button
- It illuminates for approximately 3
ECO Indicator Light
seconds and then goes OFF.
(if equipped)
• When you deactivate the AVSM
system on the LCD display.
The ECO indicator light informs you
to drive economically, and turns on
❈ For further information, refer to
green in accordance with the driving
“LCD Display” in this chapter.
condition.
When this indicator illuminates with-
This indicator light illuminates:
out selecting the AVSM OFF, there is
•
[Green] when you are driving eco-
a malfunction with the AVSM.
nomically.
In this case, have your vehicle
• The drive’s driving habit and road
inspected by an authorized EQUUS
condition can affect fuel efficiency.
dealer.
• The light will not display :
- If the condition does not meet
❈ For further information, refer to
economical driving such as P
“Advanced
Vehicle
Safety
(Park), N (Neutral), R (Reverse),
Management (AVSM) System” in
or sports mode.
the chapter 5.
- While the instant fuel Economy
of the trip computer is display on
SPORT/SNOW Mode
the LCD display.
Indicator Light
• In the "User Settings Mode" of the
LCD, you can activate or deacti-
vate the ECO driving mode.
❈ For further information, refer to
"LCD Display" in this chapter.
This indicator light illuminates:
• When you select "SPORT/SNOW"
WARNING
mode as the drive mode.
Do not monitor the ECO indica-
❈ For further information, refer to
tor while driving. This will dis-
"Drive mode integrated control
tract you and may cause an
system" in the chapter 5.
accident, resulting in severe
personal injury.
3-99
Convenient features of your vehicle
HEAD UP DISPLAY (HUD) (IF EQUIPPED)
Description
WARNING
- Head Up Display
• Do not tint the front windshield
glass or add other types of
metallic coating. Otherwise, the
head up display image may be
invisible.
• Do not place any accessories
on the crash pad or attach any
objects on the windshield
glass.
OVI0453412N
• Even though the Blind Spot
The head up display is a transparent
Detection (BSD) system is a
display which projects a shadow of
supplemental device for your
some instrument cluster information
safe driving, it may be danger-
and navigation on the windshield
ous to rely on only the BSD
glass.
information on the head up dis-
• The head up display image on the
play when changing the lane.
windshield glass may be invisible
Always pay attention to drive
when:
safely.
- Sitting posture is bad.
- Wearing polarized sunglasses.
NOTICE
- There is an object on the cover of
When replacing the front wind-
the head up display.
shield glass of the vehicles
- Driving on a wet road.
equipped with the head up dis-
- An inadequate lighting is turned
play, replace it with a windshield
ON inside the vehicle.
glass designed for the head up
display operation. Otherwise, a
- Any light comes from the outside.
single image may display in dupli-
- Wearing glasses.
cate on the windshield glass.
• If the head up display image is not
shown well, adjust the height or
illumination of the head up display
in the LCD display.
❈ For further information, refer to
"LCD Display" in this chapter.
• When the head up display needs
inspection or repair, have your
vehicle inspected by an author-
ized EQUUS dealer.
3-100
Convenient features of your vehicle
03
Head Up Display ON/OFF
In the "User settings Mode" of the
LCD display, you can activate or
deactive the Turn By Turn (TBT) nav-
igation, the Smart Cruise Control
(SCC), the Lane Departure Warning
System (LDWS), and the Blind Spot
Detection (BSD) system information.
i
Information
When you select the Turn By Turn
(TBT) navigation as the HUD content,
the Turn By Turn (TBT) navigation
will not be displayed on the LCD dis-
OVI045413N
play.
To activate the head up display,
press the HUD button.
Head Up Display Setting
If you press the HUD button again, the
head up display will be deactivated.
On the LCD display, you can change
the head up display settings as fol-
lows.
Head Up Display Information
1. Display height
2. Rotation
3. Font color
4. Font size
5. Illumination
6. Contents setting
❈ For further information, refer to
"LCD Display" in this chapter.
OVI045754N
1. Cruise Setting Speed
2. Lane Departure Warning System
(LDWS) Information (if equipped)
3. Advanced Smart Cruise Control
(ASCC) Information (if equipped)
4. Road Signs
5. Speedometer
6. Turn By Turn
(TBT) Navigation
Information (if equipped)
7. Blind Spot Detection
(BSD)
System Information (if equipped)
8. Warning Lights (Low fuel, BSD)
3-101
Convenient features of your vehicle
PARKING ASSIST SYSTEM
■ Front
WARNING
The parking assist system
should be considered only as a
supplementary function. The
driver must check the front and
rear views. The operational func-
tion of the parking assist system
can be affected by many factors
and surrounding conditions, so
Sensor
the responsibility should always
OVI045071N
be held by the driver.
■ Rear
Sensor
OVI045072N
The parking assist system helps the
driver in parking the vehicle by beep-
ing the buzzer, when any object is
sensed within 39 in (100 cm) from a
vehicle in front or 47 in (120 cm) from
a vehicle behind.
This system is a supplemental sys-
tem, which is not designed to be and
cannot be replaced with driver's
extreme care and attention.
The sensing range and detectable
objects by the sensor is limited.
Whenever parking the vehicle, pay
as much attention to what is in front
of and behind your vehicle, as you
would drive without a parking assist
system.
3-102
Convenient features of your vehicle
03
Operation of the Parking
• The system will automatically
Assist System
operate every time the driving
speed is below 6 mph (10 km/h)
Operating conditions
with the system switched ON.
■ Type A
• When you move the shift lever to
the R position with the system
switched OFF, the indicator will
turn ON and the system will oper-
ate automatically regardless of
button status. However, when the
vehicle speed exceeds
12 mph
(20 km/h) while driving forwards,
the indicator will turn OFF. The
system will not automatically oper-
ate again, even when the driving
OVI045073N
speed falls below
6 mph (10
km/h).
■ Type B
To turn ON the system, press the
parking assist system button.
• When more than two objects are
sensed at the same time, the clos-
est one will be recognized first.
OVI045074N
- When the Engine Start/Stop button
is ON
- When the shift lever is in the D or R
position
- When the vehicle speed is below 6
mph (10 km/h)
Press the parking assist system but-
ton to turn the parking assist system
ON. The indicator in the button illumi-
nates.
To turn OFF the system, press the
button again. Then, the indicator
goes OFF.
3-103
Convenient features of your vehicle
Types of warning sound and indicator
Warning indicator
Distance
Warning sound
from object
When driving
When driving
forward
rearward
39 in. ~ 24 in.
Buzzer beeps
Front
-
(100cm~60cm)
intermittently
47 in. ~ 24 in.
Buzzer beeps
Rear
-
(120cm~60cm)
intermittently
Buzzer beeps
Front
frequently
24 in. ~ 12 in.
(60cm~30cm)
Buzzer beeps
Rear
-
frequently
Buzzer sounds
Front
continuously
12 in.
(30cm)
Buzzer sounds
Rear
-
continuously
i
Information
The indicator may differ from the illustration according to an object or a sensor
status. When the indicator flashes, we recommend that the system be checked by
an authorized EQUUS dealer.
3-104
Convenient features of your vehicle
03
Inoperable conditions of the
Detecting range may decrease
Parking Assist System
when:
1. Outside air temperature is
The Parking Assist System may
extremely hot or cold.
not properly operate, when:
2. The sensor cannot detect an
1. Moisture is frozen over the sensor.
(It will operate normally again
object, as it is smaller than 39 in (1
m) or narrower than 5.5 in (14 cm)
when the frozen ice melts.)
in diameter.
2. The sensor is covered or blocked
with foreign substances, such as
snow or water. (It will normally
The following objects may not
operate again when the substance
be recognized by the sensor:
is removed, and the sensor is no
1. A sharp or slim object, such as
longer blocked.)
ropes, chains or small poles.
3. The sensor is stained with foreign
2. An object, such as clothes, spongy
substances such as snow or
material or snow, absorbs the sen-
water.
(The sensing range will
sor frequency.
return to normal when foreign sub-
stances are removed.)
i
Information
1. The warning may not sound
There is a possible malfunction
sequentially depending on the speed
with the Parking Assist System
and shapes of the objects detected.
when:
2. The Parking Assist System may
1. The vehicle drives on uneven road
malfunction if the vehicle bumper
surfaces such as unpaved roads,
height or sensor installation is mod-
gravels, bumps, or slopes.
ified. Any unauthorized installment
2. The sensor is interfered with
of equipment or accessories may
objects, which generate excessive
also limit the sensor performance.
noise, such as horns, motorcycle
3. Sensor may not recognize objects
engines, or truck air brakes.
within 12 in (30 cm), or it may mis-
3. Heavy rain or water is sprayed.
calculate the distance.
4. Wireless transmitters or mobile
4. When the sensor is frozen or stained
phones are near the sensor.
with snow or water, the sensor may
5. The sensor is covered with snow.
be inoperative until the stains are
removed using a soft cloth.
5. Do not push, scratch or strike the
sensor with any hard objects that
could damage the sensor surface.
This may damage the sensor.
3-105
Convenient features of your vehicle
Self-diagnosis
i
Information
If you do not hear an audible warning
This system can only sense objects
sound or if the buzzer sounds inter-
within the certain range and location.
mittently when shifting the gear to
it cannot detect objects in other areas
the R (Reverse) position, this may
where sensors are not installed. Also,
indicate a malfunction with the rear
the sensor may not detect small and
Parking Assist System. In this case,
slim objects, or objects located in
have your vehicle checked by an
blind spots between sensors.
authorized EQUUS dealer as soon
Always check the presence of any
as possible.
objects in front of or behind the vehi-
cle with your eyes when parking.
Make sure to inform these system
WARNING
capabilities and limitations to any
drivers of this vehicle who may be
Your new vehicle warranty does
unfamiliar with the system.
not cover any accidents or dam-
age to the vehicle or injuries to
its occupants related to the
WARNING
Parking Assist System. Always
drive safely and cautiously.
Pay close attention when the
vehicle is driven close to
objects on the road, particularly
pedestrians, and especially
children. Be aware that some
objects may not be detected by
the sensors, due to the object
distance, size or material, all of
which can limit the effective-
ness of the sensor. Always
make sure that the vehicle
stands clear of all objects with
your eyes before moving the
vehicle in any direction.
3-106
Convenient features of your vehicle
03
REARVIEW CAMERA (IF EQUIPPED)
i
Information
The rearview camera may not operate
normally, when you drive in the
extremely high or low temperature.
(Operating temperature: -4°F ~ 149°F
(-20°C ~ 65°C))
OVI045077N
The rearview camera activates when
the back-up light and the ignition
switch are ON and the shift lever in
the R position.
This system is mere a supplemental
system that shows the rearview
behind the vehicle on the navigation
display panel while backing up.
WARNING
• This system is for the supple-
mentary function only. It is the
driver's responsibility to
always check the inside/out-
side rearview mirrors and the
area behind the vehicle before
and while backing up.
• Always keep the camera lens
clean. If the lens is covered
with foreign substance, the
camera may not operate nor-
mally.
3-107
Convenient features of your vehicle
MULTI-VIEW CAMERA SYSTEM (IF EQUIPPED)
(Continued)
• Multi-view Camera System
only serves to assist the driv-
er in parking. ALWAYS look
around your vehicle to make
sure there are no objects or
obstacles before moving the
vehicle.
• Always keep the camera lens
clean. The camera may not
work normally if the lens is
OVI045400N
covered with foreign material.
The Multi-view Camera System can
assist in parking by allowing the driv-
er to see around the vehicle. Press
i
Information
the button to turn ON the system. To
• When vehicle speed is over 12.4 mph
turn OFF the system, press the but-
(20km/h), the multi-view camera
ton again.
system will turn off. The system will
not automatically turn on again,
Operating conditions
even though vehicle speed gets
- When the Engine Start/Stop but-
below 12.4 mph (20 km/h). Push the
ton is ON
button again, to turn on the system.
- When the shift lever is in the D, N
• When the vehicle is backing up, the
or R position
multi-view camera system will turn
ON regardless of vehicle speed or
- When the vehicle speed is below
button status. However, if vehicle
12.4 mph (20km/h)
speed is over 6.2 mph (10 km/h)
when driving forward, the system
CAUTION
will turn off.
• Awarning appears on the system in
one of the following situations:
- The trunk is opened
- The driver's door is opened
- The passenger's door is opened
- The outside rearview mirror is
folded
• When the multi-view camera system
does not normally operate, have the
OVI045761N
system checked by an authorized
1) Front camera
EQUUS dealer.
2) Left/Right camera
3) Rear camera
You may find further information in a
(Continued)
separate-volume supplement to this
Owner's Manual.
3-108
Convenient features of your vehicle
03
LIGHTING
Battery saver function
Headlamp escort function
•
The purpose of this function is to
When you press the Engine
prevent the battery from being dis-
Start/Stop button to the ACC or OFF
charged. The system automatical-
position with the headlamps ON, the
ly turns OFF the parking lights
headlamps (and/or tail lights) remain
when the driver turns OFF the
ON for approximately
5 minutes.
engine and opens the driver's
However, when the driver’s door is
door.
open and then closed, the head-
•
With this function, the parking
lamps are turned OFF after 15 sec-
onds.
lights are turned OFF automatical-
ly if the driver parks the vehicle on
The headlamps can be turned OFF
the side of the road at night.
by pressing the lock button on the
Smart Key twice or turning the light
If necessary, in order to keep the
switch to the OFF or Auto position.
lights ON when the engine is
turned OFF, perform the follow-
However, when you turn the light
ings:
switch to the Auto position, and when
it is dark outside, the headlamps will
1) Open the driver-side door.
not be turned OFF.
2) Turn the parking lights ON and
OFF again using the light
NOTICE
switch on the steering column.
If the driver exit the vehicle
through other doors (except dri-
ver’s door), the battery saver func-
tion does not operate and the
headlamp escort function does
not turn OFF automatically.
Therefore, it discharges the bat-
tery. In this case, make sure to
turn OFF the lamp before exiting
the vehicle.
3-109
Convenient features of your vehicle
Lighting control
Auto light/AFLS position
OVI045617N
OVI045092N
The light switch turns to be in the
When the light switch is in the AUTO
Headlamp or Parking light position.
light position while the engine is run-
ning, the taillights and headlamps
To operate the lights, turn the knob
will be turned ON or OFF automati-
on the control lever to one of the fol-
cally depending on an outside bright-
lowing positions:
ness level.
(1) OFF position
When your vehicle is equipped with
(2) Auto light / AFLS position
the Adaptive Front Lighting System
(3) Parking light position
(AFLS), and when the headlamp is
ON, it will also operate.
(4) Headlight position
NOTICE
• Never place anything over the
sensor (1) located on the instru-
ment panel. This will enhance
the auto-light system control.
• Do not clean the sensor using
window cleaner. The cleaner may
leave on the light film, which
may interfere with sensor opera-
tion.
• When your vehicle has window
tint or other types of metallic
coating on the front windshield,
the Auto light system may not
work properly.
3-110
Convenient features of your vehicle
03
High beam operation
Parking light position (
)
OVI045618N
OVI045426N
When the light switch is in the park-
To turn ON the high beam head-
ing light position, the tail, license and
lamps, push the lever away from you.
instrument panel lights are ON and
Pull it back for low beams. The high
the tail light indicator is ON.
beam indicator illuminates, when the
headlamp high beams are switched
ON.
Headlamp position (
)
To prevent the battery from being
discharged, do not leave the lights
ON for a prolonged period of time
while the engine is not running.
WARNING
Do not use high beam when
there are other vehicles. Using
high beam could obstruct the
other driver's vision.
OVI045619N
When the light switch is in the head-
lamp position, the head, tail, license
and instrument panel lights are ON.
i
Information
The Engine Start/Stop button must be
pressed ON to turn ON the head-
lamps.
3-111
Convenient features of your vehicle
Turn signals and lane change
signals
OVI045620N
To flash the headlamps, pull the lever
towards you. It will return to the
OVI045621N
default
(low beam) position when
The ignition switch must be ON to
released. The headlamp switch does
not need to be ON to flash the head-
turn ON the turn signals. To turn ON
the turn signals, move the lever up or
lamps.
down (A). Green arrow indicators on
the instrument panel indicate which
turn signal is operating. They will be
automatically OFF after a vehicle
completes a turn. If the indicator con-
tinues to flash after a turn, manually
return the lever to the OFF position.
To signal a lane change, move the
turn signal lever slightly and hold it in
position (B). The lever will return to
the OFF position when released.
If an indicator stays on and does not
flash or if it flashes abnormally, one
of the turn signal bulbs may be
burned out and require replacement.
One-touch triple turn signal
To activate a one-touch triple turn
signal, move the turn signal lever
slightly for less than 1.8 seconds and
then release it. The lane change sig-
nals will flash three times.
You can activate or deactivate this
function. Refer to the “User Settings”
in this chapter.
3-112
